GW Instek GDS-2000E Series User manual

Digital Storage Oscilloscope
GDS-2000E Series
USER MANUAL
ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will company.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve products and reserves the
rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan

TABLE OF CONTENTS
3
Table of Contents
SAFETY INSTRUCTIONS .................................................. 5
GETTING STARTED........................................................ 10
GDS-2000E Series Overview ................................ 11
Appearance ......................................................... 15
Set Up ................................................................. 27
Built-in Help ....................................................... 37
MEASUREMENT ............................................................ 38
Basic Measurement ............................................. 39
Automatic Measurement ..................................... 46
Cursor Measurement........................................... 60
Math Operation................................................... 68
CONFIGURATION.......................................................... 78
Acquisition .......................................................... 81
Segmented Memory Acquisition Overview .......... 86
Display ................................................................ 99
Horizontal View .................................................105
Vertical View (Channel) ......................................114
Bus Key Configuration ........................................122
Trigger................................................................145
Search ................................................................177
System Settings and Miscellaneous Settings ......186
APPS ............................................................................191
Applications .......................................................192
SAVE/RECALL ...............................................................214
File Format/Utility ..............................................215
Create/Edit Labels ..............................................220

GDS-2000E Series User Manual
4
Save .................................................................. 223
Recall ................................................................ 231
Reference Waveforms ........................................ 237
FILE UTILITIES .............................................................239
HARDCOPY KEY ...........................................................246
REMOTE CONTROL CONFIG ........................................250
Interface Configuration ..................................... 251
MAINTENANCE ............................................................262
FAQ..............................................................................268
APPENDIX ....................................................................271
Updating the Firmware ...................................... 272
GDS-2000E Specifications ................................. 274
Probe Specifications .......................................... 278
GDS-2000E Dimensions .................................... 280
INDEX ..........................................................................282

SAFETY INSTRUCTIONS
5
SAFETY INSTRUCTIONS
This chapter contains important safety
instructions that you must follow during
operation and storage. Read the following before
any operation to insure your safety and to keep
the instrument in the best possible condition.
Safety Symbols
These safety symbols may appear in this manual or on the GDS-
2000E.
WARNING
Warning: Identifies conditions or practices that
could result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that
could result in damage to the GDS-2000E or to
other properties.
DANGER High Voltage
Attention Refer to the Manual
Protective Conductor Terminal
Earth (ground) Terminal

GDS-2000E Series User Manual
6
Do not dispose electronic equipment as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased.
Safety Guidelines
General
Guideline
CAUTION
Make sure the BNC input voltage does not
exceed 300Vrms.
Never connect a hazardous live voltage to the
ground side of the BNC connectors. It might
lead to fire and electric shock.
Do not place any heavy object on the GDS-
2000E.
Avoid severe impact or rough handling that
leads to damaging the GDS-2000E.
Do not discharge static electricity to the GDS-
2000E.
Use only mating connectors, not bare wires, for
the terminals.
Do not block the cooling fan opening.
Do not perform measurement at a power source
or building installation site (Note below).
Do not disassemble the GDS-2000E unless you
are qualified.
(Measurement categories) EN 61010-1:2010 specifies the
measurement categories and their requirements as follows. The
GDS-2000E falls under category I.
Measurement category IV is for measurement performed at the
source of low-voltage installation.
Measurement category III is for measurement performed in the
building installation.
Measurement category II is for measurement performed on the
circuits directly connected to the low voltage installation.
Measurement category I is for measurements performed on
circuits not directly connected to Mains.

SAFETY INSTRUCTIONS
7
Power Supply
WARNING
AC Input voltage: 100 - 240V AC, 50 - 60Hz,
auto selection. Power consumption: 30 Watts.
Connect the protective grounding conductor of
the AC power cord to an earth ground, to avoid
electrical shock.
Cleaning the
GDS-2000E
Disconnect the power cord before cleaning.
Use a soft cloth dampened in a solution of mild
detergent and water. Do not spray any liquid.
Do not use chemicals containing harsh materials
such as benzene, toluene, xylene, and acetone.
Operation
Environment
Location: Indoor, no direct sunlight, dust free,
almost non-conductive pollution (Note below)
Relative Humidity: ≤80%, 40°C or below; ≤45%,
41°C ~ 50°C
Altitude: < 2000m
Temperature: 0°C to 50°C
(Pollution Degree) EN 61010-1:2010 specifies the pollution degrees
and their requirements as follows. The GDS-2000E falls under
degree 2.
Pollution refers to “addition of foreign matter, solid, liquid, or
gaseous (ionized gases), that may produce a reduction of dielectric
strength or surface resistivity”.
Pollution degree 1: No pollution or only dry, non-conductive
pollution occurs. The pollution has no influence.
Pollution degree 2: Normally only non-conductive pollution
occurs. Occasionally, however, a temporary conductivity caused
by condensation must be expected.
Pollution degree 3: Conductive pollution occurs, or dry, non-
conductive pollution occurs which becomes conductive due to
condensation which is expected. In such conditions, equipment
is normally protected against exposure to direct sunlight,
precipitation, and full wind pressure, but neither temperature
nor humidity is controlled.

GDS-2000E Series User Manual
8
Storage
environment
Location: Indoor
Temperature: -10°C to 60°C
Humidity: Up to 93% RH (non-condensing) /
≤40ºC, up to 65% RH (non-condensing) / 41ºC
~ 60 ºC
Disposal
Do not dispose this instrument as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased. Please make sure
discarded electrical waste is properly recycled to
reduce environmental impact.

SAFETY INSTRUCTIONS
9
Power cord for the United Kingdom
When using the oscilloscope in the United Kingdom, make sure the
power cord meets the following safety instructions.
NOTE: This lead/appliance must only be wired by competent persons
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in accordance with the
following code:
Green/ Yellow:
Earth
Blue:
Neutral
Brown:
Live (Phase)
As the colours of the wires in main leads may not correspond with
the coloured marking identified in your plug/appliance, proceed
as follows:
The wire which is coloured Green & Yellow must be connected to
the Earth terminal marked with either the letter E, the earth symbol
or coloured Green/Green & Yellow.
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the
terminal marked with the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment
or contact the supplier.
This cable/appliance should be protected by a suitably rated and
approved HBC mains fuse: refer to the rating information on the
equipment and/or user instructions for details. As a guide, a cable
of 0.75mm2should be protected by a 3A or 5A fuse. Larger
conductors would normally require 13A types, depending on the
connection method used.
Any exposed wiring from a cable, plug or connection that is
engaged in a live socket is extremely hazardous. If a cable or plug is
deemed hazardous, turn off the mains power and remove the cable,
any fuses and fuse assemblies. All hazardous wiring must be
immediately destroyed and replaced in accordance to the above
standard.

GDS-2000E Series User Manual
10
GETTING STARTED
This chapter describes the GDS-2000E in a
nutshell, including its main features and front /
rear panel introduction. After going through the
overview, follow the Set Up section to properly
set up the oscilloscope for first time use. The Set
Up section also includes a starter on how to use
this manual effectively.
GDS-2000E Series Overview ................................ 11
Series lineup ...................................................................................11
Main Features ................................................................................12
Accessories.....................................................................................13
Appearance ......................................................... 15
GDS-2074E/2104E/2204E Front Panel.................................15
GDS-2072E/2102E/2202E Front Panel.................................16
Rear Panel ......................................................................................23
Display ............................................................................................25
Set Up ................................................................. 27
Tilt Stand ........................................................................................27
Power Up .......................................................................................28
First Time Use...............................................................................29
How to Use This Manual ............................................................32
Built-in Help........................................................ 37

GETTING STARTED
11
GDS-2000E Series Overview
Series lineup
The GDS-2000E series consists of 6 models, divided into 2-channel
and 4-channel versions.
Model name
Frequency
bandwidth
Input channels
Max. Real-time
Sampling Rate
GDS-2072E
70MHz
2
1GSa/s
GDS-2102E
100MHz
2
1GSa/s
GDS-2202E
200MHz
2
1GSa/s
GDS-2074E
70MHz
4
1GSa/s
GDS-2104E
100MHz
4
1GSa/s
GDS-2204E
200MHz
4
1GSa/s

GDS-2000E Series User Manual
12
Main Features
Features
8 inch, 800 x 480, WVGA TFT display.
Available from 70MHz to 200MHz.
Real-time sampling rate of 1GSa/s (2 channel
models), 1GSa/s max. (4 channel models).
Deep memory: 10M points record length.
Waveform capture rate of 120,000 waveforms
per second.
Vertical sensitivity: 1mV/div~10V/div.
Segmented Memory: Optimizes the acquisition
memory to selectively capture only the
important signal details. Up to 29000 successive
waveform segments can be captured with a
time-tag resolution of 4ns.
Waveform Search: Allows the scope to search
for a number of different signal events.
On-screen Help.
32 MB internal flash disk.
Interface
USB host port: front panel, for storage devices.
USB device port: rear panel, for remote control
or printing.
Probe calibration output with selectable output
frequency (1kHz ~ 200kHz).
Ethernet port as standard.
Calibration output.

GETTING STARTED
13
Accessories
Standard
Accessories
Part number
Description
N/A
Quick Start Guide
N/A region dependent
Power cord
GTP-070B-4, for
GDS-2072E/GDS-2074E
Passive probe; 70 MHz
GTP-100B-4, for
GDS-2102E/GDS-2104E
Passive probe; 100 MHz
GTP-200B-4, for
GDS-2202E/GDS-2204E
Passive probe; 200 MHz
Standard Apps
Name
Description
Go-NoGo
Go-NoGo testing app.
DataLog
Waveform or image data logging
app.
DVM
Digital Volt Meter app.
Digital Filter
High or low pass digital filter for
analog inputs.
Remote Disk
Allows the scope to mount a network
share drive.
Demo Mode
Demonstration mode that is used
with the GDB-03 demo board.
Optional
Accessories
Part number
Description
GTC-001
Instrument cart, 470(W)x430(D)mm
(U.S. type input socket)
GTC-002
Instrument cart, 330(W)x430(D)mm
(U.S. type input socket)
GDB-03
Demo board
GTL-110
test lead, BNC to BNC heads

GDS-2000E Series User Manual
14
GTL-242
USB cable, USB2.0A-B type cable 4P
GTP-070B-4
Passive probe; 70 MHz
GTP-100B-4
Passive probe; 100 MHz
GTP-200B-4
Passive probe; 200 MHz
Drivers
USB driver
LabVIEW driver

GETTING STARTED
15
Appearance
GDS-2074E/2104E/2204E Front Panel
VARIABLE
POSITION
HORIZONTAL
POSITION
POSITION POSITION POSITION
VERTICAL
MATH
REF
BUS
SCALE
TRIGGER
LEVEL
PUSH TO
ZERO
SCALESCALESCALE
PUSH TO
ZERO
PUSH TO
ZERO
PUSH TO
ZERO
PUSH TO
ZERO
PUSH TO
ZERO
SCALE
POWER
CH1 CH2 CH3 CH4
2V
CAT I
1MW16pF
300Vrms MAX.
Digital Storage Oscilloscope
G D S -2 2 0 4 E 200 MHz 1 GS/s Visual Persistence Oscilloscope Measure
Display
Cursor
Help
APP
Save/Recall
Acquire
Utility
Autoset
Run/Stop
Single
Default
Select Search
Set/Clear
Zoom
CH1 CH2 CH3 CH4
M
R
B
Menu
50 %
Force-Trig
LCD
Variable knob
and Select key
Autoset, Run/Stop, Single
and Default settings
CH1~CH4
Trigger
controls
Function
keys
USB Host port, Probe
Compensation terminals
Power
button
Hardcopy key
Option key
Math, Reference
and Bus keys
Bottom
menu
keys
Horizontal
controls
Menu key
Vertical
controls
Side menu keys

GDS-2000E Series User Manual
16
GDS-2072E/2102E/2202E Front Panel
VARIABLE
POSITION
HORIZONTAL
TRIGGER
LEVEL
PUSH TO
ZERO
PUSH TO
ZERO
SCALE
Measure
Display
Cursor
Help
APP
Save/Recall
Acquire
Utility
Autoset
Run/Stop
Single
Default
Select Search
Set/Clear
Zoom
Menu
50 %
Force-Trig
POSITION
POSITION
VERTICAL
MATH
REF
BUS
SCALESCALE
PUSH TO
ZERO
PUSH TO
ZERO
M
R
B
Digital Storage Oscilloscope
GDS-2202E 200 MHz 1 GS/s Visual Persistence Oscilloscope
POWER
CH1 CH2 EXT TRIG
2V
CAT I
1MW16pF
300Vrms MAX.
CAT I
1MW16pF
300Vrms MAX.
LCD
Variable knob
and Select key
Autoset, Run/Stop, Single
and Default settings
CH1~CH2,
EXT TRIG
Trigger
controls
Function
keys
USB Host port, Probe
Compensation terminals
Power
button
Hardcopy key
Option key
Math, Reference
and Bus keys
Bottom
menu
keys
Horizontal
controls
Menu key
Vertical
controls
Side menu keys
LCD Display
8” WVGA TFT color LCD. 800 x 480 resolution,
wide angle view display.
Menu Off Key
Use the Menu Off key to hide the
onscreen menu system.
Option Key
The Option key is used to access
future installed options.

GETTING STARTED
17
Menu Keys
The side menu and bottom menu keys are used to
make selections from the soft-menus on the LCD
user interface.
To choose menu items, use the 7 Bottom menu
keys located on the bottom of the display panel.
To select a variable or option from a menu, use the
side menu keys on the side of the panel. See page
32 for details.
POSITION
VERT
MA
R
B
SCALE
PUSH TO
ZERO
M
R
B
Side menu keys
Bottom menu keys
Hardcopy Key
The Hardcopy key is a quick-save
or quick-print key, depending on
its configuration. For more
information see pages 248(save) or
247(print).
Variable Knob
and Select Key
Select
VARIABLE
The Variable knob is used to
increase/decrease values or to
move between parameters.
The Select key is used to make
selections.

GDS-2000E Series User Manual
18
Function Keys
The Function keys are used to enter and configure
different functions on the GDS-2000E.
Measure
Measure
Configures and runs automatic
measurements.
Cursor
Cursor
Configures and runs cursor
measurements.
APP
APP
Configures and runs GW Instek
applications.
Acquire
Acquire
Configures the acquisition mode,
including Segmented Memory
acquisition.
Display
Display
Configures the display settings.
Help
Help
Shows the Help menu.
Save/Recall
Save/Recall
Used to save and recall
waveforms, images, panel settings.
Utility
Utility
Configures the Hardcopy key,
display time, language, probe
compensation and calibration. It
also accesses the file utilities
menu.
Autoset
Autoset
Press the Autoset key to
automatically set the trigger,
horizontal scale and vertical scale.

GETTING STARTED
19
Run/Stop Key
Run/Stop
Press to Freeze (Stop) or continue
(Run) signal acquisition (page 42).
The run stop key is also used to
run or stop Segmented Memory
acquisition (page 90).
Single
Single
Sets the acquisition mode to single
triggering mode.
Default Setup
Default
Resets the oscilloscope to the
default settings.
Horizontal
Controls
The horizontal controls are used to change the
position of the cursor, set the time base settings,
zoom into the waveforms and search for events.
Horizontal
Position
POSITION
PUSH TO
ZERO
The Position knob is used to
position the waveforms
horizontally on the display screen.
Pressing the knob will reset the
position to zero.
SCALE
SCALE
The Scale knob is used to change
the horizontal scale (TIME/DIV).
Zoom
Zoom
Press Zoom in combination with
the horizontal Position knob.
Play/Pause
The Play/Pause key allows you to
view each search event in
succession –to effectively “play”
through each search event. It is
also used to play through a
waveform in zoom mode.

GDS-2000E Series User Manual
20
Search
Search
The Search key accesses the search
function menu to set the search
type, source and threshold.
Search Arrows
Use the arrow keys to navigate the
search events.
Set/Clear
Set/Clear
Use the Set/Clear key to set or
clear points of interest when using
the search function.
Trigger Controls
The trigger controls are used to control the trigger
level and options.
Level Knob
LEVEL
Used to set the trigger level.
Pressing the knob will reset the
level to zero.
Trigger Menu Key
Menu
Used to bring up the trigger menu.
50% Key
50 %
Sets the trigger level to the half
way point (50%).
Force - Trig
Force-Trig
Press to force an immediate trigger
of the waveform.
Vertical
POSITION
POSITION
PUSH TO
ZERO
Sets the vertical position of the
waveform. Push the knob to reset
the vertical position to zero.
Channel Menu
Key
CH1
Press the CH1~4 key to set and
configure the channel.
