Gymstick H2O ROWER User manual

H2O ROWER
USER MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future
reference. The specications of this product may vary from this photo, subject to change without notice.

2H2O ROWER
BEFORE YOU BEGIN
Thank you for choosing the Gymstick H2O Rower. We take great pride in producing this quality
product and hope it will provide many hours of e󰀨ective exercise to make you feel better, look
better and enjoy life to its fullest.
TABLE OF CONTENT
1. SAFETY INSTRUCTIONS .................................................................................................. 3
2. EXPLODED DRAWING ...................................................................................................... 4
3. PARTS LIST ........................................................................................................................5
4. HARDWARE PACKAGE .....................................................................................................7
5. ASSEMBLY INSTRUCTIONS .............................................................................................8
6. HOW TO FILL AND EMPTY THE TANK ............................................................................. 13
7. ADJUSTMENTS GUIDE .....................................................................................................14
8. MOVING THE MACHINE ................................................................................................... 15
9. STORAGE .......................................................................................................................... 16
10. INSTRUCTION MANUAL FOR COMPUTER ..................................................................... 17
11. CORRECT ROWING METHOD ......................................................................................... 21
12. WARM UP AND COOL DOWN ROUTINE ..........................................................................22
13. IMPLIED WARRANTY ........................................................................................................ 25
READ AND FOLLOW THE SAFETY INSTRUCTIONS. FAILURE TO FOLLOW THESE INSTRUCTIONS
CAN RESULT IN SERIOUS INJURY.
!
NOTIFICATION!

3H2O ROWER
!
WARNING!
SAFETY INSTRUCTIONS
Basic precautions should always be followed, including the following safety instructions when using
this equipment: Read all instructions before using this equipment.
1. Keep children and pets away from the Rowing Machine at all times. Do not leave unattended children in
the same room with the machine.
2. Handicapped or disabled persons should not use the Rowing Machine without the presence of a
qualied health professional or physician.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms, stop the
workout at once. Consult Physician immediately.
4. Before beginning training, remove all within a radius of 2 meters from the machine. Do not place any
sharp objects around the Rowing Machine.
5. Position the Rowing Machine on a clear, level surface away from water and moisture. Place mat under
the unit to help keep the machine stable and to protect the oor.
6. Use the Rowing Machine only for its intended use as described in this manual. Do not use any other
accessories not recommended by the manufacturer.
7. Assemble the machine exactly as the descriptions in the instruction manual.
8. Check all bolts and other connections before using the machine for the rst time and ensure that the
trainer is in the safe condition.
9. Hold a routine inspection of the equipment. Pay special attention to components which are the most
susceptible to wear o󰀨, i.e. connecting points and wheels. The defective components should be replaced
immediately. The safety level of this equipment can only be maintained by doing so. Please don’t use
the Rowing Machine until it is repaired well.
10. Never operate the Rowing Machine if it is not functioning properly.
11. This machine can be used for only one person’s training at a time.
12. Do not use abrasive cleaning articles to clean the machine. Remove drops of sweat from the machine
immediately after nishing training.
13. Always wear appropriate workout clothing when exercising. Running or aerobic shoes are also required.
14. Before exercising, always do stretching rst.
15. Maximum user weight 135 kgs.
BEFORE BEGINNING THIS OR ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN FIRST.
THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH
PRE-EXISTING HEALTH PROBLEMS.

4H2O ROWER
EXPLODED DRAWING

5H2O ROWER
PARTS LIST
Spec.DescriptionQTY No
.S
pec.Description QTY
1150Main Fframe 2Spacer forMeshbelt
2
Ø16* Ø10.2*69
151FrontStabilizerShort Spacer 4
3
Ø12.7* Ø8.2*13
SlideRrail 152SPHC,T=1.5Screw 1
4
M10*185
153Rear StabilizerWashe
r2
5
OD25*ID10.5*2.0
154ScrewSupportfor Computer 4
6
M8*30
155SupportPlate Screw
7
M6*15
156Tank Plate M8 9
8
NylonLockNut
157Platefor BushingSPHC,T=3.0 2M10
9
NylonLockNut
158HandlebarFlatScrew M8*1
51
2
10 Seat Carriage259SPHC,T=4.0Screw 1M10*55
11 160Impeller Scre
w2
0M8*15
12 PC 1UpperTtank 61 Scre
w1
2M3*20
13 PC 1LowerTank6
2M31
2
14
NylonLockNut
163Mesh Belt Wheel Scre
w1
M8*70
15 Decorate Cover164HIPS,black Scre
w4
M5*12
16 Belt Wheel165POM, blackScrew 3M8*125
17 HandlebarSeat166HIPS,black 4M8*15HexHeadScrew
18 Roller367POM, black 4M6*10
19 Axle for roller
Flat CrossScrew
36
83
CrossScrew M4*12
20 GuideRoller169POM, blac
kM41
21
NylonLockNut
Magnet Seat 170POM, blackScrew 2
22
M12*125
Bungee Pulley 471POM, blackFlatWashe
r3
1
23
OD20*ID8.5*1.5
Left Pedal172PP,black Scre
w8
24
ST4.2*16
RightPedal 173PP,black 1Knob
25 174Left EndCap S5 1AllenKey
26 175RightEnd CapAllenWrenc
h1
S13-S17
27 276Adjustable EndCap 1
28
PumpingSiphon
Rail EndCap 177PP,black 1Funnel
29 Oval Plug 278PP,black 1Lower Tank Plate
30
SPHC,T=3.0
1Rubber SealingRing79Rubber,black PlasticBushing 4
31
Ø27* Ø8.2*10
1Impeller ShaftSeal80Rubber,black Sensor Bracket
L1
32
SPHC,T=2.0
RoundPlug181PP,black Sensor Bracket
R1
33
SPHC,T=2.0
Fill Plug 182Rubber,black Scre
w1
M8*75
34 OShape Ring 183 Rubber,black 1
35
SealingRingfor Upper
Tank Rubber,black
LimitPad 284Rubber,black M3 24
36
StainlessWasher
Seat 185PU,black 1
37
Spacer forBeltWheel
PedalStrap 286PP,black 1
38
SteelSleeve
Strap1 OD40*ID20*0.387 1
39
Nylon, black
Bungee Cord 188Nylon, blackHex NutM10 2
40 PlasticWasher289 1POM, black
41 1OneWay BearingHFL2026 90 Scre
w2
M8*60
42 Bearing46000ZZ 91 Flat Washer 1
43
OD35*ID20.2*1.0
Bearing6608ZZ9
21
44
AluminiumClasp
2Bushing93Lower Pa
d2
45
50*50*T2.0
Pin194Ø6.0*40 8
46 1
Spacer forBungeePulley
95Computer 1
47
Spacer forGuide Roller Ø14* Ø1.5*19
296Sensor Wire Foam 1
48
Ø98* Ø28*20
Sensor Holder 197Nylon, black 2Roller BearingHK2010
49 Magnet 198Ø10*5Upper Pa
d2
25*25*T2.0
6
Chest Blet
Washer

6H2O ROWER
PRE-ASSEMBLY CHECK LIST
106
107
Cross screw
Adjust bolt
M4*12
U-Bracket
M6*30
4
2
2
Nylon Nut M6 2108
99
100
101
Screw
Screw
Lower rubber ring,
M5*30
ST5.5*16
L235*20*T1.0
1
1
6
103
104
Aluminum rail 2
Left decorative cover
for rail 2
102
105
2
Right decorative cover
for rail
PARTS LIST
NO.89NO.36
NO.26
NO.25
NO.46
NO.3
NO.4NO.2
NO.1
PART NO. Q’TYDESCRIPTION
1 1Main frame
2 1Front stabilizer
3 1Slide rail
4 1Rear stabilizer
25 1
Left end cap
26 1Right end cap
36 1Seat
46 1Computer
Chest Belt
1
1
1Hardware packag
e
8 9
Manual

7H2O ROWER
HARDWARE PACKAGE
#105 M4*12 2pcs
#103 1pc
#104 1pc
#68 M4*12 2pcs
#71 OD20*ID8.5*1.5 20pcs
#35 Limit pad 1pc
#58 M8*15 4pcs
#60 M8*15 16pcs
#67 M6*10 2pcs
#66 M8*15 4pcs
#74 S5 1pc
#75 S13-17 1pc

8H2O ROWER
ASSEMBLY INSTRUCTION
STEP 1:
NOTE: We recommend having 2 people to assemble the product.
Turn over the Slide Rail (No. 3) and Seat (No.36) as above.
Slide the Seat (No.36) onto the Slide Rail (No.3). Secure the Stopper (No.35) with 2 Flat Cross Screws
(No.67). Then attach the Rear Stabilizer (No.4) to the Slide Rail (No.3) with 4 Washers (No.71) and 4 Outer
Hex Screws (No.66). Tighten with Spanner (No.75).
#66 M8*15 4pcs
#67 M6*10 2pcs
#71 OD20*ID8.5*1.5 4pcs
#75 S13-17

9H2O ROWER
ASSEMBLY INSTRUCTION
STEP 2:
Secure the Left/Right Decorative Cover for Rail (No.103&104) with 2 Cross Screw (No.105) onto the Slide
Rail (No.3). Tight en with Spanner (No. 75).
105
104
103
#103 1pc
#104 1pc
#105 M4*12 2pcs
# 75 S13-17 1pc
STEP 3:
Attach L & R End Caps (No.25 & 26) to Front Stabilizer (No.2). Then tighten with 2 Cross Screws (No.68)
using Spanner (No.75).
26
68
225
68
#68 M4*12 2pcs
#75 S13-17

10H2O ROWER
ASSEMBLY INSTRUCTION
STEP 4:
Keep the Main Frame (No.1) upright. Attach Front Stabilizer (No.2) to Main Frame (No.1) using 8 Washers
(No.71) and 8 Screws (No.60). Tighten with Allen Wrench (No.74).
Note: You can put 3~4 screws into the holes rst, and start tightening by hand. After all the screws are put
in, then tighten with the tool.
2
71
60
1
#74 S5
#60 M8*15 8pcs
#71 OD20*ID8.5*1.5 8pcs
60
60
60
71
71
71

11H2O ROWER
ASSEMBLY INSTRUCTION
STEP 5:
NOTE: Move the Seat (No.36) to the front of the Slide Rail (No.3) before assembly to prevent it from gliding
down during assembly.
Attach the Slide Rail (No. 3) to the Main Frame (No. 1) using 4 Washers (No. 71), 4 Screws (No. 60) and
4 Flat Screws (No. 58). Insert all 8 screws partially into the holes rst, and then tighten with Allen Wrench
(No.74).
#74 S5
#58 M8*15 4pcs
#60 M8*15 8pcs
#71 OD20*ID8.5*1.5 8pcs

12H2O ROWER
STEP 6:
Attach the Support for computer (No.5) to Main Frame, tighten with 4 Washers (No.71) and 4 Screws
(No.60).
ASSEMBLY INSTRUCTION
#74 S5
#60 M8*15 4pcs
#71 OD20*ID8.5*1.5 4pcs
The assembly is complete!

13H2O ROWER
HOW TO FILL AND EMPTY THE TANK
Water level label
Fig. B
Fig. A
1. Remove the Fill Plug (No.33) from the Upper Tank Cover (No.12).
2. To ll tank with water, refer to Fig. A. Insert the Funnel (No.77) into the tank, then use a cup or the Siphon
Pump (No.76) and a bucket to ll the tank. Use the water level gauge on the side of the tank to measure
desired water level in the tank.
3. To empty the tank, refer to Fig. B. Place a bucket next to the rower, and use the Siphon Pump (No.76) to
pump out the water from the tank into the bucket.
4. Insert the Fill Plug (No.33) into the Upper Tank Cover (No.12). Wipe excess water o󰀨 of the frame.
NOTE:
• Fill the tank only with tap water. Add 1 water-purication tablet (1 packet is included).
Never use pool chlorine or chlorine bleach. This will damage the tank and void the warranty.
• Add a water purication tablet every 6 months or as needed. If water remains cloudy,
replace the water in the tank.
• Water from the tank is not suitable for consumption. Dispose the water after pumping it out from the tank.
WATER LEVEL:
• See Fig. A. The water level gauge is on the side of the tank. The maximum ll level is 6. Never ll it over
this limit. Filling the tank over this limit will void the warranty.
• The resistance depends on the water level in the tank. Water level 1 is the lowest resistance. Level 6 is the
highest resistance.

14H2O ROWER
ADJUSTMENT GUIDE
There are 3 hooks (A, B, C) for the bungee cord, located on the inside of the frame under the water tank.
If you hook the bungee cord on to B or C, it increases the assisted return of the mesh belt. C is the fastest
return. Use caution when adjusting the bungee cord.
ADJUSTING THE PEDAL STRAP
The pedal strap is adjustable and can be
personalized to t the user’s foot size.
To adjust the pedal strap, remove the Velcro
end of the strap from the mesh side by pul-
ling it upward then to the left.
Once removed, you may increase the ope-
ning of the pedal strap by pulling the mesh
end up and to the right.

15H2O ROWER
MOVING THE MACHINE
ADJUSTING THE BALANCE
Adjust the End Caps on the Rear Stabilizer (No.4) of the machine if the machine is unbalanced during use.
To move the machine, lift up the rear stabilizer until
the transportation wheels on the front stand touch
the ground. With the wheels on the ground, you can
transport the rower to the desired location with ease.

16H2O ROWER
STORAGE
36
3
4
4
36
3
CAUTION!
Move with caution when you
raise the rower up, as your
head may touch the Rear
Stabilizer (No. 4).
CAUTION!
Move the Seat (No.36) to
front of Slide Rail (No.3)
rst or it will glide down
when raising the rower up!
When not in use, you can save space
by storing the rower vertically. Lift by the
Rear Stabilizer (No.4) to raise the rower
to vertical position.
If not using the rower for more than a
month, empty the tank before storing.
Moving parts can cause serious injury. Keep you hands away from the rail when training!
!
WARNING!

17H2O ROWER
INSTRUCTION MANUAL FOR COMPUTER
BUTTON FUNCTIONS
UP▲/ DOWN▼:
ENTER:
START / STOP:
RESET:
RECOVERY:
FUNCTIONS
TIME:
TIME/500M:
SPM:
DISTANCE:
STROKES:
TOTAL STROKES:
CALORIES:
HRC/PULSE:
Press these two buttons to scroll through available selection. To adjust the function
value upward and downward.
To conrm your selection
During training, press the button to scan each display function.
To start and stop your selected workout program.
To return the computer back to the main menu. Press and hold to reset values.
To activate the RECOVERY PROGRAM that will automatically evaluate your tness
immediately after your work out.
The computerized display console on the H2O Rower allows the user to tailor a personalized workout by
monitoring their progress. During a workout, the display console will alternately and repeatedly display the
Time, Time/500M, SPM, Distance, Strokes, Total Strokes, Calories Burned and Pulse (all of the above).
Set target time by pressing UP and DOWN buttons (1min ~ 99 min), in 1 minute
increments.
Your average 500 M time is automatically displayed.
Strokes per minute.
Preset target value by pressing UP and DOWN buttons (10 ~ 99900meters),
100 meters increments.
Set target value by pressing UP and DOWN buttons (10~9990 strokes).10 strokes
increments.
Accumulates total strokes from 0 up to 9999.
Set target CALORIES by pressing UP or DOWN buttons (10Cal ~9990Cal),
10 Cal increments.
Displays heart rate. In Manual Mode, set target value by pressing UP and DOWN
buttons (30~240), 1 BPM increments. HRC will display at the top of the computer.
The computer will display your heart rate during training. When it reaches the target
value, PULSE will ash and computer will beep until it is changed to another mode or
you remove the chest belt. Pulse measurement function only works with 5.3 kHz chest
strap heart rate monitors.

18H2O ROWER
INSTRUCTION MANUAL FOR COMPUTER
3. When you enter into the SPORT screen, MANUAL and RACE will blink. Press UP or DOWN to select
MANUAL or RACE. Press ENTER to conrm your selection.
MANUAL (Fig.4): There are 2 options in MANUAL mode.
A. The computer can be set to countdown. When you select MANUAL, the value of TIME will start to ash.
Press UP to set the value of TIME to countdown. Press ENTER to conrm it. If you do not want to set the
value of time to COUNTDOWN, press ENTER to go to the next function. You can set the values for
DISTANCE, STROKES, CALORIES, or PULSE. (You can only set the value for one function to countdown.
For example, if you have set the target value for TIME, then DISTANCE can’t be set.)
B. The computer counts the value of your workout. Press START to start.
OPERATION
1. Install 2PCS AA batteries (included) and computer will beep for 2 seconds (Fig.1). Then, the computer
enters into the CLOCK & CALENDAR MODE (Fig.2).
2. The CLOCK will ash. Press UP to set the hour. Press ENTER to conrm. Press UP to set the minutes.
Press ENTER to conrm. Continue to set up YEAR (in the STROKES window); MONTH (in the
CALORIES window); DAY (in the PULSE window) by pressing UP or DOWN. Each time, press ENTER
to conrm.
After you conrm it, ALARM will blink. To skip setting up an alarm, press ENTER. To set up an alarm, press
UP KEY to turn on ALARM. An arrow will appear next to ALARM. Press ENTER. CLOCK window will ash.
Press UP or DOWN to set the alarm time. Press ENTER to conrm. Computer will go into the SPORT
screen (Fig.3).
CALENDAR:
TEMPERATURE:
CLOCK:
The computer will display year, month, and day when computer is in sleep mode.
The computer will display current room temperature when the computer is in sleep
mode.
The computer will display current clock when the computer is in sleep mode.
Fig.
1F
ig.2
Fig.3Fig.4

19H2O ROWER
INSTRUCTION MANUAL FOR COMPUTER
RACE (Fig.5):
Select RACE mode and L1 will ash. The TIME/500M will display 8:00. Then, press UP or DOWN to select
L1 ~ L15. Press ENTER to conrm. Then, you can set the distance of the race (500M~10000M) while the
value of DISTANCE is blinking.
Press ENTER, and the picture of the race will display on the screen. The TIME/500M of the programs are as
follows:
B. When the race is over, you can press START to start a race once again. Press RESET to leave the RACE
screen.
RECOVERY:
This meter works with a 5.3 kHz chest strap heart rate monitor. After exercising for a period of time, keep
wearing chest strap monitor and press “RECOVERY” button. All function displays will stop except “TIME”
starts counting down from 00:60 to 00:00.
Screen will display your heart rate recovery status with the F1, F2….to F6
F1 is outstanding. F6 is poor. User may keep exercising to improve the heart rate recovery status.
(Press the RECOVERY button again to return the main display)
L1 L2 L3 L4 L5 L6 L7 L8 L9 L10 L11 L12 L13 L14 L15
8:00 7:30 7:00 6:30 6:00 5:30 5:00 4:30 4:00 3:30 3:00 2:30 2:00 1:30 1:00
A. Press START button to start and STOP will disappear. USER and PC will display in the matrix (Fig.6).
The computer will stop when either user or computer has reached the race distance that was set. Then the
matrix displays “PC WIN” or “USER WIN” (Fig.7).
Fig.5
Fig.6
Fig.7

20H2O ROWER
INSTRUCTION MANUAL FOR COMPUTER
ALARM
Alarm only works while the computer is in sleep mode. Alarm will not sound during exercise.
Press and hold RESET to go to clock screen to set up ALARM.
SLEEP MODE
The computer will go into sleep mode after about 4 minutes of inactivity.
BATTERY
This meter uses 2 AA batteries, which are included. Changing the batteries will reset all values.
If there is a problem with the display, try changing the batteries rst. When changing the batteries, change
both of them. Do not mix battery types. Do not mix old and new batteries. Dispose of old batteries according
to your regional guidelines.
