H3C LSUM1TGT24FD0 User manual

Manual version: 6PW101-20191215 BOM: 3123A1QJ
i
LSUM1TGT24FD0 10GE copper interface module
1 Identifier
The module identifier LSUM1TGT24FD0 is in the upper right corner of the front panel.
2 Specifications
Table 1 Module specifications
Item Specifications
Dimensions (H × W × D) 40 × 399 × 355 mm (1.57 × 15.71 × 13.98 in)
SDRAM (DDR4) 2 GB
Power consumption 60 W to 112 W
Connector type RJ-45
Ports 24
Port rate
•100 Mbps
•1000 Mbps
•2.5 Gbps
•5 Gbps
•10 Gbps
Available cables
•100M/1000M/2.5G copper port: Category 5e or higher twisted pair
cables
•5G copper port: Category 6 or higher twisted pair cables
•10G copper port: Category 6a or higher twisted pair cables
Transmission medium and max
transmission distance 100 m (328.08 ft)
NOTE:
To verify the compatibility of the card with the software release you are using, see the release notes.
The 100M/1000M/2.5G/5G/10G copper port uses an RJ-45 connector.
Figure 1 RJ-45 connector
PIN #8
PIN #1

Manual version: 6PW101-20191215 BOM: 3123A1QJ
ii
Table 2 RJ-45 connector pin assignment
Pin 10G/5G/2.5G/1000/100BASE-T
Signal Function
1 MX_0+ Transmits and receives data
2 MX_0- Transmits and receives data
3 MX_1+ Transmits and receives data
4 MX_2+ Transmits and receives data
5 MX_2- Transmits and receives data
6 MX_1- Transmits and receives data
7 MX_3+ Transmits and receives data
8 MX_3- Transmits and receives data
3 Related documentation
For module installation, see the installation guide for the device.
For software upgrade, see the release notes for the device.
