H3C SecPath M9000 NSQM1MBFEA0 User manual

资料版本: 6PW102-20180530 BOM: 3123A1N2
i
H3C SecPath M9000 NSQM1MBFEA0 interface
module
1 Identifier
The module identifier NSQM1MBFEA0 is in the upper right corner of the front panel.
2 Introduction
The NSQM1MBFEA0 interface module is developed for H3C SecPath M9000 gateways. It provides
two subcard slots. By using the interface module with M9000 high-performance service modules, the
M9000 gateway is capable of providing security for 100G networks.
3 Specifications
Figure 1 Front panel
(1) Captive screw (2) Ejector lever
(3) Subcard slot 1 (4) Subcard slot 2
Table 1 Module specifications
Item Specifications
Dimensions (H × W × D) 40 × 399 × 354 mm (1.57 × 15.71 × 13.93 in)
SDRAM (DDR3) 2 GB
Power consumption 41W to 62W
Net weight 2.90 kg (6.39 lb), including the ejector lever
Hot swapping Supported
Ambient temperature •Operating: 0°C to 40°C (32°F to 104°F)
•Storage: –40°C to +70°C (–40°F to +158°F)
Ambient humidity •Operating: 5% RH to 95% RH, noncondensing
•Storage: 5% RH to 95% RH, noncondensing
Compatible device models
•M9006 gateway
•M9010 gateway
•M9014 gateway

资料版本: 6PW102-20180530 BOM: 3123A1N2
ii
4 Installing or removing the module
CAUTION:
•Wear a reliably-grounded ESD wrist strap or ESD gloves before you install or remove the
module.
•Do not touch the components on the module.
4.1 Installing the module
1. Face the front panel of the device and remove the filler panel from the target slot.
This example uses slot 2 on an M9006 gateway.
2. Place the module on a flat surface with the surface-mounted components facing up. Open the
ejector levers, and then gently push the module into the slot along the guide rails.
3. Close the ejector levers and ensure that the module makes close contact with the backplane.
4. Use a Phillips screwdriver to fasten the captive screws on the module.
Figure 2 Installing the module
4.2 Removing the module
1. Use a Phillips screwdriver to loosen the captive screws on the module until all pressure is
released.
2. Open the ejector levers to disengage the module connectors from the backplane, and then pull
the module out of the slot along the guide rails.
3. Place the module on an anti-static workbench or in an anti-static bag with the surface-mounted
components facing up.
4. If you are not to install a new module, install a filler panel in the slot to prevent dust and ensure
good ventilation in the chassis.
Copyright © 2018 New H3C Technologies Co., Ltd.
The information in this document is subject to change without notice.
