H3C SecPath DC2400 User manual

H3C SecPath DC2400 Power Module
User Manual
New H3C Technologies Co., Ltd.
http://www.h3c.com.hk
Document version: 6PW101-20170414

Copyright © 2016-2017, New H3C Technologies Co., Ltd.
and its licensors
All rights reserved
No part of this manual may be reproduced or transmitted in any form
or by any means without prior written consent of New H3C
Technologies Co., Ltd.
Trademarks
H3C, , H3CS, H3CIE, H3CNE, Aolynk, ,
H3Care, , IRF, NetPilot, Netflow, SecEngine, SecPath,
SecCenter, SecBlade, Comware, ITCMM and HUASAN are
trademarks of New H3C Technologies Co., Ltd.
All other trademarks that may be mentioned in this manual are the
property of their respective owners
Notice
The information in this document is subject to change without notice.
Every effort has been made in the preparation of this document to
ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of
any kind, express or implied.
Environmental protection
This product has been designed to comply with the environmental
protection requirements. The storage, use, and disposal of this
product must meet the applicable national laws and regulations.

Obtaining documentation
To access the most up-to-date H3C product documentation, go to the
H3C website at http://www.h3c.com.hk
To obtain information about installation, configuration, and
maintenance, click http://www.h3c.com.hk/Technical_Documents
To obtain software version information such as release notes,
click http://www.h3c.com.hk/Software_Download
Technical support
[email protected]
http://www.h3c.com.hk
Documentation feedback
You can e-mail your comments about product documentation to
[email protected].
We appreciate your comments.

i
Contents
Overview ·················································· 1
Front panel ···································································· 2
LEDs············································································ 2
Technical specifications ··················································· 4
Power module configuration·············································· 5
Installing and removing the power module······· 6
Installing the power module··············································· 6
Installing the power module ·········································· 7
Connecting the power cord··········································10
Removing the power module············································11
Removing the power cord············································12
Removing the power module········································12

1
Overview
The DC2400 DC-input and DC-output power module provides a
maximum output of 2400 W. The available model is NSQM1DC2400.
It has the following features:
•It has protection against undervoltage input, overvoltage input,
overvoltage output, output short circuit, overcurrent output, and
overtemperature.
•It is hot swappable. You can install and remove the power
module on an operating device.
•It can operate in N+1 or N+N redundancy. For more information,
see "Power module configuration."
NOTE:
The power module shuts down automatically when its
temperature exceeds the acceptable range. When the
temperature returns to the acceptable range, the power module
restarts automatically.

2
Front panel
Figure 1 Front panel
(1) Captive screw (2) Handle
(3) Power receptacle (4) Power cord screw hole
(5) Power input status LED
(INP OK) (6) Power output status LED (DC/FLT)
LEDs
The power module has two LEDs.

3
Table 1 LED description
LED Mark Color Description
Power
input
status
LED
INP OK
Green Normal power input.
Off
•No power input.
•Low power input voltage.
The power module has
entered self-protection
mode.
Power
output
status
LED
DC/FLT
Green Normal power output.
Red
•An output exception has
occurred, for example,
output short circuit, output
overcurrent, output
overvoltage, input
undervoltage,
overtemperature, or remote
shutdown. The power
module has entered
self-protection mode.
•No power is being input to
the power module. Other
power modules are
supplying power to the
device.
Orange
The temperature of the power
module exceeds the
acceptable range. The power
module has entered
self-protection mode.

4
NOTE:
A
fte
r
the circuit breaker of the power module is switched off, the
LEDs on the power module will remain on for a while. Make sure
the LEDs are off when you remove the power module.
Technical specifications
Table 2 Technical specifications
Item Specifications
Rated input voltage –48 to –60 VDC
Rated output voltage 12 VDC
Maximum input current 60 A
Maximum output current 200 A at 12 VDC
Maximum output power 2400 W
Dimensions (H × W × D) 41 × 102 × 391 mm (1.61 ×
4.00 × 15.36 in)
Ambient
temperatur
e
Operating
temperature –10°C to +50°C (–14°F to +122°F)
Storage
temperature –40°C to +85°C (–40°F to +185°F)
Relative
humidity
Operating
humidity 30% to 95%, non-condensing
Storage humidity 10% to 95%, non-condensing

5
Power module configuration
Follow these guidelines to configure power modules for a device:
•Determine the required number of power modules based on the
actual power consumption, the power module slot number, and
power redundancy design.
•Determine the power module redundancy design based on the
power source conditions.
{When two mains power inputs are provided, you can
configure the power modules in N+N redundancy. N+N must
be not greater than the total number of power module slots.
{When one mains power input is provided, you can configure
the power modules in N+1 or N+N redundancy. N+1 or N+N
must be not greater than the total number of power module
slots.
•For easy usage and maintenance, configure a circuit breaker for
each power input. The rated current of the circuit breaker must
be greater than 80 A.

6
Installing and removing the power
module
CAUTION:
Do not install the DC2400 power module and other types of
power modules on the same device.
The power module slots are either vertically or horizontally oriented,
depending on the device model. The power module installation and
removal procedure is similar for vertical and horizontal power module
slots. The figures in this section are for illustration only.
Installing the power module
To avoid bodily injury and device damage, follow the procedure
in Figure 2 to install the power module.

7
Figure 2 Installation flow
NOTE:
If the power module slot does not have a blank panel, skip the
"Remove the blank panel" procedure.
Before installing the power module, prepare an ESD wrist strap and a
Phillips screwdriver.
Installing the power module
1. Wear an ESD wrist strap, and make sure the wrist strap makes
good skin contact and is reliably grounded.
2. Use the Phillips screwdriver to loosen the captive screw on the
blank panel in the target slot, and remove the blank panel.
3. Take the power module out of the package.

8
4. Correctly orient the power module. The blank panel is printed
with a diagram of correct installation direction. Follow the
direction to orient the power module.
5. Holding the handle of the power module with one hand and
supporting the bottom with the other, push the power module
into the slot along the guide rails.
Figure 3 Installing the power module (vertical power module
slot)

9
Figure 4 Installing the power module (horizontal power module
slot)
6. Press the handle back into the notch of the power module.
7. Use the Phillips screwdriver to fasten the captive screw on the
handle to secure the power module in the slot.

10
Figure 5 Securing a power module in the slot
Connecting the power cord
WARNING!
•Make sure each power cord has a separate circuit breaker.
•Before connecting a DC power cord to the power source
terminals, make sure the circuit breakers for both the
negative terminal and positive terminal are switched off.
To connect the power cord:
1. Insert the DC power cord plug into the power receptacle on the
power module, as shown by callout 1 in Figure 6.
2. Fasten the screw on the plug to secure the plug in place, as
shown by callout 2 in Figure 6.

11
Figure 6 Connecting the power cord (vertical power module
slot)
(1) Plug the DC power cord connector into the receptacle of the
power module.
(2) Fasten the screw on the plug.
3. Connect the other end of the DC power cord to the circuit
breaker, with the negative wire (–) in blue to the negative
terminal (–) and the positive wire (+) in black to the positive
terminal (+).
Removing the power module
CAUTION:
Before you insert a removed power module into a power module
slot, make sure the LEDs on the power module are off.
To avoid device damage and bodily injury, follow the procedure
in Figure 7 to remove the power module.

12
Figure 7 Removal flow
Before removing the power module, prepare an ESD wrist strap and
a Phillips screwdriver.
Removing the power cord
1. Turn off the circuit breakers for the power cord.
2. Wear an ESD wrist strap, and make sure that the wrist strap
makes good skin contact and is reliably grounded.
3. Loosen the screw that fastens the power cord plug, and pull the
plug out.
Removing the power module
1. Use the Phillips screwdriver to loosen the captive screw on the
power module.

13
2. Hold the captive screw and pull out the handle of the power
module.
3. As shown in Figure 8, grasp the handle of the power module
with one hand and pull it part way out of the slot. Support the
bottom of the power module with the other hand, and pull the
module slowly out of the slot along the guide rails.
Figure 8 Removing the power module (vertical power module
slot)
4. Put the power module on an antistatic mat.
5. Install the blank panel in the power module slot, and fasten the
captive screw on the blank panel.
