H3C S5800-54S User manual

i
Contents
Overview···········································································································1
About this guide ······························································································· 1
Product overview······························································································ 1
Installation preparations···················································································2
Installation site·································································································· 2
Installation tools································································································ 2
Installing the switch···························································································3
Installation flow ································································································ 3
Installing the switch in a rack ········································································· 4
Attaching an ESD wrist strap ································································· 4
Installation accessories ··········································································· 4
Mounting positions·················································································· 5
Installing an S5800-54S switch in a 19-inch rack ······························ 7
Installing an S5800-60C-PWR switch in a 19-inch rack ··················10
Installing the other S5800 switch models in a 19-inch rack ············12
Mounting the switch on a workbench··························································13
Connecting the grounding cable··································································14
Installing fan trays··························································································16
Installing power modules···············································································18
Connecting the power cord ··········································································22
Connecting an AC power cord ···························································22
Connecting the DC power cord···························································24
Installing an interface card ···········································································27
Installing an OAP card ··················································································28
Installing a PoE module ·················································································29

1
Overview
About this guide
This guide describes the basic installation procedures for the S5800 Switch
Series. For more information about the installation and configuration
procedures, system description, appearance, LEDs, software loading and
upgrading, and troubleshooting, see H3C S5800 Switch Series Installation
Guide.
Product overview
The H3C S5800 Switch Series includes the following models:
•S5800-56C
•S5800-56C-PWR
•S5800-32C
•S5800-32C-PWR
•S5800-32F
•S5800-60C-PWR
•S5800-54S
NOTE:
The H3C S5800 Switch Series models and installation procedures might
be updated without prior notice. For the latest quick start guide, go
to http://www.h3c.com.hk.

2
Installation preparations
Installation site
The switch must be used indoors. Before installation, verify that the rack is
sturdy enough to support the switch and its accessories.
To ensure correct operation and long service life of your switch, install it in an
environment that meets the temperature, humidity, and electromagnetic shield
(EMS) requirements. For more information, see H3C S5800 Switch Series
Installation Guide.
Installation tools
The installation tools are not provided with the switch. Prepare them yourself.
Figure 1 Installation tools
(1) ESD wrist strap (2) Flat-blade screwdriver
(3) Phillips screwdriver (4) Marker
(5) Wrench (6) Blow dryer

3
Installing the switch
Installation flow
Figure 2 Installation flow
Connect the grounding cable
Install the switch to a
specified position
Start
Connect the power cord
Verify the installation
Power on the switch
Select and install power modules
Hot swappable power
modules are used?
Yes
No
Correctly operating? Power off the switch
Troubleshoot the switch
No
Yes
Install hot swappable
components?
Install a PoE module
Install an interface cardInstall an OAP card
Select hot swappable
components
Yes
Correctly operating? Troubleshoot the switch
Verify the installation
Yes
No
End
No
Hot swappable fan
trays are used?
Select and install
fan trays
Yes
No
Fan trays have
been installed?
No
Yes

4
Installing the switch in a rack
Attaching an ESD wrist strap
Before installation, wear an ESD strap, and make sure one end of the wrist
strap has a good skin contact and the other end is attached to a post of the
correctly-grounded rack, as shown in Figure 3.
Figure 3 Attaching an ESD wrist strap
Installation accessories
All switch models except the S5800-60C-PWR switch come with a pair of 1 U
mounting brackets. The S5800-60C-PWR switch comes with a pair of 2 U
mounting brackets, and each mounting bracket is attached with a cable
management bracket.

5
Figure 4 Mounting brackets
(1) 1 U mounting brackets
(2) 2 U mountin
g
brackets and cable mana
g
ement brackets
In addition to a pair of 1 U mounting brackets, the S5800-54S switch also
comes with a pair of chassis rails and a pair of slide rails.
Figure 5 Chassis rail and slide rail
(1) Chassis rail (2) Slide rail
Mounting positions
All switch models except the S5800-54S switch provide three mounting
positions: one front mounting position (near the network ports), one
mid-mounting position, and one rear mounting position (near the power
modules). Figure 6 shows the mounting positions on these switches.

6
Figure 6 Mounting positions
(1) Front mountin
g
position (2) Mid-mountin
g
position
(3) Rear mountin
g
position
The S5800-54S switch provides two mounting positions: one front mounting
position (near the network ports) and one rear mounting position (near the
power modules), as shown in Figure 7.
Figure 7 Mounting positions on an S5800-54S switch
(1) Front mountin
g
position (2) Rear mountin
g
position
1
2

7
Installing an S5800-54S switch in a 19-inch
rack
Table 1 Installing an S5800-54S switch in a 19-inch rack
Installation
p
rocedure Remarks Installation dia
g
ram
1. Attach the mounting
brackets to the switch. Required
•For mounting near the power
modules, see Figure 8.
•For mounting near the ports,
see Figure 9.
2. Attach chassis rails to the
switch. Required
•For mounting near the ports,
see Figure 8.
•For mounting near the power
modules, see Figure 9.
3. Install cage nuts in the rack
posts. Required See Figure 10.
4. Attach slide rails to the
rack posts. Required See Figure 11.
5. Connect the grounding
cable to the primary
grounding point
Optional See Figure 12.
6. Install the switch in the
rack. Required
See Figure 13. This figure uses
the mounting position near the
power modules as an example.
NOTE:
•The depth of the rack must be a minimum of 1000 mm (39.37 in).
•The S5800-54S switch has three grounding points, as shown in Fi
g
ure
19. The primary grounding point and auxiliary grounding point 1 are
on the right side panel. If you use one of these grounding points, you
must connect the grounding cable to the grounding point before you
mount the switch in the rack.

8
Figure 8 Installing the mounting brackets near the power modules and
installing the chassis rails
Figure 9 Installing the mounting brackets near the ports and installing the
chassis rails
Figure 10 Installing cage nuts in a rack post

9
Figure 11 Installing slide rails to the rack
Figure 12 Connecting the grounding cable to the primary grounding point
(1) Grounding sign (2) Grounding cable

10
Figure 13 Installing the switch in the rack (mounting brackets near the power
modules)
Installing an S5800-60C-PWR switch in a
19-inch rack
Table 2 Installing an S5800-60C-PWR switch in a 19-inch rack
Installation
p
rocedure Remarks Installation dia
g
ram
1. Separate the mounting brackets
from cable management
brackets.
Optional See Figure 14.
2. Attach the mounting brackets to
the switch. Required
•For mounting near the
ports, see Figure 14.
•For mounting in the
mid-mounting position,
see Figure 14.
•For mounting near the
power modules,
see Figure 14.
3. Install cage nuts in the rack
posts. Required See Figure 10.
4. Install the switch in the rack Required See Figure 15.

11
NOTE:
Before you install the mounting brackets in the mid-mounting position,
separate the mounting brackets from the cable management brackets.
Figure 14 Attaching mounting brackets to the S5800-60C-PWR switch
(1) Separate the mountin
g
bracket from the cable mana
g
ement bracket
(2) Install mountin
g
brackets near the ports
(3) Install mounting brackets in the mid-mounting position
(4) Install mountin
g
brackets near the power modules
12
3 4

12
Figure 15 Installing the switch in a rack
Installing the other S5800 switch models in a
19-inch rack
Table 3 Installing other S5800 switch models in a 19-inch rack
Installation
p
rocedure Remarks Installation dia
g
ram
1. Attach the mounting brackets to the
switch. Required See Figure 16.
2. Install cage nuts in the rack posts. Required See Figure 10.
3. Install the switch in the rack Required See Figure 17.
Figure 16 Attaching the mounting bracket to the switch
(1) Mountin
g
near the ports (2) Mountin
g
in the mid-mountin
g
position
(3) Mounting near the power modules

13
Figure 17 Installing the switch in a rack
Mounting the switch on a workbench
CAUTION:
•Ensure 10 cm (3.94 in) of clearance around the switch.
•Do not place heavy objects on the switch.
If a standard 19-inch rack is not available, you can place you switch on a
workbench. The S5800-54S switch cannot be mounted on a workbench.
To mount the switch on a workbench:
1. Make sure the workbench is clean and correctly grounded.
2. Place the switch with bottom up carefully, and clean the round holes on
the chassis bottom with dry cloth.
3. Attach the rubber feet to the four round holes in the chassis bottom.
4. Place the switch with upside up on the workbench.

14
Figure 18 Mounting the switch on a workbench
Connecting the grounding cable
W
ARNING!
Correctly connecting the switch grounding cable is crucial to lightning
protection and EMS of a switch.
The S5800 switch models except the S5800-54S switch have one grounding
point at their rear panels. The S5800-54S switch has three grounding points,
as shown in Figure 19. H3C recommends that you use the primary grounding
point for the S5800-54S switch.
Figure 19 Grounding points of the S5800-54S switch
(1) Auxiliary grounding point 2 (2) Primary grounding point
(3)
A
uxiliary
g
roundin
g
point 1
To connect the grounding cable:
1. Connect one end of the grounding cable to the grounding point of the
switch.

15
Figure 20 Connect the grounding cable to the switch
2. To connect the other end of the grounding cable to a grounding strip:
a. Cut the grounding cable to a length according to the distance
between the switch and the grounding strip.
b. Peel 5 mm (0.20 in) of insulation sheath from the end, and then
insert the naked metal part through the black insulation covering into
the end of the ring terminal.
c. Secure the metal part of the cable to the ring terminal with a crimper,
and then cover it with the insulation covering.
d. Heat the insulation covering with a blow dryer to let it completely
cover the metal part.
e. Attach the ring terminal to the grounding post of the grounding strip,
and then secure it with a hex nut.
Figure 21 Connecting the other end of the grounding cable to the grounding
strip

16
Installing fan trays
CAUTION:
You must install two fan trays of the same model on the same switch.
Table 4 lists the fan trays available for the switch. For more information about
the fan trays, see H3C LSW1FAN & LSW1BFAN Installation Manual and
H3C LSWM1FANSC & LSWM1FANSCB Installation Guide.
Table 4 Installing fan trays
Switch
model
Support for
hot-swappable
fan tra
y
s
Shipped
with fan
tra
y
s
Available
fan trays
Installation
diagram
S5800-32C
No No N/A N/A
S5800-56C
S5800-32C
-PWR
S5800-56C
-PWR
S5800-32F Yes Yes LSW1BFAN See Figure 22.
S5800-60C
-PWR Yes Yes LSW1FAN See Figure 23.
S5800-54S Yes No
•LSWM1
FANSC
•LSWM1
FANSCB
See Figure 24.
The installation
procedures are
the same for the
LSWM1FANSC
and
LSWM1FANSCB
fan trays.

17
Figure 22 Installing an LSW1BFAN fan tray
Figure 23 Installing an LSW1FAN fan tray
Figure 24 Installing an LSWM1FANSC fan tray

18
Installing power modules
The S5800-32F, S5800-54S, and S5800-60C-PWR switches provide two
power modules slots and support hot-swappable power modules. A power
module can meet the power requirements of the switch. You can install two
power modules for redundancy.
Table 5 lists the power modules available for these switches. For more
information about the power modules, see H3C PSR150-A & PSR150-D Series
Power Modules User Manual, H3C PSR300-12A & PSR300-12D Series Power
Modules User Manual, H3C LSVM1AC650 & LSVM1DC650 Power Modules
User Manual, H3C LSVM1AC300 & LSVM1DC300 Power Modules User
Manual, and H3C PSR750-A & PSR750-D Power Modules User Manual.
Table 5 Installing power modules
Switch
model
Support for
hot-swappable
p
ower modules
Available power
modules
Installation
diagram
S5800-32C
No N/A N/A
S5800-56C
S5800-32C-
PWR
S5800-56C-
PWR
S5800-32F Yes
•PSR150-A
•PSR150-A1
•PSR150-D
•PSR150-D1
See Figure 25. The
figure uses a
PSR150-A power
module as an
example.
S5800-54S Yes
•LSVM1AC650
•LSVM1DC650
•LSVM1AC300
•LSVM1DC300
See Figure 26. The
figure uses an
LSVM1AC650
power module as an
example.

19
Switch
model
Support for
hot-swappable
p
ower modules
Available power
modules
Installation
diagram
S5800-60C-
PWR Yes
•PSR300-12A
•PSR300-12A1
•PSR300-12A2
•PSR300-12D1
•PSR300-12D2
•PSR750-A
•PSR750-D
See Figure 27. This
figure uses a
PSR300-12A power
module as an
example.
CAUTION:
The two power modules on an S5800-60C-PWR switch can be of differen
t
types. Follow these guidelines to install power modules on an
S5800-60C-PWR switch:
•Do not install a 300 W power module (PSR300-12A, PSR300-12A1,
PSR300-12A2, PSR300-12D1, or PSR300-12D2) and a 750 W power
module (PSR750-A or PSR750-D) on the same S5800-60C-PWR switch.
•Do not install a PSR750-A power module and a PSR750-D power
module on the same S5800-60C-PWR switch.
•To install a PSR750-A or PSR750-D power module on an
S5800-60C-PWR switch, first remove the filler module in the power
modules slot (as shown in Figure 28), and then install the power module
as shown in Figure 29, which uses a PSR750-D power module as an
example.
•Before you install a PSR300-12A, PSR300-12A1, PSR300-12A2,
PSR300-12D1, or PSR300-12D2 power module on an S5800-60C-PWR
switch, make sure the filler module has been installed.
CAUTION:
Do not install a 650 W power module (LSVM1AC650 or LSVM1DC650)
and a 300 W power module (LSVM1AC300 or LSVM1DC300) on the
same S5800-54S switch.
