Introduction
This document provides configuration examples of link layer attack protection, ARP attack protection,
network layer attack protection, and transport layer attack protection, as defined in Table 1.
Table 1 Attack protection types
Attack
p
rotection t
yp
es Descri
p
tion
Link layer attack
protection
MAC address attack
protection
Prevents the attack of packets with different source
MAC addresses or VLANs by configuring the
maximum number of MAC addresses that an interface
can learn.
STP packet attack protection Provides protection measures such as BPDU guard,
root guard, loop guard, and TC-BPDU guard.
ARP attack
protection
ARP source suppression Prevents IP attack packets from fixed sources.
ARP black hole routing Prevents IP attack packets from sources that are not
fixed.
ARP active acknowledgement Prevents user spoofing.
Source MAC-based ARP
attack detection
Prevents ARP packet attacks from the same source
MAC.
ARP packet source MAC
consistency check
Prevents attacks from ARP packets whose source MAC
address in the Ethernet header is different from the
sender MAC address in the message body.
Network layer
attack protection
uRPF check Protects a network against source spoofing attacks.
TTL attack protection Prevents an attack by disabling sending ICMP time
exceeded messages.
Transport layer
attack protection SYN flood attack protection
Enables the server to return a SYN ACK message
when it receives a TCP connection request, without
establishing a half-open TCP connection.
Prerequisites
The configuration examples in this document were created and verified in a lab environment, and all the
devices were started with the factory default configuration. When you are working on a live network,
make sure you understand the potential impact of every command on your network.
This document assumes that you have basic knowledge of attack protection.

2
Example: Configuring link layer attack
protection
Network requirements
As shown in Figure 1, Device A, Device B, and Device C run MSTP. Device B acts as the root bridge, and
GigabitEthernet 2/0/1 on Device C is blocked.
Configure the following features to prevent link layer attacks:
•Configure root guard on GigabitEthernet 2/0/1 and GigabitEthernet 2/0/2 of Device B for
Device B to act as the root bridge.
•Configure loop guard on GigabitEthernet 2/0/2 of Device C to prevent temporary loops. The loop
guard feature keeps the port in Discarding state in all MSTIs when it receives no BPDU.
•Configure BPDU guard on ports at the access side of Device A and Device C. The BPDU guard
feature prevents the ports from performing spanning tree calculations when it receives forged
BPDUs with a higher priority.
•Enable TC-BPDU guard on Device A, Device B, and Device C. The TC-BPDU guard feature prevents
a large number of TC-BPDUs from affecting the network in a short time.
•Set the maximum number of MAC addresses that can be learned by ports at the access side of
Device A and Device C. This configuration protects the devices from a large number of attack
packets that have different source MAC addresses. The attack packets might cause a large MAC
table and low forwarding performance.
•Configure broadcast and multicast suppression on the designated ports of Device B and all ports on
Device A and Device C. When incoming broadcast or multicast traffic exceeds the threshold, an
interface discards broadcast or multicast packets until the traffic drops below the threshold.

3
Figure 1 Network diagram
Requirements analysis
For the ports at the access side of Device A and Device C to rapidly transit to the forwarding state, use
the stp edged-port command to configure these ports as edge ports.
This example uses GigabitEthernet 2/0/3 to illustrate the configuration on the ports at the access side on
Device A and Device C.
Software version used
This example was created and verified on S7500EX-CMW710-R7168.
Configuration restrictions and guidelines
When you configure link layer attack protection, follow these restrictions and guidelines:
•On a port, the loop guard feature is mutually exclusive with the root guard feature or the edge port
setting.
•Do not configure the loop guard feature on ports at the access side. Otherwise, the ports stay in
Discarding state in all MSTIs because they cannot receive BPDUs.

4
Configuration procedures
Configuring Device B
# Specify IP addresses for interfaces. (Details not shown.)
# Configure root guard on GigabitEthernet 2/0/1 and GigabitEthernet 2/0/2.
<DeviceB> system-view
[DeviceB] interface range GigabitEthernet 2/0/1 to GigabitEthernet 2/0/2
[DeviceB-if-range] stp root-protection
[DeviceB-if-range] quit
# Configure TC-BPDU guard.
[DeviceB] stp tc-protection
[DeviceB] stp tc-protection threshold 10
# Configure broadcast and multicast suppression on GigabitEthernet 2/0/1 and GigabitEthernet
2/0/2.
[DeviceB] interface range GigabitEthernet 2/0/1 to GigabitEthernet 2/0/2
[DeviceB-if-range] broadcast-suppression pps 6400
[DeviceB-if-range] multicast-suppression pps 6400
[DeviceB-if-range] quit
Configuring Device A
# Specify IP addresses for interfaces. (Details not shown.)
# Configure STP BPDU guard.
<DeviceA> system-view
[DeviceA] stp bpdu-protection
# Configure GigabitEthernet 2/0/3 as an edge port.
[DeviceA] interface GigabitEthernet 2/0/3
[DeviceA-GigabitEthernet2/0/3] stp edged-port
[DeviceA-GigabitEthernet2/0/3] quit
# Configure TC-BPDU guard.
[DeviceA] stp tc-protection
[DeviceA] stp tc-protection threshold 10
# Set the maximum number of MAC addresses that GigabitEthernet 2/0/3 can learn.
[DeviceA] interface GigabitEthernet 2/0/3
[DeviceA-GigabitEthernet2/0/3] mac-address max-mac-count 1024
[DeviceA-GigabitEthernet2/0/3] quit
# Configure broadcast and multicast suppression on all ports.
[DeviceA] interface range GigabitEthernet 2/0/1 to GigabitEthernet 2/0/3
[DeviceA-if-range] broadcast-suppression pps 6400
[DeviceA-if-range] multicast-suppression pps 6400
[DeviceA-if-range] quit

5
Configuring Device C
# Specify IP addresses for interfaces. (Details not shown.)
# Configure STP BPDU guard.
<DeviceC> system-view
[DeviceC] stp bpdu-protection
# Configure GigabitEthernet 2/0/3 as an edge port.
[DeviceC] interface GigabitEthernet 2/0/3
[DeviceC-GigabitEthernet2/0/3] stp edged-port
[DeviceC-GigabitEthernet2/0/3] quit
# Configure root guard on GigabitEthernet 2/0/1.
[DeviceC] interface GigabitEthernet 2/0/1
[DeviceC-GigabitEthernet2/0/1] stp root-protection
[DeviceC-GigabitEthernet2/0/1] quit
# Configure loop guard on GigabitEthernet 2/0/2.
[DeviceC] interface GigabitEthernet 2/0/2
[DeviceC-GigabitEthernet2/0/2] stp loop-protection
[DeviceC-GigabitEthernet2/0/2] quit
# Configure TC-BPDU guard.
[DeviceC] stp tc-protection
[DeviceC] stp tc-protection threshold 10
# Set the maximum number of MAC addresses that GigabitEthernet 2/0/3 can learn.
[DeviceC] interface GigabitEthernet 2/0/3
[DeviceC-GigabitEthernet2/0/3] mac-address max-mac-count 1024
[DeviceC-GigabitEthernet2/0/3] quit
# Configure broadcast and multicast suppression on all ports.
[DeviceC] interface range GigabitEthernet 2/0/1 to GigabitEthernet 2/0/3
[DeviceC-if-range] broadcast-suppression pps 6400
[DeviceC-if-range] multicast-suppression pps 6400
[DeviceC-if-range] quit
Verifying the configuration
# Verify that the edge ports go down after they receives STP BPDUs. (Details not shown.)
# Bring the edge ports up by using the undo shutdown command. (Details not shown.)
# Verify that the root ports do not change and that the STP topology remains stable after STP BPDUs with
higher priority are sent to the designated ports. (Details not shown.)
# Verify that the devices do not refresh the FIB table frequently and that no serious packet loss occurs after
a large number of various TC BPDUs are sent to the devices. (Details not shown.)
# Verify that the uplink ports are not flooded after a large number of broadcasts are sent to the edge
ports on device A and Device C. (Details not shown.)

6
Configuration files
•Device A:
#
stp bpdu-protection
stp tc-protection
stp tc-protection threshold 10
#
interface GigabitEthernet 2/0/1
port link-mode bridge
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
interface GigabitEthernet 2/0/2
port link-mode bridge
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
interface GigabitEthernet 2/0/3
port link-mode bridge
mac-address max-mac-count 1024
stp edged-port
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
•Device B:
#
stp tc-protection
stp tc-protection threshold 10
#
interface GigabitEthernet 2/0/1
port link-mode bridge
stp root-protection
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
interface GigabitEthernet 2/0/2
port link-mode bridge
stp root-protection
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
interface GigabitEthernet 2/0/3
port link-mode bridge
stp edged-port
#
•Device C:

7
#
stp bpdu-protection
stp tc-protection
stp tc-protection threshold 10
#
interface GigabitEthernet 2/0/1
port link-mode bridge
stp root-protection
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
interface GigabitEthernet 2/0/2
port link-mode bridge
stp loop-protection
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
interface GigabitEthernet 2/0/3
port link-mode bridge
mac-address max-mac-count 1024
broadcast-suppression pps 6400
multicast-suppression pps 6400
#
Example: Configuring ARP attack protection
Network requirements
As shown in Figure 2, the device is the gateway for the internal network. Configure ARP attack protection
on the device to prevent ARP attacks.
Figure 2 Network diagram

8
Software version used
This example was created and verified on S7500EX-CMW710-R7168.
Configuration procedures
# Specify IP addresses for interfaces. (Details not shown.)
# Enable ARP source suppression.
<Device> system-view
[Device] arp source-suppression enable
# Configure the device to accept a maximum of 8 unresolvable packets per source IP address in 5
seconds.
[Device] arp source-suppression limit 8
# Enable ARP black hole routing to prevent unresolvable IP packet attacks.
[Device] arp resolving-route enable
# Enable ARP active acknowledgment to prevent user spoofing.
[Device] arp active-ack enable
# Configure source MAC-based ARP attack detection to prevent ARP packet attacks from the same source
MAC.
[Device] arp source-mac filter
[Device] arp source-mac threshold 25
# Enable ARP packet source MAC address consistency check to prevent attacks from ARP packets with
different source MAC addresses in the Ethernet header and in the message body.
[Device] arp valid-check enable
Verifying the configuration
1. Verify that ARP attack protection functions on the device:
# Send ARP attack packets to the device. (Details not shown.)
# Verify that the CPU usage does not surge. (Details not shown.)
2. Verify that each ARP attack protection feature functions on the device (this example uses the ARP
source suppression feature):
# Send the device 20 forged packets with the same source IP address and unresolvable
destination IP addresses. (Details not shown.)
# Verify that the device stops resolving the packets after receiving 8 forged packets within 5
seconds. (Details not shown.)
# Verify the ARP source suppression configuration.
<Sysname> display arp source-suppression
ARP source suppression is enabled
Current suppression limit: 8
Current cache length: 16

9
Configuration files
#
arp valid-check enable
arp source-mac filter
arp source-mac threshold 25
arp active-ack enable
arp source-suppression enable
arp source-suppression limit 8
#
Example: Configuring network layer attack
protection
Network requirements
As shown in Figure 3, Device A is the gateway for the internal network. To protect Device A against IP
packet attacks from internal and external networks, configure the following network layer attack
protection features:
•Configure strict uRPF check to prevent source address spoofing attacks.
•Disabling sending ICMP time exceeded messages. The device will not be flooded by ICMP time
exceeded messages when receiving a large number of packets in which the TTL is 1.
Figure 3 Network diagram
Software version used
This example was created and verified on S7500EX-CMW710-R7168.
Configuration restrictions and guidelines
After you disable sending ICMP time exceeded messages, the traceroute feature will not be available.
Configuration procedures
# Specify IP addresses for interfaces. (Details not shown.)
# Enable strict uRPF check.
[DeviceA] ip urpf strict

10
# Disable sending ICMP time exceeded messages. Sending ICMP time exceeded messages is disabled
by default.
[DeviceA] undo ip ttl-expires enable
Verifying the configuration
1. Verify that Device A can prevent source address spoofing attacks:
# Verify that Device A can filter out packets with forged source IP addresses. (Details not shown.)
# Verify the uRPF configuration.
<DeviceA> display ip urpf
Global uRPF configuration information:
Check type: strict
Allow default route
2. Verify that TTL attack protection functions on Device A:
# Enable ICMP debugging by executing the debugging ip icmp command on Device A. (Details
not shown.)
# Use a PC to send packets in which the TTL is 1 to Device A. (Details not shown.)
# Verify that Device A does not display any debugging information and that the PC does not
receive any ICMP time exceeded messages. (Details not shown.)
# Enable sending ICMP time exceeded messages and send packets in which the TTL is 1 to Device
A. (Details not shown.)
# Verify that Device A responds with ICMP time exceeded messages.
<DeviceA> *Jun 14 14:43:31:068 2013 NM-3 SOCKET/7/ICMP: -MDC=1-Slot=2;
Time(s):1371221011 ICMP Output:
ICMP Packet: src = 6.0.0.1, dst = 202.101.0.2
type = 11, code = 0 (ttl-exceeded)
Original IP: src = 202.101.0.2, dst = 192.168.0.2
proto = 253, first 8 bytes = 00000000 00000000
Configuration files
#
ip urpf strict
#
Example: Configuring transport layer attack
protection
Network requirements
As shown in Figure 4, the device is the gateway for the internal network. Configure SYN Cookie
protection on the device to protect against SYN flood attacks. With this feature enabled, the device

11
responds to a SYN packet with a SYN ACK packet without establishing a TCP semi-connection. The
device establishes a TCP connection only when it receives an ACK packet from the sender.
Figure 4 Network diagram
Software version used
This example was created and verified on S7500EX-CMW710-R7168.
Configuration procedures
# Specify IP addresses for interfaces. (Details not shown.)
# Enable SYN Cookie.
<Device> system-view
[Device] tcp syn-cookie enable
Verifying the configuration
# Verify that the device does not have any TCP semi-connections. The state "SYN_RECEIVED" represents
semi-connections.
[Device] display tcp
*: TCP MD5 Connection
Local Addr:port Foreign Addr:port State Slot Cpu PCB
0.0.0.0:21 0.0.0.0:0 LISTEN 1 0 0xfffffffffff
fff9d
0.0.0.0:23 0.0.0.0:0 LISTEN 1 0 0xfffffffffff
fff9f
192.168.2.88:23 192.168.2.79:2197 ESTABLISHED 1 0 0xfffffffffff
fffa3
192.168.2.88:23 192.168.2.89:2710 ESTABLISHED 1 0 0xfffffffffff
fffa2
192.168.2.88:23 192.168.2.110:50199 ESTABLISHED 1 0 0xfffffffffff
fff
Configuration files
#
tcp syn-cookie enable
#

12
Related documentation
•H3C S7500E-X Switch Series Layer 2—LAN Switching Configuration Guide-Release 7168
•H3C S7500E-X Switch Series Layer 2—LAN Switching Command Reference-Release 7168
•H3C S7500E-X Switch Series Layer 3—IP Services Configuration Guide-Release 7168
•H3C S7500E-X Switch Series Layer 3—IP Services Command Reference-Release 7168
•H3C S7500E-X Switch Series Security Configuration Guide-Release 7168
•H3C S7500E-X Switch Series Security Command Reference-Release 7168
