HADEF 53/07A Assembly instructions

5.52.187.00.01.09
Rev.09
HADEF Ratchet Lever Hoist
Type 53/07 + 53/07A
Installation,- Operating and
Maintenance Instructions

2
5.52.187.00.01.09
NOTICE!
The installation or mounting instructions for incomplete machines you’ll find in chapter “Installation”
o

by Heinrich de Fries GmbH
Heinrich de Fries GmbH, Gauss Str. 20, D-40235 Düsseldorf
Heinrich De Fries GmbH will be named HADEF in the following text.
Original operating- and maintenance instructions in German language.
Translation in other languages is made of the German original.
A copy may be requested in writing or is available for download on www.hadef.com
Subject to changes.
Table of Contents
1Information.........................................................................................3
2Safety .................................................................................................3
2.1 Warning notice and symbols..........................................................................................3
2.2 Duty of care of the owner................................................................................................4
2.3 Requirements for the operating personnel....................................................................4
2.4 Appropriate use...............................................................................................................5
2.5 Basic safety measures....................................................................................................5
3Transport and Storage......................................................................7
3.1 Transport..........................................................................................................................7
3.2 Safety device for transport..............................................................................................7
3.3 Storage.............................................................................................................................7
4Description.........................................................................................7
4.1 Areas of application.........................................................................................................7
4.2 Design ..............................................................................................................................7
4.3 Functions .........................................................................................................................8
4.4 Important components....................................................................................................8
5Technical data ...................................................................................8
5.1 Main dimensions..............................................................................................................9
6Installation .........................................................................................9
7Operation ...........................................................................................9
7.1 Devices from 250 kg up to 3000 kg capacity (Type A) ..................................................9
7.2 Devices from 800 kg up to 9000 kg...............................................................................10
7.3 Brake and pawl ..............................................................................................................11
8Commissioning ...............................................................................11
8.1 General...........................................................................................................................11
8.2 Load chain......................................................................................................................12
9Safety check ....................................................................................12
10 Maintenance.....................................................................................12
10.1 General...........................................................................................................................12
10.2 Monitoring......................................................................................................................12
10.3 Replacing the load chain...............................................................................................12

5.52.187.00.01.09
3
11 Inspection........................................................................................ 13
11.1 Periodic checks .............................................................................................................13
11.2 Checking the load chain................................................................................................13
11.3 Checking the load hook ................................................................................................14
11.4 Checking - pawl .............................................................................................................14
11.5 Checking – Brake System.............................................................................................15
11.6 Checking – Suspension and load hook bolt................................................................15
12 Service .............................................................................................15
12.1 Load chain......................................................................................................................15
12.2 Pulleys............................................................................................................................16
12.3 Load hook ......................................................................................................................16
12.4 Gear................................................................................................................................16
12.5 Gear spring pressure brake..........................................................................................16
12.6 Lubricant - Selection.....................................................................................................17
12.7 Lubricant for food industry – Selection (as option*)...................................................17
13 Trouble............................................................................................. 17
14 Remedy............................................................................................ 18
15 Decommissioning ...........................................................................18
15.1 Temporary decommissioning.......................................................................................18
15.2 Final decommissioning/disposal..................................................................................18
16 Documents available on request....................................................19
1 Information
The products meet European Union requirements, in particular the valided EU Machine Directive.
The entire company works acc. to a certified quality assurance system as per ISO 9001.
The production of components at our work is subject to strict, intermediate checks.
After assembly, each product is subject to a final test with overload.
For the operation of hoists, the national accident prevention regulations apply in Germany, amongst others.
The stated performance of the devices and meeting any warranty claims require adherence to all instructions
in this manual.
Before delivery, all products are packed properly. Check the goods after receipt for any damage caused
during transport. Report any damage immediately to the forwarding agent.
This manual allows a safe and efficiently use of equipment. Images of this manual are for a principle
understanding and can be different from the real design.
NOTICE!
We refer to the prescribed equipment tests before initial start-up, before putting back into operation and the
regular periodic inspections.
In other countries any additional national regulations must be observed.
2 Safety
2.1 Warning notice and symbols
Warnings and notice are shown as follows in these instructions:
DANGER!
This means that there is a high risk that leads, if it is not avoided, to death or severe injury.
WARNING!
This means that there is a risk that could lead, if it is not avoided, to death or severe injury.
CAUTION!
This means that there is little risk that could lead, if it is not avoided, to slight injury or damage to the device or its
surrounding.

4
5.52.187.00.01.09
NOTICE!
Gives advice for use and other useful information.
Danger from electricity.
Danger from explosive area.
2.2 Duty of care of the owner
DANGER!
Failure to follow the instructions of this manual can lead to unpredictable hazards.
For any resulting damage or personal injury, HADEF assumes no liability.
The unit was designed and built following a risk analysis and careful selection of the harmonized standards
that are to be complied with, as well as other technical specifications. It therefore represents state-of-the-art
technology and provides the highest degree of safety.
Our delivery includes the hoist supplied beginning at its suspension and ending at the load hook and if
supplied with control, the control line/hose that leads to the hoist. Further operating material, tools, load
attaching devices as well as main energy supply lines must be assembled according to the valid rules and
regulations. For explosion-proof equipment, all these parts must be approved for use in area prone to
explosion, or they must be suitable for use in area prone to explosion. The owner is responsible for this.
However, in everyday operation this degree of safety can only be achieved if all measures required are
taken. It falls within the duty of care of the owner/user of the devices to plan these measures and to check
that they are being complied with.
Complete the operating and installation instructions by any instructions (regarding supervision or
notifications)that are important for the special kind of use of the equipment, i.e. regarding organization of
work, work flow and human resources.
In particular, the owner/user must ensure that:
The unit is only used appropriately.
The device is only operated in a fault-free, fully functional condition, and the safety components, in
particular, are checked regularly to ensure that it is functioning properly.
The required personal protective equipment for the operators, service and repair personnel is available
and is used.
The operating instructions are always available at the location where the equipment is used and that they
are legible and complete.
The unit is only operated, serviced and repaired by qualified and authorized personnel.
This personnel is regularly trained in all applicable matters regarding safety at work and environmental
protection, and that they are familiar with the operating manual and, in particular, the safety instructions it
contains.
Any safety and warning signs on the devices are not removed and remain legible.
Devices for use in area prone to explosion must (from customer's side) be earthed with a shunting
resistor of < 106Ω against earth.
WARNING!
It is not allowed to make constructive changes of the equipment!
2.3 Requirements for the operating personnel
The units may only be operated by qualified persons that are appropriately trained and that are familiar with
it. They must have their employer’s authorization for operation of the units.
Before starting work, the operating personnel must have read the operating and installation instructions,
especially the chapter "Safety Instructions".
This is especially important for operating personnel that rarely uses the equipment, i.e. for installation or
maintenance work.

5.52.187.00.01.09
5
DANGER!
In order to avoid severe injury, please pay attention to the following when using the equipment:
Use protective clothes/equipment.
Do not wear long hair hanging down open.
Do not wear rings or other jewelry.
Do not wear clothes that are too big/wide.
Do not reach into ropes, chains, drive parts or other moving parts with your hands
2.4 Appropriate use
The permitted safe working load of the devices must not be exceeded! An exception can be made during the
load test before initial operation, carried out by a licensed qualified person.
The permissible ambient temperature during operation of manual driven devices is -20 ° C / + 50 ° C and
at all power driven devices -20 ° C / + 40 ° C!
Defective devices and load suspension devices must not be used until they have been repaired! Only
original spare parts must be used. Non-compliance will result in any warranty claims becoming void.
Liability and warranty will become void if unauthorized modifications of the units are made by the user!
Vertical lifting, lowering, pulling and tightening of loads.
It must be assured that the unit can position itself in true alignment to the load.
DANGER!
Ratchet hoists with ship hook can be used for tightening!
Only ship hooks can be loaded on its point!
The ratchet hoist is "a unit ready for operation"acc. to the valid national regulations and obtails the
declaration of conformity CE.
NOTICE!
If the units are not used appropriately, it is not possible to ensure safe operation.
The owner and operator have sole liability for all personal injury and damage to property arising from
inappropriate use.
DANGER!
It is not allowed:
Pulling loose of stuck loads, dragging of loads and inclined pulling is not allowed.
The use in area at risk from explosion.
In reactor containment vessels.
To transport people with the equipment.
The device is not suitable for use on stages and in studios!
Persons must not stand under a suspended load.
Motor drive of the equipment.
Blocking of the loose chain end.
Charging the loose chain end.
Dragging of loads with motor-driven hoists.
2.5 Basic safety measures
Observe installation-, operation and maintenance instruction.
Take notice of caution notes at units and in the manual
Observe safety distances.
Take care for a free view on the load.
Only use the hoists appropriately.

6
5.52.187.00.01.09
The equipment is to be used exclusively for movement of goods. Under no circumstances my persons be
moved.
Never load the devices beyond their working load limit.
Pay attention to the accident prevention regulations (UVV).
Should the hoist be used outside of Germany, please pay attention to the national regulations that apply.
Supporting structures and load-attached devices used in conjunction with this equipment must provide an
adequate safety factor to handle the rated load plus the weight of the equipment. In case of doubt, consult
a structural engineer.
If the equipment has not been used for a period of time, carry out visual checks of all main components
such as chains, load hooks etc. and replace any damaged parts with new, original spare parts before
putting the equipment back into operation!
Do not use a hoist that is defective, pay attention to any abnormal noise it makes during operation.
Stop working immediately in case of disturbances and remedy failures.
Any damage and faults must be reported to a responsible supervisor immediately.
If the unit is put into motion, any persons in the immediate vicinity must be informed by calling to them!
Please pay attention to the regulations for load carrying devices UVV for both positive and non-positive
methods of attaching loads.
The lifting tackle or the load must be securely attached to the hook and be seated at the bottom of the
hook.
The safety catch of hooks must be closed.
When charged, the housing may not be in contact somewhere.
Stop lowering the load when the bottom block or the load is being set down or is prevented from being
lowered further.

The load chain must not be twisted.
Twisted chains must be aligned before attaching the load.
The correct alignment of the chain links can be seen from the weld seams.
The chain links must always be aligned in one direction.
Don't bump against something with load or hook
Illustration 1
We recommend a unit with sliding clutch to prevent overload, when the unit is used for tightening,
Motor drive is prohibited.
WARNING!
The following is not allowed:
to lift another load than the nominal safe working load
to manipulate the sliding clutch
The use of elongated or damaged chains. Replace worn out chains immediately by new, original chains.
Never loop the load chain around a load nor place or pull the chain over edges.
Never repair damaged load hooks (e.g. by hammering). They must be replaced by original hooks.
Do not operate the hoist by stepping on the lever with a foot.
Never use an elongation piece for the lever.
It is prohibited to charge the load hook at its point. (Only allowed for hoists with shipyard hook)
It is prohibited to weld or cut when a load is suspended.
It is prohibited to swing the load.
It is prohibited to use the load chain for earthing during welding.
Do not use the hoist when it makes abnormal noise.
Do not use the lever without rubber handle.
Do not leave a lifted load unintended for a longer period of time.

5.52.187.00.01.09
7
3 Transport and Storage
CAUTION!
Transport may only be done by qualified personnel. No liability for any damage resulting from improper
transport or improper storage.
3.1 Transport
The devices are checked and if so adequately packed before delivery.
Do not throw or drop the equipment.
Use adequate means of transport.
Transport and means of transport must be suitable for the local conditions.
3.2 Safety device for transport
NOTICE!
Should a safety device for transport exist, please remove it before commissioning.
3.3 Storage
Store the equipment at a clean and dry place.
Protect the equipment against dirt, humidity and damage by an appropriate cover.
Protect hooks, wire ropes, chains and brakes against corrosion.
4 Description
4.1 Areas of application
The devices must be as far as possible installed in a covered room.
If they are used in the open, protect the units against the effects of weather such as rain, hail, snow, direct
sunshine, dust, etc. - we recommend to use a cover in parking position. If the device is set up in a
continuously humid environment with strong temperature fluctuations, the correct functionings are
endangered by the forming of condensation.
Ambient temperature -20°C up to +50°C. Power-operated units -20 up to +40°C. Humidity 100 % or less but
not under water
DANGER!
It is not permitted to use the unit in an area at risk from explosion!
4.2 Design
HADEF ratchet lever hoists are compact hoists
with suspension hook for stationary use.
Illustration 2

8
5.52.187.00.01.09
4.3 Functions
The load is lifted, lowered or tensioned by operating the lever. The load pressure brake prevents automatic
lowering of the load.
NOTICE!
If used "overhead" or "lashing" undefined forces may appear. We recommend to use a hoist with
slipping clutch for these cases.
NOTICE!
The best protection against functional failures in case of extreme environmental impact is the regular use of
the equipment.
4.4 Important components
Gear
Gear components are made of high-quality material.
Load pressure brake
Holds the load in any position.
A new brake system is used for the hoists (except
for the Aluminium Ratchet Lever Hoists). Brake
discs have sintered brake linings which are
designed for the lifetime of the devices when used
as intended.
According to DIN 13157 lifetime is 1500 operating
cycles (lifting/lowering movements) with 300 mm
lift with nominal load.
Illustration 3
Housing
Depending on the model made from steel plate or aluminium.
Load chain
According to EN 818-7-T high quality chain. All components match precisely to each other. Therefore please
only use original chains.
Load hook with safety catch
Forged steel. Rotating, this facilitates attaching the load and avoids twisting of the chain.
Ship hook with safety catch – as option
Ratchet Lever Hoists of capacity 1600 kg and 3200 kg can be fitted with ship hook - as option
The hook tip may only be loaded for tightening.
For lift and lower use, the load must lie on
on the hook base and the hook safety catch
must be closed.
Bild 4
DANGER!
In hazardous area, the load on the hook tip is prohibited!
Free-wheeling of chain
For pulling through of the uncharged chain.
5 Technical data
Capacity kg 250 500 750 1500 3000 800 1000 1600 2500 3200 6300 9000
Type A A A A A - - - - - - -
with shipyard hook as opion - - - - - - - S - S - -
Number of chain falls 1 1 1 1 2 1 1 1 1 1 2 3
Load chain dimensions
mm
3x9
4,2x12,2
5x15
7,1x20,1
7,1x20,1
5,6x15,8
5,6x15,8
7,1x20,1
9,0x24,8
10x28,1
10x28,1
10x28,1
low headroom dimension
mm
200
250
260
330
432
280
300
335
375
395
540
680
lever force approx.
N
200
240
290
320
335
290
360
340
370
370
380
390
weight* approx.
kg
1,5
2,5
3,4
5,9
11
5,7
5,9
8,0
11,2
15,0
26,0
40,0
weight per add. m lift approx.
kg
0,2
0,4
0,6
1,1
2,2
0,7
0,7
1,1
1,7
2,3
4,7
7,0

5.52.187.00.01.09
9
5.1 Main dimensions
Capacity in kg
Dimensions
mm
250 500 750 1500 3000 800 1000 1600 2500 3200 6300 9000
Typ
A
A
A
A
A
-
-
-
-
-
-
-
A
76
81
92
109
160
119
119
126
150
159
217
304
B
87
100,5
105
122
122
144
144
159
173
190
190
190
C
32
34,5
35,5
42,5
50
35,5
42,5
42,5
47
50
60
85
D
140
180
180
220
220
245
245
265
265
415
415
415
E
55,5
62,5
64
68,5
68,5
97
97
100
102
112
112
112
F
11
12
14
21,5
24,5
14
15
19
21
24,5
34
41,5
G
21
24,5
28,5
35
43
26,5
29
32
36,5
39
50
72,5
H
200
250
260
330
432
280
300
335
375
395
540
680
Illustration 5
6 Installation
Please observe the following points in order to avoid any damage to equipment or injury of person:
Please read chapter "Safety".
Before loading the hoist make sure the hooks are placed safely. The safety catch of the hook must be
closed.
Make sure that the fastening position cannot be changed either by the load nor by other influences.
7 Operation
Only people that are familiar with the operation of the lifting devices and cranes may be entrusted with their
operation. They must be authorized by the employer for the operation of the equipment. The employer must
ensure that the operating instructions are available near the equipment and that they are accessible for the
operating personnel.
7.1 Devices from 250 kg up to 3000 kg capacity (Type A)
Before start up please make sure the free-wheeling mechanism is deactivated.
Forcible pulling may possibly close the brake and stop the chain. Should this be the case place the switching
pin in position "DN", do some lowering operation movements and begin lifting again.
Lifting or pulling
Turn the switching pin in position "UP" for lifting or
pulling and move the load by opera
ting the hand
lever.
Lowering or relieving
Turn the switching pin in position "DN", lowering
or relieving and move the load by operating the
hand lever.
A Chain pin
B Switching pin
C Lever
Illustration 6
7.1.1 Free-wheeling of chain
DANGER!
Never activate the free-wheeling mechanism if the hoist is under charge.
Switching ON the free-wheeling mechanism
switch in middle position
Illustration 7

10
5.52.187.00.01.09
Turn the free-wheeling mechanism anti-
clockwise, if necessary pull the loose fall of the
chain jerkily.
The chain can be pulled through in both
directions.
Illustration 8
Switching OFF the free-wheeling mechanism
Turn the free-wheeling mechanism clockwise,
if necessary pull the chain fall jerkily.
Free-wheeling mechanism is switched OFF.
The chain cannot be pulled through any longer
and working operation can be proceeded.
Illustration 9
7.2 Devices from 800 kg up to 9000 kg
Before start up please make sure the free-wheeling mechanism is deactivated.
Forcible pulling may possibly close the brake and stop the chain. Should this be the case place the switching
pin in position "▼", do some lowering operation movements and begin lifting again.
Lifting or pulling
Turn the switching pin in position (1) lifting or
pulling as marked on the type plate and move the
load by operating the hand lever.
Lowering or relieving
Turn the switching pin in
position (2) lowering or
relieving and move the load by operating the hand
lever.
Illustration 10
7.2.1 Free-wheeling of chain
When the unit is used appropriately, unintended activation of the free-wheeling mechanism under load is
impossible. Opening of the brake system with only small load is possible, this is no mistake.
DANGER!
Never activate the free-wheeling mechanism if the hoist is under charge.
Switching ON the free-wheeling mechanism
Place the switch knob in middle position.
Illustration 11
Pull the free-wheeling wheel upwards in
direction ▲ .

The chain can be pulled through in both
directions.
A free-wheeling OFF
B free-wheeling switched ON
Illustration 12
