Hama 00 220844 User manual
00
220844
TV WALL BRACKET
GOperating Instructions
Contents
1. Explanation of warning symbols and notes ..........................3
2. Package contents.............................................4
3. Additionally required tools ......................................4
4. Safety instructions ............................................5
5. Application and specifications ...................................5
6. Preparation and assembly ......................................6
6.1 Mounting on the wall.........................................7
6.1.1 Preparing the intended mounting surface ........................7
6.1.2 Attaching the wall bracket....................................8
6.2 Mounting on the TV set .......................................8
6.2.1 Mount the VESA arms on the back of the TV set....................9
6.3 Mounting the TV on the wall bracket ............................10
7. Adjustment & maintenance ....................................11
8. Setting options..............................................11
9. Technical data ..............................................12
10. Warranty disclaimer .........................................13
11. Service and support .........................................13
12. Warranty conditions .........................................13
GOperating Instructions
Thank you for choosing aHama product.
Take your time and read the following instructions and information completely. Please keep these instructions
in a safe place for future reference. If you sell the device, pass on the illustrated quick start guide and the safety
instructions in printed form to the new owner.
1. Explanation of warning symbols and notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic hazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package contents
•TV wall bracket
•VESA arms
•Spirit level
•Mounting kit
•Safety instructions, illustrated quick start guide
Mounting kit
A1 8x60 (x8) C2 M6x20(x4)
A2 Ø10x60 (x8) D1 M8x12 (x4)
A3 M8 (x8) D2 M8x20(x4)
B1 M6 (x4) D3 M8x30(x4)
B2 Ø8x10 (x4) D4 M8x50(x4)
B3 Ø8x20(x4) E1 (x1)
C1 M6x12 (x4)
* M8x50 + Ø 8x5 = M8x45
Note
Please check the mounting kit for completeness before installing the bracket andensure that thereareno
faulty or damaged parts.
3. Additionally required tools
10 mm 13
Note
Never install the bracket alone. Seek assistance and help!
4. Safety instructions
Warning
•Given the multitude of terminal devices and wall structures available on the market, the supplied mounting
kit is unable to cover every option.
•It occasionally happens that the screws for attaching the device to the bracket aretoo long.
•Please note that the supplied wall plugs are for use with solid, hollow and board construction materials
only.
•Read the operating instructions for your terminal device before attempting to mount it. The instructions
provide information about the type and measurements of suitable fastening materials.
•If the supplied mounting kit does not contain suitable fastening materials for mounting the terminal device,
purchase these from a specialised dealer.
•Never apply force during assembly. This can damage your device or the holder.
•If in doubt, have this product installed by aqualied technician - do not attempt to installit yourself!
•Do not mount the product above locations where persons might sit or stand.
•Once you have mounted the product and the attached load, check thatthey aresuciently secure and safe
to use.
•You should repeat this check at regular intervals (at least every three months).
•Ensure that the productdoes not exceed its maximum permitted carrying capacity and thatno load exceeding
the maximum permitted dimensions is attached.
•Make sure that the product is loaded symmetrically.
•Maintain the necessary safety clearance around the attached load (depending on the model).
•In the event of damage to the product, remove the attached load and stop using the product.
•Do not attach any additional objects to the product.
5. Application and specifications
•The bracket is used for mounting at screens in private, non-commercial households.
•The bracket is intended only for use inside buildings.
•Use the bracket only for the intended purpose.
6. Preparation and assembly
Note
•Never install the bracket alone. Seek assistance and help!
•Different end devices have different connections for cabling and otherdevices. Before commencing the
installation, check whether the necessary connections can stillbe reached aftermounting.
•Depending on the product and mounting method, you may not need allparts of the mounting kit. It is
therefore possible that unneeded screws and other small parts will be left overeven aftercorrect mounting.
Keep these in a safe place together with these operating instructions foruse for later reference (sale of the
product, moving house, relocation of the bracket, new TV, etc.).
Warning
•Be aware that the brackets are only suitable for wall mounting.
•Before installation, check that the wall you have chosen is suitable for the weight to be mounted. Also
make sure that there are no electric, water, gas or other lines running through the wall at the mounting
site.
Note - Fischer plugs
The Fischer plugs supplied are approved for the following building materials:
•Concrete
•Plasterboard and gypsum breboard
•Vertical perforated brick
•Lightweight concrete hollow block
•Hollow brick and concrete ceilings
•Perforated sand-lime brick
•Solid sand-lime brick
•Natural stone
•Aerated concrete
•Chipboard
•Solid plaster boards
•Lightweight concrete solid block
•Solid brick
6.1 Mounting on the wall
6.1.1 Preparing the intended mounting surface
Get support and help from other people for the following assemblysteps.
10 mm
70mm
Ø10mm
•First use the bracket as a template and re-measure if necessary to ensure thatthe position is correct. Use a
spirit level to check the horizontal and vertical alignment of the bracket on the wall.Now mark the holes on
the wall.
•To attach the wall bracket to the wall, you need a drill and a drilling attachment with a diameter of 10mm.
Make sure that the drilling attachment is suitable for the intended wall. Thedepth of the hole should be 70
mm .
•To ensure a secure hold, vacuum out the drill holes with a vacuum nozzle so that the drillhole is free of drill
dust. Now insert the plug [A2] into the drill hole so that it is ush with the hole.
6.1.2 Attaching the wall bracket
13
E1
A2
A3 A1
E1
•Attach the wall bracket to the wall as shown above using the enclosed mounting material ([A2] plug, [A3] M8
washer, [A1] 8x60 mm screw and the [E1] spirit level).
6.2 Mounting on the TV set
Note
•Given the multitude of terminal devices structures available on the market, we cannot describe all possible
mounting options here.
•Please ensure that the bracket lays at and evenly on the back of the television.
•Use the enclosed spacer to even out any unevenness on the back of the television.
•Ensure that all screws have the proper length and can be mounted until they are hand-tight.
6.3 Mounting the TV on the wall bracket
Get support and help from other people for the following assemblystep.
Wall
•Hang the TV set with the mounted VESA arms on the wall bracket as shown above.
-12°/+5°
Wall
•To adjust the tilt angle, open the fastening screws at the side, set the required tilt, and then secure the screws
in place again.
•Hang the TV set with the mounted VESA arms on the wall bracket as shown above untilit audibly engages.
•The ends of the securing cords can be fastened at the back to the wallbracket using the magnets.
7. Adjustment& maintenance
Note
Never adjust the bracket alone. Seek assistance and help!
Note - tiltable / full-motion brackets
•Ensure that no electrical cables are crushed or damaged during installation or adjustment.
•During adjustment, ensure that the product is loaded symmetrically and that the maximum permitted carrying
capacity is not exceeded.
•Check the strength and operational safety of the bracket and the load attached to it at regular intervals (at
least quarterly).
•Clean only with water or conventional household cleaners.
8. Setting options
-12°/+5°
Tilting
•To adjust the tilt angle, open the fastening screws at the side, set the required tilt, and then secure the screws
in place again.
9. Technical data
Maximum load: 100 kg
Screen diagonal:
94.0 - 304.8 cm (US: 37" - 120")
Depth: 2.8 cm
Tilt: -12°/+5° (depending on device)
Dimensions of the wall mounting plate: 20.2 x 115.6 cm
Mount:
Compliant with VESA standard:
50 x 50
75 x 75
75 x 100
100 x 100
200 x 100
200 x 200
200 x 300
300 x 100
300 x 200
300 x 300
300 x 400
400 x 200
400 x 300
400 x 400
500 x 400
600 x 200
600 x 300
600 x 400
700 x 400
800 x 200
800 x 400
800 x 600
900 x 200
900 x 300
900 x 400
900 x 600
1000 x 200
1000 x 300
1000 x 400
1000 x 600
1100 x 200
1100 x 300
1100 x 400
1100 x 600
10. Warranty disclaimer
Hama GmbH & Co KG assumes no liability and provides no warranty for damage resulting from improper
installation/mounting, improper use of the product or from failure to observe the operating instructions and/or
safety notes.
11. Service and support
Please contact Hama Product Consulting if you have any questions about this product.
Hotline: +49 9091 502-0 (German/English)
Further support information canbe found here: www.hama.com
12. Warranty conditions
For this product, HAMA GmbH&CoKG grants you an extended manufacturer's warranty for freedom from
defects, usability, workmanship and the durability of the materials used foraperiod of 10 years. Excluded from
the guarantee is the compatibility of the product with future standards of further developed hardware.
Within the specied period, Hama GmbH & Co KG will remedy a justied warranty claim at its own discretion,
free of charge, either by repair or replacement.
The warranty period begins on the date of purchase of this product andis valid throughout the EU.
The warranty granted is in addition to and does not affect your statutoryrights. Damage caused by improper
use, normal wear and tear, exposure to chemicals or force majeure, as well as tampering or repairs by you or
third parties, are excluded from the warranty.
Furthermore, accessories that are not part of the basic equipment of the product (promotional parts) are
excluded from the warranty.
In the event of a warranty claim, please contact us at Hama GmbH & Co KG, DresdnerStr. 9, 86653 Monheim,
Germany, enclosing proof of purchase. Youare also welcome to contact us at www.hama.de or by phone on
+49 (0)9091/502-0.
