Hamilton Beach Big Mouth Duo Plus User manual

Big Mouth™ Duo Plus
Food Processor
READ BEFORE USE
Visit www.hamiltonbeach.co.il for our
complete line of products and Use and
Care Guides – as well as delicious recipes,
tips, and to register your product online
70583-IS

IMPORTANT SAFEGUARDS
1. Read all instructions.
2. This appliance is not intended for use by persons with
reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they are closely supervised
and instructed concerning use of the appliance by a person
responsible for their safety.
3. This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
4. Close supervision is necessary when any appliance is used
near children. Children should be supervised to ensure that
they do not play with the appliance.
5. To protect against risk of electric shock, do not immerse base,
motor, cord, or plug in water or other liquid.
6. Turn the appliance OFF( ), then unplug from outlet when
not in use, before putting on or taking off parts, and before
cleaning. To unplug, grasp the plug and pull from the outlet.
Never pull from the power cord.
7. Avoid contacting moving parts. Keep fingers out of feed chute.
8. Do not operate any appliance with a damaged supply cord or
plug, or after the appliance malfunctions or has been dropped
or damaged in any manner. Supply cord replacement and
repairs must be conducted by the manufacturer, its service
agent, or similarly qualified persons in order to avoid a hazard.
Call the provided customer service number for information on
examination, repair, or adjustment.
9. The use of attachments not recommended or sold by the
appliance manufacturer may cause fire, electric shock, or
injury.
10. Do not use your food processor if any part is broken.
11. Do not use appliance outdoors.
12. Do not let cord hang over edge of table or counter or touch hot
surfaces, including stove
13. Keep hands and utensils away from moving blade and disc
while processing food to reduce the risk of severe personal
injury and/or damage to the food processor. A rubber scraper
may be used but ONLY when the food processor is not
running.
14. Blades are sharp. Handle cutting blades carefully when inserting
or removing, emptying the bowl, and during cleaning. Store out
of reach of children.
15. To reduce the risk of injury, never place cutting blade or disc
on base without first putting bowl properly in place.
16. Be certain lid is securely locked in place before operating
appliance.
17. Never feed food into food chute by hand. Always use the food
pushers.
18. Do not attempt to defeat the lid interlock mechanism.
19. Make sure the blade or disc has come to a full stop before
removing lid.
20. To reduce the risk of injury, be sure to insert or remove blade
and disc using hubs provided for this purpose. Use caution
when removing blade and disc from the bowl, when emptying
the bowl, and when cleaning.
21. Be sure to turn OFF ( ) after each use. Always use the pushers
to clear the food chute. When this method is not possible,
unplug cord from outlet and disassemble unit to remove the
remaining food.
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to
persons, including the following:

SAVE THESE INSTRUCTIONS
OTHER CONSUMER SAFETY INFORMATION
This product is intended for household use only.
WARNING Shock Hazard: This appliance has a polarized plug
(one wide blade) that reduces the risk of electric shock. The plug
fits only one way into a polarized outlet. Do not defeat the safety
purpose of the plug by modifying the plug in any way or by using
an adapter. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, have an electrician replace the outlet.
The length of the cord used on this appliance was selected to
reduce the hazards of becoming tangled in or tripping over a
longer cord. If a longer cord is necessary, an approved extension
cord may be used. The electrical rating of the extension cord must
be equal to or greater than the rating of the appliance. Care must
be taken to arrange the extension cord so that it will not drape over
the countertop or tabletop where it can be pulled on by children or
accidentally tripped over.
To avoid an electrical circuit overload, do not use another high-
wattage appliance on the same circuit with this appliance.
22. The appliance is not intended for commercial, professional,
or industrial use. It is designed and built exclusively for
household use only.
23. Never use appliance for a longer period or with a larger
amount of ingredients other than that recommended by
appliance
manufacturer. See section titled “Processing Charts.”
24. The maximum rating of this unit is based on using the
chopping/ mixing blade. Using the slicing/shredding disc may
draw significantly less power.
25. Do not place on or near a hot gas or electric burner, or in a
heated oven.
26. Do not use appliance for other than intended use.
27. Check that the appliance is OFF ( ) before plugging cord into
wall outlet. To disconnect, turn the control to OFF ( ); then
remove plug from wall outlet. To unplug, grasp the plug and
pull from the outlet. Never pull from the power cord.
28. CAUTION! In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on and off
by the utility.
29. Be careful if hot liquid is poured into the food processor bowl
as it can be ejected out of the appliance due to a sudden
steaming.
30. Do not fill the bowl above the marked maximum fill line (or
rated capacity) to avoid risk of injury due to damage to the
cover or bowl.

Mixing Plastic Blade
Use to mix, or puree food.
Parts and Features
Lid
Control
Panel
Reversible Slicing/Shredding Disc
Use to shred cheese or to slice or shred
a variety of foods (such as potatoes,
pepperoni, carrots, celery).
French Fried Blade Disk
Use to shred potatoes
for french fries
Chopping/Mixing Blade
Use to coarsely chop, mince,
mix, or puree food.
Food
Chute
Motor
Shaft
BEFORE FIRST USE: Unpack processor. Handle blade and disc(s)
carefully; they are very sharp. Wash all parts except base in hot,
soapy water. Rinse; then dry.
Large
Bowl
Small
Bowl
Large Food
Pusher
Cord Stuff Storage
(located on back of base)
Small
Food
Pusher
Reversible Fine-Shred/Crinkle-
Cut Disc
Usetofinelyshredorcrinkle-cutavariety
of foods. Finely shred cheese, cabbage,
zucchini, or onions. Crinkle-cut carrots,
cucumbers, beets, radishes, or peppers.
Special Blade Disk

How to Use Chopping/Mixing Blade
123
Align bowl and base. Turn bowl
clockwise to lock into place.
NOTE: Unit will not work unless
bowl is locked.
Carefully place blade onto motor
shaft.
4
Align lid and bowl. Turn lid
clockwise to lock into place.
NOTE: Unit will not work unless lid
is locked.
5 6
WARNING
Laceration Hazard.
Handle blade carefully; it is very
sharp.
Make sure control button is OFF
() and unit is unplugged.
NOTE: Operate using only one
blade or disc at a time.
Place large food pusher with small food pusher in
food chute. Always use food pusher to feed food
into the chute. NEVER PUSH FOOD THROUGH
CHUTE WITH FINGERS OR OTHER OBJECTS.
7
Push the desired speed button:
LO, HI, or PULSE (P).

8 9 10
wWARNING Laceration Hazard:
Always wait until blade has
stopped moving before
removing lid.
Turn lid counterclockwise to
unlock lid.
11
Carefully remove blade from
motor shaft.
12 13
When finished, press the OFF ( )
button .
How to Use Chopping/Mixing Blade (cont.)

123
How to Use Slicing/Shredding Disc and Optional
Reversible Fine-Shred/Crinkle-Cut Disc
Put large food pusher into place.
Place food into open tube of
large food pusher.
Push small, thin food with small
food pusher. NEVER PUSH
FOOD THROUGH CHUTE WITH
FINGERS OR OTHER OBJECTS.
LARGER FOODS
For larger foods: Push large foods using large and small food pushers together. NOTE:
Unit will not operate until large food pusher engages the protective interlock. Do not
add food above the MAX fill line.
WARNING
LACERATION HAZARD: ALWAYS USE
FOOD PUSHER TO FEED FOOD INTO THE CHUTE. NEVER PUSH FOOD THROUGH CHUTE
WITH HANDS OR OTHER OBJECTS.
SMALLER, THINNER FOODS
4A SMALLER, THINNER FOODS LARGER FOODS
4B
OR
WARNING
Laceration Hazard.
Handle blade carefully; it is very
sharp.
Make sure control button is OFF
() and unit is unplugged.
NOTE: Operate using only one
blade or disc at a time.
Align large bowl and base. Turn large bowl clockwise to lock into place. NOTE: Unit will not work unless
large bowl is locked. Carefully place slicing/shredding disc or optional fine-shred/crinkle-cut disc onto
motor shaft with desired side facing UP. (“SLICE” or “SHRED” is stamped on each side of the blade.) Align
lid and large bowl. Turn lid clockwise to lock into place. NOTE: Unit will not work unless lid is locked.

8
wWARNING Laceration Hazard:
Always wait until blade has
stopped moving before
removing lid.
67
9 10
Turn lid counterclockwise to
unlock lid. Carefully remove blade from
motor shaft.
11 12
5
Push the desired speed button: LO or HI. NOTE: LO is recommended
for most foods when using the slicing/shredding disc or fine-shred/
crinkle-cut disc. When finished, press the OFF () button .
How to Use Slicing/Shredding Disc and Optional
Reversible Fine-Shred/Crinkle-Cut Disc (cont.)

Tips and Techniques
• For a more uniform consistency,
start with pieces of food that
are similar in size. Cut food into
1-inch (2.5 cm) pieces before
processing with chopping/
mixing blade.
• This food processor is
excellent to chop, mix, slice,
or shred most foods. However,
to maintain peak performance,
do not use your food processor
for the following: grinding grain,
coffee beans, or spices; slicing
frozen meats; kneading dough;
or crushing ice.
• When chopping foods, pulsing
on and off will produce the best
results.
• Operating time will depend
on quantity of food being pro-
cessed. Most foods can be
sliced, chopped, or shredded
in seconds. If unit is operated
continuously for an extended
period of time, let the processor
rest about 4 minutes before
continuing.
• Do not puree or mash starchy
vegetables like potatoes as they
are easily overprocessed and
will become gummy.
• To slice or shred cheese, use
only firm cheese like cheddar,
Monterey Jack, or Swiss that
has been chilled for at least 30
minutes.
•
The reversible slicing/shredding
disc and reversible fine-shred/
crinkle-cut disc have a slicing
blade on one side and shredding
teeth on the other and can only
be used with the large bowl. The
name engraved on the blade,
facing up, is the function
selected. For slicing, the word
“SLICE” should face up; for
shredding, the word “SHRED”
should face up. Place on motor
shaft with desired cutting edge
facing up.
• To julienne vegetables, slice,
remove from bowl, and restack
the vegetables. Pack into food
chute with slices vertical. Slice
again to make matchstick-cut
vegetables.
Processing Charts
Disc attachments are reversible and labeled. The label should face
up for the desired function. When using disc attachments, do not
process past the MAX LEVEL on the bowl.
For best results do not exceed the following amounts when
chopping, mincing, or pureeing with the chopping/mixing blade.
ATTACHMENT
Chopping/Mixing Blade
Slicing Disc or
Optional Crinkle-Cut Disc
(“SLICE” side facing UP)
Shredding Disc or
Optional Fine-Shred Disc
(“SHRED”side facing UP)
FOODS
Chop: Nuts, meat, garlic, onions, peppers,
celery, herbs, bread (for crumbs), crackers
Mince/Puree: Vegetables, fruit
Mix: Salad dressings
Puree: Soups, sauces
Grate: Cheese, such as Parmesan (chilled)
Cucumbers, apples, mushrooms, carrots,
potatoes, cabbage, tomatoes, pepperoni,
peppers, radishes, rm cheeses (chilled)
Cabbage,potatoes,carrots,cheese(chilled)
FOOD
Fruits and Vegetables
Meats
Parmesan or Romano
Cheddar,Jack,Mozzarella
Crackers
MAXIMUM AMOUNT
2 to 3 cups (500 to 750 ml)
(cut into 1-in. [2.5-cm] cubes
2 lb. (900 g) (cut into 1-in. [2.5-cm] cubes)
5 ounces (140 g) (cut into 1-in. [2.5-cm] cubes)
8 ounces (226 g) (cut into 1-in. [2.5-cm] cubes)
Full bowl

Cleaning and Care
2
1
Wipe base, control panel, and
cord with a damp cloth or
sponge. If necessary, use a mild
nonabrasive cleanser.
wWARNING Electrical Shock Hazard.
Disconnect power before cleaning. Do not immerse cord,
plug, or base in any liquid.
DISHWASHER-SAFE (TOP RACK ONLY)
DO NOT use the “SANI” setting when washing in the dishwasher.
“SANI” cycle temperatures could damage your product. Removable
parts may also be washed by hand in hot, soapy water. Use care
when hand-washing sharp edges.

PROBLEM
Unit does not operate
on any speed or Pulse.
Food is not chopped,
sliced or shredded
uniformly.
Unit stops and will
not come back on.
Unit has a burning smell.
Motor seems weak.
It is difficult to remove lid
from bowl(s) or bowl(s) from
base.
PROBABLE CAUSE
• Is the unit plugged in? Does the outlet work?
• Are the bowl(s) and lid locked in place and large food pusher in food chute? See “How to Use” sections.
• Packing too much food in the food chute or pushing too hard on the food pusher may cause the
processed food to be irregulary sliced or shredded.
• Recommended speed for slicing and shredding disc should be LO for cheeses and LO or HI for
vegetables or fruit.
• Refer to the food processing charts for recommended sizes, speeds, and quantities.
• Are the bowl(s) and lid locked in place and large food pusher in food chute? They may have moved
slighty during processing. See “How to Use” sections.
• Is the outlet still working? Check it by plugging in a working lamp or other appliance. You may have
overloaded the circuit and blown a fuse or tripped the circuit breaker.
•
Turn unit OFF ( ), allow to stand for 3 to 4 minutes, and then turn back ON. If none of these suggestions
correct the problem, DO NOT attempt to repair the unit. Call the Customer Service number to get the
name of your nearest Authorized Service Center.
• There may be a residue left on the motor from the manufacturing process, causing a slight odor
during initial use. This will go away. If a strong odor or any visible smoke appears, unplug unit
IMMEDIATELY and call the Customer Service number.
• Are you using the recommended food size and quantity to be processed? Refer to the Food Processing
Charts for recommended food sizes and speeds.
• After washing in the dishwasher, allow parts to return to room temperature prior to placing on base.
A small amount of vegetable oil may be placed on snaps for easy removal.
Troubleshooting

13

14
18
ןוזמ דוביע תלבט
רזיבאןוזמ
לובריעו ךותיח בהל ,לצב ,םוש ,רשב ,םיזוגא :ץוציק
םחל ,לובית יבשע ,ירלס ,םילפלפ
.םירקרק ,)םירוריפ(
,םיבטר ,תוריפ ,תוקרי :תיחמל דוביע
.םיקרמ
ןזמרפ ןוגכ תוניבג :םירורפל דוביע
.)תננוצמ(
- הסירפ בצמב הסירגו הסירפ תקסד
.הלעמ יפלכ הנפומ ”SLICE“
,רזג ,תוירטפ ,ץע יחופת ,םינופפלמ
,ינורפפ ,תוינבגע ,בורכ ,המדא יחופת
תושק תוניבג ,תוינונצ ,םילפלפ
.)תוננוצמ
- הסירג בצמב הסירגו הסירפ תקסד
.הלעמ יפלכ הנפומ ”SHRED“
הניבג ,רזג ,המדא יחופת ,בורכ
.)תננוצמ(
:תואבה תויומכה תא רובעל ןיא ,תוילמיטפוא תואצותל
ןוזמתומכ
תוריפו תוקרי תוכיתחב )ל"מ 500-750( תוסוכ 2-3
.מ"ס 2.5 ןלדוגש
םירשב.מ"ס 2.5 ןלדוגש תוכיתחב םרג 900
ןזמרפ תניבג.מ"ס 2.5 ןלדוגש תוכיתחב םרג 140
הלרצומ וא רד'צ תניבג.מ"ס 2.5 ןלדוגש תוכיתחב םרג 225
םירקרק.לכמה אולמ

15
19
ןויקינו הקוזחת
 תויראש תורבטצה עונמל ידכ שומישה רמגב דיימ רישכמה תא תוקנל שי
.םתוא תוקנל רתוי השק היהיו ושקתיש
1. .למשחהמ קתנל שי
2. םילכ לזונ תפיט ףיסוהל ןתינ .החל תילטמב רישכמה ףוג תא בגנל שי
.השבי תילטמ םע בוש םירבוע רחאש יאנתב
 ןובסו םימח םימב ןוזמה םע עגמב םיאבה ןוזמה דבעמ יקלח לכ תא תוקנל שי
.חידמב וא םילכ
 וא םילכל הנטק תשרבמ םע תוניפב וא םיצירחב רבטצהש ךולכל תוקנל שי
.םייניש תשרבמ םע
.טלחומ שוביי לעו תידוסי הפיטש לע דיפקהל שי

16
19
ןויקינו הקוזחת
 תויראש תורבטצה עונמל ידכ שומישה רמגב דיימ רישכמה תא תוקנל שי
.םתוא תוקנל רתוי השק היהיו ושקתיש
1. .למשחהמ קתנל שי
2. םילכ לזונ תפיט ףיסוהל ןתינ .החל תילטמב רישכמה ףוג תא בגנל שי
.השבי תילטמ םע בוש םירבוע רחאש יאנתב
 ןובסו םימח םימב ןוזמה םע עגמב םיאבה ןוזמה דבעמ יקלח לכ תא תוקנל שי
.חידמב וא םילכ
 וא םילכל הנטק תשרבמ םע תוניפב וא םיצירחב רבטצהש ךולכל תוקנל שי
.םייניש תשרבמ םע
.טלחומ שוביי לעו תידוסי הפיטש לע דיפקהל שי

17
17
תובושח תוצע
2.5 לש דיחא לדוגב תוכיתחל ןוזמה תא ךותחל ץלמומ ,רתוי דיחא םקרמל
.מ"ס
 ךותיחל ,םינילבתו הפק ילופ ,האובת תניחטל ןוזמה דבעמב שמתשהל ןיא
.חרק קוסירל וא קצב ת ָי ִלל ,אופק רשב
.רתויב תובוטה תואצותה ולבקתי ״םיסלופ״ בצמב
 ול רשפאל שי ,םמחתהו תיסחי ךשוממ ןמז ךשמב לעפוה רישכמה םא
.הלעפה ךשמה ינפל תוקד 4-כ ךשמב ררקתהל
 םהש םושמ ,המדא יחופת ומכ םיינלימע תוקרי תיחמל דבעל ץלמומ אל
.הקיבד הסיעל תוריהמב ךופהל םילולע
.םדוק התוא ררקל שיו תיסחי השק הניבגב רוחבל ףידע ,הניבג ררופל ידכ
 ןתינ .ינש דצב הסירג בהלו דחא דצב הסירפ בהל שי הסירגו הסירפ תקסדל
רחאל הלעמ יפלכ הנופש תיבותכה יפל .לודגה לכמה םע קר וב שמתשהל
הסירפל ”SLICE“ :הז בצמב עצבמ אוהש הלועפה המ תעדל רשפא ,ותבכרה
.הסירגל ”SHRED“ וא
 .יוצרה ןוויכב הסירפ בצמב רישכמל םתוא סינכהל שי ,תוקרי ץוציקל

18
16
הסירגו הסירפ תקסדב שומיש
.הקסדה תא תוריהזב ואיצוה
בוביסב סיסבהמ לכמה תא וקרפ
.ןועשה ןוויכ דגנ

19
15
הסירגו הסירפ תקסדב שומיש
LO :םיאתמה רותפכה לע וצחל
תוריהמ - HI ,הכומנ תוריהמ -
בצמב הלעפה - PULSE ,ההובג
.״םיסלופ״
לע הציחלב ובכ ,שומישה םויסב
.OFF רותפכ
וקתנ ,ובכ ,הסכמה תחיתפ ינפל
הריצעל וניתמהו למשחהמ
!תטלחומ
דגנ ותוא ובבוס ,הסכמה תחיתפל
.ןועשה ןוויכ

20
14
הסירגו הסירפ תקסדב שומיש
ןוזמה תפיחדל ןטקה ןפחודב ורזעה
וא תועבצאב שמתשהל ןיא .המינפ
!םירחא םימצעב
הנזהה חתפ ךרד לודג ןוזמ וסינכה
.לודגה
ןוזמה תפיחדל לודגה ןפחודב ורזעה
וא תועבצאב שמתשהל ןיא .המינפ
!םירחא םימצעב
.למשחל רישכמה תא ורבח
