HAMPTON BAY 290-286 User manual

Lifetime Limited Warranty
Date Purchased
Store Purchased
Model No.
Serial No.
Vendor No.
UPC
290-286
219054
718212340219
Hampton Bay Lifetime Motor Warranty
The retailer warrants the fan motor to be free from defects in workmanship and material
present at time of shipment from the factory for a lifetime after the date of purchase by the
original purchaser. The retailer also warrants that all other fan parts, excluding any glass or
plexiglass parts, to be free fromdefects in workmanshipand material at the time of shipment
from the factory for a period of one year after the date of purchase by the original purchaser.
We agree to correct such defects withoutcharge or at our option replace with acomparable or
superior model ifthe product isreturned to the retailer. To obtain warranty service,you must
present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the
product are your responsibility. Damage to any part such as by accident or misuse or
improper installation or by affixing any accessories, is not covered by this warranty.
Because of varying climatic conditions in the United States this warranty does not cover any
changes in brass finish, including rusting, pitting, corroding, tarnishing or peeling. Brass
finishes of this type give their longest useful life when protected from varying weather
conditions. A certain amount of wobble is normal and should not be considered a defect.
Servicing performed by unauthorized persons shall render the warranty invalid. There is no
other express warranty. The retailer hereby disclaims any and all warranties, including
but not limited to. Those of merchantability and fitness for a particular purpose to the
extent permitted by law. The duration of any implied warranty which cannot be disclaimed
is limited to the time period as specified in the express warranty. Some states do not allow
limitation on how long an implied warranty lasts, so the above limitation may not apply to
you. The retailer shall not be liable for incidental, consequential, or special damages
arising out of or in connection with product use or performance except as may
otherwise be accorded by law. Some states do not allow the exclusion of incidental or
consequential damages, so the above exclusion or limitation may not apply to you. This
warranty gives specific legal rights, and you may also have other rights which vary from
state to state. This warranty supersedes all prior warranties.

Table of Contents
SAFETY RULES....................................................................................................
PACKAGE CONTENTS ........................................................................................
INSTALLING YOUR FAN.....................................................................................
HANGING THE FAN.............................................................................................
ELECTRICAL CONNECTIONS ..........................................................................
.........................................................
FINISHING THE INSTALLATION.......................................................................
BLADE INSTALLATION .....................................................................................
.............................................................
.......................................................
OPERATING TRANSMITTER....................................................................
CARE OF YOUR FAN..........................................................................................
TROUBLESHOOTING.......................................................................................
SPECIFICATIONS..............................................................................................
INSTALLING THE WALL TRANSMITTER
INSTALLING THE MOUNTING PLATE
INSTALLING THE LIGHT KITASSEMBLY
THE
1
2
3
4
5
6
7
8
9
10
11
12
13
14

1. Before you begin installing the fan, shut power off at the
circuit breaker orthe fuse box.
2. Be cautious! Read all instructions and safety information
before installing your new fan. Review accompanying
assembly diagrams.
3. Make sure that all electrical connections comply with local
codes, ordinances, or National Electrical Codes. Hire a
qualified electrician or consult a do-it-yourself wiring
handbook if you are unfamiliar with installing electrical
wiring.
4. Make sure the installation site you choose allows the fan
blades to rotatewithout any obstructions. Allow a minimum
clearance of 7 feet from the floor and 18 inches from the tip
of the bladesto the wall.
5. If you are mounting the fan to a ceiling outlet box, use U.L.
Listed metal octagonal outlet box marked "Acceptable for
fan support". Secure the box directly to the building
structure. The outlet box and its support must be able to
support the moving weight of the fan (at least 50 lbs.) Do
not use aplastic box.
6. Caution: To reduce the risk of personal injury use only the
screws provided withthe outlet box.
7. If you are mounting the fan to a joist, make sure it is able to
support the movingweight of thefan (at least50 lbs.).
8. After you install the fan, make sure that all mountings are
secured to preventthe fan fromfalling.
1. Safety Rules
9. Do notinsert anything intothe fan bladeswhile the fanis operating.
10. To change the direction of the rotation of the blades the fanmust be in
operation mode.
ATTENTION: The Energy Policy Act of 2005 requires this fan to be
equipped with a 190 watt limiting device. If lamping exceeds 190
watts, the ceilingfan's light kitwill shut off automatically.
NOTE: The important safeguards and instructions appearing in this
manual are not meant to cover all possible conditions and situations that
may occur.It must beunderstood that commonsense, caution andcare are
factors which can not be built into this product. These factors must be
supplied by theperson(s) installing, caringfor and operatingthe unit.
TO REDUCETHE RISK OFFIRE, ELECTRIC SHOCK,OR OTHER PERSONAL
INJURY, MOUNT FAN ONLY TOA U.L. LISTED OUTLETBOX OR SUPPORTING
SYSTEM MARKEDACCEPTABLE FORFAN SUPPORT ANDUSE MOUNTING
SCREWS ANDLOCK WASHERS PROVIDED WITHTHE OUTLET BOX, MOST
OUTLET BOXES COMMONLY USEDFOR THE SUPPORT OF LIGHTING
FIXTURES ARENOT ACCEPTABLE FOR FAN SUPPORTAND NEEDTO BE
REPLACED. CONSULT AQUALIFIED ELECTRICIAN IF IN DOUBT.
TO REDUCETHE RISK OFPERSONAL INJURY,DO NOT BENDTHE BLADE
HOLDERS WHILE INSTALLING, BALANCING THEBLADES, OR CLEANING
THE FAN.DO NOT INSERT FOREIGN OBJECTSBETWEEN ROTATING FAN
BLADES.
TO REDUCETHE RISK OFFIRE OR ELECTRIC SHOCK, DO NOTUSE THIS FAN
WITH ANYSOLID-STATE SPEED CONTROLDEVICE
WARNING
NOTE
READ AND SAVE ALLINSTRUCTIONS!

Unpack your fanand check the contents. You should havethe following items;
.
1 Fan blades (5)
2. Hanger bracket
3. Canopy
4. Canopy cover
5a. Standard downrod assembly
5b. Minimum-length downrod(for close
to the ceilinginstallation only)
6.
7. Fan motorassembly
8. Blade holders (5)
Coupling cover
9. Blade medallions(5)
10. Mounting plate
11. Lightplate
12. Glass shade
13.
14a. Wall transmitter incl. 2 mounting screws
+ 3
14b. Wall plate w/2mounting screws
15. 50W Halogen bulb (2)
16. Balancing kit
Receiver+6 wire nuts
wire nuts
s
Package Contents 2.
3
1
2
11
10
13
12
16
15
4
6
7
8
9
5a
5b
a. Mounting hardware:
Wire nuts(3)
b. Blade attachmenthardware:
Screws (16)
(16)
c. Blade holderhardware:
Screws with lockwashers (11)
Rubber washers
a
c
b
14b
14a

3. Installing Your Fan
Outlet box
Figure 1
Ceiling
joist
Ceiling
joist
Cross brace
Outlet box
Figure 2
Ceiling joist
or cross brace Parallel
wood brace
Provide strong
support
Recessed
outlet box
Hanger bracket
opening must
be facing up-side
Figure 3
Outlet box
Figure 4
Ceiling
joist
Hanger bar
(optional)
Hanger
bracket
Angled ceiling
maximum
18 angle
Phillips screw driver; slotted screw driver; step-
ladder; wire cutters;electrical tape.
If there isn'tan existing mountingbox, then readthe
following instructions. Disconnect the power by
removing fuses orturning off circuit breakers.
Secure the outlet box directly to the building
structure. Use appropriate fasteners and building
materials. The outlet box and its support must be
able to fully support the moving weight of the fan
(at least 50 lbs.). Use a UL Listed metal outlet box.
Do not usea plastic outletbox.
Figure 1, 2 and 3 are examples of different ways to
mount the outletbox.
Note: You may need a longer downrod to maintain
proper blade clearance when installing on a steep,
sloped ceiling. Longer downrods are available from
your Hampton Baydealer.
To hang your fan where there is an existing fixture
but no ceilingjoist, you mayneed to install a hanger
bar as shown in Fig. 4 (available at your Hampton
Bay dealer).
Tools Required
Mounting Options

REMEMBER to turn off the power.
Follow the steps below to hang your fan
properly:
Step 1. Secure the hanger bracket to the
ceiling outlet box using screws and
included with your outlet box,
(Fig.5)
Step 2. Loosen the two set screws and
from the
top coupling ofthe motor assembly. (Fig.6)
Step 3. Remove the hanger ball from
downrod assembly by loosening set
screw, removing the cross pin, and sliding
ball off rod. (Fig.7)
Step 4. Carefully feed fan wires up
through the downrod. (Fig. 8) Thread the
rod into the coupling. Next line up holes
and replace lock pin and hitch pin. Tighten
set screws.
Step 5. Slip coupling cover, canopy cover
and canopy onto downrod. (Fig.9)
Carefully reinstall
lock
washers
remove the hitch pin and lock pin
the
the
hanger ball onto rod
being sure that cross pin is in correct
position, set screws are tighten and wires
are not twisted.
Step 6. Now lift motor assembly into
position and place hanger ball into hanger
bracket. Rotate until the check groove has
dropped into the registration slot and seats
firmly. (Fig. 10) Rod should not rotate if
this is donecorrectly.
Outlet box
Hanger bracket
Cross pin
Hanger
ball
Downrod
Downrod
Supply
wires
Figure 5
Figure 7 Figure 8
Figure 6 Figure 9
Figure 10
Registration
slot
Downrod
Canopy
Canopy cover
Set screws
Hitch pin
Lock pin
Hitch
pin Lock
pin
Set
screws
Hanger ball
Coupling
*Omit coupling
cover when
downrod
cover
using
the minimum-length
Hanging the Fan 4.

Receiver
Hanger bracket
Figure 11
Figure 12
WARNING: To avoid possible electrical
shock be sure electricity is turned off at the
main fuse orbreaker box beforewiring.
NOTE: The Wall Control units included
with your ceiling fan are equipped with 16
code combinations to prevent possible
interference from or to other remote units.
The dip switches on your Receiver and
Transmitter units have been preset at the
factory, please re-check to make sure the
switches on both units are set to the same
positions. The frequency settings should be
changed only in case of interference or if a
second or more remote controlled ceiling
fans are installed in the same structure. Any
code combination will operate the ceiling
fan and light as long as the Receiver and
Transmitter units are set to the same codes
(Fig. 11)
Step 1. Insert Receiver into Hanger Bracket
with the flat side of the Receiver facing the
ceiling. (Fig. 12)
Step 2. Motor to Receiver Electrical
Connections: Connect the Black wire
from the fan to Black wire marked "TO
MOTOR L". Connect the White wire from
the fan to the White wire marked "TO
MOTOR N" from the receiver. Connect the
Blue wire from the fan to the Blue wire
marked "For Light" from the receiver. Secure
wire connections with the plastic wire nuts
provided. (Fig. 13 and 14)
(Fig. 13 and14)
connectors
Step 3. Receiver to House Supply Wires
Electrical Connections: Connect the WHITE
wire (Neutral) from the outlet box to the
WHITE wire marked "AC in N" from the
receiver. Connect the BLACK wire (Hot)
from the outlet box to the BLACK wire
marked "AC in L" from the receiver. Secure
all wire connections with the plastic wire nuts
provided.
Step 4. If your outlet box has a GROUND
wire (Green orBare Copper) connectthis wire
to the Hanger Ball and Hanger Bracket
Ground wires. If your outlet box does not
have a Ground Wire, then connect the Hanger
Ball and Hanger Bracket Ground Wires
together. Secure wire connection with the
plastic wire nutprovided. (Fig. 13& 14)
After all are made, check to make
sure there are no loose strands. As an
additional precaution wesuggest to secure the
plastic wire connectors to the wires with
electrical tape.
ONON
5. Electrical Connections

Fan
White (neutral)
White (neutral)
Green or bare
copper (ground)
White ("AC INN")
White ("to motor N")
Ground
(green)
(Connect to
ground wire on
hanger bracket
if no house
ground wire
exists.)
Outlet box
Black (hot)
Black ("AC INL")
Black ("to motor L")
Receiver
Blue ("for light")
Blue ("for light")
Black (motor)
Figure 13
Figure 14
Wall
control
Black
Black
Black
Black
Black
Black
Black
Black
White
White
White
White
Blue
Blue
Ground Green
Green Ground
INPUT
AC120V
AC SUPPLY

WARNING: HOOK UP IN "SERIES ONLY" DO NOT CONNECT THE HOT AND NEUTRAL WIRES OF ELECTRIC
CIRCUIT TO THE TRANSMITTER WALL SWITCH - DAMAGE TO THE SWITCH AND POSSIBLE FIRE COULD
OCCUR.
Step 1. Remove the existingwall plate andswitch from thewall junction box.
Step 2.
Step 3. (Fig. ) Carefully tuck the wire connections inside the junction box. Secure the wall transmitter with the two screws
provided. Attach the wall plate over the wall transmitter and secure with thetwo screws provided.
Make the electrical connections as shown in (Fig. 14). If your outlet box has a ground wire (green or bare copper) connect
the wall transmitter's ground wire to it; otherwise connect the wall transmitter's ground wire directly to one of the screws from the
outlet box.
15
Figure 15
REMEMBER to Shutthe Power Off at the Circuit Breaker or Fuse Box.
6. Installing the Wall Transmitter

8. Blade Installation
Step 1. Attach the fan blades to the blade
holder and blade medallions using the
screws and rubber washers provided,
tighten screws securely. (Fig. 17)
Step 2. Rotate motor so that the screw holes
are revealed through the opening on
mounting ring. Align motor holes to blade
holders and secure with screws provided,
tighten screws securely. (Fig. 17)
Blade
Blade holder
Screws
Screws
Rubber
washers
Blade medallion
Figure 17
9. Installing the
Mounting Plate
Step 1. Remove 1 of the 3 screws from the
mounting ring and loosen the other 2 screws.
(Do not remove)
Step 2. Place the key holes on the mounting
plate over the 2 screws previously loosened
from the mounting ring, turn mounting plate
until it locks in place at the narrow section of
the key holes. Secure by tightening the 2
screws previously loosened and the one
previously removed. (Fig.18)
Figure 18
Mounting plate
Mounting ring
Screws
7. Finishing the
Installation
Step 1. Tuck connections neatly into ceiling
outlet box.
Step 2. Slide the canopy up to ceiling and
over the two crews on hanger bracket. Rotate
canopy clockwise. Next, while holding the
canopy with one hand, slide the canopy
cover over the screws and rotate clockwise
until tight. Note: adjust the canopyscrews as
necessary until the canopy and canopy cover
are snug. (Fig.14)
Figure 16
Canopy
cover
Outlet box
Hanger
bracket
Hanger
ball
Canopy

Connector
plugs
Screws
Mounting plate
Light plate
Glass
shade
Bulbs Mounting
plate
Figure 20
Figure 19
WARNING: Shut off the power supply
before removing or replacing lamp. In
handling of halogen bulb, care should be
taken not to touch it with your bare hands.
Oil residue will shorten the life of the
halogen bulb. If you accidentally come
into contact, wipe thoroughly with a clean,
lint-free, cotton cloth. Allow the bulb to
cool off for 10 minutesbefore changing the
bulb. Use light bulb in accordance with the
fan's specification. TO REDUCE THE
RISK OF FIRE DO NOT EXCEED
MAXIMUM WATTAGE RATING.
ATTENTION: The Energy Policy Act of
2005 requires this fan to be equipped with
a 190 watt limiting device. If lamping
exceeds 190 watts, the ceiling fan's light
kit will shutoff automatically.
Step 1. Remove 1 of the 3 screws from the
mounting plate and loosen the other 2
screws. (Do notremove)
Step 2. Raise and hold the light plate close
to the mounting plate and proceed to do the
wire connections. Connect the white wire
connectors from the light plate and fan,
follow the same procedure with the black
wire connectors. (Fig.19)
Step 3. Place the key holes on the light
plate over the 2 screws previously
loosened from the mounting plate, turn
light plate until it locks in place at the
narrow section of the key holes. Secure by
tightening the 2 screws previously
loosened and the one previously removed.
(Fig. 19)
Step 4. Install 2x50W halogen bulbs
(included). (Fig. 20).
Step 5. Raise glass shade up against
bottom of fan housing and secure it to fan
by twisting glass clockwise until snug. DO
NOT OVERTIGHTEN. (Fig. 20)
10. Installing the Light Kit Assembly

Operating the Transmitter 11.
Restore power to ceiling fan and test for
proper operation.
1. " LOW, MED, HI" buttons:
These three buttons are used to set the fan
speed as follows:
LOW= Low speed MED= Medium speed
HI= High speed
2. "FAN OFF" button:
This button turns the fanoff.
3. The "LIGHT" button turns the light ON or
OFF and alsocontrols the brightnesssetting.
Press and release the button to turn the light
ON or OFF. Press and hold the button to set
the desired brightness. The light key has an
auto-resume, it will stay at the same
brightness as thelast time itwas turned off.
4. "OFF-ON " Slide Button: This button turns
the power Off and On to the Fan and Light(s).
5. "REV" Button: This button is used to change
the direction of the rotation of the blades;
forward for warm weather or reverse for
warm weather.
Warm weather-(Counter-Clockwise
direction) A downward airflow creates a
cooling effect.(Fig. 22) This allows you to
set your air conditioner on a higher setting
without affecting your comfort.
Cool weather-(Clockwise direction) An
upward airflow moves warm air off the
ceiling area.(Fig. 23) This allows you to set
your heating unit on a lower setting without
affecting your comfort.
Speed settings for warm or cool weather
depend on factors such as the room size,
ceiling height, numberof fans, etc.
NOTE: To operate the reverse function on
this fan, press the reverse button while the
fan is running.
Figure 22
Figure 23
Figure21

12. Care of Your Fan
Here are some suggestions to help maintain
your fan.
1. Because of the fan's natural movement
some connections maybecome loose. Check
the support connections, brackets and blade
attachments twice a year. Make sure they
are secure. (Itis not necessary to remove fan
from the ceiling).
2. Clean your fan periodically to help
maintain its new appearance over the years.
Use only a soft brush or lint free cloth to
avoid scratching the finish. Plated finishes
are sealed with lacquer to minimize
discoloration or tarnishing. Do not use
water when cleaning, this could damage the
motor, wood blades or possibly cause an
electrical shock.
3. If your fan is provided with wood veneer
blades; you can apply a light coat of
furniture polish for additional protection
and enhanced beauty. Cover small scratches
with a lightapplication of shoepolish.
4. Use a lint free lightly damp cloth or duster
to remove dustfrom the blades.
5. There is no need to oil your fan. The motor
has permanently lubricatedbearings.
6. If your fan is provided with glass shades,
clean with lukewarm soapy water and a soft
cloth or sponge. DO NOT IMMERSE GLASS
SHADES IN HOT WATER. DO NOT PUT
GLASS SHADES INTO AN AUTOMATIC
DISHWASHER.
WARNING: Make sure the power
is off atthe electrical panelbox
Before you attempt any repairs.
Refer to the section, "Making
Electrical Connections".
For any additional information on your
Hampton Bay CeilingFan, please writeto:
THE HAMPTON BAY FAN & LIGHTINGCO.
P.O. Box 395
Norco, CA92860
Call toll free 1-800-527-0998

13.Troubleshooting
Problem
Fan will notstart.
Fan sounds noisy.
Remote control
malfunction.
Lights shut off and will
not come backon.
Fan Wobble.
Solution
1. Check circuitfuses or breakers.
2. Check linewire connections tothe fan andswitch wire connectionsin the switchhousing.
CAUTION: Make suremain power isoff.
1. Make sureall motor housingscrews are snug.
2. Make surethe screws thatattach the fanblade bracket tothe motor hubis tight.
3. Make surewire nut connectionsare not rubbingagainst each otheror the interiorwall of theswitch housing.
CAUTION: Make suremain power isoff.
4. Allowa 24-hour "breaking-in"period. Most noiseassociated with anew fan disappearduring this time.
5. If usingan optional lightkit, make surethe screws securingthe glassware aretight. Check thatthe light bulb
is also secure.
6. Do notconnect the fanwith a wall mounted variable speedcontrol (s)
7. Make surethe upper canopyis a shortdistance from theceiling. It should not touch the ceiling.
1. Do notconnect the fanwith a wall mounted variable speedcontrol (s).
2. Check tomake sure thedip switches fromthe transmitter andreceiver are setto the samefrequency.
1. This unit is equippedwith a wattagelimiting device. Lampingin excess of190 watts willdisable your ceiling
fan's light kit. To reset your light kit you must turn the poweroff and re lamp, keepingthe wattage under190
watts. Restore powerto your ceilingfan and continuenormal operation.
3. Check tomake sure thedip switches fromthe transmitter andreceiver are setto the samefrequency.
NOTE: All blade setsare grouped byweight. Because woodand plastic blades vary in density, the fan
may wobble eventhough blades arematched.
1. Make sureall blade attachmentscrews are tight.
2. Make sureOutlet box issecured to buildingstructure, if necessary use the wood screws provided to
further secure outletbox to joist.
3. Make sureHanger Bracket issecure to theoutlet box, screws are tight.
4. Use the balancing kit provided if the wobble is excessive (follow instructions included with balancing kit)

14. Specifications
These are typicalreadings. Your actual fanmay vary. They do not include Amps and Wattage used by thelight kit.
Distributed by
Your Other Warehouse, LLC
12100 Little Cayman Dr.
Baton Rouge, LA 70809
RPM CFM N.W. G.W.
C.F.
120 1867
3731
5297
16
38
74
65
118
170
0.34
0.51
0.64
120
120
Fan Size Speed Volts Amps Watts
Low
Medium
High
2.51'13.2 kgs
( lbs)29.07
15.15 kgs
(33.36 lbs)
54"
(137 cm)
