HAMPTON BAY G40C User manual

THANK YOU
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
8 X 5 POP UP GRILL GAZEBO
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-841-1350
HAMPTONBAY.COM
Item #1007 985 145
Model# G40C

2
Table of Contents
Safety Information...................................2
Warranty................................. . 2
Pre-Installation ..................................... 3
Package Contents ............................... 3
Setting Up the Canopy ............................... 3
Taking Down the Canopy ............................ . 4
Care And Cleaning ..................................4
Service Parts.......................................5
Safety Information
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC.
f left in continuous
WARNING: Do not leave the tent where there is a risk of high wind, as possible damage will occur to the structure.
CAUTION:
CAUTION: Never set up or continuetouse in any rain, wind, storm conditions, or lightning storms. Damage can occur tothe tent and putyou and others
in potential danger.
CAUTION: Avoid setting up the tent on steep inclines.
CAUTION: Do not climb on top ofthe tent. Falling off the tent can resultin serious injury, or even death.
CAUTION: Never leave the tent unattended.
Warranty
1 YEAR WARRANTY
WHAT IS COVERED
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the
item is maintained with care and used only for personal, residential purpose. The item is warranted to be free from defects in material or
workmanship for a period of 1 year.
WHAT IS NOT COVERED
We do not reimburse for transportation of delivery costs, or compensate the individual or any outside party for assembling or disassembling
the product.
Contact the Customer Service Team at 1-888-502-9589, 9:00 a.m. to 4:00 p.m. PST; email [email protected]; or visit
www.HAMPTONBAY.com.
........

3 HAMPTONBAY.COM
Please contact 1-800-841-1350 for further assistance.
Frame
Lower leg assembly 4
Large top
C
Steel table
Small top
2
E
B
A
D
8
Knob 10F
StakeG
F G
SettingUpthe Canopy
OPENING THE CANOPY FRAME
With a partner, stand across from each other.
Grab one leg of the frame (A) in each hand as
shown. Lift slightly off the ground and step
backwards while pulling the legs away from
each other, bringing the truss closer together
vertically.
Pull out the four telescopic poles until the
click indicating the pin
is locked.
ATTACHING THE CANOPY
Unfold the small top (D) and place it over the
opened frame (A). Then attach the four small
top corners to the frame.
Unfold the large top (E) and place it over the
opened frame (A). Be sure the neckband of
the large top (E) is totally under the small
top (D). Then attach the four large top
corners to the frame.
LOCKING THE FRAME
With a partner, start on a short side. Place
one hand on the upper corner, and use the
other hand to push the truss straight up
until the “click” heard indicating the truss
is set into the hole on the leg.
Repeat with the remaining legs.
IMPORTANT:
Lift up the frame 2”-3” off the ground
especially in tall grass or sand.
Grasp the trusses away from the connections
to avoid pinching.
Open the frame to 80% - 90% to make for
easier canopy fabric installation.
IMPORTANT:
Find the corners of the top before draping
over frame.
Do not attach the top while the frame is
fully extended.
INSERTING THE LOWER LEG
With a partner, start on the short side and lift the frame up at the
same time.
Align the groove on the lower leg (B) with the indentation on the
upper leg. Insert the leg and turn counterclockwise to lock.
Repeat with the remaining legs.
IMPORTANT:
This step must be done by two people.
INSTALLING THE TABLES
With one person holding the table (C) in position, the another person
using the knob (F) to attach the table to the leg.
Repeat with the remaining table and leg.
IMPORTANT:
This step must be done by two people.
80%
CLICK!
1
2
AA
x4
x4
DDE
LOCK
UNLOCK
x4
B
1
2
x4
C
F
x4
CLICK!

1
2
3
4
REMOVING THE STAKES
Pull up all stakes (G) from the ground.
5 FOLDING THE FRAME
Lift the legs off the ground 2-3 inches and walk it in from both
sides until the frame is fully closed.
Taking Down the Canopy
Setting Up the Canopy (continued)
4 HAMPTONBAY.COM
Please contact 1-800-841-1350 for further assistance.
Care and Maintenance
Hand wash the top using only mild soap and water. Never use harsh detergents, abrasives, or bleach.
Do not machine wash.
Never fold or store the top when it is wet or damp. Allow it to dry completely to avoid mildew.
6SECURING THE CANOPY IN PLACE
Insert two stakes (G) into the foot of each canopy leg if possible.
TAKING DOWN THE TABLE
With one person holding the table (C), the another person removing
the knob (F) to detach the table from the leg.
Repeat for remaining table.
REMOVING THE LOWER LEG
With a partner, start on the narrow side, rotate and pull down
the lower leg at the same time.
UNLOCKING THE CANOPY
From underneath the canopy, press in the
red lock button on the leg assembly.
Press the pin on plastic part of each corner
to retract the telescoping poles. (right fig)
IMPORTANT:
This step must be done by two people.
2
1
G
x4
IMPORTANT:
Always secure your product with stakes.
2
G
1
x4
C
1
F
2
x4
x4
LOCK
UNLOCK
PRESS!
x4 x4
2
1
PRESS!

5 HAMPTONBAY.COM
Please contact 1-800-841-1350 for further assistance.
Spare Parts
To access spare parts, please call toll free 1-888-502-9589, Monday - Friday, 9:00 AM - 4:00 PM PST; or visit www.crown-shades.com;
or email [email protected].
Part Description Reference No.
ACentral cap
BLeg Cap-48
D
CSlider-48
E
Left Outer Leg Assembly UNLA19BKLO
F Inner Leg Assembly
UNLA19BKRO
G
H
Right Outer leg Assembly
UNLA19BKIN
Celing Assembly
Long Eave Assembly UNEA05BK00
UNCA58BK00
I Short Eave Assembly UNEA08BK00
Part Description Reference No.
UNCP00BK01
UNLC19BK00
K
UNLS19BK00
J
L
M
N
O
Plastic Foot UNFT19BK00
UNBKM4BKCS
M4 Bolt Kit
M5 Bolt Kit UNBKM5BK4P
Knob Bolt
Steel Table
UNTS58KA00
UNTB04BKAL
UNKB06BK00
Small Top-Brown
Large Top-Khaki UNTL58KA00
P
SCAN ME FOR MORE
IMPORTANT PRODUCT
INFORMATION.
G
A
B
D
D
E
E
C
J
K
L
F
G
H
I
P
O
A B
D
CJ
K
L
P
M
N
E
F
G
H
I
O

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-841-1350
HAMPTONBAY.COM
Retain this manual for future use.
