HAMPTON BAY GSS00208B-4 User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this swing. We strive to continually create
.sdeentnemevorpmiemohruoyrofelbaliavastcudorpfoenilllufruoeesotenilnosutisiV.emohruoyecnahneotdengisedstcudorpytilauq
Thank you for choosing Hampton Bay!
Item # 1001 414 641
Model # GSS00208B-4
USE AND CARE GUIDE
CANE SWING WITH CUSHIONS
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
5.......................................................................ylbmessA
stnetnoCegakcaP .................................................................... 4
Care and Cleaning.......................................... 6..............
Table of Contents..........................................................2
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
WARNING: Weight limit for the swing chair is 250 lbs
(113.39 kg) for each seat.
CAUTION: Do not locate the product near any
heat source.
!
WARNING: This swing unit is heavy, and may require
two adults for safe assembly.
WARNING: Do not shake from side to side when using
the product.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This swing was as made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this set
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
Please keep children out of the assembly area before assembly.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
3.
CAUTION: Do not place heavy objects on the swing.
!
2. Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
Part
Description
Quantity
AA M8x50 combination bolt
BB M6x50 combination bolt 8+1
4+1
HARDWARE INCLUDED
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
CC Connector ring 2
DD Wrench 1
AA BB CC DD
NOTE: Hardware not shown to actual size.
This swing is compatible with the Cane A-frame.
Warranty
2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric.
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part
Description
Quantity
A
Seat
1
B
Backrest
1
C
Right arm
1
D
Left arm
1
E
Seat cushion
1
F
Pillow
4
A
B
C
D
E
F

1
l
5
Assembly
Attach the right arm (C) and the left arm (D) to the seat (A) using M6x50 combination bolts (BB).
Attach the right arm (C) and the left arm (D) to the backrest (B) using M8x50 combination bolts (AA).
Tighten all the bolts using the wrench (DD).
Assembling the swing frame
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
BB
B
C
BB
AA
A
D
AA

2
l
6
Assembly (continued)
Attaching the connector rings and the seat cushions
Open the connector rings (CC) by twisting counterclockwise.
Insert the connector rings (CC) into each swing rope hole.
Close the connector ring (CC) by twisting clockwise.
Place the seat cushions (E) and the pillows (F) on the seat (A).
CC CC
F
E
A
FFF
Care and Cleaning
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles
that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the swing in a dry, sheltered place when not in use.
Keep the swing away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
Factory swing ID # GSS00208A
