HAMPTON BAY UMB-922120 User manual

THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this Umbrella. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
THANK YOU
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
9 FT. (2.72 m) TILTING UMBRELLA
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
01 800 004 6633
HOMEDEPOT.COM
111 474 Grey
111 476 Blue
111 477 Red
Model UMB-922120-BL
UMB-922120-GR
UMB-922120-RED
IMPORTER: SERVICIOS HOME DEPOT, S. DE R.L. DE C.V.
RICARDO MARGÁIN NO. 605, SANTA ENGRACIA, SAN PEDRO GARZA GARCÍA, NUEVO LEÓN, MÉXICO CP 66267
PHONE: [phone]
111 474 Gray 121 932 Dark Apricot
121 933 Red 121 927 Corsair Blue
121 928 Brown
Model #UMB-922120

2
Table of Contents
Safety Information ..................................2
Warranty ..........................................3
Pre-Installation.....................................3
Planning Installation ...............................3
Package Contents .................................4
Installation ........................................5
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
File a Claim ........................................7
Care and Cleaning ..................................7
Troubleshooting ....................................7
Safety Information
WARNING: This umbrella is designed for easy
operation, sunshade and decorative purposes only.
It is NOT recommended that this umbrella be used
during periods of high wind and rain. Always take
the umbrella down during high or gusting wind
and rain, when not in use and in the off-season.
Failure to do so may result in personal injury and/or
property damage.
CAUTION: Placement of the umbrella over or
near a swimming pool will cause premature fading,
it goes against the normal conditions of use,
especially to darker colors.
DANGER: Keep children away from the umbrella
during assembly to avoid injury.
CAUTION: If the crank becomes too hard to
crank, check to see if the rope has come off the
pulley. If you continue to turn the crank, the rope or
crank handle could break.

3 HOMEDEPOT.C0M
Please contact 01 800 004 6633 for further assistance.
Pre-Installation
PLANNING INSTALLATION
Before beginning assembly of the product, make sure all parts are present. Compare parts with the package contents list and diagram on
page 4. If any part is missing or damaged, do not attempt to assemble the product or return to the place of purchase. Contact our customer
service toll free at 01 800 004 6633 for replacement parts or further instructions.
NOTE: We recommend that you insert the umbrella into
an umbrella base or table (not included) for securing the
umbrella.
DANGER: Keep children away from the umbrella during
assembly to avoid injury.
TOOLS REQUIRED
No tools required.
HARDWARE INCLUDED
No hardware required for assembly.
ONE YEAR LIMITED FRAME WARRANTY
WHAT IS COVERED
The Frame is warranted to be free of manufacturing defects for one year from purchase date. If the frame of your furniture fails (i.e. broken
frame or weld) within one year of ownership, Hampton Bay will repair, provide replacement parts, or replace the product at our option.
Frame nishes are warranted against blistering, cracking, or peeling for one year from purchase date. This is a residential use warranty
only. Warranty is void for product used in commercial settings. This warranty is a limited warranty and applies to the original purchase only.
Proof of purchase is required.
WHAT IS NOT COVERED
Failure caused by unreasonable or abusive use, re, freight damage, acts of nature (such as, but not limited to freezing or high winds),
suntan oil or other chemicals, normal fading, scratching or chipping of the nish, fading, weathering or staining or discoloration of furniture,
accidental damage, repair, or modications by customer, glass breakage, normal wear and tear are excluded from the warranty. Furniture
used in commercial, contract or any other non-residential applications; clearance items, and display models are not covered under this
warranty. In no event shall Hampton Bat responsibility exceed the value of the replacement part/product. Freight damage is not covered
under this warranty. Freight and packaging charges to return a product or part are not covered under this warranty.
Contact the Customer Service Team at 01 800 004 6633 or visit www.homedepot.com.
Warranty printed in the manual is not valid for Mexico.
Warranty

4
Pre-Installation
PACKAGE CONTENTS
C
B
Part Description Quantity
A Umbrella Frame and Canopy 1
B Bottom Pole 1
C Finial 1
A

5 HOMEDEPOT.C0M
Please contact 01 800 004 6633 for further assistance.
Installation
1 Attach the Finial
□
screw-in adapter on the top of the umbrella frame (A).
Twist until secure but do not over tighten
C
A
2 Assemble the Pole
□ Insert the bottom pole (B) into the upper pole while pressing
the snap button on the upper pole (A) until the snap button
locks into position.
C
B
A
A

6
Operation
Open/Close the Canopy
□ Turn the crank handle (1) in a clockwise direction to open the umbrella canopy (A), opposite direction to close the canopy (A).
THE UMBRELLA MUST BE IN THE UPRIGHT POSITION WHEN CLOSING. Turn the crank handle in the clockwise direction and it will
automatically tilt the umbrella to an angle. It will automatically come back to original position if turning the crank handle in the
counterclockwise direction.
C
A
1

7 HOMEDEPOT.C0M
Please contact 01 800 004 6633 for further assistance.
□.
a claim please contact us at 01 800 004 6633 or visit us through our website: www.homedepot.com.
□Simply clean the umbrella canopy with a soft brush and mild detergent.
□DO NOT machine wash or dry.
□DO NOT iron.
□AIR DRY the canopy thoroughly in an open position before storing for extended periods of time.
□FABRIC: 100% polyester
□Clean with damp cloth
Problem Possible Cause Solution
The umbrella does not close The top of the umbrella is in a
tilted position.
□Adjust the top of the umbrella top to be in the
upright position and then to close the umbrella.
The crank does not click and the
canopy does not move up when turning
the crank handle in the open direction.
The rope is loose and needs
to be wound around the crank
shaft and stretched.
□Keep turning the crank handle in the open direction
several turns to wind and stretch the rope until the
canopy moves up.
The crank becomes too hard to crank. The rope has come off the
pulley.
□Slack the rope and put it back onto the pulley.
File a Claim
Care and Cleaning
Troubleshooting

Questions, problems, missing parts? Before returning to the store,
call Customer Service
8 a.m.-6 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
01 800 004 6633
HOMEDEPOT.COM
Retain this manual for future use.
