HAMPTON BAY X1250B-CPY User manual

Item # 1000 117 123
Model # X1250B-CPY
USE AND CARE GUIDE
HARBOR GAZEBO REPLACEMENT CANOPY
1-855-HD-HAMPTON
HAMPTONBAY.COM
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
THANK YOU
Hampton Bay through the purchase of thi s harbor canopy. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

2
Table of Contents
Table of Contents..........................................................2
Warranty.........................................................................2
What is Covered.......................................................................2
What is Not Covered ................................................................2
Pre-Assembly ................................................................ 2
Planning Assembly ..................................................................2
Package Contents ....................................................................3
Care and Cleaning ........................................................ 6
Warranty
2 YEAR FABRIC WARRANTY
WHAT IS COVERED
We warrant the fabric to be free of manufacturing defects to the original purchaser for two years.
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-
abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
complete the assembly of this product.
Assembly ....................................................................... 4
Safety Information
SAFETY WARNINGS
!
WARNING:
gazebo fabric.
!
WARNING: This application of any foreign substance to the
ineffective.
!
WARNING: This gazebo is made with fabric that meets
proof. The fabric will burn if left continuous contact with any
Safety Information ...................................................................2
Safety Warnings .............................................................................2
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com

3
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
N
Small fabric cover 1
OLarge fabric cover 1
N
O
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

4
Assembly
1
Replacing the large fabric cover
Place the large fabric cover (O) on top of the assembled frame.
Fully extend the large fabric cover (O) to the end of the spokes.
O

5
Assembly (continued)
2
Reattaching the canopy spokes and hub (not included)
Insert the upper canopy spokes (I) into the upper canopy hub (J).
Then insert the upper canopy spokes (I) into the top tubes (G).
I
I
I
I
J
I
I
I
I
NOTE: The upper canopy spokes (I), upper canopy
hub (J), and top tubes (G) are not included with the
replacement canopy.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

6
Assembly (continued)
3
Replacing the small fabric cover
Place the small fabric cover (N) on the upper canopy spokes, and fully extend the small fabric cover to the ends of the upper
canopy spokes.
O
N
Care and Cleaning
For best results, clean the fabric with a damp cloth, and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the canopy in a dry, sheltered place when not in use.
Keep the canopy away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
