Hanlong UC840(P) User manual

HardwareOverview


LEDs

1.PowerIndicator:Steadygreenwhenpoweron,blinkinggreenwhenthecallisringing.
2.LineKeys
Steadygreen:duringtheconversation,orplantodialacall.
Blinkingred:thecallisringing.
Off:idleinterface
Placeacall
Threewaystomakeacall:
1)Handset:Pickupthehandset;enterthenumber,andthenpressthesendsoftkeyor
press.
2)Speaker:Press  orthelinekeys;enterthenumber,andthenpressthesendsoftkey
orpress.
3)Headset:Press;enterthenumber,andthenpressthesendsoftkeyorpress.
Note:YoucanalsouseContactsorcalllogtodialthenumberyouwant,pressplacethecall
bythethreewaysmentioned.More,youcanalsoalternatethemodeduringthecall.
Endacall
Toendacallinthreedifferentmodes:
1) Handset:hangupthehandsetorpressthecancelsoftkey.
2) Speaker:press,orpressthecancelsoftkey
3) Headset:pressthecancelsoftkey.
Answeracall
1)Handset:pickupthehandset;
2)Speaker:press;
3)Headset:press.
Note:YoucanalsorejectthecallbypresstheRejectsoftkey.
Redial
Press  toredialthelastcallthatdialed.
Hold
Pressorpresstheholdsoftkeyduringacalltoholdthecall,
Pressorresumesoftkeytoresumethecall.
CallTransfer
BlindTransfer
a.Press  ortransfersoftkeyduringtheconversation,thecallisonholdnow.
b.Enterthenumberthattransfersto.
c.Pressorthetransfersoftkey,andnowtheblindtransfercompleted.
AttendedTransfer(atleastonelinekeysetasAuto)
a.Press  ortransfersoftkeyduringtheconversation,thecallisonholdnow.
b.Enterthenumberthattransferto,andpressthesendsoftkeyor.
c.Startthesecondconversation,pressortransfersoftkey,then,transfercompleted.
Semi‐AttendedTransfer(atleastonelinekeysetasAuto)
a.Press  ortransfersoftkeyduringtheconversation,thecallisonholdnow.
b.Enterthenumbertransferto,andthenpress,thenyoucanheartheringtone.
c.PressortheTransoftkey,andnowtheSemi‐attendedtransfercompleted.
CallConference
AssumingthatAandBareinconversation.AwantstobringC(orD&E)inaconference:
1)Apressline2,thecallisplacedonhold.
2)AenterthenumberofCandthenpresssendsoftkeyor.Canswersthecall.
3)Apressortheconferencesoftkey,thenA,BandCarenowinaconference.
4)IfaddD&E,pressLine3,thecurrentconferenceisonhold,dialDandpress,thefour
areinconference.Pressline4,anddialE,press,thenA,B,C,D,Eareinconference.
Note:1)IfCdoesnotanswerthecall,AcanbacktocontinuetheconversationwithB;2)
OnceAhangsupthecall,theconferenceisended,whileifBorCdropsthecall,A&Cor
A&Bconversationcontinues.
CallMute
Presstomutethemicrophoneduringthecall
Pressagaintoun‐mutetheconversation.

Instruction



Configuration

1.ConfigurationviaPhone
a.PressMenu→Setting→AdvancedSettings(Defaultpassword:admin)
b.SelectNetwork:ToconfiguretheWanPort(DHCP/Static/PPPoE),PCPort…
c.SelectAccounts:Toconfigureenabletheaccount;filltheSIPSERVER,OutboundProxy,ID…
d.Savetheconfiguration
2.ConfigurationviaWeb
a.GettheIPaddress:PressMenu→Status.
b.Login:inputtheIPaddressinthewebbrowser.ThePCandphoneshouldbeinthesame
segment)/Loginname:adminpassword:admin(default)
c.Configure:selectnetwork/Account…tofilltherelevantcontent.
d.Savetheconfiguration,orifwanttoreboot,clicktherebootbutton.
SupportContact

NanjingHanlongTechnologyCo.,Ltd.
[email protected]
Tel:0086‐25‐84658050
Fax:0086‐25‐84658319
www.hanlongtek.com
5thFloor,1stBuilding
HuashenTechPark
10HuashenTemple
YuhuataiDis.Nanjing210012
China

©NanjingHanlongTechnologyCo.,Ltd.2005‐2014Allrightsreserved.



QuickReference
For
UC842,UC840P,UC804P,UC804

