Hans Grohe Axor Citterio 39224 0 Series Installation guide

Vertical Spray Bidet Fitting
Rough 1322X181
Citterio
39224xx0
Starck
10220xx0
Steel
35220800
Uno
38220xx0
Terrano
37224xx0
Terrano
37225xx0
Carlton
17224xx0
Carlton
17225xx0
Phoenix
17226xx0
Phoenix
17227xx0
Montreux
16521xx0
Montreux
16522xx0
Citterio
39225xx0
Installation Instructions / Warranty

2
Citterio
39224xx0
Citterio
39225xx0
Starck
10220xx0
Steel
35220800
Uno
38220xx0

3
Terrano
37225xx0
Carlton
17224xx0
Carlton
17225xx0
Phoenix
17226xx0
Phoenix
17227xx0
Terrano
37224xx0

4
Technical Information
Recommended water pressure 14.7 - 72.5 psi
Max. water pressure 147 psi
Recommended hot water temp. 120° - 140° F*
Max. hot water temp 165° F*
Hole size in mounting surface
valves 1½"
transfer valve 1¼"
pull rod min. ⅜"
Max. depth of mounting surface 1 ⁹⁄₁₆"
Flow rate 2.2 gpm
Cartridge with high temperature limit stop
*Please know and follow all applicable local plumbing codes when setting
the temperature on the water heater.
Installation Considerations
For best results, Hansgrohe recommends that
this unit be installed by a licensed, profes-
sional plumber.
Please read over these instructions thorough-
ly before beginning installation. Make sure
that you have all tools and supplies needed
to complete the installation.
Keep this booklet and the receipt (or other
proof of date and place of purchase) for
this product in a safe place. The receipt is
required should it be necessary to request
warranty parts.
This unit requires ½" hot and cold supply
lines (not included).
This unit is for use on a bidet with a vertical
spray.
•
•
•
•
•
Montreux
16521xx0
Montreux
16522xx0

5
Rough-in Installation Instructions
Install the transfer valve
Install the y-connector and seal on the bottom of the transfer
valve.
Connect the hoses to the y-connector.
Connect the elbow to the outlet on the transfer valve. The
arrow on the elbow connector indicates the direction of the
water ow. It should point downward.
Connect the spray hose to the elbow.
Push the transfer valve, nylon washer, and one of the china
seals (tapered side up) through the transfer valve hole.
Install the second china seal, tapered side down.
Install the mounting nut on the transfer valve. It should rest
on the mounting surface.
Make sure that the transfer valve
stands straight.
Install the spray assembly
Position the spray and sealing washer in the hole in the bidet.
Install the washer and mounting nut.
Connect the spray hose to the spray.
Do not to twist or kink the hose.

6
Install the pop-up guide assembly
Remove the nut, metal washer, and sealing washer from the
pop-up guide assembly.
Position the pop-up guide and sealing washer on the proper
hole on the bidet.
Install the metal washer and nut.

7
Install the pop-up drain
Attach the swivel connector to the end of the horizontal
rod.
Attach the swivel connector to the end of the pull rod.
Position as desired and tighten with a small, at bladed
screwdriver.
Remove the plunger assembly.
Unscrew the drain outlet ange from the tee.
Unscrew the tailpiece from the tee. Wrap the threads
with Teon tape and replace.
Install the white, exible sealing gasket to the ange.
Place it in the sink outlet.
Install the black mack gasket, white friction ring and
retainer nut on the ange.
Do not tighten the nut against the bottom of the sink at
this time.
Thread the tee and tailpiece to the ange. The pivot
must face the faucet. Turn the drain assembly if neces-
sary.
Tighten the retainer nut.
Place the plunger assembly in the drain.
Install the horizontal rod so that the end goes through
the loop in the bottom of the plunger.
Install and hand tighten the pivot ball nut.

8
Trim Kit Installation
Install the valves: Starck only
Remove the valve mounting nuts from the valves.
Push the valves up into the mounting surface.
Install the mounting plates.
Tighten the tensioning screws.
Install the valves: all other styles
Remove the plaster shields, mounting plates, and stop rings
from the valves.
Push the valve up through the mounting surface.
Slide the stop ring onto the valve.
Install the mounting plate. The stop ring will stop it at the
proper height.
Rest the mounting plate on the mounting surface. Tighten the
mounting nut. Tighten the tensioning screws.
All models:
Connect the connecting hoses to the valve outlets.
Hold the hose steady with one wrench
while tightening the hose nut with a
second wrench.
Do not allow the hose to twist.
Install the hot and cold supply lines (not included).

9
Install the transfer valve trim
Install the sleeve on the transfer valve.
Push the handle over the stem. Secure it using the screw.
Line up the locator tab on the screw cover with the notch in
the handle. Press down rmly.
Install the handles
Citterio/Carlton/Phoenix/Terrano
Install the escutcheons on the mounting plates.
Position the handle over the valve with the lever or cross in
the desired o position.
Hold the lever or cross steady with one hand.
Connect the handle to the valve by rotating the valve
clockwise.
Uno / Steel
Install the snap connectors and screws on the valves.
Install the escutcheons.
Position the handle over the valve.
Press downward rmly, so that the handle snaps into place
over the snap connector.

10
Starck
Position the handle over the valve.
Hold the lever steady with one hand.
Secure the handle to the mounting plate by rotating the
escutcheon clockwise with the other hand..
Montreux
Position the handle over the valve.
While holding the cross steady with one hand, use the other
hand to turn the escutcheon clockwise to thread it onto the
valve.
Lightly grease the o-rings. Press the hot and cold caps into
place on the handles.
User Instructions
Turn the left handle to obtain hot water, the right handle for cold water.
Turn the transfer valve handle to select between the vertical spray and the rim wash.
While the vertical spray is functioning, water will also come from the rim wash.
