Congratulations on the purchase of your Hapro appliance. Your new appliance has been
manufactured with the utmost care and attention and consists of high-quality parts. All Hapro
appliances have been developed to give you the best possible tan, whilst complying with the
strictest applicable European standards. (original instructions )
Lamp information ............................................4
Operation ..................................................5
Symbols ...................................................14
Warranty policy.............................................15
Declaration of Confirmity .....................................16
Contents
This manual provides the required information on warnings, instructions and assembly. You should use this manual for more
than just the necessary appliance assembly and/or maintenance instructions; you need to familiarize yourself with all of the
information provided. Persons who use the tanning appliance need to be informed and supervised, and it is your duty to make
sure they receive proper assistance. Digital version at www.hapro.com.

4
Model : XXXXX
Type : XXXXXXXX
Serial number : XXXXXXXXXX / 3
Rated voltage : XXXXXXXX
Rated power input : XXX W
Manufactured by: Hapro International B.V.
PO Box 73
4420 AC Kapelle, Netherlands
XXXXX_XX
UV type 3 (Total Erythema output limited at 0,3W/m3)
48 x maxlight XL 120W-R CE III
120-R-(27-36)/(2,8-3,8) Ballast: 200W
Lamp information
The lamps listed below are those that are installed as standard equipment at the factory. These standard lamps have been selected for
optimal tanning results and to match the UV classication of your tanning unit. We recommend that when you replace a lamp you only use
lamps of the type currently installed in your tanning unit and which are listed in the table below and on the identication plate. If you choose
to install a dierent type of lamp, you must only use lamps that are marked with an equivalent code which indicates that the UV component
falls within the equivalence range listed on the identication plate
Note: • The equivalent code is only applicable to low-pressure uorescent lamps.
• The total erythema is limited to 0.3 W/m².
Example:
On the example identification plate the equivalent codes for the installed lamps are circled.
The equivalent code for the canopy is 120-R-(27-36)/(2,8-3,8)
120 = the wattage of the lamp
R = the reector type
(27-36) = the equivalence range for the total eective erythema
(2,8-3,8) = the equivalence range for the NMSC ratio
If you intend to install a new lamp, the wattage and reector type must always match the equivalent code
on the identication plate. The eective erythema and NMSC ratio must also match the specied range.
You may only use a lamp other than the recommended type if all of these criteria are met. You must also be
aware that:
a. The tanning unit is likely to be less eective in terms of tanning performance.
b. The circuit protection for your tanning unit must be adapted because the electrical current
consumption will have changed.
c. The UV classication no longer matches the original classication shown on the identication plate.
d. We will not necessarily honour warranty claims arising from the use of lamps other than those we
recommend, because the technical operation of your tanning unit might be aected.
LAMPS ART NR EQUIVALENT CODES UV TYPE (EU) UV TYPE (NON EU)
Maxlight XL 180W-R CE III 12818 180-R-(21-28)/(2-2,6) 3 2
Maxlight XL 180W-R High Intensive 12821 180-R-(86-114)/(6,7-9,1) 5 5
Maxlight XL 200W-R High Intensive S 18525 200-R-(83-111)/(6,8-9,2) 5 5
Maxlight XL 180W-R CE III S 18067 180-R-(21-28)/(1,7-2,3) 3 2
Maxlight XL 180W-R CE III E 27353 180-R-(26-34)/(2-2,8) 3 2
Maxlight XL 180W-R High Intensive E 27354 180-R-(106-141)/(6,9-9,3) 5 5
Maxlight XL 200W-R Ultra Intensive E 27355 180-R-(138-184)/(8,8-12) 5 5

2
3
4
5
6
7
8
9
10
11
2
3
4
5
6
7
8
9
10
Operation
5
Display
Start/ Stop
Plus
Min
Bodycooling
Volume
Chanal
Switch song
Xsens
Qsens

Control functions
+
6
STARTING THE APPLIANCE IN STANDALONE MODE
Press start/stop
The display shows the maximum tanning time.
The LEDs above plus/minus ash red.
Set the desired time.
Press start/stop to conrm the set time.
The tanning lamps now switch on.
The timer counts down.
STARTING THE APPLIANCE WITH AN EXTERNAL TIMER OR COINBOX
The appliance will be started automatically if there is no‘remote start’ present on the external timer or coinbox.
If this is present, the LED above the start/stop button will ash green. The tanning session begins as soon as the
start/stop button is pressed. The timer counts up.
PAUSE MODE
Press start/stop. The lamps are switched o. NOTE! The session time continues counting.
Press start/stop again to restart the tanning session.
In stand-alone mode the session can be ended at any time by holding the start/stop button for three seconds.
The appliance is set up for standard use with an external timer or a coinbox. If the appliance must function without the external timer or coinbox,
i.e. with an internal timer, the required tanning time will have to be adjusted according to the following procedure.
Note: If an external timer or coinbox does not have a ‘remote start’ function and instead the appliance must be started with
the start/stop button, this can be congured by your dealer.

+
+
+
+
7
BODYCOOLING
Press the body cooling button.
The LED above the button begins to ash.
The LEDs above plus/minus ash red.
Set the desired value. The standard value is 1.
After 5 minutes, you can't turn of the body cooling.
VOLUME WITH SOUND SYSTEM ONLY
Press the volume button.
The LED above the button begins to ash.
The LEDs above plus/minus ash red.
Set the desired value. The standard value is 4.
The LED will remain lit as long as the volume button is depressed.
MUSIC CHANNEL SELECTION WITH SOUND SYSTEM ONLY
Press the channel button. (option)
The LED above the button begins to ash.
The LEDs above plus/minus ash red.
Set the desired value.
The LED above channel will remain lit as long as the volume is on.
SWITCH SONG WITH SOUND SYSTEM ONLY
The function is only available if the channel is set to BT, C1 or C2.
The LED above the button begins to ash.
The LEDs above plus/minus ash red.
The previous or next song can now be selected with the plus and minus buttons.
Due to a bug in old Android and Windows Phone software it is possible that this function is not working. To solve this
problem: switch o and then back on the Bluetooth*on the phone. The problem should be solved after reconnecting to the
appliance.
XSENS OPTIONAL
Press the Xsens button.
The text‘ON’now appears on the display; Xsens is on. The LED above Xsens is now on.
Switch o Xsens by pressing the Xsens button again.
The text‘OFF’now appears on the display. The LED above Xsens is now o.
*The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by VDL Hapro is under licence.

ambient
8
QSENS OPTIONAL
Press the Qsens button.
The text‘ON’now appears on the display; Qsens is on. The LED above Qsens is now on.
Switch o Qsens by pressing the Qsens button again.
The text‘OFF’now appears on the display. The LED above Qsens is now o.
WARNINGS
Unknown fault, caused by newer control section
Time error in switching section or relay fault
Overheating appliance
Communication error
Internal fault in switching section, sense controller not communicating
Touch panel communication not present
Lamp hours exceeded
See section ‘resetting the hour counters’to clear the LH message from the display.
AMBIENT FLOWLIGHT SWITCH OFF OPTIONAL
To switch o the Ambient Flowlight, hold the bodycooler button for ve seconds.
Press any button to switch the Ambient Flowlight back on.
Note: If an option is not installed, "NA" appears in the display
Note: When one of the above-mentioned fault messages appears on the display, you should no longer use the tanning
appliance and the plug should be removed from the mains outlet. Contact your dealer. (This does not apply to the LH message.)

ambient
+
+
+
+
+
Reading the hour counters and software versions
9
STATUSMENU
Hold the body cooling and plus buttons for ve seconds.
You now see the unit status menu.
The hour counters and software versions can be viewed here.
RESETTING THE HOURS COUNTERS
Select LH.
Hold the start/stop button for three seconds.
Enter the PIN code and press start/stop. It is set to 000 by default.
The hour counters are reset.
Maintenance
CLEANING
The tanning appliance is equipped with a touch panel control. To prevent accidental operation of the machine
during cleaning, you can temporarily switch o the control.
Hold the plus and minus buttons for ve seconds.
The display counts down from 60 to 0.
During this period the display cannot be operated.
The time you have to clean the machine can be changed.
The standard cleaning time is 1 minute.
REPLACING THE QSENS OPTION LIQUID JUG
Never rell your Qsens liquid jug with regular tap water or any other liquid. Replace with an original Hapro Sanitized Qsens liquid jug. Remember to order the
Qsens liquid jugs in time. Before Qsens can be used for the rst time or after replacement of the liquid jug, the system must be bled of air.
Hold the body cooling and minus buttons for ve seconds.
Enter the PIN code; it is set to 000 by default. Press start/stop to conrm the PIN code.
You are now in the parameter menu.
Navigate to‘05 - Qsens’with plus and minus, and press start/stop to conrm your choice.
Navigate to‘03 - Qsens initialization’with plus and minus, and press start/stop to conrm your choice.
Navigate to‘YES’with plus and minus to immediately start the initialization.
Wait until the Qsens nozzles produce a ne mist of water.
Press plus or minus to stop the initialization.
Press 3x the body cooling button to exit the parameter menu.
Your Qsens set is now ready for use.

SmartVoice
Studio
Wellness
1
3
2
6
4
5
10
REPLACING THE XSENS OPTION CARTRIDGES
If you purchased an Xsens I set, you can replace an empty can with a full one.
CHANGING SOUNDAROUND OPTION MEMORY CARDS
You can replace your SmartVoice card with a dierent SmartVoice card.
You can place your own music on the Studio card or Wellness card. Only use the supplied memory cards.

SmartVoice
Studio
Wellness
1
3
2
6
4
5
+
+
+
11
DISPLAY DEFAULT
1Unit
1. Start time (minutes) 0 = Coin unit / 1 - maximum time = Stand alone 0
2. Maximum time Time at which the decorative lighting is switched on 30 (min.)
3. Special mode 1 = Restore factory settings / 6 = Reset TL hour meter 0
4. Pin code Unique code for entering the parameter menu 000
5. Usefull life lamps Step Size: 100 hours. 0 = no message 0 (hours)
6. Clean time (minutes) The length of time the display is switched o for cleaning 1 (min.)
2Bodycooler
1. Bodycooler at start Speed of the body cooler at the beginning of the session 1
3Xsens
1. Xsens available O
2. Xsens at start Xsens scent at the beginning of the session (0 = o) O
4SoundAround
1. My MP3 input present On
Tanning appliance settings
Note: If no button is pressed for one minute, you automatically return to the stand-by screen.
PARAMETERMENU
Hold the body cooling and minus buttons for ten seconds.
Enter the PIN code; it is set to 000 by default.
You can change the value of the digit with plus and minus.
Press the body cooling button to proceed to the next digit.
Press start/stop to conrm the PIN code.
PARAMETERS
The sunbed can be set to your preferences by changing the parameters shown here. The parameters that are not shown in the table may only be changed by
your dealer.
Navigate to the desired submenu with plus and minus, and press start/stop to conrm your choice.
Press the body cooling button to return to stand-by.
Navigate to the desired parameter menu with plus and minus, and press start/stop to conrm your choice.
Press the body cooling button to return to the parameter menu. Use plus and minus to change the value.
Save the new value with start/stop. You now return to the submenu.
Press the body cooling button to cancel the new value. You now return to the submenu.

12
2. Wellness card present On
3. Studio card present On
4. Bluetooth ID code ID on smartphone: LUXURA ## 00
5. Bluetooth PIN code Pincode Bluetooth connection 000
6. Number of external music channels 0
7. Smartvoice language 2
8. Volume My MP3 input 32
9. Volume My Bluetooth 32
10. Volume Wellness card 30
11. Volume Studio card 30
12. 12-19 Volume channel 1/ channel 8 26
20. SmartVoice volume 26
21. Tone high 9
22. Tone low 11
23. Standby volume 0
24. Standby channel 0= MP3 input (Display: np3) 1= Bluetooth (Display: bt)
2= Wellness card (Display: C1) 3= Studio card (Display: C2)
4-11 = Studio channel (Display: C3-C10) 2
25. Start volume 4
26. Start channel 0= MP3 input (Display: np3) 1= Bluetooth (Display: bt)
2= Wellness card (Display: C1) 3= Studio card (Display: C2)
4-11 = Studio channel (Display: C3-C10) 3
27. Start audio volume On
5Qsens
1. Qsens at start State of the Qsens at the beginning of the session O
3. Qsens initialization Bleeding of the Qsens system O
7. Spray time nozzle 1 4 (sec.)
10. Interval time Qsens session 2 (min.)
6Coin
1. Relais puls 1 (sec.)
2. Direct on Whether or not turn on directly after coin signal On
3. ATF Mode O
7Ambient Flowlight
1. Eect Colour programme 1
0 = single color (see color sub: 4. color number)
1 = all colors
2 = base colors quickly
3 = base colors slowly
4 = shades of white
5 = soft colors
6 = shades of white (base white)
7 = shades of red, orange and yellow
8 = shades of purple and pink
9 = shades of red
10 = shades of orange
11 = shades of yellow
12 = shades of green
13 = shades of blue
14 = shades of purple
15 = shades of pink
2. Eect speed Speed at which the colour programme cycles (1-20) 10
3. Ambient Flowlight at start Decorative lighting at the beginning of the session On
4. Color number Colour 27

13
0 = o
1 = red
3 = orange
5 = yellow
7 = bright green
11 = green
15 = ice blue
20 = blue
23 = purple
28 = pink
30 = dark red
31 = white

14
SENSSENSSENSSENS
SENSSENS
Symbols
Warning symbol:
People with long hair should wear a hairnet!
Warning symbol:
Wear the protective goggles provided
Warning symbol:
Attention please!
Warning symbol:
Sunbed should be disconnected from power source
Warning symbol:
Remove plug from socket
Warning symbol:
Not for household use
Symbol:
Facial tanner
Symbol:
Vertical sunbed
Symbol:
Only applicable if this option is ordered

15
SENSSENSSENS
SENS
SENSSENS
Symbols
Warning symbol:
People with long hair should wear a hairnet!
Warning symbol:
Wear the protective goggles provided
Warning symbol:
Attention please!
Warning symbol:
Sunbed should be disconnected from power source
Warning symbol:
Remove plug from socket
Warning symbol:
Not for household use
Symbol:
Facial tanner
Symbol:
Vertical sunbed
Symbol:
Only applicable if this option is ordered
Our appliances are manufactured with the great-
est attention and are of excellent quality.
Every Luxura appliance is manufactured to meet
the international IEC/EN standards and carries the
Kema seal of approval. We provide a manufactur-
er’s warranty of 1 year.
Your new appliance has a manufacturer’s guaran-
tee of 1 year, which commences on the date of in-
stallation. Within the warranty period all faults that
are the result of material or manufacturing errors
will be repaired at no cost. Please contact your
dealer for any warranty enquiries.
In order to make a claim under the terms of this
guarantee, you must be able to produce the origi-
nal invoice or receipt bearing the date of purchase.
The type and serial number of the appliance
should also be indicated.
The warranty is subordinate to the national regula-
tions on product warranties.
Warranty
Units which have the type, serial number and/or
other identication labels removed, damaged or
altered.
Lamps, starters and acrylic sheets.
Damage due to purchaser abuse, neglect, trans-
port, improper use or improper maintenance.
Damage due to use of accessories not originally
supplied by Hapro or inferior accessories.
Damage due to installation, repair or assembly not
done by Hapro authorised personnel.
Damage due to re, lightning, earthquakes or oth-
er natural disasters.
Not covered under this warranty

16
28453_01.1
02/11/2014
VDL Hapro
Declaration of Conformity
Manufacturer
VDL Hapro bv
Fleerbosseweg 33
4420 AC Kapelle, The Netherlands
www.vdlhapro.com
Product identification
Product: Tanning equipment
Model:
Type:
This document is valid for all above mentioned
types produced from:
Means of conformity
The products are in conformity with Directive 2004/108/EC of the European Community and the Low-
Voltage Directive 2006/95/EC of the European Community.
Testing, Electro-Magnetic Compatibility
Carried out by: VDL Hapro Laboratory
Fleerbosseweg 33
4420 AC Kapelle, The Netherlands
Standards used: EN 61000-6-3:2007+A1: 2011; EN 55014-1:2006+A1:2009, +A2:2011
EN 61000-3-2:2006+A1:2009, +A3:2009; EN 61000-3-3:2008;
EN 61000-6-1:2007; EN 61000-4-2:2009; EN 61000-4-3:2006+A1:2008,
+A2:2010; EN 61000-4-4:2012; EN 61000-4-5:2006; EN 61000-4-6:2009;
EN 61000-4-8:2010
2112431.0551-QUA/EMC
Testing, Low-Voltage Directive
Carried out by: VDL Hapro Laboratory
Fleerbosseweg 33
4420 AC Kapelle, The Netherlands
Standards used: EN 60335-1:2012/C11:2014
EN 60335-1:2012/A11:2014
EN 60335-2-27:2014
Representative
Name: D.C. van de Linde
Function: Managing Director
Date:
Signature:
ENG
EN 60335-1:2012/C11:2014
EN 60335-1:2012/A11:2014
EN 60335-2-27:2014
EN 61000-6-3:2007+A1: 2011; EN 55014-1:2006+A1:2009, +A2:2011
EN 61000-3-2:2006+A1:2009, +A3:2009; EN 61000-3-3:2008;
EN 61000-6-1:2007; EN 61000-4-2:2009; EN 61000-4-3:2006+A1:2008,
+A2:2010; EN 61000-4-4:2012; EN 61000-4-5:2006; EN 61000-4-6:2009;
EN 61000-4-8:2010
Luxura V6
42 XL Intensive, 42 XL High Intensive,
42 XL Ultra High Intensive, 44 XL Intensive,
44 XL High Intensive, 44 XL Ultra Intensive
48 XL Ultra High Intensive
02-11-2014

17
28454_01.1
02/11/2014
VDL Hapro
Declaration of Conformity
Manufacturer
VDL Hapro bv
Fleerbosseweg 33
4420 AC Kapelle, The Netherlands
www.vdlhapro.com
Product identification
Product: Tanning equipment
Model:
Type:
This document is valid for all above mentioned
types produced from:
Means of conformity
The products are in conformity with Directive 2004/108/EC of the European Community and the Low-
Voltage Directive 2006/95/EC of the European Community.
Testing, Electro-Magnetic Compatibility
Carried out by: VDL Hapro Laboratory
Fleerbosseweg 33
4420 AC Kapelle, The Netherlands
Standards used: EN 61000-6-3:2007+A1: 2011; EN 55014-1:2006+A1:2009, +A2:2011
EN 61000-3-2:2006+A1:2009, +A3:2009; EN 61000-3-3:2008;
EN 61000-6-1:2007; EN 61000-4-2:2009; EN 61000-4-3:2006+A1:2008,
+A2:2010; EN 61000-4-4:2012; EN 61000-4-5:2006; EN 61000-4-6:2009;
EN 61000-4-8:2010
2112431.0551-QUA/EMC
Testing, Low-Voltage Directive
Carried out by: VDL Hapro Laboratory
Fleerbosseweg 33
4420 AC Kapelle, The Netherlands
Standards used: EN 60335-1:2012/C11:2014
EN 60335-1:2012/A11:2014
EN 60335-2-27:2014
Representative
Name: D.C. van de Linde
Function: Managing Director
Date:
Signature:
ENG
Luxura V8
48 XL Intensive, 48 XL High Intensive,
48 XL Ultra High Intensive
02-11-2014
EN 60335-1:2012/C11:2014
EN 60335-1:2012/A11:2014
EN 60335-2-27:2014
EN 61000-6-3:2007+A1: 2011; EN 55014-1:2006+A1:2009, +A2:2011
EN 61000-3-2:2006+A1:2009, +A3:2009; EN 61000-3-3:2008;
EN 61000-6-1:2007; EN 61000-4-2:2009; EN 61000-4-3:2006+A1:2008,
+A2:2010; EN 61000-4-4:2012; EN 61000-4-5:2006; EN 61000-4-6:2009;
EN 61000-4-8:2010

18

19

VDL Hapro
© VDL Hapro bv - 28400 rev. 04 / 2014
