Harken 3813 User manual

Please read these instructions carefully before installing, servicing, or operating the equipment.
This manual may be modified without notice. See: www.harken.com/manuals for updated versions.
PLEASE SAVE THESE INSTRUCTIONS
BATTCAR INSTALLATION MANUAL
System AA
Installation manual – Intended for specialized personnel or expert users
4247 10/14
Introduction
Safety precautions 2
Preassembly (slug mount/drill & tap)
Parts 3
Tools 4
Sizing 4
Sail modifications 4
Track length (slug mount only) 4 - 5
Cutting top track to length (slug mount only) 6
Check fit of mounting slugs/cars (sug mount only) 7
Installation (slug mount)
Install track 8 - 10
Install screwpin endstop kit 10
Preassembly (drill & tap)
Parts 4, 11
Track length 11
Remove old track 11
Installation (drill & tap)
Drill, tap, and fasten 11 - 12
Operation (slug mount/drill & tap)
Load cars on track without sail 13
Load cars on track with sail 14
Lost balls 14
Load sail on cars 15
Maintenance (slug mount/drill & tap)
Car maintenance/cleaning 16
Removing sail 16
Lazy jacks 16
Operating precautions 16
Sailmaker's instructions (slug mount/drill & tap)
Dimensions 17
Installing 3813 headboard coupler assembly 17
Headboard pates 17
Distance between atachment points/reef points 18
Attaching sail to intermediate cars 18
Troubleshooting – installation/operation

2 System AA (CB)
Introduction
WARNING! Strictly follow all instructions to avoid potential hazards that may kill or hurt you and others.
See www.harken.com/manuals for general warnings and instructions.
WARNING! This symbol alerts you to potential hazards that may kill or hurt you and others if you don't follow
instructions. The message will tell you how to reduce the chance of injury.
This manual gives technical information on installation and service. This information is destined exclusively for specialized personnel
or expert users. Installation, disassembling, and reassembling by personnel who are not experts may cause serious damage to property
or injury to users and those in the vicinity of the product. If you do not understand an instruction contact Harken.
The user must have appropriate training in order to use this product.
Harken accepts no responsibility for damage or harm caused by not observing the safety requirements and instructions in this manual.
See limited warranty, general warnings, and instructions in www.harken.com/manuals.
Purpose
Harken Battcars are designed to reduce the size of or completely drop the mainsail on a sailboat so wind has little effect on the sail.
Use of this product for other than normal sailboat applications is not covered by the limited warranty.
Safety Precautions
CAUTION! This symbol alerts you to potential hazards that may hurt you and others if you do not follow instructions.
The message will tell you how to reduce the chance of injury.

3813
Part No. Description Includes
Mounting slug method
3818, 3819
3820 Track Mounting Kit (a) 19 x mounting slugs 19 mm (3/4"); (b) 1 x connector slug 67 mm (2
5/8"); (c) 2 x tubes blue Loctite®
(d) 21 x HFS1009 flathead screws 4 x 20 mm.
3821, 3822
3823 Screwpin Endstop Kit (a) 1 x 152 mm (6") end track with screwpin stop; (b) 1 x flathead screw HFS948 4 x 25 mm; (c) 1 x topstop;
(d) 2 x HFS1009 flathead screws 4 x 20 mm; (e) 1 x mounting slug 19 mm (3/4"); (f) 1 x tube blue Loctite®.
3817 Track Section length: 2.05 m (6'8 7/8"). Number track sections vary according to luff length of mainsail.
Drill & tap method
3837 Screwpin Endstop Kit (a) 1 x 152 mm (6") end track with screwpin stop; (b) 1 x 2711 splice link; (c) 1 x H-28411C endstop (d) 1 x tube blue Loctite®
2707 Track (Micro CB) Use for masts without grooves or when slugs will not fit. Purchase stainless steel 4 mm (#8) screws separately.
Do not use 3817 open-backed track. It requires mounting slugs. See page 11 for drill/tap sizes and mounting instructions.
Track and Accessories
Part No. Description Comments
3813 Headboard car
3814 Slider intermediate car If battens are close enough intermediate cars are not needed.
3815 CB intermediate car If battens are close enough intermediate cars are not needed.
3816 Batten car 10 mm Threaded stud. Purchase batten receptacle separately.
Cars
3816
Batten cars without receptacle
3815
3814
Spare car
screw/nut
Track
drill/tap type
9 mm
(3/8")
13 mm
(1/2")
2707
Preassembly – CB System (Slug Mount/Drill & Tap) Parts
System AA (CB) 3
Track mounting kit
3818, 3819, 3820
(mounting slug method)
b
d
a
c
a
bc
d
e
f
Screwpin endstop kit
3821, 3822, 3823
(mounting slug method)
d
a
b
c
Screwpin endstop kit
3837
(drill & tap method)
12 mm
(15/32")
13 mm
(1/2")
Track
mounting slug type
Loctite is a trademark of Henkel AG & Company KGaA

Sizing
Make sure that you have the correct size battcar system for your boat.
Sail Modifications
See page 12 - 13.
1. Mainsail Headboard
A. Drill new halyard location
B. Drill Attachment to accept clevis pin for 3813 headboard
car coupler.
2. Batten receptacle on sail to accept 10 mm threaded stud.
Note: Harken does not supply receptacle.
3. Becket spacer on sail for 3815 intermediate car, or install
3814 slider on sail.
Number of 3817 Track Sections (Slug Mount)
Determine Track Length
Note: Track length is longer than sail luff length.
1. Upper End: Extend track 8" (203 mm) above headboard
halyard attachment point to allow for sail stretch as sail ages.
Track must not block mast halyard exit.
2. Lower End: Place 6" (152 mm) Screwpin Endstop track on
mast. Make sure car clears gooseneck fittings and adjust
height as necessary. Measure to lower end of track.
Preassembly– CB System (Slug Mount/Drill & Tap) Tools/Sizing/Sail Modifications/Track Length
8"
203 mm
1
2
4 System AA (CB)
Maximum Sail Area Part No. Part No. Part No.
Monohull Multihull Headboard Battcars Intermediate Car
300 ft228 m2250 ft223 m23813 3816 3814, 3815
Variable length top track included
Track length Number of 2.05 m (6'8 7/8")
track sections
6.350 m to 8.382 m
20'10" to 27'6"
8.407 m to 10.439 m
27'7" to 34'3" 5
10.465 m to 12.471 m
34'4" to 40'11" 6
12.497 m to 14.529 m
41'0" to 47'8" 7
Tools you will need
2
57
1
6
4
1.Tape measure 10. Putty knife
2. Tape 11. Hex wrench (4 mm)
3. Power drill (screwdriver) 12. Nut driver (8 mm) or open wrench
4. Drill bit 3/16" (4.5 mm) Drill & tap (additional)
5. Phillips screwdriver 13. Spring clamp
6. Hammer 14. Spring-loaded centerpunch (not shown)
7. Hacksaw 15. Drill bit 1/8" (3 mm) (not shown)
8. Center punch 16. Tap 8-32 (M4) (not shown)
9. File 17. Transfer punch
Mast-up installation: Stepladder secured to the boat.
Work height: 7' (2.13 m) above boom
8
910
3
11
12 13
17

System AA (CB) 5
Round track length to nearest 1" (25 mm).
Note: Chart is based on using 3817 track–length 2.05m (6'8 7/8") and 3821, 3822, or 3823 Endstop Kits–length 152.4 mm (6").
Pre-Assembly (Slug Mount) Top Track Length
Total track length (as defined on page 3) Top track length
20'10" 6.350 m 27' 7" 8.407 m 41' 0" 12.497 m 13/16"30 mm
20'11" 6.375 m 27' 8" 8.433 m 34' 4" 10.465 m 41' 1" 12.522 m 2" 51 mm
21' 0" 6.401 m 27' 9" 8.458 m 34' 5" 10.490 m 41' 2" 12.548 m 3" 76 mm
21' 2" 6.452 m 27'11" 8.509 m 34' 7" 10.541 m 41' 4" 12.598 m 5" 127 mm
21' 4" 6.502 m 28' 1" 8.560 m 34' 9" 10.592 m 41' 6" 12.649 m 7" 178 mm
21' 6" 6.553 m 28' 3" 8.611 m 34'11" 10.643 m 41' 8" 12.700 m 9" 229 mm
21' 8" 6.604 m 28' 5" 8.661 m 35' 1" 10.693 m 41'10" 12.751 m 11" 279 mm
21'10" 6.655 m 28' 7" 8.712 m 35' 3" 10.744 m 42' 0" 12.802 m 1' 1" 330 mm
22' 0" 6.706 m 28' 9" 8.763 m 35' 5" 10.795 m 42' 2" 12.852 m 1' 3" 381 mm
22' 2" 6.756 m 28'11" 8.814 m 35' 7" 10.846 m 42' 4" 12.903 m 1' 5" 432 mm
22' 4" 6.807 m 29' 1" 8.865 m 35' 9" 10.897 m 42' 6" 12.954 m 1' 7" 483 mm
22' 6" 6.858 m 29' 3" 8.915 m 35'11" 10.947 m 42' 8" 13.005 m 1' 9" 533 mm
22' 8" 6.909 m 29' 5" 8.966 m 36' 1" 10.998 m 42'10" 13.056 m 1'11" 584 mm
22'10" 6.960 m 29' 7" 9.017 m 36' 3" 11.049 m 43' 0" 13.106 m 2' 1" 635 mm
23' 0" 7.010 m 29' 9" 9.068 m 36' 5" 11.100 m 43' 2" 13.157 m 2' 3" 686 mm
23' 2" 7.061 m 29'11" 9.119 m 36' 7" 11.151 m 43' 4" 13.208 m 2' 5" 737 mm
23' 4" 7.112 m 30' 1" 9.169 m 36' 9" 11.201 m 43' 6" 13.259 m 2' 7" 787 mm
23' 6" 7.163 m 30' 3" 9.220 m 36'11" 11.252 m 43' 8" 13.310 m 2' 9" 838 mm
23' 8" 7.214 m 30' 5" 9.271 m 37' 1" 11.303 m 43'10" 13.360 m 2'11" 889 mm
23'10" 7.264 m 30' 7" 9.322 m 37' 3" 11.354 m 44' 0" 13.411 m 3' 1" 940 mm
24' 0" 7.315 m 30' 9" 9.373 m 37' 5" 11.405 m 44' 2" 13.462 m 3' 3" 991 mm
24' 2" 7.366 m 30'11" 9.423 m 37' 7" 11.455 m 44' 4" 13.513 m 3' 5" 1.041 m
24' 4" 7.417 m 31' 1" 9.474 m 37' 9" 11.506 m 44' 6" 13.564 m 3' 7" 1.092 m
24' 6" 7.468 m 31' 3" 9.525 m 37'11" 11.557 m 44' 8" 13.614 m 3' 9" 1.143 m
24' 8" 7.518 m 31' 5" 9.576 m 38' 1" 11.608 m 44'10" 13.665 m 3'11" 1.194 m
24'10" 7.569 m 31' 7" 9.627 m 38' 3" 11.659 m 45' 0" 13.716 m 4' 1" 1.245 m
25' 0" 7.620 m 31' 9" 9.677 m 38' 5" 11.709 m 45' 2" 13.767 m 4' 3" 1.295 m
25' 2" 7.671 m 31'11" 9.728 m 38' 7" 11.760 m 45' 4" 13.818 m 4' 5" 1.346 m
25'4" 7.722 m 32' 1" 9.779 m 38' 9" 11.811 m 45' 6" 13.868 m 4' 7" 1.397 m
25' 6" 7.772 m 32' 3" 9.830 m 38'11" 11.862 m 45' 8" 13.919 m 4' 9" 1.448 m
25' 8" 7.823 m 32' 5" 9.881 m 39' 1" 11.913 m 45'10" 13.970 m 4'11" 1.499 m
25'10" 7.874 m 32' 7" 9.931 m 39' 3" 11.963 m 46' 0" 14.021 m 5' 1" 1.549 m
26' 0" 7.925 m 32' 9" 9.982 m 39' 5" 12.014 m 46' 2" 14.072 m 5' 3" 1.600 m
26' 2" 7.976 m 32'11" 10.033 m 39' 7" 12.065 m 46' 4" 14.122 m 5' 5" 1.651 m
26' 4" 8.026 m 33' 1" 10.084 m 39' 9" 12.116 m 46' 6" 14.173 m 5' 7" 1.702 m
26' 6" 8.077 m 33' 3" 10.135 m 39'11" 12.167 m 46' 8" 14.224 m 5' 9" 1.753 m
26' 8" 8.128 m 33' 5" 10.185 m 40' 1" 12.217 m 46'10" 14.275 m 5'11" 1.803 m
26'10" 8.179 m 33' 7" 10.236 m 40' 3" 12.268 m 47' 0" 14.326 m 6' 1" 1.854 m
27' 0" 8.230 m 33' 9" 10.287 m 40' 5" 12.319 m 47' 2" 14.376 m 6' 3" 1.905 m
27' 2" 8.280 m 33'11" 10.338 m 40' 7" 12.370 m 47' 4" 14.427 m 6' 5" 1.956 m
27' 4" 8.331 m 34' 1" 10.389 m 40' 9" 12.421 m 47' 6" 14.478 m 6' 7" 2.007 m
27' 6" 8.382 m 34' 3" 10.439 m 40'11" 12.471 m 47' 8" 14.529 m 6'8 7/8" 2.054 m

2. Deburr cut.
Slightly round track corners that will slide against mast.
1. Cut special length top track from 2.05 m (6'8 3/4") track.
3. Drill 4.5 m (3/16") top stop hole in cut end of track.
Use existing hole if top track is 30 mm (1 3/16").
3/8" (10 mm)
Preassembly – CB System (Slug Mount) Cut Top Track to Length
6 System AA (CB)

System AA (CB) 7
Preassembly – CB System (Slug Mount) Check Fit of Mounting Slugs/Cars
Clear of Storm Trysail Track?
67 mm (2 5/8") connector slug must fit feeder opening. File opening to
make longer.
Use halyard with retrieval line to hoist 67 mm (2 5/8") connector slug
up mast to check for burrs in groove.
Mast prebend: May require straightening before installation.
Storm Trysail Track
Car’s 40 mm (1 9/16") width must clear storm trysail track.
Tracks often converge above spreaders.
Aft face of mast must be flat or convex.
Check Fit
40 mm (1 9/16")
11 or
more
Will tighten Will not tighten
Test track: Put mounting slug in groove, track section on mast.
Tighten with screw. Track must be drawn tightly to mast.
Mounting screw must be long enough for mast groove. If
necessary, purchase longer screws.
Warning! Screws need minimun 11 threads (turns) engaged
to hold track to mast. Turn screw 360° five times after threads
engage slug.

1. Slip top track slugs into mast groove. Use 19 mm (3/4") mounting
slug for top stop.
Note: If top track is 30 mm (1 3/16"), use 67 mm (2 5/8") connector
slug for top stop.
Install 67 mm (2 5/8") connector slug at bottom.
Mast up: Tape 32 mm (1 1/4") slug even with top of upper track.
Tape other slugs in place.
2. Squeeze one drop blue Loctite®into each connector slug hole.
3. Thread 4 mm x 25 mm endstop screw through endstop, track, and
into endstop slug.
Mast up: Remove tape. Tighten screw to hold track.
Installation – CB System (Slug Mount) Install Track
8 System AA (CB)
Loctite is a trademark of Henkel AG & Company KGaA

Installation – CB System (Slug Mount) Install Track
System AA (CB) 9
4. Slide slugs into place with putty knife. Loosely install 4 mm x 20 mm screws.
Tip: Use putty knife to see if screws are loose enough to slide in groove.
Remember: Tracks may stick when reaching a spliced area on mast.
5. Loosen top screw. Slide top track up and position next 2.05 m (6'8 7/8") track.
Mast up: Tighten bottom screw to hold track.
6. Slide 19 mounting slugs and then the connector slug into mast groove.
Mast up: Tape in place.
One drop blue Loctite®into each hole.
Loctite is a trademark of Henkel AG & Company KGaA

Installation – CB System (Slug Mount) Install Track
10 System AA (CB)
7. Hold full-length track piece up to mast. Loosely install top screw.
Use putty knife to slide additional slugs and connector slug into place.
Loosely install all nineteen 4 mm x 20 mm screws.
8. Slide tracks up enough to fit next track.
Mast up: Hold upper tracks. Loosen screw that holds tracks. Slide track up.
Tighten new bottom screw securely.
9. Repeat until full-length tracks installed.
10. Raise tracks so 152 mm (6") bottom
track fits.
11. Install Screwpin Endstop Kit.
Note: If bottom full-length track blocks
feeder gap, load bottom track slugs
before installing track.
CAUTION! Do not let tracks drop.
Severe injury to hands and/or fingers can result.

2707
2711
Preassembly/Installation – CB System (Drill & Tap) Parts/Remove Track/Install Track
System AA (CB) 11
Important! Be careful not to lose
the threaded backing plate.
3837
Screwpin
endstop kit
H-45685
H-34380A
H-34382A
H-28411C
2711
Remove old track
IMPORTANT! Before removing old track,
scribe pencil line down either side.
Drill, Tap, and Fasten
After old track is removed, attach string to mast to line up track during installation.
1. Start at one end of track and work down: Do not drill and tap from
both track ends.
Clamp or duct tape track on mast. Center punch in center of track hole.
Tip: Use a narrow shaft spring-loaded machinist's center
punch with plastic centering tube or a transfer punch.
Part No. Description Includes
Purchase from Harken
3837 Screwpin endstop
kit
(a) 1 x 152 mm (6") end track with screwpin stop; (b) 1 x 2711 splice link;
(c) 1 x H-28411C endstop (d) 1 x tube blue Loctite®
2707 Track (micro CB)
Use for masts without grooves or when slugs will not fit. Purchase stainless steel
4 mm (#8) screws separately. Do not use 3817 open-backed track. It requires
mounting slugs. See page 11 for drill/tap sizes and mounting instructions.
2711 Splice links One needed for each track joint
Purchase Separately
#8 (4 mm) Flathead screws Purchase 20 fasteners/meter of track
Drill 3 mm (1/8")
Tap 8-32 (M4)
Track and Accessories
Considerations for
Determining Track Length.
Note: Track is longer than sail luff length.
1. Upper end: Extend track 203 mm (8") above
headboard halyard attachment point to allow for
sail stretch as main ages. Track must not block
mast halyard exit.
2. Lower end: Place 152 mm (6") Screwpin
Endstop track on mast. Make sure car clears
gooseneck fittings and adjust height as
necessary. Measure to lower end of track.

12 System AA (CB)
2. Drill track hole, holding drill perpendicular to mast face. Tap threads and install
screws using blue Loctite®.
3. Align track at joints. Use 2711 splice links and round rods or dowels on
outside of track to align during installation. Hold in place with spring or “C”
clamps until track is secured.
Load all cars before installing bottom track and endstop.
Installation – CB System (Drill & Tap) Install Track
Loctite is a trademark of Henkel

System AA (CB) 13
IMPORTANT! Keep balls captive by loading cars onto track without sail installed. Car must have 20 balls per side.
Consult chart for correct type of balls.
DO NOT MIX CARS. High-load brown Torlon®balls are used in headboard and batten cars. Luff cars use low-load black Delrin®balls.
2. Load Intermediate car (if used). Alternate with batten cars until all cars are loaded.
Mast up: Use halyard to hold cars up.
1. Headboard cars: Hold car so cap screw head faces up. Align car on guide section of
loader track and gently roll onto upper tracks. If car sticks, realign and roll onto track.
Tip: To load headboard car assembly, angle headboard coupler, roll car onto track.
If necessary, remove headboard assembly.
3. Install Screwpin stop.
Installation – CB System (Slug Mount/Drill & Tap) Load Cars on Track
Part
No. Car Type
Car Length Bearings Number
per Car
Part
No. Balls/Set
Ball Ø
in mm Color Material in mm
3813 Headboard Cars 5 3/16 132 Brown Torlon®40 2708 20 3/16 5
3814 Slider Intermediate Car 1 3/4 44 — — — — — — —
3815 CB Intermediate Car 2 3/16 56 Black Delrin®40 HSB240 1 3/16 5
3816 Batten Car w/Threaded Stud 2 3/16 56 Brown Torlon®40 2708 20 3/16 5
Torlon is a registered trademark of Solvay Advanced Polymers.
Delrin is a registered trademark of E. I. du Pont de Nemours and Company or its affiliates.

Load Cars with Sail
Line up car on guide portion of loader. Press car towards mast and
carefully roll car onto track. Begin with upper cars and work down.
Lost Balls
Consult chart for ball type: Torlon®or Delrin®. Place car on edge with
retaining clip in place. Insert balls one-by-one from center of clip and
roll into return race. Do not overfill car.
Operation – CB System (Slug Mount/Drill & Tap) Load Cars on Track
14 System AA (CB)
Torlon is a registered trademark of Solvay Advanced Polymers.
Delrin is a registered trademark of E. I. du Pont de Nemours and Company or its affiliates.

System AA (CB) 15
Operation – CB System (Slug Mount/Drill & Tap) Load Sail on Cars
1. Beginning with lower cars, use 4 mm hex wrench and 8 mm wrench or
nut driver to attach sail to cars. Tighten locknut until bottom tip of fastener
is flush with nut.
4. Attach head of sail to headboard car with clevis pin and cotter pin.
2. Screw threaded stud to terminal.
3. Load toggle using 4 mm hex wrench and 8 mm wrench or nut driver.
Tighten locknut. Do not over tighten.

Car Maintenance/Cleaning
Clean beginning of season, or if cars bind.
Squirt detergent and water into ball bearings. Circulate by moving cars up and down.
Let stand. To remove detergent, spray water into ball bearings and circulate. Clean
tracks with detergent and water.
Use OneDrop™Ball Conditioner
Once dry, use only a single drop of McLube®OneDrop™ ball bearing conditioner.
Do not use spray lubricants because ball bearings may skid not roll. Apply one to
two drops of McLube®OneDrop™ to ball contact surfaces of track. Roll car back
and forth through OneDrop™ several times to distribute onto bearings. Wipe
remaining OneDrop™ off track. OneDrop™ is preferred but you can also use
one to two drops of alight machine oil. Too much attracts dirt.
Inspect
Inspect Battcars for loose locknuts. Replace. Inspect batten receptacles for
loose screws.
Removing Sail
From Cars: Remove clevis pin from head of sail. Use a 4 mm hex wrench
and a 8 mm wrench or nut driver on other cars.
Cars and Sail: Keep cars lined up with track when sliding off.
Inspect Cars: 20 balls per side. Replace 5 mm locknut after two removals.
HARKEN
HARKEN
Lazy Jacks
Use shock cord to hold lazy jacks open so
battcars and battens will not catch on them
when hoisting sail. This will also help stop
slapping of lazy jacks on sail. Attach one end
to lower spreader tips and the other to lazy
jacks. Make sure shock cord is long enough
so boom can swing out all the way
without damaging spreaders.
Operating Precautions
When lowering sail, do not let halyard go.
Ease cars down by keeping a wrap on winch.
On boats with unstayed masts, vang must
be used to prevent over rotation of upper
part of sail. Over rotation can damage
batten receptacles.
Maintenance – CB System (Slug Mount/Drill & Tap) Sail Removal/Lazy Jacks/Operating Precautions
16 System AA (CB)
Shock Cord
McLube is a trademark of McGee Industries, Inc.

3814
A
E
D
3813
A
D
E
3816
D
C
B
A
E
F
Installing 3813 Headboard Coupler Car Assembly
3813 headboard coupler attaches to standard headboards—some headboard modification required.
Maximum thickness of headboard plates and sail: 9/16" (14 mm)
Halyard Attachment Hole
Use aft hole if headboard has two.
If not, drill second hole to accept halyard
shackle pin. Locate hole approximately
63.5 mm (2 1/2") aft of existing hole.
Coupler Attachment Hole
Drill 11 mm (7/16") coupler attachment hole so
center is 101 mm (4") from top of headboard
and 25 mm (1") from front edge of boltrope.
Leave at least 9 mm between front of headboard
plate and front edge of coupler attachment hole.
Dimensions
3815
A
E
D
B
C
B
B
Sailmaker's Instructions – CB System (Slug Mount/Drill & Tap) Dimensions/Installing Headboard Coupler Car
Part
No.
A B C D E
Locknut Size
mm
F
Stud Size
mm
in mm in mm in mm in mm
3813 5
3
/ 16 132 1 25 1
13
/ 16 46 2
3
/ 4 70 5 —
3814 1
3
/ 4 44 1 25 — —
3
/ 4 19 5 —
3815 2
3
/ 16 56 1 25 — —
3
/ 4 19 5 —
3816* 2
3
/ 16 561 1 25 1
3
/4 45 3
5
/ 16 84 5 10
*Batten receptacle not included
System AA (CB) 17

Distance Between Attachment Points
Battens and intermediate cars placed at sailmaker's discretion.
Maximum distance between attachment points is 1.2 m to
1.35 m (4' to 4'6").
Distance may be slightly greater. Contact Harken to discuss
sail reshaping to eliminate luff flutter.
Note: Adding battens may reduce stack height by eliminating
luff cars.
Setting Reef Points
Space reef points halfway between sail attachment points.
Battens or reef points may need to be moved—Diagram A.
Note Batten fittings and cars cannot handle reefing outhaul or
downhaul loads. Transfer loads to tack fitting—Diagram B.
Diagram B
Diagram A
Attach Sail to Intermediate Cars
Sail setback from luff tape to intermediate car clevis pin:
3814 – 20 mm (13/16")
3815 – 20 mm (13/16")
Plastic spacers come with 3814 and 3815 intermediate cars. Seize spacer to webbing by stitching just behind plastic spacer.
Seize webbing to sail by stitching up against sail.
See Above
Sailmaker's Instructions – CB System (Slug Mount/Drill & Tap) Attachment Points/Reef Points
18 System AA (CB)
INCORRECT
CORRECT
Sailmaker's Instructions – (CB/Slider Systems) Attaching Sail to Intermediate Cars

System AA (CB) 19
General Maintenance (see specific maintenance on page 16)
Harken equipment is designed for minimal maintenance, but some maintenance is required for optimum and safest possible operation
and to comply with the Harken limited warranty. In general, the most important aspect of maintenance is to keep your equipment clean
by frequently flushing with fresh water.
In corrosive atmospheres, stainless parts may show discoloration around holes, rivets and screws. This is not serious and may be
removed with a fine abrasive.
With the exception of winches, do not use grease unless specifically recommended in the instruction sheet.
Flush blocks thoroughly with fresh water. Periodically disassemble blocks, if possible, and flush with detergent and fresh water.
Lubrication is not required.
Important! Exposure to some teak cleaners and other caustic solutions can result in discoloration of part and is not covered under
the Harken warranty.
Warranty
For additional safety, maintenance and warranty information see www.harken.com/manuals or the Harken®catalog.
CB System (Slug Mount/Drill & Tap) Operation Troubleshooting
Problem Probable Cause Solution
Cars bind. Balls missing from car. Remove cars, load balls and slide cars back on track.
Dirt in cars. Use detergent and fresh water to flush dirt out of cars;
move cars up/down do circulate; follow with high
pressure water; clean track grooves.
Nut on Battcar is not holding. Locknut has been used too many times. Get new 5 mm locknut.
Batten receptacle does not rotate. Nuts are too tight. Loosen nuts slightly.
Cars jam when raising sail. Headboard or cars are catching on lazy jacks. Use topping lift or rod vang and shock cord to pull
lazy jacks out to shrouds.
Sail will not go all the way up. Sail is too tall or sheave is too far forward. Have sail shortened or move sheave aft.
Vertical post or pin on batten receptacle bending. Reef loads are being transferred to batten
receptacle.
Transfer reef downhaul and outhaul loads to mast
or boom gooseneck.
Reef tack fitting will not reach reef hook. Reef point too close to sail attachment. Move intermediate car sail attachment.
CB System (Slug Mount/Drill & Tap) Operation Troubleshooting
Problem Probable Cause Solution
Tracks do not butt up against each other Cut end of top or bottom track is at joint. Make sure the anodized end is towards the
full length track.
Track weight pulling tracks apart. Tracks will come together when you loosen bottom
screw and push the tracks up mast.
Mounting slugs do not fit Slugs wrong size. Different size slug required. Contact your dealer.
Mounting screws will not tighten. Incorrect mounting slug used. Different size slug required. Contact your dealer.
Track will not slide up mast.
Slugs catching on mast splice. Loosen screws slightly. If necessary have someone
at splice area to wiggle the slug past the splice.
Corners of cut track catching. Use file to round off corners of track.
Mast has too much prebend. Ease backstay and/or straighten mast.
Paint or other material clogging mast groove. Clean out groove.
Cars do not fit on track. Track and cars are not the same size. Contact your dealer or Harken.
Balls are missing. Remove cars, load balls and slide cars back on track.
Sail headboard does not fit inside coupler. Ring was not pressed far enough. Take sail to sailmaker.

Printed in USA 4247 10/14
Corporate Headquarters
N15W24983 Bluemound Rd, Pewaukee, WI 53072 USA
Telephone: [phone] • Fax: [phone]
Web: www.harken.com • Email: [email protected]
Harken Australia Pty, Ltd.
1B Green Street, Brookvale, N.S.W. 2100, Australia
Telephone: [phone] • Fax: [phone]
Web: harken.com.au • Email: [email protected]
Harken France
ZA Port des Minimes, BP 3064, 17032 La Rochelle Cedex 1, France
Telephone: [phone] • Fax: [phone]
Web: harken.fr • Email: [email protected]
Harken Italy S.p.A.
Via Marco Biagi, 14, 22070 Limido Comasco (CO) Italy
Telephone: [phone] • Fax: [phone]
Web: harken.it • Email: [email protected]
Harken New Zealand, Ltd.
158 Beaumont Street
Unit 11, Orams Marine Centre
Westhaven, Aukland, 1010, New Zealand
Telephone: [phone] • Fax: [phone]
Web: harken.co.nz • Email: [email protected]
Harken Polska SP ZOO
ul. Rydygiera 8, budynek 3A, lokal 101, I piętro, 01-793 Warszawa, Poland
Tel: [phone] • Fax: [phone]
Web: harken.pl • Email: [email protected]
Harken Sweden AB
Main Office and Harken Brandstore: Västmannagatan 81B
SE-113 26 Stockholm Sweden
Telephone: [phone] • Fax: [phone]
Mailing address: Harken Sweden AB, Box 64, SE -440 30 Marstrand
Web: harken.se • Email: [email protected]
Harken UK, Ltd.
Bearing House, Ampress Lane, Lymington, Hampshire S041 8LW, England
Telephone: [phone] • Fax: [phone]
Web: harken.co.uk • Email: [email protected]
Please visit: http://www.harken.com/locator.aspx
to locate Harken dealers and distributors
09
97653 21170
