Harman JBL BAR 800 User manual

QUICK START GUIDE
BAR 800
HA_JBL_Bar800_QSG_China_CR_V5.indd 1HA_JBL_Bar800_QSG_China_CR_V5.indd 1 2022/11/10 16:16:342022/11/10 16:16:34

HA_JBL_Bar800_QSG_China_CR_V5.indd 2HA_JBL_Bar800_QSG_China_CR_V5.indd 2 2022/11/10 16:16:342022/11/10 16:16:34

Before using this product, read the safety sheet carefully. 使用本产品前，请仔细阅读安全说明书。
在你的 Android™ 或iOS 设备上，扫描二维码下载“JBL One”
app。
On your Android™ or iOS device, scan the QR code to
download the "JBL One" app.
HA_JBL_Bar800_QSG_China_CR_V5.indd 3HA_JBL_Bar800_QSG_China_CR_V5.indd 3 2022/11/10 16:16:352022/11/10 16:16:35

x 2
x 2
x 6
x 6
x 2
x 2
x 2
x 2
x 2 (AAA) (1.2 m / 3.9 ft)
HA_JBL_Bar800_QSG_China_CR_V5.indd 4HA_JBL_Bar800_QSG_China_CR_V5.indd 4 2022/11/10 16:16:352022/11/10 16:16:35

> 4 m / 13 ft
3 m / 10 ft
>10 cm / 4”
2.5-3.0 m / 8.2-9.8 ft
>5cm/2”
1-1.4 m / 3-4.6 ft
1-1.4 m / 3-4.6 ft
1-6 m/3-20 ft
2.5-3.0 m / 8.2-9.8 ft
>5cm/2”
1-1.4 m / 3-4.6 ft
1-1.4 m / 3-4.6 ft
1-6 m/3-20 ft
L
R
HA_JBL_Bar800_QSG_China_CR_V5.indd 5HA_JBL_Bar800_QSG_China_CR_V5.indd 5 2022/11/10 16:16:352022/11/10 16:16:35

(A)
5
1
2
4
3
555.7 mm / 21.88”
≥30mm/1.18"
≤8mm/0.31"
4mm/0.16"
(B)
1
2
4
5
≥30mm/1.18"
≤8mm/0.31"
4mm/0.16"
3
HA_JBL_Bar800_QSG_China_CR_V5.indd 6HA_JBL_Bar800_QSG_China_CR_V5.indd 6 2022/11/10 16:16:352022/11/10 16:16:35

To move the soundbar, first remove the two detachable
speakers to avoid accidental damage.
移动本条形音箱时，请先取下两个可拆分扬声器以避免意
外损坏。
HA_JBL_Bar800_QSG_China_CR_V5.indd 7HA_JBL_Bar800_QSG_China_CR_V5.indd 7 2022/11/10 16:16:352022/11/10 16:16:35

HDMI IN
TV (HDMI ARC)
*
HDMI (ARC)
HDMI OUT
*
HDMI (ARC)
HDMI OUT
*
See
参见
HA_JBL_Bar800_QSG_China_CR_V5.indd 8HA_JBL_Bar800_QSG_China_CR_V5.indd 8 2022/11/10 16:16:362022/11/10 16:16:36

TVTV
TV (HDMI eARC)
HDMI (eARC)
HDMI IN
*
HDMI OUT
HDMI (eARC)
HDMI IN
*
HDMI OUT *
See
参见
HA_JBL_Bar800_QSG_China_CR_V5.indd 9HA_JBL_Bar800_QSG_China_CR_V5.indd 9 2022/11/10 16:16:362022/11/10 16:16:36

LOADHELLO
4
3
1
2
The soundbar will pair with the two detachable speakers and
the subwoofer automatically when they are powered on.
当本条形音箱、可拆分扬声器以及低音扬声器均为开机状
态时，本条形音箱会自动完成与可拆分扬声器及低音扬声
器的配对
HA_JBL_Bar800_QSG_China_CR_V5.indd 10HA_JBL_Bar800_QSG_China_CR_V5.indd 10 2022/11/10 16:16:362022/11/10 16:16:36

REAR SPKR LOW BATTREAR SPKR LOW BATT
100%
USB-C
*
3.5H
100%
*
HA_JBL_Bar800_QSG_China_CR_V5.indd 11HA_JBL_Bar800_QSG_China_CR_V5.indd 11 2022/11/10 16:16:362022/11/10 16:16:36

CALIBRATING
PRESS AGAIN TO CONFIRM
1DONE
1-CALIBRATION
CALIBRATING
PRESS AGAIN TO CONFIRM
1DONE
1-CALIBRATION
LR
HA_JBL_Bar800_QSG_China_CR_V5.indd 12HA_JBL_Bar800_QSG_China_CR_V5.indd 12 2022/11/10 16:16:362022/11/10 16:16:36

PRESS CALIBR AGAIN
CALIBRATING
2-CALIBRATION
2DONE
LR
LR
HA_JBL_Bar800_QSG_China_CR_V5.indd 13HA_JBL_Bar800_QSG_China_CR_V5.indd 13 2022/11/10 16:16:372022/11/10 16:16:37

声音校准
根据聆听环境优化 3D 环绕声体验。
Sound Calibration
Optimize your 3D surround sound experience for your unique
listening environment.
HA_JBL_Bar800_QSG_China_CR_V5.indd 14HA_JBL_Bar800_QSG_China_CR_V5.indd 14 2022/11/10 16:16:372022/11/10 16:16:37

< 10 m / 33 ft
JBL One
SETUP WIFI
On an Android or iOS device, add the soundbar to your home
Wi-Fi network through the JBL One app. Follow the app
instructions to complete setup.
* Some features require subscriptions or services not available
in all countries.
在Android 或iOS 设备上，通过 JBL One 应用将条形音箱添
加到您的家庭 Wi-Fi 网络。按照应用提示完成设置。
* 有些功能需订阅相关服务才能使用，但并非在所有国家
和地区上线。
HA_JBL_Bar800_QSG_China_CR_V5.indd 15HA_JBL_Bar800_QSG_China_CR_V5.indd 15 2022/11/10 16:16:372022/11/10 16:16:37

General specication:
• Model: BAR 800 (soundbar unit)
BAR 800 SURROUND (detachable speaker)
BAR 800 SUB (subwoofer unit)
• Sound system: 5.1.2 channel
• Power supply: 100 - 240V AC, ~ 50/60Hz
• Total speaker power output
(Max @THD 1%): 720W
• Soundbar output power (Max @THD 1%): 340W
• Surround speaker output power
(Max @THD 1%): 2x 40W
• Subwoofer output power
(Max. @THD 1%): 300W
• Soundbar transducer: 3x (46x90)mm
racetrack drivers, 3x 0.75”(20mm) tweeters,
2x 2.75” (70mm) up-firing full-range drivers
• Surround speaker transducer: 1x (46x90)mm
racetrack driver
• Subwoofer transducer: 10”(260mm)
• Networked standby power: < 2.0 W
• Operating temperature: 0 °C - 45 °C
• Lithium battery: 3.635V, 3283mAh
• Detachable surround speaker playtime: up
to 10 Hours (may vary according to content
type and volume level)
HDMI specication
• HDMI video input: 1
• HDMI video output (with Enhanced Audio
Return Channel, eARC): 1
• HDMI HDCP version: 2.3
• HDR pass through: HDR10, Dolby Vision
Audio specication
• Frequency response: 35Hz - 20kHz (-6dB)
• Audio inputs: 1 Optical and Bluetooth
USB specication
• USB port: Type A
• USB rating: 5V DC, 0.5A
Wireless specication
• Bluetooth version: 5.0
• Bluetooth profile: A2DP 1.2, AVRCP 1.5
• Bluetooth transmitter frequency range:
2400 MHz - 2483.5 MHz
• Bluetooth transmitter power:
<15 dBm (EIRP)
• Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax
(2.4GHz/5GHz)
• 2.4G Wi-Fi transmitter frequency range:
2412 - 2472 MHz (2.4 GHz ISM Band,
USA 11 Channels, Europe and others
13 Channels)
• 2.4G Wi-Fi transmitter power: <20 dBm (EIRP)
• 5G Wi-Fi transmitter frequency range:
5.15 - 5.35GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power:
5.15 - 5.25GHz <23dBm,
5.25 - 5.35GHz <20dBm,
5.725 - 5.825GHz <14dBm (EIRP)
• 2.4G wireless transmitter frequency range:
2406 - 2474 MHz
• 2.4G wireless transmitter power:
<10 dBm (EIRP)
Dimensions
• Total soundbar dimensions (W x H x D):
1174 x 56 x 120 mm / 46.2” x 2.2” x 4.7”
• Main soundbar dimensions (W x H x D):
884 x 56 x 120 mm / 34.8” x 2.2” x 4.7”
• Detachable surround speaker dimensions
(each) (W x H x D):
145 x 56 x 120 mm / 5.7” x 2.2” x 4.7”
• Subwoofer dimensions (W x H x D):
305 x 440.4 x 305 mm / 12” x 17.3” x 12”
• Soundbar weight: 3.4 kg / 7.4 lbs
• Detachable surround speaker weight (each):
0.65 kg / 1.4 lbs
• Subwoofer weight: 10 kg / 22 lbs
• Packaging dimensions (W x H x D):
1000 x 375 x 475 mm / 39.4” x 14.8” x 18.7”
• Packaging Weight: 18.9 kg / 41.6 lbs
一般规格：
• 型号：BAR 800（条 形音箱部件）
BAR 800 SURROUND（可拆卸扬声器）
BAR 800 SUB（低音扬声器部件）
• 音响系统：5.1. 2 声道
• 电源：100 - 240V AC, ~ 50/60Hz
• 扬 声 器 总 输 出 功 率（ THD 为1% 时的最
大 值 ）：720W
• 条 形 音 箱 输 出 功 率（ THD 为1% 时的最
大 值 ）：340W
• 环绕声扬声器输出功率（THD 为1% 时的
最 大 值 ）： 2x 40W
• 低 音 炮 输 出 功 率（ THD 为1% 时的最大
值 ）：300W
• 条形音箱喇叭单元：3 个(46x90)mm 跑
道型喇叭单元，3 个0.75” (20mm) 高音
喇叭单元，2 个2.75”(70mm) 向上发声
全频喇叭单元
• 环绕音箱喇叭单元：1个(46x90)mm 跑
道型喇叭单元
• 低音炮喇叭单元：10”(260mm)
• 联网待机功率：< 2.0W
• 工作温度：0 °C - 45 °C
• 锂电池：3.635V，3283mAh
• 可拆卸环绕音箱播放时间：长达 10 小时
（可能因内容类型和音量而异）
HDMI 规格
• HDMI 视频输入：1
• HDMI 视频输出（带高级音频回传通道，
eARC）：1
• HDMI HDCP 版本：2.3
• HDR 直通：HDR10、Dolby Vision
音频规格
• 频率响应：35Hz - 20kHz (-6dB)
• 音频输入：1 个 光 纤 接 口 、蓝 牙
USB 规格
• USB 端口：A 型
• USB 额定电流：5V DC, 0.5A
无线规格
• 蓝牙版本：5.0
• 蓝牙配置文件：A2DP 1.2、AVRCP 1.5
• 蓝牙发射器频率范围：
2400MHz - 2483.5MHz
• 蓝牙发射器功率：< 15dBm（EIRP）
• Wi-Fi 网络：IEEE 802.11 a/b/g/n/ac/ax
(2.4GHz/5GHz)
• 2.4G Wi-Fi 发射器频率范围：
2412 - 2472MHz（2.4GHz ISM 频带，
美国 11 个频道，欧洲和其他国家/地区
13 个频道）
• 2.4G Wi-Fi 发射器功率：< 20dBm（EIRP）
• 5G Wi-Fi 发射器频率范围：
5.15 - 5.35GHz、5.725 - 5.825GHz
• 5G Wi-Fi 发射器 功率：
5.15 - 5.25GHz <23dBm、
5.25 - 5.35GHz <20dBm、
5.725 - 5.825GHz <14dBm (EIRP)
• 2.4G 无线发射器 频率范围：
2406 - 2474MHz
• 2.4G 无线发射器功率：< 10dBm（EIRP）
尺寸
• 条形音箱总尺寸（宽 x 高x 厚 ）：
1174 x 56 x 120mm / 46.2” x 2.2” x 4.7”
• 主 条 形 音 箱 尺 寸（ 宽 x 高x 厚 ）：
884 x 56 x 120mm / 34.8” x 2.2” x 4.7”
• 可拆卸环绕声扬声器尺寸
（每个，宽 x 高x 厚 ）：
145 x 56 x 120mm / 5.7” x 2.2” x 4.7”
• 低 音 炮 尺 寸（ 宽 x 高x 厚 ）：
305 x 440.4 x 305mm / 12” x 17.3”x 12”
• 条形音箱重量：3.4kg / 7.4 lbs
• 可 拆 卸 环 绕 声 扬 声 器 重 量（ 每 个）：
0.65 kg / 1.4 lbs
• 低音炮重量：10kg / 22 lbs
• 包装尺寸（宽 x 高x 厚 ）：
1000 x 375 x 475mm / 39.4” x 14.8”x 18.7”
• 包装重量：18.9kg / 41.6 lbs
HA_JBL_Bar800_QSG_China_CR_V5.indd 16HA_JBL_Bar800_QSG_China_CR_V5.indd 16 2022/11/10 16:16:372022/11/10 16:16:37

This product contains open source software licensed under GPL. For your convenience, the source code and relevant build instruction are
also available at https://harman-webpages.s3.amazonaws.com/JBL_BAR_Gen3_package_license_list.htm
Please feel free to contact us at:
Harman Deutschland GmbH
ATT: Open Source, Gregor Krapf-Gunther, Parkring 3
85748 Garching bei Munchen, Germany
or_OpenSourceSuppor[email protected]_if you have additional question regarding the open source software in the product.
HA_JBL_Bar800_QSG_China_CR_V5.indd 17HA_JBL_Bar800_QSG_China_CR_V5.indd 17 2022/11/10 16:16:372022/11/10 16:16:37

The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by HARMAN International
Industries, Incorporated is under license. Other trademarks and trade names
are those of their respective owners.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade
dress and the HDMI Logos are trademarks or registered trademarks of HDMI
Licensing Administrator, Inc.
Wi-Fi CERTIFIED 6™ and the Wi-Fi CERTIFIED 6™ Logo are trademarks of
Wi-Fi Alliance®.
Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are registered
trademarks of Dolby Laboratories Licensing Corporation. Manufactured
under license from Dolby Laboratories. Confidential unpublished works.
Copyright © 2012–2021 Dolby Laboratories. All rights reserved.
Use of the Works with Apple badge means that an accessory has been
designed to work specifically with the technology identified in the badge
and has been certified by the developer to meet Apple performance
standards.
Apple, and AirPlay are trademarks of Apple Inc., registered in the U.S. and
other countries.
To control this AirPlay 2–enabled speaker, iOS 13.4 or later is required.
