GLO-RAY ®
DESIGNER HEATED GLASS DISPLAY CASES
Models GRCD-2PDG, GRCD-3PDG, GRCDH-2PDG, GRCDH-3PDG
For hot meals-to-go, the Hatco Glo-Ray
Designer Heated Glass Display Cases
feature innovative technology that
improves heated merchandising while
generating more impulse sales. The
transparent shelf utilizes a patented
heated glass, which radiates heat down
while conducting heat up, allowing you
to hold foods longer and safer at
optimum serving temperatures.
FLEXIBILITY
These Hatco merchandisers are
available in two-pan and three-pan
models, doubling the holding capacity
while using the same amount of
counterspace and increasing product
visibility. The slim-line profile provides
safe and higher clearance.
The patented heated glass shelf
provides an even heat source for top
and bottom heat to safely hold product,
along with superior visibility to promote
and display product.
A vast array of options include
humidified models, mirrored glass doors,
pan skirt (bottom shelf only, standard on
humidified units), backlit base sign holder,
and Designer powdercoated colors of
warm red, black, gray granite, white
granite, navy blue, and hunter green.
QUALITY
The following features assure the finest
performance for years to come.
• The patented heated glass shelf
provides an even heat source for top
and bottom heat to safely hold
product.
• High visibility merchandiser with
curved tempered glass.
• Hinged front glass panel tilts forward
for easy cleaning.
• These merchandisers feature a
thermostatically-controlled heated base
with exclusive cool base construction.
•
All models are shipped with 4" (102 mm)
adjustable legs and factory attached
6' (1829 mm) cord and plug.
• Shatter-resistant incandescent lights
enhance product display while
safeguarding food products from
bulb breakage.
HEATED GLASS SHELVES AND BASE BLANKET
HEATING ELEMENTS ARE WARRANTED AGAINST
BURNOUT FOR ONE YEAR.
Model GRCD-2PDG in
optional Designer color
with accessory pans
Model GRCDH-3PDG in
optional Designer color
with accessory pans

ITEM#
GLO-RAY ®
DESIGNER HEATED GLASS DISPLAY CASES
Models GRCD-2PDG, GRCD-3PDG, GRCDH-2PDG, GRCDH-3PDG
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Form No. GRCD-PDG-1006(S) Printed in U.S.A.
Model†•Width Watts Amps Shipping Weight
GRCD-2PDG 321⁄2" ( 826 mm) 1130 9.4 170 lbs. (77 kg)
GRCD-3PDG 451⁄2" (1156 mm) 1665 13.9 218 lbs. (99 kg)
Model†•Width Watts Amps Shipping Weight
GRCDH-2PDG 321⁄2" ( 826 mm) 1380 11.5 174 lbs. ( 79 kg)
GRCDH-3PDG 451⁄2" (1156 mm) 1915 15.9 222 lbs. (101 kg)
DIMENSIONS
32
1/2
" or 45
1/2
"W x 26"D x 31
3/4
"H w/legs
(826 or 1156 x 660 x 806 mm).
VOLTAGE
120 volts, single phase.
GRCD-2PDG, -3PDG, and GRCDH-2PDG use NEMA 5-15P
(GRCD-3PDG uses NEMA 5-20P for Canada).
GRCDH-3PDG uses NEMA 5-20P.
CORD LOCATION
Control side at right base corner.
PLUG CONFIGURATIONS
PRODUCT SPECS
Designer Heated Display Case
The Designer Heated Display Case shall be a Glo-Ray®Model
....as manufactured by the Hatco Corporation, Milwaukee, WI
53234 U.S.A.
The Display Case shall be rated at ....watts, ....volts, and be ....
inches (millimeters) in overall width. It shall consist of a
thermostatically controlled heated base, a patented heated
glass shelf, full view tempered glass sides, incandescent and
fluorescent display lights.
NEMA 5-20PNEMA 5-15P
OPTIONS (NOT FOR RETROFIT)
❑Designer Colors: Warm Red, Black, Gray Granite,
White Granite, Navy Blue, Hunter Green
❑ Pan Skirts (Bottom shelf only, standard on
GRCDH models)
❑ Mirrored Glass Doors on Server's Side
❑ Halogen Bulbs in lieu of Standard Display Lights
ACCESSORIES
❑Display Sign Holder
❑Food Pans
321⁄2"or 451⁄2" (826 or 1156 mm)
FRONT VIEW
313⁄4"
(806 mm)
SIDE VIEW
26" (660 mm)
25"
(635 mm)
151⁄4"
(387 mm)
Designer Heated Display Cases with Humidity‡
†Model number indicates number of full-size food pans bottom shelf
will accommodate.
•NSF requires units over 36" (914 mm) in width or weighing more than
80 lbs. (36 kg) to be either sealed, or raised on the installation surface
with the 4" (102 mm) legs included.
‡Humidity on bottom shelf only.
The use of metal pans or ceramic dishes on the glass shelves may scratch
the glass. Hatco’s warranty does not cover scratches to the shelves.
It is recommended that the glass shelves be used for food products contained
in disposable paper or plastic containers or wrapping.
SPECIFICATIONS
Designer Heated Display Cases
The infrared heating element shall be tubular metal sheathed
and the warmer shall have a cord with plug attached.
