FPG INLINE 3000S Series User manual

Ambient Cabinets
Square Format

Part No.26114 Rev. H September 2018. - 2 - Inline 3000 Square Series Cabinets
Copyright © September 2018, Future Products Group Limited.
All rights reserved.
No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior
written permission of Future Products Group Ltd.

IN 3A06,09,12,15-SQ - 3 - © Future Products Group
Table of Contents
INTRODUCTION................................................................................................................6
Welcome..........................................................................................................................................................6
Future Products Group (FPG)...................................................................................................................6
Guidance and Help....................................................................................................................................6
Warranty..........................................................................................................................................................6
Warranty Period ........................................................................................................................................6
Liability Exceptions....................................................................................................................................7
Specific Exclusions....................................................................................................................................7
Assessment...............................................................................................................................................7
Time Limit..................................................................................................................................................7
Caution......................................................................................................................................................7
OPERATION......................................................................................................................8
Cabinet Layout................................................................................................................................................8
3000 Square Series Cabinets....................................................................................................................8
Door Configuration....................................................................................................................................8
Shelf Lighting.............................................................................................................................................8
Controls...........................................................................................................................................................8
Control Panel.............................................................................................................................................8
Power and Lights.......................................................................................................................................8
Preparation .....................................................................................................................................................9
Shelf Location and Ticketing .....................................................................................................................9
Shelf Adjustment .......................................................................................................................................9
Fumes and Odours....................................................................................................................................9
Close Doors...............................................................................................................................................9
Turn on Lights ...........................................................................................................................................9
TROUBLE SHOOTING....................................................................................................10
CLEANING ......................................................................................................................11
Cautions........................................................................................................................................................11
Power......................................................................................................................................................11
Water.......................................................................................................................................................11
Exterior..........................................................................................................................................................11
Metal Surfaces ........................................................................................................................................11
Glass.......................................................................................................................................................11
Sliding Doors...........................................................................................................................................11
Interior...........................................................................................................................................................12
Access to the Cabinet Interior .................................................................................................................12
Trays and Shelves...................................................................................................................................12
Routines........................................................................................................................................................12
Schedules................................................................................................................................................12
Inspection................................................................................................................................................12
Fault Correction.......................................................................................................................................12

Part No.26114 Rev. H September 2018. - 4 - Inline 3000 Square Series Cabinets
INSTALLATION...............................................................................................................13
Regulations...................................................................................................................................................13
Compliance with Local Requirements .....................................................................................................13
Setting Up .....................................................................................................................................................13
Unpacking ...............................................................................................................................................13
Site Preparation.......................................................................................................................................13
Cabinet Preparation ................................................................................................................................13
Shelf Trays..............................................................................................................................................13
Grounding................................................................................................................................................14
Power Supply..........................................................................................................................................14
Isolation...................................................................................................................................................14
SERVICING .....................................................................................................................15
Control Gear .................................................................................................................................................15
Location...................................................................................................................................................15
Lighting.........................................................................................................................................................15
Caution....................................................................................................................................................15
Shelf Lights..............................................................................................................................................15
Test Lighting Components ......................................................................................................................15
Access to LED Strips...............................................................................................................................15
LED Strip Replacement...........................................................................................................................16
Door Seals.....................................................................................................................................................16
Seal Replacement...................................................................................................................................16
Sliding Doors...........................................................................................................................................16
Mains Lead....................................................................................................................................................16
Lead Replacement..................................................................................................................................16
SPECIFICATIONS ...........................................................................................................17
Mechanical....................................................................................................................................................17
Electrical .......................................................................................................................................................17
Compliance...................................................................................................................................................18
Standards................................................................................................................................................18
Operational Safety...................................................................................................................................18
Improvements...............................................................................................................................................18
Ongoing Development.............................................................................................................................18

IN 3A06,09,12,15-SQ - 5 - © Future Products Group
ELECTRICAL CIRCUIT DIAGRAMS...............................................................................19
Model: IN 3A06-SQ.................................................................................................................................19
Model: IN 3A09-SQ.................................................................................................................................19
Model: IN 3A12-SQ.................................................................................................................................20
Model: IN 3A15-SQ.................................................................................................................................20
SPARE PARTS................................................................................................................21
Cabinet Serial Number............................................................................................................................21
MECHANICAL DRAWINGS.............................................................................................23
Dimensions...................................................................................................................................................23
Cabinet Variants......................................................................................................................................23
IN-3A06/15-SQ Fixed Front In counter mounting.................................................................................23
IN-3A06/15-SQ Sliding Door In counter mounting.................................................................................24
IN-3A06/15-SQ Fixed Front On counter mounting ................................................................................25
IN-3A06/15-SQ Sliding Door On counter mounting...............................................................................26

Part No.26114 Rev. H September 2018. - 6 - Inline 3000 Square Series Cabinets
INTRODUCTION
Welcome
AMBIENT CABINETS - INTRODUCTION
Future
Products
Group (FPG)
Welcome to the world of FPG! Our products are designed and engineered to
give you the optimal performance that you deserve with innovative visual
merchandising appeal.
We are confident that you will be delighted with your state of the art inline food
service cabinet, and that it will become a valued appliance in your store.
Guidance and
Help
Any new appliance can seem very complex and confusing at first glance. To
ensure you receive the utmost benefit from your new inline cabinet, there are
two things you can do.
•Before operating the cabinet, please read the instruction book carefully and
follow its recommendations. The time taken will be well spent. These
instructions both general and technical tell you how to install, operate and
look after your inline food service cabinet so that you can receive the full
benefits that this cabinet has to offer.
•These instructions cannot, however, cover all eventualities. If you are
unsure of any aspect of the installation, instructions or performance of your
cabinet, contact your dealer promptly or contact us via email to
[email protected].
Warranty
AMBIENT CABINETS - INTRODUCTION
Warranty
Period
Future Products Group Limited warrants, to the original purchaser of an FPG
manufactured food service cabinet that for ONE YEAR (12 months), from the
date of purchase, any defect in workmanship or material resulting in the product
malfunctioning while under correct use will be rectified.
The warranty is extended to THREE YEARS (36 months), for refrigeration
condenser units. Conditions apply, see Liability Exceptions.
Liability under this warranty is limited to replacing or repairing a part, without
charge.
Continued on next page

IN 3A06,09,12,15-SQ - 7 - © Future Products Group
Warranty cont.
AMBIENT CABINETS - INTRODUCTION
Liability
Exceptions
Liability under this warranty does not include:
•Any loss, or damage or expenses directly or indirectly arising from use or
inability to use the product or from any other cause.
•Any part of the cabinet which has been subject to misuse, neglect,
alteration, incorrect installation, accident, or damage caused by
transportation, use of abrasive or caustic chemicals, flooding, fire or acts of
God.
•Damage, resulting from failure to have the cabinet regularly serviced every
three months by a refrigeration engineer. NB: You will be required to
provide copies of service records in the event of compressor failure.
•Any damage or malfunction resulting from the use of non-FPG supplied
spare parts.
Specific
Exclusions
The following are specifically excluded from warranty:
•Breakage of glass or plastic components or the replacement of LED lighting
strips or gaskets.
•Failure to re-assemble the cabinet correctly after cleaning.
•Fair wear and tear.
Assessment
The liability under this warranty is dependent on an assessment by FPG, to
determine the defect in workmanship or materials.
Time Limit
FPG does not guarantee that any service to be performed under this warranty
will be carried out within any particular time limit.
Caution
No warranty claim will be accepted unless authorised by FPG prior to
commencement of service.

Part No.26114 Rev. H September 2018. - 8 - Inline 3000 Square Series Cabinets
OPERATION
Cabinet Layout
AMBIENT CABINETS - OPERATION
3000 Square
Series Cabinets
The 3000 Square Series cabinets include Ambient, Heated and Refrigerated
models.
On Counter, In Counter and Free Standing models are available.
Door
Configuration
Sliding doors can be fitted to the front and back of the cabinets.
Fixed glass can be fitted in place of doors at the front.
Shelf Lighting
Cabinets are fitted with a top light as standard. Lights below each shelf are
available as an optional extra, at the time of ordering.
Cabinets are fitted with high efficiency LED lighting.
Controls
AMBIENT CABINETS - OPERATION
Control Panel
The controls are mounted on
the back of the cabinet, at the
top.
Power and
Lights
To turn the power and lights on, rotate the main switch.
The lights and extractor fan will operate.

IN 3A06,09,12,15-SQ - 9 - © Future Products Group
Preparation
AMBIENT CABINETS - OPERATION
Shelf Location
and Ticketing
The shelves are adjustable in
height and can easily be moved
up or down, to match product
size.
The movement is restricted to
50mm, because of the electric
cables to the lights. For greater
movement contact the
manufacturer or supplier for
advice, as electrical modifications
may be required.
The front and rear edges of the shelves are profiled to carry ticketing/labels.
Shelf
Adjustment
To move the shelf brackets, first remove the shelf
trays.
Lift the brackets straight up firmly and then pull the
brackets forward, to disengage them from the slots
in the support posts.
Insert the brackets into their new position, and
push bracket down firmly.
The brackets may be positioned to give two
different degrees of slope to the shelves.
Refit all shelf trays and doors.
N.B. Make sure brackets are pushed down as
far as they can go. Failure to do this may result in shelf collapse, when
loaded with product.
Fumes and
Odours
Before first use, operate the cabinet for 1-2 hours with the doors open, to
remove any fumes or odours, which may be present. This will avoid possible
tainting of food.
Close Doors
It is important to keep the cabinet doors closed during normal use, to prevent
food drying out.
Turn on Lights
When ready for service, turn on the cabinet lights.

Part No.26114 Rev. H September 2018. - 10 - Inline 3000 Square Series Cabinets
TROUBLE SHOOTING
FAULT
POSSIBLE CAUSE
REMEDY
Cabinet does not operate/start
The mains isolating switch on
the wall, circuit breaker or
fuses are off at the power
board
Turn isolating switch circuit
breaker or fuses on
Internal fuse has blown
Have wiring checked and
replace fuse (5A Slow Blow)
The main switch on the
cabinet is OFF
Turn the main switch ON
Cabinet lights not working
The main switch is OFF
Turn the switch ON
LED Power supply has failed
Replace LED power supply
LED strip has failed
Replace the LED assembly
Fuse has blown
Check wiring and replace
fuse (5A Slow Blow)
Doors are not sliding smoothly
Door not in track
Install door correctly in track
Debris in track
Clean door tracks (see cleaning)
Lack of lubricant
Apply food grade lubricant to
door track
Aluminium parts corroded
Caustic detergent damage
Order replacement parts
Service
Personnel Only
The table entries in italics indicate actions to be taken only by qualified Service
Personnel.

IN 3A06,09,12,15-SQ - 11 - © Future Products Group
CLEANING
Cautions
AMBIENT CABINETS - CLEANING
Power
ALWAYS TURN THE POWER SUPPLY OFF BEFORE CLEANING.
Water
THIS UNIT IS NOT WATERPROOF. DO NOT USE A WATER JET SPRAY TO
CLEAN THE INTERIOR OR EXTERIOR OF THIS CABINET.
Exterior
AMBIENT CABINETS - CLEANING
Metal Surfaces
Stainless steel or aluminium surfaces should be cleaned with hot soapy water or
a good quality metal cleaning compound. DO NOT clean surfaces with abrasive
pads or cleaners, as stainless steel and aluminium surfaces will be damaged.
Glass
All glass should be cleaned using a good quality glass cleaner and a clean
cloth.
DO NOT use abrasive pads or cleaners, because they will damage the surface
of the glass.
Sliding Doors
Sliding glass doors are
located by plastic guides
at the top and bottom.
The doors can be
removed for cleaning by
sliding the door to a
central position, placing
hands either side of the
door, lifting it up and then
swinging it out at the
bottom.
When replacing doors,
make sure that they are
located in the correct slots, top and bottom. The left door should be in the inner
slots, and the right door in the outer slots.
Sliding door tracks should be vacuumed out regularly to keep doors sliding
freely.

Part No.26114 Rev. H September 2018. - 12 - Inline 3000 Square Series Cabinets
Interior
AMBIENT CABINETS - CLEANING
Access to the Cabinet
Interior
Remove the doors, by sliding them to the centre and lifting, to disengage
them from the door tracks.
Lift out the deck trays.
The cabinet interior can now be cleaned.
Trays and
Shelves
Stainless steel trays and shelves should be cleaned with hot soapy water. Do
not use abrasive pads or cleaners, as these may damage surfaces.
Warning: Dishwasher detergents will damage any anodised aluminium parts.
Routines
AMBIENT CABINETS - CLEANING
Schedules
To maintain optimum performance, regular cleaning schedules should be
established.
Inspection
As part of the cleaning routine, the controls, mechanical parts and electrical
wiring should be inspected for damage, deterioration or need of adjustment.
Fault
Correction
If any small faults are found, have them attended to promptly by a competent
serviceman. Don’t wait until they cause a complete breakdown.

IN 3A06,09,12,15-SQ - 13 - © Future Products Group
INSTALLATION
Regulations
AMBIENT CABINETS - INSTALLATION
Compliance
with Local
Requirements
It is very important that your inline food cabinet is installed correctly and that the
operation is correct before use. Installation must comply with local electrical,
health & safety and hygiene requirements.
Setting Up
AMBIENT CABINETS - INSTALLATION
Unpacking
Unpack and check unit for damage and report any damage to the carrier and
supplier. Report any deficiencies to your supplier.
The display cabinet is supplied fully assembled, but the compressor unit and
shelf trays are packed separately.
Site
Preparation
Ensure the cabinet location and any bench cut outs are made to the precise
measurements shown in the Mechanical Drawings. Position the cabinet in its
allocated working position. Use a spirit level to ensure the cabinet is level from
side to side and front to back.
Cabinet
Preparation
Remove all protective
plastic film, tapes, ties
and packers, used to
prevent movement
during transit.
Shelf Trays
Remove the shelf trays from their packing, peel off any protective plastic coating
and assemble them on the support members.
Fit the correct size trays for each shelf level.
Continued on next page

Part No.26114 Rev. H September 2018. - 14 - Inline 3000 Square Series Cabinets
Setting Up cont.
AMBIENT CABINETS - INSTALLATION
Grounding
WARNING: THIS APPLIANCE MUST BE GROUNDED TO EARTH
The grounding lead, in the mains cable, must always be connected to ground.
A binding post is also provided adjacent to the control gear chassis, to allow the
cabinet to be bonded to a surge grounding conductor or to adjacent equipment,
should this be required.
Power Supply
Before connecting to the power supply, check that the local supply is correct to
that shown on the rating plate, located on the rear of the cabinet.
Isolation
If the cabinet is not connected by a plug and socket, but is hard wired to the
mains supply, a means of isolation must be provided.
If a plug and socket are used, they should still be accessible after the cabinet is
installed.

IN 3A06,09,12,15-SQ - 15 - © Future Products Group
SERVICING
Control Gear
AMBIENT CABINETS - SERVICING
Location
The electrical control gear
is located in the top of the
cabinet.
Remove the top plate to
access the control gear.
The chassis has power
supplies for the lights, an
extractor fan and a
protective fuse.
Lighting
AMBIENT CABINETS - SERVICING
Caution
Do not service lights without isolating the cabinet from the mains supply.
Shelf Lights
Shelf lights are an optional extra, which can be fitted during manufacture.
Test Lighting
Components
Before replacing an LED strip, check that the power supply is working.
If there is no dc voltage at the output, the power supply should be replaced.
If there is a dc output, the LED strip must be replaced.
Access to LED
Strips
The LED strips are
protected with plastic
covers. These clip into
grooves in the aluminium
extrusion.
Remove the plastic cover
to access the LED strip.
The top light assembly is
different from the shelf
lights, so the correct
replacement unit must be
used.
Continued on next page

Part No.26114 Rev. H September 2018. - 16 - Inline 3000 Square Series Cabinets
Lighting cont.
AMBIENT CABINETS - SERVICING
LED Strip
Replacement
Individual LED modules cannot be
replaced. A complete light unit must
be used.
Connection is made with a plug and
socket. Disconnect the supply lead
from the faulty unit, and reconnect it
to the replacement unit.
Door Seals
AMBIENT CABINETS - SERVICING
Seal
Replacement
The doors should be removed to allow the old seals to be removed and the new
ones fitted. See the Cleaning section for details.
Sliding Doors
Each sliding door has a
rubber seal between the
door and the cabinet end
panel. The seal slides
into a groove in the door
extrusion, and can be
withdrawn and replaced,
if damaged.
A centre seal is fitted
between the inner and
outer doors. The Qlon
seal is located in a slot in
the aluminium extrusion,
and can be replaced if
damaged.
Mains Lead
AMBIENT CABINETS - SERVICING
Lead
Replacement
If damaged, the mains lead must ONLY be replaced by a qualified service
person.

IN 3A06,09,12,15-SQ - 17 - © Future Products Group
SPECIFICATIONS
Mechanical
AMBIENT CABINETS - SPECIFICATIONS
CABINET MODEL
IN 3A06S
IN 3A09S
IN 3A12S
IN 3A15S
Height (Counter Top)
781 (+321) mm
781 (+393) mm
781 (+393) mm
781 (+393) mm
Height (In Counter)
621 (+481) mm
621 (+553) mm
621 (+553) mm
621 (+553) mm
Height (Free Standing)
1272 (-0+30) mm
1272 (-0+30) mm
1272 (-0+30) mm
1272 (-0+30) mm
Width
600 mm
900 mm
1200 mm
1500 mm
Depth
662 mm
662 mm
662 mm
662 mm
Dry Weight
Cabinet Well Material
Stainless steel
Cabinet Colour
Grey and natural anodised aluminium.
Top Lighting
Standard
Shelf Lighting
Optional
Glass Type
Double glazed
Front Doors
Fixed glass or Sliding Doors
Number of Shelves
Two plus base
Display Area
0.51 m2
0.85 m2
1.3 m2
1.8 m2
Climatic Class & IP
Cabinets are tested under Climate Class 3 conditions and have IP 20 ratings
Electrical
AMBIENT CABINETS - SPECIFICATIONS
CABINET MODEL
IN 3A06S
IN 3A09S
IN 3A12S
IN 3A15S
Voltage
220 - 240 V 50 Hz 1
Power (with shelf lights)
20 W
31 W
37 W
55 W
Current (with shelf lights)
0.08 A
0.13 A
0.16 A
0.24 A
Connection
3 pin plug, 10 A lead
Temperature Range
Ambient
Top Lights
1 x LED strip
1 x LED strip
1 x LED strip
1 x LED strip
Optional Shelf Lights
2 x LED strips
2 x LED strips
2 x LED strips
2 x LED strips

Part No.26114 Rev. H September 2018. - 18 - Inline 3000 Square Series Cabinets
Compliance
AMBIENT CABINETS - SPECIFICATIONS
Standards
FPG refrigerated, controlled ambient and ambient food display cabinets are
designed to meet and exceed:
•International safety standards for electrical appliances: IEC 60335-1, IEC
60335-2-89, and the equivalent country-specific standards including
AS/NZS, BS EN and UL 471.
•International standards for electromagnetic compatibility/emissions: CISPR
14-1, and the equivalent county-specific standards including AS/NZS CISPR
and BS EN 55014-1.
•Essential safety requirements: AS/NZS 3820 and AS/NZS 4417
•Energy efficiency for refrigerated appliances: MEPS (Australia/New
Zealand)
Please contact FPG to discuss your requirements for meeting country-specific
standards.
Operational
Safety
This appliance is not intended for use by young children or infirm persons,
unless they have been adequately supervised by a responsible person, to
ensure that they can use the appliance safely.
Young children should be supervised, to ensure that they do not play with the
appliance.
Improvements
AMBIENT CABINETS - SPECIFICATIONS
Ongoing
Development
FPG reserves the right to change specifications and construction, as part of
ongoing product improvement.

IN 3A06,09,12,15-SQ - 19 - © Future Products Group
ELECTRICAL CIRCUIT DIAGRAMS
Model: IN 3A06-SQ
Inline 3000 Square Series, 600mm Ambient Cabinet
Model: IN 3A09-SQ
Inline 3000 Square Series, 900mm Ambient Cabinet

Part No.26114 Rev. H September 2018. - 20 - Inline 3000 Square Series Cabinets
Model: IN 3A12-SQ
Inline 3000 Square Series, 1200mm Ambient Cabinet
Model: IN 3A15-SQ
Inline 3000 Square Series, 1500mm Ambient Cabinet
