Unique Needs, Exact Solutions.
PORTABLE FOODWARMERS

800.558.0607
www.hatcocorp.com
OPTIMUM SERVING TEMPERATURES,
UNCOMPROMISING QUALITY
The Hatco Serv-Rite™ Portable Buffet Warmers
are designed to keep prepared foods at optimum
serving temperatures without affecting quality.
They’re perfect for self-serve buffet areas and
customer serving points. All Serv-Rite Buffet
Warmers feature a thermostatically controlled
heated base, durable stainless steel construction,
sturdy aluminum extrusions, and a 6' (1829 mm)
cord with plug.
Hatco Serv-Rite Buffet Warmers are ideal for use
in buffet lines and as hors d’ouevre displays.
These unique foodwarmers are available with or
without overhead halogen heat lamps and glass
sneeze guards. The Choice is Yours.
• All models equipped with removable utensil tray
• Digital temperature control
• SRBW and SRGBW models have top light and
heat variably controlled from a base mounted
dimmer switch
2
PORTABLE BUFFET WARMERS
SRBW-1 with halogen lights
and glass sneeze guard
SRGBW-1 with heated
black glass inset, halogen
lights and glass sneeze guard
See Page 5 for Serv-Rite Heated Shelf models.

Unique Needs, Exact Solutions.
THE MARRIAGE OF UNIFORM HEAT
AND DIRECT FOOD PLACEMENT
The Hatco Heated Black Glass Shelf surface color
is an elegant black, to add the right touch to
any décor. Thermostatically-controlled heated
ceramic glass surface helps hold your food hot
and delicious at a surface temperature ranging
from 100° to 200°F (38°-93°C). NSF approval
allows you to place food product directly on
the glass surface. The Heated Black Glass Shelf
excels in pass-through areas, buffet lines
and as a tempting hors d’ouevre display.
The Choice is Yours.
• Available in portable and built-in models
• Lighted on/off rocker switch
• Portable units are available with
accessory trim rings and handles
in stainless steel (standard) or
powdercoated Designer Black
• All units come with a 6' (1829 mm)
cord and plug
3
HEATED CERAMIC GLASS SURFACE
HBG-2418 with
accessory handles.
HBG-2418

TWICE AS EFFECTIVE,
SAME HATCO QUALITY
Depending on your foodserving
layout, your product could benefit
from a more effective arrangement:
heat from above and below. Now
there’s no need to worry about drying
out foods or cooking beyond the
desired stage when you entrust your
product to Hatco’s Glo-Ray® line
of foodwarmers. They’re portable,
flexible, and available in a variety
of arrangements. Let Glo-Ray
technology work for you.
HEATING TECHNOLOGY FOR EVERY APPLICATION
800.558.0607
www.hatcocorp.com
4
GRSR-17 with optional
Designer color and
accessory food pan
GRAH-30 with optional Designer color and
infinite switch and accessory C-leg stand over
Heated Shelf GRS-24-I in optional Designer
color, with accessory food pans
Navy BlueWhite Granite Hunter GreenGray GraniteBlack
DESIGNER COLORS
Warm Red
Printed colors are a
representation and
may not exactly match
our Designer Colors.

GRSS-3618 in Bermuda
Sand Decorative Stone Unique Needs, Exact Solutions.
FITS JUST RIGHT
Simplicity and functionality team up
in Hatco’s Glo-Ray® Portable, Designer,
Drop-in, and Round Heated Shelves.
Whether you need a heated workspace
or extra base heat in a pass-through or
buffet area, Hatco’s full line of shelf
options can help you. Using a blanket
or metal-sheathed heating element for
an even temperature, the thermostatically
controlled base extends the holding
time of your food. Made with durable
stainless steel or hardcoated aluminum
tops, Hatco Heated Shelves are available
in a broad selection of sizes to fit your
operation. If bottom heat is what you need,
then Hatco has it. The Choice is Yours.
• Hatco Heated Stone Shelves are
made of NSF-approved foodsafe
materials
• Features a lighted rocker switch
and thermostatically-controlled
heated base to help hold your
food hot and delicious
• GRSSB models include a remote
box with a 3' (914 mm) conduit
and 6' (1829 mm) cord and plug
• Accessory 3" or 5" (76 mm or
127 mm) Risers available (GRSSR
models only) in stainless steel
(standard) or Designer colors
5
GRSSR-20 in Gray Granite
Decorative Stone
GRSSR20-DL77516 in Night Sky
Decorative Stone with accessory curved
Swanstone® Night Sky Cutting Board
GLO-RAY®
HEATED STONE SHELVES
Match the heat zone to your
countertops with Hatco’s Glo-Ray
Heated Stone Shelves. The built-in
or portable food-safe shelves come
in four standard colors and are
ideal for buffet lines or as hors
d’ouevre displays. These unique
warmers will safely hold food hot
while blending in with your décor.
Printed colors are a representation
and may not exactly match our
Heated Stone Colors.
SawgrassNight Sky
Bermuda Sand
Gray Granite
HEATED STONE COLORS
SRB-1 with
standard full-size
food pan
SRG-1 with
black glass inset
and food pans
SERV-RITE™HEATED SHELVES (NOT AVAILABLE IN DESIGNER COLORS)

FOOD ACCESS, WITH NO
TEMPERATURE SACRIFICE
Think flexible working space and quality
heat. Take a closer look at Hatco’s Ultra-Glo®
Portable Foodwarmers. They’re designed
to provide more distance between the heat
source and the holding pan than most
foodwarmers, while maintaining even heat
from above, below, or both. The Ultra-Glo
line was created with customerization
in mind. A wide selection of styles, colors,
lights, controls, hardcoated fry ribbons,
pans, and trivets can mean only one
thing... The Choice is Yours.
800.558.0607
www.hatcocorp.com
6
ULTIMATE HEAT SOURCE
GRCSCL-24 with optional
sneeze guards, drip pan, and
cutting board (not available
in other colors or finishes)
UGFFL in optional gloss finish
with accessory fry ribbon
Navy BlueWhite Granite Hunter Green
Gray GraniteBlackWarm Red
DESIGNER COLORS
Bold BlackBrilliant BlueGlossy GrayGleaming GoldRadiant Red
GLOSS FINISHES
Printed colors are a representation
and may not exactly match our
Designer Colors and Gloss Finishes.

CHOOSE YOUR SOLUTION
You can take it with you when you opt for
the versatility of Hatco’s Glo-Ray® Portable
Foodwarmers. Need heat from above, below,
or both? We’ve got it! Hatco’s foodwarmers
offer design flexibility without sacrificing
food product quality. The optional sign
holder helps generate impulse sales. The
complete Glo-Ray line has the solution for
your foodwarming need, and the design
capabilities to match a product to your
specifications. The Choice is Yours.
• Portable – ready to plug and “GLO”
• Each unit comes with a factory attached
6' (1829 mm) cord and plug so you can
put heat where you need it
• Versatile – available in many sizes, styles,
and heat sources to fit your needs
• Flexible – both top and thermostatically
controlled bottom heat available
• Accessories to customize foodwarmers to
any setting and application
Unique Needs, Exact Solutions.
7
GRFFB with optional infinite
switch and accessory food pans
GR-B Heated Base with
accessory sheet pan
LW-2 Lamp Warmer with
optional Designer color
and accessory food pans
TRADITIONAL WARMERS –
EXCEPTIONAL
PERFORMANCE
It’s easy to find a portable Hatco
foodwarmer for your application.
The Glo-Ray portable foodwarmer
displays your product while
keeping it hot and fresh. The
Hatco Lamp Warmer has a
specially designed, adjustable
stand, and unique insulating
base to extended holding time.
Available in six Designer colors,
they’re an updated version
of classic designs that have
served operators for years.
WHEREVER YOU NEED IT, HEAT IT

Printed in U.S.A. Form No. PFWB-0408-WWSG
April 2008
ANSI/NSF 4
P.O. Box 340500
Milwaukee, WI 53234-0500 U.S.A.
[phone] [phone]
www.hatcocorp.com
E-mail: [email protected]
Unique Needs, Exact Solutions.
At Hatco we look, listen, and bring our full experience to your operation. “Customerization” is our brand
promise…providing you with foodservice innovations that build your profits. That’s Hatco, and that’s always
good for business. Contact us today for all of your foodservice equipment needs.
SPECIFICATIONS
GLO-RAY®PORTABLE FOODWARMERS
PORTABLE LAMP WARMER
22" (559 mm)
18" (457 mm)
18"
(457 mm)
22"
(559 mm)
SIDE VIEWFRONT VIEW
12"
(305 mm)
ULTRA-GLO®PORTABLE FOODWARMERS
91⁄16"
(230 mm)
4"
(102 mm)
157⁄8"
(403 mm)
123⁄8"
(314 mm) 221⁄4" (565 mm)
24" (610 mm)
FRONT VIEW SIDE VIEW
22" (559 mm)
24" (610 mm)
16"-20"
(406-508 mm)
12"-16"
(305-406 mm)
SIDE VIEWFRONT VIEW
12"
(305 mm)
18" to 72" (457 to 1829 mm)
FRONT VIEW
191⁄2" (495 mm)
Standard
6" to 251⁄2" (152 to 648 mm)
Available
21⁄4" (57 mm)
SIDE VIEW 3" (76 mm)
HEATED SHELVES
301⁄8" to 781⁄8"
(765 to 1984 mm)
233⁄4" to 713⁄4"
(603 to 1822 mm)
213⁄4"
(552 mm)
4"
(102 mm)
27" (686 mm)
3"
(76 mm)
FRONT VIEW SIDE VIEW
SIDE VIEW TOP VIEW
37⁄8" (98 mm)
16
3⁄4"
,18
3⁄4", or 203⁄4
"
(425, 476, or
527 mm) Diameter
Glo-Ray®Model GRSR
Round Heated Shelf
Available in 120 volts, single phase,
and come in six Designer colors.
Glo-Ray®Model GRSSR Round
Heated Stone Shelf
Available in 120 volts, single phase,
and come in four Decorative Stone
colors with base available in six
Designer colors.
Glo-Ray®Model GRSS Portable Heated Stone Shelf
Available in 120 volts, single phase, and come in four
Decorative Stone colors with base available in six Designer colors.
Models UGFF, UGFFL, UGFFB, and UGFFBL
Portable Foodwarmers with Ceramic Elements
Available in 120 volts, single phase, and come in
six Designer Colors and five Gloss finishes.
Glo-Ray®Model GRS Heated Shelf
Available in 120 volts, single phase, and come in six Designer colors.
Glo-Ray® Model GRSSR20-DL7716
Heated Stone Shelf with Decorative Lamp
Available in 120 volts, single phase, and come in four Decorative Stone
colors with lamp and base available in six Designer colors.
Glo-Ray®Model GR2S Designer Heated Shelf
Available in 120 volts, single phase, and come in six Designer colors.
Models GRFF, GRFFL, GRFFB, and GRFFBL Portable
Foodwarmers with Metal-Sheathed Elements
Available in 120 volts, single phase, and come in six Designer
colors and five Gloss finishes (excludes heated base).
Model LW-2 Portable Lamp Warmer
Available in 120 volts, single phase, and come in six Designer colors.
123⁄8"
(314 mm)
SIDE VIEW
24" to 30"
(610-762 mm)
141⁄2" to 191⁄2"
(368-495 mm)
101⁄2" to 161⁄2"
(267-419 mm)
FRONT VIEW
203⁄4" (527 mm)
22" (559 mm)
PLEASE REFERENCE PRODUCT SPECIFICATION SHEETS FOR INDIVIDUAL MODEL LISTINGS
221⁄2" (572 mm)
SIDE VIEW
20" (508 mm)
36" (914 mm)
163⁄8" (416 mm)
FRONT VIEW
25⁄8"
(67 mm)
GRSR
GRSSR
UGFFBL
GRFFL
GRFFBL
LW-2
GRS
GR2S
GRSSR20-
DL77516
SERV-RITE™BUFFET WARMERS
AND HEATED SHELVES
Model Models SRB-1, SRBW-1, SRG-1, SRGBW-1
Available in 120 volts, single phase.
BLACK GLASS HEATED SHELVES
Models HBGB-2418, -3018, -3618, -4818, -6018, -7218
Heated Black Glass Shelf
Available in 120 volts, single phase only.
SRBW
Dimmer For
Overhead
Lamps
23¹/2"
(597 mm)
5 ³/ 8 "
(137 mm)
26"
(660 mm)
31³/8"
(797 mm)
2 X 300 Watt
Halogen Lamps
Provide Light
and Top Heat
Digital Control with
Lighted Rocker Switch
Temperature Range
up to 240º F (11º C)
Tempered Glass
Breath Shield
9¹/4"
(235 mm)
22
¹/ 8 "
(562 mm)
27³/4"
(705 mm)
32 ³/4"
(832 mm)
Tempered Glass
Breath Shield
9¹/4"
(235 mm)
Digital Control with
Lighted Rocker Switch
Temperature Range
up to 240º F (11º C)
2 X 300 Watt
Halogen Lamps
Provide Light
and Top Heat
27³/4"
(705 mm)
32 ³/4"
(832 mm)
31³/8"
(797 mm)
22
¹/ 8 "
(562 mm)
Dimmer for
Overhead
Lamps
23¹/2"
(597 mm)
5 ³/ 8 "
(137 mm)
26"
(660 mm)
SRB - base only
SRGBW
SRG - base only
HBG Models
183⁄8"
(467 mm)
243⁄8, 303⁄8, 363⁄8, 483⁄8, 603⁄8, or 723⁄8"
(619, 772, 924, 1229, 1534, or 1838 mm)
21⁄2"
(64 mm)
GLO-RAY®CARVING STATIONS
Models GRCSCL-24 and GRCSCLH-24 (with Base Heater)
Carving Stations
Available in 120 volts, single phase (not available in
Designer Colors and Gloss Finishes).
25" (635 mm)
28" (711 mm)
191⁄2" (495 mm)
23" (584 mm)
26" (660 mm)
FRONT VIEW SIDE VIEW
171⁄2" to 231⁄2"
(445 to 597 mm)
21⁄2" (64 mm)
21⁄2" (64 mm)
221⁄2" to 281⁄2"
(572 to 724 mm)
GRCSCL
TOP VIEW
16, " 18 ," or 20 "
(406, 457, or 508 mm)
Diameter
SIDE VIEW
25⁄8"
(67 mm)
GRSS
24", 30", 36", 48", 60", or 72"
(610, 762, 914, 1219, 1524, or 1829 mm)
FRONT VIEW
18" (457 mm)
SIDE VIEW
21⁄2"
(64 mm)
27³/4"
(705 mm)
Digital Control with
Lighted Rocker Switch
Temperature Range
up to 240º F (11º C)
5 ³/ 8 "
(137 mm)
315/8"
(805 mm)
22 ¹/ 8 "
(562 mm)
27³/4"
(705 mm)
315/8"
(805 mm)
22 ¹/ 8 "
(562 mm)
5 ³/ 8 "
(137 mm)
Digital Control with
Lighted Rocker Switch
Temperature Range
up to 240º F (11º C)
Cover photo and photos appearing on Pages 2-3
taken at the Pfister Hotel, Milwaukee, WI
