FR2 HYDRO-HEATER FOOD RETHERMALIZERS / BAIN-MARIE HEATERS
Models FR2-3, -4, -6 FR2-3B, -4B, -6B, -9B
The Hatco Hydro-Heater is a state-o -
the-art, high e iciency circulation water
heater, using a combination o “ ree- low”
technology and advanced electronic
controls or circulating hot water by
natural convection in a sink or
reconstituting rozen oods.
This heater eatures a tubular water
chamber with heating elements uniquely
wrapped outside the low tube so
elements do not come in direct contact
with the water. The design eliminates
sediment and lime buildup on the
element, resulting in longer li e. A special
electronic controller maintains the
setpoint temperature assuring
a responsive and e icient operation.
FLEXIBILITY
As a ood reconstitutor, the Hydro-
Heater FR2 heats or holds ood at sa e
temperatures between 140°F and 190°F
(60°-88°C).
QUALITY
The ollowing eatures assure the inest
per ormance or years to come:
• Utilizes “ ree- low” technology and
advanced electronic controls to assure
a responsive and e icient operation.
• All models include a stainless steel
ront, powdercoated body, convenient
drain outlet, and clean-out caps.
ANSI/NSF 4
Model FR2-3
Patented
WATER QUALITY REQUIREMENTS
Incoming water in excess o 3.0 grains o hardness per gallon (GPG)
(.75 grains o hardness per liter) must be treated and so tened be ore
being supplied to water heater(s). Water containing over 3.0 GPG
(.75 GPL) will decrease the e iciency and reduce the operating li e
o the unit.
Note: Product failure caused by liming or sediment buildup is not
covered under warranty
FOOD RETHERMALIZING REQUIREMENTS
NSF Standard 4 has added per ormance requirements or ood rethermalizing. The requirements mirror
the requirements or ood rethermalizing in the FDA Food Code. The basic requirement is that ood
reaches a temperature o 165°F (74°C) in a time period o two hours or less.
Appliances that are manu actured or the purpose o rethermalizing ood will need to meet these
per ormance requirements in order to be listed to NSF Standard 4.
Hatco sells a heating unit speci ically made to be used or ood rethermalizing, however, the heating
unit is designed to be incorporated into a hot water bath rethermalizer. Hatco does not supply the vessel
that contains the water, nor the system which determines how ood is placed and held in the vessel.
The Hatco FR2 unit simply attaches to the bottom o the vessel and supplies hot water to the vessel.
Hatco does supply sizing recommendations to enable the appliance manu acturer to correctly size the
FR2 unit to the vessel. However, there are variables in the way that the vessel is manu actured that a ect
its ability to pass the NSF per ormance requirements. The Hatco FR2 unit is listed with NSF or
construction only. Due to the act that the FR2 is only a portion o a larger system, it is impossible to do
per ormance testing until the FR2 unit is incorporated onto the water vessel.
The result is that it is the responsibility o the vessel manu acturer to have the entire rethermalizing
appliance tested and listed in accordance with NSF Standard 4. Simply hanging an NSF listed FR2 unit
on the appliance does not trans er NSF listing to the entire appliance.

ITEM#
HATCO CORPORATION P.O. Box 340500 Milwauk , WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: quipsal [e-mail]
FR2 HYDRO-HEATER FOOD RETHERMALIZERS / BAIN-MARIE HEATERS
Models FR2-3, -4, -6 FR2-3B, -4B, -6B, -9B
SPECIFICATIONS
Mod l kW Phas Shipping W ight
FR2-3 3124 lbs. (11 kg)
FR2-4 4124 lbs. (11 kg)
FR2-6 6127 lbs. (12 kg)
FR2-3B✝3324 lbs. (11 kg)
FR2-4B✝4324 lbs. (11 kg)
FR2-6B✝6327 lbs. (12 kg)
FR2-9B✝9327 lbs. (12 kg)
DIMENSIONS
73⁄4"W x 171⁄8"D x 123⁄8"H (197 x 435 x 314 mm).
VOLTAGE
208 or 240 volts, 50/60 Hz.
PLUG CONFIGURATIONS (FR2-3 and FR2-4 only)
NEMA 6-30P
NEMA 6-20P
FR2-3: 208 or 240 volts (uses NEMA 6-20P).
FR2-4: 208 volts (uses NEMA 6-30P, 240 volts uses NEMA 6-20P,
NEMA 6-30P – Canada).
OPTIONS (NOT FOR RETROFIT)
❑Stainless Steel Body and Base
❑Auto- ill Solenoid
❑Remote Mounted Control
❑Security Package
ACCESSORIES
❑4' (1219 mm) Cord with Plug
(NEMA 6-20P) and Receptacle (NEMA 6-20R) (FR2-3 only)
❑4' (1219 mm) Cord with Plug
(NEMA 6-30P) and Receptacle (NEMA 6-30R) (FR2-4 only)
❑Flush Hose, Cleaning Brush, Stopper, and Adapter
SIZING INFORMATION
For a Bain-Marie or Steam Table: MINIMUM 750 WATTS PER
SQUARE FOOT (0,8 watts per sq. cm) o vessel top.
For a Food Rethermalizer: MINIMUM 2000 WATTS PER
SQUARE FOOT (2,2 watts per sq. cm) o vessel top.
Use one FR2 or a Bain-Marie up to 6' (1829 mm) long.
Over 6' (1829 mm), minimum two required.
MUST BE INSTALLED WITH A PERFORATED WATER
BAFFLE. This ba le is not suppli d with heater. The FR2
should be positioned with no more than 3' (914 mm) on either
side when mounted in holding vessel. Consult actory or
installation manual or abricating details.
PRODUCT SPECS
Hydro-H at r Food R constitutor/Bain-Mari H at r
The electric heater designed to hold oods in the bain-marie or
heat and hold rozen oods in a ood reconstitutor shall be a
Hydro-Heater Model .... as manu actured by the Hatco
Corporation, Milwaukee, WI 53234 U.S.A.
With 24/7 service (U.S. and Canada only), the Hatco Model FR2
shall be rated at ....kW, ....volts, ....phase. The heater shall be
complete with all internal plumbing and wiring ready or external
installation to the bottom o the
holding vessel.
The heater shall consist o 1 to 3 stainless steel tubes wrapped
with external heating elements. Each tube may be accessed or
cleaning purposes. The unit may be emptied easily by a
convenient drain.
The heater shall be equipped with an electronic temperature
controller adjustable rom 140°F to 190°F (60° to 88°C),
an on-o switch, a low-water cut-o , and a digital
temperature display.
The heater shall consist o powdercoated black hammertone
ront and body (or optional stainless steel body and base).
✝Balanced 3-phase.
SIDE VIEW REAR VIEW
93⁄4"
(248 mm)
1⁄2"&3⁄4"
Conduit K.O.
1⁄2" & 3⁄4" Conduit K.O.
3⁄4" hose
connection
to drain
1"
(25 mm)
123⁄8"
(314 mm)
51⁄2"
(140 mm) 81⁄2"(216 mm) 33⁄8" (86 mm)
63⁄4"
(171 mm)
31⁄16"
(78 mm)
171⁄8"(435 mm)
25⁄8"
(67 mm)
