Hatco Glo-Ray GRSB-24-F User manual

ITEM#
ANSI/NSF 4
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
[phone] • [phone] • Fax [phone] • Int’l. Fax [phone]
www.hatcocorp.com • E-mail: [email protected]
Form No. GRSB-1006(S) Printed in U.S.A.
GLO-RAY ®
BUILT-IN HEATED SHELVES
Models GRSB-24-F, -I, -O, -30-F, -I, -O, -36-F, -I, -O, -42-F, -I, -O, -48-F, -I, -O, -54-I, -60-F, -I, -O, -66-I, -72-F, -I, -O
GRSBF-24-F, -I, -S, -O, -30-F, -I, -S, -O, -36-F, -I, -S, -O, -42-F, -I, -S, -O, -48-F, -I, -S, -O, -60-F, -I, -S, -O, -72-F, -I, -S, -O
The Hatco Glo-Ray Built-in Heated Shelf
has a hardcoat aluminum top and
blanket type foil element for uniform
heat. Fiberglass insulation keeps heat
at the holding surface while a built-in
adjustable thermostat controls surface
temperature. Recommended for use in
metallic counters. For other surfaces,
verify that the material is suitable for
temperature up to 180°F (82°C). Hatco
is not responsible for counter damage
caused by heat from the warmer.
FLEXIBILITY
Ideal for pass-through areas, buffet lines
or as a heated work shelf.
The Built-in Heated Shelf models
feature a hardcoated aluminum top and
blanket-type foil element for uniform
heat distribution. Available as flush top
or 1⁄2" (13 mm) recessed models.
A 3' (914 mm) flexible conduit channels
the power lines from the shelf to a
remote control enclosure. The control
enclosure comes with a control
thermostat with a range of 80° to 181°F
(27°to 83°C), an illuminated on/off
switch and mounting brackets. The
attached control enclosure can be
mounted remotely up to 3' (914 mm)
from the unit. A 6' (1829 mm) cord and
plug is attached to easily reach the
power source.
The Built-in Heated Shelf has a 3⁄4"
(19 mm) flanged edge that allows the
unit to fit into a countertop opening.
The Heated Shelf is easy-to-clean with a
soft damp cloth or non-abrasive cleaner.
QUALITY
The following features assure the finest
performance for years to come:
• All models feature a thermostatically-
controlled heated base to extend the
holding times of most food.
• GRSB models available in widths
from 24" to 72" (610-1829 mm) and
depths of 151⁄2", 191⁄2", or 30"
(394, 495, or 762 mm).
• GRSBF models are available in widths
from 251⁄2" to 731⁄2" (648-1867 mm)
and depths of 17", 21", 251⁄2", or 311⁄2"
(432, 533, 648, or 800 mm).
BLANKET ELEMENTS GUARANTEED AGAINST
BURNOUT AND BREAKAGE FOR ONE YEAR.
Model GRSBF-72-O
with accessory pizza pans
Item Minimum Width Maximum Width Minimum Depth Maximum Depth
GRSB-24-F/GRSBF-24-F 241⁄2" ( 622 mm) 243⁄4" ( 629 mm) 16" (406 mm) 161⁄4" (413 mm)
GRSB-24-I/GRSBF-24-I 241⁄2" ( 622 mm) 243⁄4" ( 629 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSBF-24-S 241⁄2" ( 622 mm) 243⁄4" ( 629 mm) 241⁄2" (622 mm) 243⁄4" (629 mm)
GRSB-24-O/GRSBF-24-O 241⁄2" ( 622 mm) 243⁄4" ( 629 mm) 301⁄2" (775 mm) 303⁄4" (781 mm)
GRSB-30-F/GRSBF-30-F 301⁄2" ( 775 mm) 303⁄4" ( 781 mm) 16" (406 mm) 161⁄4" (413 mm)
GRSB-30-I/GRSBF-30-I 301⁄2" ( 775 mm) 303⁄4" ( 781 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSBF-30-S 301⁄2" ( 775 mm) 303⁄4" ( 781 mm) 241⁄2" (622 mm) 243⁄4" (629 mm)
GRSB-30-O/GRSBF-30-O 301⁄2" ( 775 mm) 303⁄4" ( 781 mm) 301⁄2" (775 mm) 303⁄4" (781 mm)
GRSB-36-F/GRSBF-36-F 361⁄2" ( 927 mm) 363⁄4" ( 933 mm) 16" (406 mm) 161⁄4" (413 mm)
GRSB-36-I/GRSBF-36-I 361⁄2" ( 927 mm) 363⁄4" ( 933 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSBF-36-S 361⁄2" ( 927 mm) 363⁄4" ( 933 mm) 241⁄2" (622 mm) 243⁄4" (629 mm)
GRSB-36-O/GRSBF-36-O 361⁄2" ( 927 mm) 363⁄4" ( 933 mm) 301⁄2" (775 mm) 303⁄4" (781 mm)
GRSB-42-F/GRSBF-42-F 421⁄2" (1080 mm) 423⁄4" (1086 mm) 16" (406 mm) 161⁄4" (413 mm)
GRSB-42-I/GRSBF-42-I 421⁄2" (1080 mm) 423⁄4" (1086 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSBF-42-S 421⁄2" (1080 mm) 423⁄4" (1086 mm) 241⁄2" (622 mm) 243⁄4" (629 mm)
GRSB-42-O/GRSBF-42-O 421⁄2" (1080 mm) 423⁄4" (1086 mm) 301⁄2" (775 mm) 303⁄4" (781 mm)
GRSB-48-F/GRSBF-48-F 481⁄2" (1232 mm) 483⁄4" (1238 mm) 16" (406 mm) 161⁄4" (413 mm)
GRSB-48-I/GRSBF-48-I 481⁄2" (1232 mm) 483⁄4" (1238 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSBF-48-S 481⁄2" (1232 mm) 483⁄4" (1238 mm) 241⁄2" (622 mm) 243⁄4" (629 mm)
GRSB-48-O/GRSBF-48-O 481⁄2" (1232 mm) 483⁄4" (1238 mm) 301⁄2" (775 mm) 303⁄4" (781 mm)
GRSB-54-I 541⁄2" (1384 mm) 543⁄4" (1391 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSB-60-F/GRSBF-60-F 601⁄2" (1537 mm) 603⁄4" (1543 mm) 16" (406 mm) 161⁄4" (413 mm)
GRSB-60-I/GRSBF-60-I 601⁄2" (1537 mm) 603⁄4" (1543 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSBF-60-S 601⁄2" (1537 mm) 603⁄4" (1543 mm) 241⁄2" (622 mm) 243⁄4" (629 mm)
GRSB-60-O/GRSBF-60-O 601⁄2" (1537 mm) 603⁄4" (1543 mm) 301⁄2" (775 mm) 303⁄4" (781 mm)
GRSB-66-I 661⁄2" (1689 mm) 663⁄4" (1695 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSB-72-F/GRSBF-72-F 721⁄2" (1842 mm) 723⁄4" (1848 mm) 16" (406 mm) 161⁄4" (413 mm)
GRSB-72-I/GRSBF-72-I 721⁄2" (1842 mm) 723⁄4" (1848 mm) 20" (508 mm) 201⁄4" (514 mm)
GRSBF-72-S 721⁄2" (1842 mm) 723⁄4" (1848 mm) 241⁄2" (622 mm) 243⁄4" (629 mm)
GRSB-72-O/GRSBF-72-O 721⁄2" (1842 mm) 723⁄4" (1848 mm) 301⁄2" (775 mm) 303⁄4" (781 mm)
GRSB/GRSBF Countertop Cut-Out Dimensions
Model GRSB-30-I

21⁄4"
(57 mm)
21⁄32"
(52 mm)
71⁄16" (179 mm)
17", 21", 251⁄2", or 311⁄2"
(432, 533, 648, or 800 mm)
FRONT VIEW
SIDE VIEW
251⁄2" to 731⁄2" (648 to 1867 mm)
GRSBF Models
ITEM#
PRODUCT SPECS
Built-in Heated Shelf
The Heated Shelf shall be a Glo-Ray®Model ....as manufactured
by the Hatco Corporation, Milwaukee, WI 53234 U.S.A.
The Shelf shall be rated at ....watts, ....volts and be ....inches
(millimeters) in overall width. It shall consist of a thermostatically-
controlled heated base and a cord with plug attached.
GLO-RAY ®
BUILT-IN HEATED SHELVES
Models GRSB-24-F
, -I, -O, -30-F, -I, -O, -36-F, -I, -O, -42-F, -I, -O, -48-F, -I, -O, -54-I, -60-F, -I, -O, -66-I, -72-F, -I, -O
GRSBF-24-F
, -I, -S, -O, -30-F, -I, -S, -O, -36-F, -I, -S, -O, -42-F, -I, -S, -O, -48-F, -I, -S, -O, -60-F, -I, -S, -O, -72-F, -I, -S, -O
Model Watts Interior Width Shipping Weight
GRSB-24-F 420 24" ( 610 mm) 20 lbs. ( 9 kg)
GRSB-24-I 550 24" ( 610 mm) 22 lbs. (10 kg)
GRSB-24-O 790 24" ( 610 mm) 26 lbs. (12 kg)
GRSB-30-F 505 30" ( 762 mm) 23 lbs. (10 kg)
GRSB-30-I 665 30" ( 762 mm) 25 lbs. (11 kg)
GRSB-30-O 950 30" ( 762 mm) 28 lbs. (13 kg)
GRSB-36-F 590 36" ( 914 mm) 26 lbs. (12 kg)
GRSB-36-I 780 36" ( 914 mm) 29 lbs. (13 kg)
GRSB-36-O 1110 36" ( 914 mm) 32 lbs. (15 kg)
GRSB-42-F 685 42" (1067 mm) 29 lbs. (13 kg)
GRSB-42-I 885 42" (1067 mm) 32 lbs. (15 kg)
GRSB-42-O 1270 42" (1067 mm) 35 lbs. (16 kg)
GRSB-48-F 770 48" (1219 mm) 33 lbs. (15 kg)
GRSB-48-I 1000 48" (1219 mm) 36 lbs. (16 kg)
GRSB-48-O 1430 48" (1219 mm) 39 lbs. (18 kg)
GRSB-54-I 1110 54" (1372 mm) 43 lbs. (20 kg)
GRSB-60-F 950 60" (1524 mm) 45 lbs. (20 kg)
GRSB-60-I 1220 60" (1524 mm) 50 lbs. (23 kg)
GRSB-60-O 1750 60" (1524 mm) 54 lbs. (24 kg)
GRSB-66-I 1330 66" (1676 mm) 54 lbs. (25 kg)
GRSB-72-F 1130 72" (1829 mm) 52 lbs. (24 kg)
GRSB-72-I 1440 72" (1829 mm) 58 lbs. (26 kg)
GRSB-72-O 2070 72" (1829 mm) 64 lbs. (29 kg)
Built-in Heated Shelf with Inset Top
DIMENSIONS
GRSB: (Interior Width + 11⁄2 ") W x 17", 21", or 31
1⁄2
"D x 2
7⁄8
"H
(
Interior Width + 38 x 432, 533, or 800 x 73 mm).
Cutout: ( Interior Width + 1⁄2 "to
3⁄4
")W x 16", 20", or 30
1⁄2
"D
( Interior Width + 13 to 19 mm x 406, 508, or 775 mm ).
GRSBF: (251⁄2 " to 73
1⁄2
") W x 17", 21", 25
1⁄2
", or 31
1⁄2
"D x 2
1⁄4
"H
( 648 to 1867 x 432, 533, 648, or 800 x 57 mm).
Cutout: ( Width - 3⁄4 " to 1") W x 16", 20", 24
1⁄2
", or 30
1⁄2
"D
( Width - 19 to 25 mm x 406, 508, 622, or 775 mm ).
VOLTAGE
All models ending in -F and -I and models 24" through 48"
(610-1219 mm) wide ending in -S and -O: 120 volts,
single phase only, NEMA 5-15P.
Models 60" through 72" (1524-1829 mm) wide ending in -S
and -O: 120 volts, single phase only, NEMA 5-20P.
GRSB-72-O and GRSBF-72-O: 208 or 240 volts,
single phase only, NEMA 6-15P.
Export voltages available.
CORD LOCATION
End of Remote Enclosure.
PLUG CONFIGURATIONS
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Form No. GRSB-1006(S) Printed in U.S.A.
Model Watts Heated Width Shipping Weight
GRSBF-24-F 420 251⁄2" ( 648 mm) 20 lbs. ( 9 kg)
GRSBF-24-I 550 251⁄2" ( 648 mm) 22 lbs. (10 kg)
GRSBF-24-S 700 251⁄2" ( 648 mm) 24 lbs. (11 kg)
GRSBF-24-O 790 251⁄2" ( 648 mm) 26 lbs. (12 kg)
GRSBF-30-F 505 311⁄2" ( 800 mm) 23 lbs. (10 kg)
GRSBF-30-I 665 311⁄2" ( 800 mm) 25 lbs. (11 kg)
GRSBF-30-S 825 311⁄2" ( 800 mm) 26 lbs. (12 kg)
GRSBF-30-O 950 311⁄2" ( 800 mm) 28 lbs. (13 kg)
GRSBF-36-F 590 371⁄2" ( 953 mm) 26 lbs. (12 kg)
GRSBF-36-I 780 371⁄2" ( 953 mm) 28 lbs. (13 kg)
GRSBF-36-S 950 371⁄2" ( 953 mm) 31 lbs. (15 kg)
GRSBF-36-O 1110 371⁄2" ( 953 mm) 32 lbs. (15 kg)
GRSBF-42-F 685 431⁄2" (1105 mm) 29 lbs. (13 kg)
GRSBF-42-I 885 431⁄2" (1105 mm) 32 lbs. (15 kg)
GRSBF-42-S 1100 431⁄2" (1105 mm) 34 lbs. (15 kg)
GRSBF-42-O 1270 431⁄2" (1105 mm) 35 lbs. (16 kg)
GRSBF-48-F 770 491⁄2" (1257 mm) 33 lbs. (15 kg)
GRSBF-48-I 1000 491⁄2" (1257 mm) 36 lbs. (16 kg)
GRSBF-48-S 1225 491⁄2" (1257 mm) 38 lbs. (17 kg)
GRSBF-48-O 1430 491⁄2" (1257 mm) 39 lbs. (18 kg)
Built-in Heated Shelf with Flush Top
Model Watts Heated Width Shipping Weight
GRSBF-60-F 950 611⁄2" (1562 mm) 45 lbs. (20 kg)
GRSBF-60-I 1220 611⁄2" (1562 mm) 50 lbs. (23 kg)
GRSBF-60-S 1500 611⁄2" (1562 mm) 53 lbs. (24 kg)
GRSBF-60-O 1750 611⁄2" (1562 mm) 54 lbs. (25 kg)
GRSBF-72-F 1130 731⁄2" (1867 mm) 52 lbs. (24 kg)
GRSBF-72-I 1440 731⁄2" (1867 mm) 58 lbs. (26 kg)
GRSBF-72-S 1750 731⁄2" (1867 mm) 62 lbs. (28 kg)
GRSBF-72-O 2070 731⁄2" (1867 mm) 64 lbs. (29 kg)
Built-in Heated Shelf with Flush Top
SPECIFICATIONS
27⁄8"
(73 mm)
1⁄2"
(13 mm)
(GRSB
only) 21⁄32"
(52 mm)
71⁄16" (179 mm)
0 to 11⁄4"
(0 to 32 mm)
24" to 72" (610 to 1829 mm)
251⁄2" to 731⁄2" (648 to 1867 mm) 151⁄2", 191⁄2", or 30"
(394, 495, or 762 mm)
17", 21", or 311⁄2"
(432, 533, or 800 mm)
FRONT VIEW
SIDE VIEW
GRSB Models
NEMA 6-15PNEMA 5-20P
CEE 7/7 Schuko
NEMA 5-15P
BS-1363
UNIT DEPTH CODES:
F = 17" (432 mm)
I = 21" (533 mm)
S = 251/2"(648 mm)
O = 311/2" (800 mm)
OPTIONS (NOT FOR RETROFIT)
❑Stainless Steel Top Surface (GRSBF models only)
