3CS SANITIZING SINK HEATERS
Models 3CS-3, 3CS-4, 3CS-6, 3CS-9, 3CS-3B, 3CS-4B, 3CS-6B, 3CS-9B
The Hatco 3CS Sanitizing Sink Heater
makes manual warewashing faster and
more convenient. It maintains a continuous
supply of sanitizing rinse water without
taking up valuable sink space.
FLEXIBILITY
Designed to fit under the center of
the sink, the 3CS is perfect for 3- or
4-compartment sinks, pot and pan sinks,
and bar sinks.
The 3CS features a unique dual reservoir
system. One reservoir contains the
heating element and should always be
filled with water. The other reservoir
traps and collects soil carried from other
sink compartments. This reservoir is
easily emptied after each use by a
convenient drain.
QUALITY
The following features assure the finest
performance for years to come:
• All models include stainless steel front,
powdercoated silver-gray hammertone
body, and convenient side drain.
• Every Hatco 3CS is equipped with an
ECO (Energy Cut-Off) wired into the
electrical circuit. This built-in protection
“breaks” the power to the elements if
the temperature of the water goes
above the normal thermostat setting.
• An on-off toggle switch activates the
heater and a yellow light indicates
when power is on. A red light is an
overtemp indicator pointing out the
need to refill the unit with water and
reset the unit.
• Each 3CS model features a stainless
steel tank with a five-year warranty.
• Available with an optional temperature
monitor or temperature light that
indicates when water reaches the
sanitizing temperature.
• The 3CS is shipped ready to install
with all gaskets and fittings.
• Meets NSF Standard of 180°F (82°C)
for dish sanitizing.
Water
Inlet
Water
Outlet
Sump
Drain
Drain
Handle
(Shown in closed
position)
Heating
Chamber
Drain
Front
WATER QUALITY REQUIREMENTS
Incoming water in excess of 3.0 grains of hardness per gallon (GPG)
(.75 grains of hardness per liter) must be treated and softened before
being supplied to water heater(s). Water containing over 3.0 GPG
(.75 GPL) will decrease the efficiency and reduce the operating life
of the unit.
Note: Product failure caused by liming or sediment buildup is not
covered under warranty.

VOLTAGE
208 or 240 volts, 50/60 Hz standard. 480 volts and CSA wiring
for Canada available.
Export voltages available.
ELECTRICAL RATINGS
OPTIONS (NOT FOR RETROFIT)
❑Stainless Steel Body and Base
❑Temperature Monitor (Not available with Light)
❑Temperature Light (Not available with Monitor)
ITEM#
SPECIFICATIONS
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Form No. 3CS-1006(S) Printed in U.S.A.
SIDE VIEW REAR VIEW
A
B C D
E
93⁄4"
(248 mm)
F
4" (102 mm)
3⁄4"
Conduit
K.O.
3⁄4" hose
connection
to drain
1"
(25 mm)
125⁄8"
(321 mm)
27⁄8" (73 mm)
PRODUCT SPECS
Sanitizing Sink Heater
The electric heater to maintain the final sanitizing rinse in a third
compartment sink shall be a Hatco Model .... as manufactured
by the Hatco Corporation, Milwaukee, WI 53234 U.S.A.
The Third Compartment Sink Heater shall be rated at ....kW,
....volts, ....phase. The heater shall be complete with all internal
plumbing and wiring ready for external installation to the bottom
of sink.
The heater tank shall be of stainless steel construction and
dual reservoir design; one reservoir to contain a permanently
submerged heating element, the other to trap and collect soil
which can be emptied easily by a convenient drain.
The sink heater shall be equipped with an on-off reset switch and
optional indicator lights (or gauge) to signal operating conditions.
The heater shall consist of stainless steel front and powder-
coated silver-gray hammertone body (or stainless steel body
and base).
Model kW Phase Sink Area Shipping Weight
3CS-3 3 1 15" (381 mm) Sq. or less 24 lbs. (11 kg)
3CS-4 4.5 1 16"-18" (406-457 mm) Sq. 24 lbs. (11 kg)
3CS-6 6 1 or 3★19"-21" (483-533 mm) Sq. 27 lbs. (12 kg)
3CS-9 9 1 or 3★21"-25" (533-635 mm) Sq. 27 lbs. (12 kg)
3CS-3B†3 3 15" (381 mm) Sq. or less 30 lbs. (14 kg)
3CS-4B†4.5 3 16"-18" (406-457 mm) Sq. 30 lbs. (14 kg)
3CS-6B†6.8 3 19"-21" (483-533 mm) Sq. 30 lbs. (14 kg)
3CS-9B†9 3 21"-25" (533-635 mm) Sq. 30 lbs. (14 kg)
★Open delta on 3-phase. Larger circuit required than for balanced 3-phase
of equal kW.
†Balanced 3-phase.
3CS SANITIZING SINK HEATERS
Models 3CS-3, 3CS-4, 3CS-6, 3CS-9, 3CS-3B, 3CS-4B, 3CS-6B, 3CS-9B
SIZING INFORMATION
For a Sink Heater: 2000 watts per sq. ft. (2,2 watts per sq. cm)
of vessel top.
3CS Sink Heaters are sized based on 140°F (60°C) supply
water with a 30-minute preheat period to reach the sanitizing
temperature. Sink Heaters are mounted in the center of the
third compartment sink with standard plumbing fittings
provided. Two 2" (51 mm) diameter holes are required for these
fittings and a full-size template is provided to locate holes in
the sink. The 3CS Sink Heater is easily attached to the
plumbing fittings with self-contained unions.
DIMENSIONS
Single or 3-Phase: 63⁄4"W x 167⁄8"D x 125⁄8"H (171 x 429 x 321 mm).
Balanced 3-Phase: 8"W x 171⁄8"D x 125⁄8"H (203 x 435 x 321 mm).
3CS-9 480V model: 8"W x 171⁄8"D x 125⁄8"H (203 x 435 x 321 mm).
208 Volts Wire Size Fuse or
kW Rating Phase Amps AWG Circuit Breaker
3.0 1 14.5 12 20
4.5 1 22 10 30
6.0 1 29 8 40
6.0 3* 25 8 40
6.8 3 (Bal.) 18.8 10 30
9.0 1 43 4 60
9.0 3* 37 6 50
9.0 3 (Bal.) 25 10 40
240 Volts Wire Size Fuse or
kW Rating Phase Amps AWG Circuit Breaker
3.0 1 12.5 12 20
4.5 1 19 10 30
6.0 1 25 8 40
6.0 3* 22 10 30
6.0 3 (Bal.) 14.4 12 20
9.0 1 38 6 50
9.0 3* 33 8 40
9.0 3 (Bal.) 22 10 30
❑Wiring to CSA Specifications
❑Security Package
ACCESSORIES
❑Flush Hose Kit
480 Volts Wire Size Fuse or
kW Rating Phase Amps AWG Circuit Breaker
3.0 1 6.3 14 15
4.5 1 9.4 14 15
6.0 1 12.5 12 20
6.0 3* 10.8 14 15
6.0 3 (Bal.) 7.2 14 15
9.0 1 18.8 10 30
9.0 3* 16.2 12 20
9.0 3 (Bal.) 10.8 14 15
* Open Delta – standard construction (Amperage higher than balanced 3-phase).
Model A B C D E F
1- or 3-phase 167⁄8"5
1⁄2"8 1⁄2"2 7⁄8"6 3⁄4"3 3⁄8"
429 mm 140 mm 216 mm 73 mm 171 mm 86 mm
Bal. 3-phase 171⁄8"4
5⁄8"8 1⁄2"4"8"4"
435 mm 117 mm 216 mm 102 mm 203 mm 102 mm
