Hatco POWERMITE PMG-100 User manual

NATURAL GAS
Altitude: ft. above sea level 0 – 2000 2001-3000 3001-4000 4001-5000 5001-6000 6001-7000 7001-8000 8001-8500 8501-9500 9501-10500
PMG-60
Approved Input Rate: c58000 56154 54308 52462 50615 48769 46923 46000 44160 42320
Suggested Orifice Size: d#55DMS
#56DMS
GPH Capacity Derate: e1 0.97 0.94 0.90 0.87 0.84 0.81 0.79 0.76 0.73
PMG-100
Approved Input Rate: c105000 103363 101726 100089 98452 96815 95178 94360 90585 86811
Suggested Orifice Size: d#34DMS
GPH Capacity Derate: e1 0.98 0.97 0.95 0.94 0.92 0.91 0.90 0.86 0.83
PMG-200
Approved Input Rate: c195000 171600 163800 156000 148200 140400 132600 128700 123552 118404
Suggested Orifice Size: d#35 DMS #36DMS #37DMS #38DMS #39DMS #40DMS #41DMS #42DMS
GPH Capacity Derate: e1 0.88 0.84 0.80 0.76 0.72 0.68 0.66 0.63 0.61
Notes:
cThis is the maximum allowable btu rate certified by AGA. These are to be verified by the qualified gas installer on site. Check Heat Value with local Gas Utility.
dThefirst orifice size is the factory built unit.
The next sizes are shown at the altitudes where a change is required to allow pressure adjustments to the approved input rates.
eThis is a derate multiplier to use when sizing a gas booster for a given application.
Take this value and multiply it by the GPH found on the Hatco sizing chart to insure it will provide the capacity you need.
You can also use this value by dividing it into your capacity needs and take the resulting adjusted GPH to the sizing chart to select a gas booster.
ALTITUDE SUMMARY
PUBLICATION DATA FOR POWERMITE®GAS BOOSTERS

LIQUID PROPANE GAS
Altitude: ft. above sea level 0 - 2000 2001-3000 3001-4000 4001-5000 5001-6000 6001-7000 7001-8000 8001-8500 8501-9500 9501-10500
PMG-60 LPG
Approved Input Rate: c58000 57154 56308 55461 54615 53769 52923 52500 50400 48300
Suggested Orifice Size: d#68DMS
GPH Capacity Derate: e1 0.99 0.97 0.96 0.94 0.93 0.91 0.91 0.87 0.83
PMG-100 LPG
Approved Input Rate: c105000 102937 100874 98810 96747 94684 92621 91589 87925 84262
Suggested Orifice Size: d#50DMS
GPH Capacity Derate: e1 0.98 0.96 0.94 0.92 0.90 0.88 0.87 0.84 0.80
PMG-200 LPG
Approved Input Rate: c195000 171600 163800 156000 148200 140400 132600 128700 123552 118404
Suggested Orifice Size: d#50 DMS #51DMS
#52DMS #53DMS
GPH Capacity Derate: e1 0.88 0.84 0.80 0.76 0.72 0.68 0.66 0.63 0.61
Notes:
cThis is the maximum allowable btu rate certified by AGA. These are to be verified by the qualified gas installer on site. Check Heat Value with local Gas Utility.
dThefirst orifice size is the factory built unit.
The next sizes are shown at the altitudes where a change is required to allow pressure adjustments to the approved input rates.
eThis is a derate multiplier to use when sizing a gas booster for a given application.
Take this value and multiply it by the GPH found on the Hatco sizing chart to insure it will provide the capacity you need.
You can also use this value by dividing it into your capacity needs and take the resulting adjusted GPH to the sizing chart to select a gas booster.
HATCO CORPORATION P. O. Box 340500, Milwaukee, WI 53234-0500 U.S.A. [phone] [phone] Fax [phone] Int’l. Fax: [phone]
www.hatcocorp.com
PrintedinU.S.A. FormNo.PMGALT-1097
