haupa SMART-LINE SH-6 User manual

… convincing solutions
Batt ry pow r d crimping tool
„SH-6“
Art. 215881-1
INSTRUCTION MANUALBattery powered crimping tool SMART-LINE
Vid o 215881

1. T chnical data
Area of application:
Scope of delivery:
Pressing force:
Oil type:
Safety:
Structure:
Guarantee:
For the creation of an electrical connection by means of
compression
1 pressing tool, 1 charger, 1 battery, 1 carry loop, in plastic case,
without pressing dies.
60kN
ISO class viscosity 15
The tool is fitted with a safety value that has been set at the factory.
The working head can be rotated by 180° to make it easier to adapt
to the operation to be carried out. The model Art. 215881-1 does
not protect the operator when working on cables that carry power.
2 year guarantee if used for the purpose it is intended
2. Ar a of work/P rformanc charact ristics
• Pressing force in kN: 60kN
• Working pressure in bar: 700
• Head can be opened
• Opening / Hub: 9 mm
• Pressing width: slim
• Motorstop
• Crimping range cable lugs: Cu 10-240 / DIN Cu 10-240 / DIN Al 16-185
• Crimping range connectors: Cu 10-240 / DIN Cu 10-240 / DIN Al 16-185
• Pressing time, battery-operated in seconds: 2
• Battery charging time in minutes: 60
• Battery type: Li-Ion, 18 V, 2 Ah
• Weight in kg: 2,4
• Weight Set in kg: 3,2
• 6 tonnes of pressing force for maximum performance
• Motor stop. The feed is stopped immediately the operating switch is released.
No post-travel of the piston
• 180° rotating crimping head. Can thus be mounted even in places that are difficult to
access
• Manual return enables shorter process cycles and saves battery capacity
• The manual return enables the operator to bring the piston back to the starting point in
the event of a faulty pressing.
• After the pressing is completed, the device operates in idle.
(If the compression is not completed, manual return of the piston on the return operation
button is „very perceptibly“ more difficult)
• The two button operation ensures logical, simple and quick single-handed operation.
• The tool is supplied with 1 Li-Ion battery, 2 Ah and a quick charger.

Germany: HAUPA GmbH & Co. G, önigstraße 165-169, D -42853 Remscheid.
Phone: [phone], Fax: [phone], [email protected] • Errors and technical changes reserved.
… convincing solutions
nglish
3. Op rating instructions
CAUTION! TOOLS MAY NEVER BE USED WITHOUT FIRST INSERTING THE PRESSING DIES.
Ensure that the pressing dies fit precisely to the appropriate area and are seated perfectly in
the holders.
OTHERWISE THIS MAY CAUSE SERIOUS DAMAGES OR BREA AGES AND THE GUARANTEE
WILL BE VOIDED.
Pr paration
Before starting up the tool, read the operating instructions first.
All current-carrying elements in the area you are working in should be disconnected.
Otherwise the protective procedures for working in the vicinity of components under current
must be implemented. (DIN EN 50110)
Do not use the tool if you are tired or under the influence of medication, drugs or alcohol.
Take into account the valid accident prevention and safety regulations and use the tool exclu-
sively for the purpose for which it is intended.
Only electro-technically trained persons over 16 years of age may process connecting materi-
als using the tool.
The operating instructions must always be carried with the tool.
The instructions must have been read and understood by the user.
The operator must ensure that this is the case.
• Pressing dies from 10 to 120 mm2can be used on both sides (2 conductor cross-sections
with only one pressing die)
• Area of application in accordance with the available pressing dies (max. 240 mm2DIN
tube terminals)

Op rating:
• Select the required pressing die.
• Never use a crimping tool without pressing dies!
• The pressing procedure can be stopped at any time by releasing the actuation switch.
• No components under power may be compressed.
• The tool is not insulated!
• The tool is not designed for permanent use.
• After 35 - 45 compression actions carried out one after another, you must take a break
of 10 to 15 minutes to allow the tool to cool down.
• If it is heated too high, this may cause damages to the tool.
• Do not use under water or when it is raining.
• Please observe the processing notes for the relevant connection materials as detailed in
our catalogue.
Die holder Pushbutton for return movement
Pushbutton to advance

HAUPA GmbH & Co. KG, Königstraße 165-169, D-42853 Remscheid,
Tel.: [phone]. Fax: [phone], E-Mail: [e-mail]. Subject to technical changes and printing errors.
... convincing solutions
english
Mounting and unmounting the battery
Charger specifications
Model Nr.: 215527
Input: 100 – 240 V AC
Frequency: 50 / 60 Hz
Output V: 21 V
Output A: 1 A
Weight: 0,164 kg
Measurements: 92 mm (L) x 47 mm (B) x 45 mm (H)
Charger: Connecting battery to charger:

215523 (2 Ah) 215525 (4 Ah)
Please remove the battery after use and keep it removed when storing the
tool!
HAUPA is not liable for wrong or unintended use
2 Ah Battery Specifications
Model Nr.: 215523
Voltage: 18 V
Weight: 0,35 kg
Measurements: 114 mm (L) x 73,5 mm (B) x 67 mm (H)
est. Charging Time: approx. 30 Min
Capacity: 2 Ah
4 Ah Battery Specifications
Model Nr.: 215525
Voltage: 18 V
Weight: 0,58 kg
Measurements: 114 mm (L) x 73,5 mm (B) x 67 mm (H)
est. Charging Time: approx. 60 Min
Capacity: 4 Ah
LED charge indicator: (Pressing the button will light up LEDs)

5. Car and maint nanc
Cl aning
• Careful cleaning of the tool, in particular, the moving parts contributes towards a longer
useful life. Remember that dust, sand, environmental influences, in particular a high salt
index, and dirt in general are extremely damaging to hydraulic tools.
• Particular care should be taken when cleaning the pump drive piston and the piston.
The tiniest of contaminations may scratch the walls of the cylinder and damage the
leakproof seals. For the correct cleaning of the piston, we recommend extending the piston
and then cleaning it with a high-quality, non-corrosive solution.
Pow r switch
Check to see whether the switch on the machine automatically pops out again when you
release it.
Storag
To prevent damage to the tool as a result of bumps, dust etc. you should if possible store the
tools in the original packaging.
Guarant :
2 year guarantee when used for the purpose it is intended when the annual maintenance
intervals are maintained by an authorised HAUPA service centre.
We reserve the right to rework the product.
Faults:
Loss of oil:
Send to the HAUPA service centre. Do not open!
Very slow feed of the piston:
Air is in the hydraulic system. eep the head upright and operate both operating switches for
10 seconds at the same time in idle. As soon as the air has been expelled from the hydraulic
system, the feed rate and the pressure is restored.
Disposal:
…in accordance with the scope of validity of the European WEEE (2002/96/EU) and RoHS
directives (2002/95/EU). Batteries must be disposed off separating according to the battery
directive.
Always use original replacement parts. Other parts may seriously damage the tool and will
void the guarantee.
If the tool still does not work correctly, send it to the nearest repair service for specialist main-
tenance and fine tuning, or send an email to: [email protected]
Germany: HAUPA GmbH & Co. G, önigstraße 165-169, D -42853 Remscheid.
Phone: [phone], Fax: [phone], [email protected] • Errors and technical changes reserved.
… convincing solutions

nglish
WITH EVERY REPLACEMENT PART ORDER, INCLUDE THE FOLLOWING INFORMATION:
1) Article number.
2) Article description.
3) Reference to the operating instructions and/or date.
4) Tool type.
5) Serial number of the tool.
The guarantee is voided if you use parts that are not original replacement parts from HAUPA.

HAUPA GmbH & Co. KG, Königstr. 165-169, 42853 Remscheid, Germany
E
E
C
C
d
d
e
e
c
c
l
l
a
a
r
r
a
a
t
t
i
i
o
o
n
n
o
o
f
f
c
c
o
o
n
n
f
f
o
o
r
r
m
m
i
i
t
t
y
y
H
H
A
A
U
U
P
P
A
A
f
f
a
a
c
c
t
t
o
o
r
r
y
y
c
c
e
e
r
r
t
t
i
i
f
f
i
i
c
c
a
a
t
t
e
e
Remscheid, 15.06.2020
Product: Battery hydraulic crimping tool
Product range: Around the cable
Art. no.: 215881; 215881-1; 215881/M
Note: A correct connection according VDE 0220 Part 2 is only
quaranteed if the user work with HAUPA cable lugs and also
adequate HAUPA pressing tools.
The tools are not isolated and it is forbidden to work under
tension.
HAUPA GmbH & Co. KG, Königstr. 165 - 169, 42853 Remscheid, Germany
Phone [phone] – 0, Fax [phone] – 840
Herewith we declare that the above mentioned tools are manufactured according the
following guidelines:
CE guidelines 98/37/EEC, 89/336/EEC
HAUPA GmbH & Co. KG
Product management
