INSTALL INSTRUCTIONS C-TCB-28
1997-2007 DODGE DAKOTA
TELESCOPING COMPUTER BASE
TOOLS REQUIRED:
Ratcheting wrench
3/8” Metric Socket Set
T-20 torx bit
3/8” Standard Socket Set
Combination wrench set
Powered Drill
Drill Bit set
HARDWARE:
QTY DESCRIPTION PART #
4 ¼” x 1” Hex head lag bolt GSM33060
1 5/16” Flat Washer GSM31006
1 5/16” Nylock Nut GSM30017
1 “Z” Bracket Support CM002001
1 ¼” x ¾” Carriage Bolt GSM32000
1 ¼” Serrated Nut GSM30023
1 Pole Support Assembly CM93071-28W
1 Lateral Support Brace CM93146
1 Inner Telescoping Pole Assembly CM93072-3
Always!
 Disconnect the vehicles’ battery. Removing seat bolts on some vehicles may give the
vehicles computer a false reading leading to warning lights on dash. This requires the
vehicles’ computer to be reset.
 Read all instructions before installing any Havis-Shields Equipment Corp products.
 Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
 Use hardware provided with install kit.
 For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html, email [email protected] or call
1-800-524-9900.

C-TCB-28-INST-6-07
2
Install “Z” support bracket to base
assembly using ¼ x ¾” carriage bolt
and serrated nut.
Re-attach front bolts on passenger-
side seat through C-TCB base plate.
Remove front bolts on passenger-
side seat and position base assembly
in front of seat mount brackets.
Attach bracket to floor using ¼” x
1” hex head lag bolts
Tighten “Z” bracket to base
assembly.
Pre-drill floor of vehicle with 3/16”
drill bit Use holes in the “Z” bracket
as a drill template
CM93072-3
CM93146
CM93071-28W
Location of factory
seat bolts

C-TCB-28-INST-6-07
3
Insert inner telescoping pole
assembly and thread lock handle
into pole support base assembly.
Loosely attach lateral support brace
to TCB base using 5/16” flat washer
and 5/16” nylock nut
Tighten 5/16” nylock nut
Pre-drill floor of vehicle with 3/16”
drill bit. Use holes in the support
brace as a drill template
Attach support brace to floor using
¼” x 1” hex head lag bolts
Final Installation
Install C-3090-x laptop platform (sold separately)
