Havis-Shields KK-F-ST-SS Configuration guide

KK-F-ST-SS-INST-9-06
INSTALL INSTRUCTIONS KK-F-ST-SS
FORD FULL SIZE VAN SIDE SLIDE-OUT STEP
1997-2007 FORD VAN (GAS & DIESEL)
TOOLS REQUIRED:
Powered drill
Ratcheting wrench
Tape measure
Drill bit set
Socket Set
HARDWARE:
QTY DESCRIPTION PART #
4 ¼-20 x ¾” Hex Head Bolt GSM33001
4 ¼” Flat Washer GSM31005
4 ¼-20 Serrated Nut GSM30023
2 5/16-18 Hex Head Bolt GSM33012
4 5/16” Flat Washer GSM31006
2 5/16-18 Nylock Nut GSM30017
SUB ASSEMBLY:
1. Determine and mark center of door opening to help aid in positioning of step.
2. Mark center of step and position step.
INSTALLATION:
1. ATTACH STEP TO VAN FRAME:
• Position step assembly under van on center mark made in sub-assembly.
• (2) Holes on step will line up with (2) holes in frame rail.
• Attach using (2) 5/16-18 x 1” Hex head bolts, washers and Nylock nuts.
5/16” Bolts,
washers &
Nylock nuts

KK-F-ST-SS-INST-9-06
2. MARK & DRILL FENDER LIP MOUNTING HOLES:
• Raise outer side holes and attach step to fender lip using ¼” of step until level.
• Mark (4) mounting holes on fender lip.
• Drill ¼” holes on these marks.
• Attach using ¼-20 x ¾” Hex head bolts, washers and serrated nuts.
Fender lip
mounting
Frame
mounting holes
Fender lip
mounting
