INSTALL INSTRUCTIONS KK-S-ST-RP
PERMANENT REAR STEP
2002-2008 SPRINTER VAN
TOOLS REQUIRED:
Ratcheting wrench
Standard socket set
Open-end wrench set
Power drill
Drill bit set
HARDWARE:
QTY DESCRIPTION PART #
8 ½-13 x 1 ½” Hex head bolt SM33050
12 ½-13 x 4” Hex head bolt SM33056
40 ½” Flat washer SM31009
8 ½” Lock washer SM31030
8 ½-13 Hex nut SM30011
12 ½-13 Nylock nut SM30020
4 ¼” x ¾” Lag bolt SM33060-1
SUB ASSEMBLY:
1. Confirm receipt of all parts.
2. Differentiate all components and hardware in kit.
Channel bracket(s)
(See note below)
Note: Three Channel
brackets will come with Rear Step
kit, one short and two long. Use two long brackets for
vehicles with single rear wheels & one short bracket
and one long on vehicles with d al rear wheels.
(2 pe
-
side)
Upper
mounting brackets
Bumper mounting
“L” bracket
Step assembly

KK-S-ST-RP_INST_12-06
INSTALLATION:
1. MOUNT PERMANENT REAR STEP:
• Locate (4) ½” holes located on each side of the vehicle frame rails.
• Bolt the Upper mounting brackets (2 per-side) using the ½” holes and (8) ½-13 x 4”
Hex bolts, washers, and Nylock nuts. If also mounting Kwik Kit, be sure to mount to
doorframe brackets at this time. See photo below.
Note: Depending on single rear wheel standard length van, d al rear wheels standard length van,
and d al rear wheels extended length van will effect which side of the frame rail the (4) Upper
Mo nting Brackets will bolt to.
Note: It is necessary to use Nylock nuts to avoid crushing the vehicles frame.
• Mount channel brackets to Upper
mounting brackets (4 total) using (6) ½-
13 x 1 ½” Hex bolts, flat washers, lock
washers, and hex nuts.
• Slide Step assembly onto channel
brackets and attach using (4) ½-13 x 4”
Hex bolts, washers, and Nylock nuts.
• Level step and tighten all hardware.
• Attach Bumper mounting “L” brackets
using (2) ½-13 x 1 ½” Hex bolts, flat
washers, lock washers, and hex nuts.
• Pre-drill and attach (4)-(2 per side) ¼” x
¾” Lag bolts into the vehicles bumper to
secure Bumper mounting “L” brackets.
Kwik Kit
doorframe support
Bumper
mounting “L”
(2 per-side)
Upper Mounting
Brackets
