Havis DS-GTC-900 Series User manual

Owner’s Manual
Havis Docking Station
For Getac K120 Tablet
DS-GTC-900 Series
DS-GTC-901
DS-GTC-901-3
DS-GTC-902
DS-GTC-902-3
DS-GTC-903
DS-GTC-903-3
DS-GTC-906
DS-GTC-906-3
DS-GTC-900-SERIES_OMN_10-18
Havis, Inc.
75 Jacksonville Road
Warminster, PA 18974

Before Beginning
Havis is pleased to provide this Owner’s Manual to aid in the proper installation and use of the
DS-GTC-900 Series Docking Station for the Getac K120 Tablet.
For questions regarding the set-up of your DS-GTC-900 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional product support and information.
This Owner’s Manual applies to the following Part Numbers:
DS-GTC-901
DS-GTC-901-3
DS-GTC-902
DS-GTC-902-3
DS-GTC-903
DS-GTC-903-3
DS-GTC-906
DS-GTC-906-3
•CUSTOMERS USING HAVIS K120 DOCKING STATIONS WITH PORT REPLICATION:
DO NOT CONNECT A SECOND POWER SOURCE DIRECTLY TO THE POWER INPUT JACK OF A DOCKED COMPUTER AS
THIS MAY CAUSE DAMAGE TO THE COMPUTER OR POWER SOURCES.
•NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE AIRBAG DEPLOYMENT ZONE.
•DO NOT USE COMPUTER WHILE DRIVING.
•READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
•DO NOT STORE, INSTALL, OR OPERATE THE DOCKING STATION WHERE WATER, MOISTURE, STEAM, DUST, ETC.
ARE PRESENT
•DO NOT DOCK OR UNDOCK YOUR COMPUTER UNLESS IT IS POWERED OFF. DOCKING OR UNDOCKING WITH YOUR
COMPUTER IN ON, STANDBY, HIBERNATION, OR SLEEP MODES CAN CAUSE PERMANENT DAMAGE.
•FOR THE DS-GTC-901, DS-GTC-901-3, DS-GTC-902, & DS-GTC-902-3 DOCKING STATIONS: DO NOT CONNECT
DIRECTLY TO VEHICLE VOLTAGE SOURCE: This product requires a certified, automotive grade, Getac approved
120W power source rated for a continuous, regulated 19VDC output (Havis Part Number LPS-140 or equivalent).
Failure to comply with this requirement will cause product damage that is NOT repairable and is NOT covered
under warranty.
•FOR THE DS-GTC-903, DS-GTC-903-3, DS-GTC-906 & DS-GTC-906-3 DOCKING STATIONS: DO NOT CONNECT
DIRECTLY TO VEHICLE VOLTAGE SOURCE: The Getac K120 Tablet requires a certified, Getac approved power source
rated for a continuous, regulated 19VDC output. Failure to comply with this requirement will cause product
damage that is NOT repairable and is NOT covered under warranty.
•FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY (DS-GTC-902, DS-GTC-902-3, DS-
GTC-906, & DS-GTC-906-3) REFER TO THE SUPPLIED GETAC POWER SUPPLY REFERENCE GUIDE.
•WHEN TABLET IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN 2°C to 50°C (35°F to 122°F).
PLEASE REFER TO GETAC K120 TABLET OWNER’S MANUAL FOR MORE INFORMATION.
Precautions
•Do not place metal objects or containers of liquid on top of the Docking Station
•If amalfunction occurs, immediately unplug the Power Supply and remove the laptop
•Use only the specified Power Supply (Part # LPS-140) with this Docking Station
•Do not connect cables into ports other than what they are specified for
•Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F) for a long period of
time

Specifications
Power Supply Input External Power Supply
LPS-140 DC-DC
INPUT
11-32 V DC-In
OUTPUT
19V DC
Dimensions 11.4” (28.9 cm) H x 11.9” (30.2 cm) W x 3.7” (9.4 cm) D
Weight 3.72 lbs. (1.69 kg)
Operating Environment -21°C to 60°C (-6° F to 140°F)
Storage Environment -51°C to 71°C (-60°F to 160°F)
EC DECLARATION OF CONFORMITY in accordance with EN 50498
Manufacturers Name: Havis, Inc.
Manufacturers Address: 75 Jacksonville Road, Warminster, PA 18974 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Getac K120 Tablet Only
Model: DS-GTC-90X, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
Automotive EMC Directive EN 50498:2010, Electromagnetic compatibility (EMC) -
2004/108/EC: Product family standard for aftermarket electronic equipment in vehicles
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
Supplementary Information:
The product herewith complies with the requirements of the Automotive EMC Directive 2004/108/EC, Annex I, 6.5, 6.6, 6.8, and 6.9. This product requires the
use of a recommended e-Marked automotive power supply when used within vehicles.
Warminster, PA, USA September 20, 2018 Bruce Jonik, Director of Engineering , Havis, Inc.
FCC 47CFR, Part 15 compliance: This is an FCC Class B device. Any changes or modifications to the model DS-GTC-90X not expressly
approved by Havis, Inc. could void the user's authority to operate this equipment.

Parts Included
Latch Hook
Pass-Through Antenna
(Triple, optional)
Barrel Lock
Docking Connectors (x2)
Alignment Posts
Docking Station
Strain Relief Points
Mounting Holes
(VESA 75 Hole Pattern)
Ports

Parts Included (continued)
Hardware Kit (HWK-0031)
This Hardware Kit includes:
1. Zip Ties (4)
2. Keys (2)
3. M4 x 0.7 x 20mm long Pan Head Screws (5)
4. Split Lock Washers (5)
5. Washers, M4 (5)
Tools required for installation:
• #2 Phillips (For M4 Pan Head Screws)

Antenna Identification
DS-GTC-901-3, DS-GTC-902-3, DS-GTC-903-3, & DS-GTC-906-3
Antenna Connectors (SMA) Tablet Interface




A – WIFI
B –GPS
C –CELLULAR
CB
A
CB
A

Port Replication Capability
Downward Facing Ports
DS-GTC-901, DS-GTC-901-3, DS-GTC-902, DS-GTC-902-3
Forward Facing Ports
DS-GTC-901, DS-GTC-901-3, DS-GTC-902, & DS-GTC-902-3
Ethernet
RJ45 (x2) Serial
Antenna (SMA)
Optional: Part IDs
DS-GTC-901-3
DS-GTC-902-3
DS-GTC-903-3
DS-GTC-906-3
VGA HDMI
USB 2.0 (x1)
USB 3.0 (x3) Power Input
USB 2.0 (x2)

1) Align Docking Station mounting holes with the hole pattern on mounting device. Using the
four (4) M4 0.7 x 20mm Pan Head Screws (Hardware Kit Item 3), four (4) Washers, M4
(Hardware Kit Item 4), and four (4) Lock Washers, M4 (Hardware Kit Item 5), secure the
Docking Station to device. Torque screws to 20 in-lbs (2.3Nm) ±10%
A) Havis Desktop Stand installation (sold separately, Part # DS-DA-218).
B) In-Vehicle mounting system installation (not included).
Installation
Washer, M4
M4 x 0.7 x 20mm
Pan Head Screws
Lock Washer, M4
Desktop Stand
(VESA 75 mm)
Washer, M4
M4 x 0.7 x 20mm
Pan Head Screws
Lock Washer, M4
Mounting Device
(Not included)

1) Tip the Docking Station to a position that is comfortable to work with.
2) Install all cables that are necessary for computing needs.
3) Use Zip Ties (Hardware Kit Item 1) and the Strain Relief Points to secure cables and reduce risk of
accidental disconnects.
4) Create a service loop with cables to ensure that no tension is on the connectors and to enable
intended motion.
5) Tie off cables onto a stationary part of the mounting system.
Cable Management
4
5
This loop must be large enough to allow
full range of expected rotation and
extension without stressing connections.
Collect cables to secure to the
mounting system.
(Note: mounting system not included)

Operation -Docking
1) Docking Station must be unlatched before docking your tablet. Push down on the Barrel Lock button
and release slowly.
DO NOT FORCE TABLET ONTO DOCKING STATION. IF THERE IS RESISTANCE,
CHECK ALIGNMENT OF TABLET ON DOCKING STATION.
NOTE: Ensure a proper connection by aligning the tablet’s
Alignment Sockets with the Docking Station’s Alignment Posts
Latched Unlatched
Alignment Sockets on the bottom of
Getac K120 Tablet
Alignment Posts on the
DS-GTC-900 Series Docking Station

2) Hold tablet in landscape orientation, with bottom mounted docking connector angled toward Docking
Station. Lower tablet into the bottom of the Docking Station.
3) Pivot tablet so it sits flush in the Docking Station and hold while depressing the Latch Handle to secure
tablet in place. You will hear an audible click when Latch Hook is fully engaged.
4) For theft deterrence, secure tablet by locking Docking Station with supplied key (Hardware Kit Item 2).
Operation - Docking (continued)

1) If previously locked, unlock Docking Station using supplied key.
2) Secure tablet to avoid inadvertent ejection from Docking Station. Push down on the Barrel Lock button
and release quickly taking care not to obstruct the travel of the Latch Hook. If the Latch Hook does not
extend fully to its unlatched position, lift up lightly on the front of the Latch Hook to fully release.
3) Once unlatched grab both sides of tablet, rock the top forward and carefully lift out of Docking Station,
top end first.
Operation -Undocking

Related Products
Havis offers a wide variety of accessory products specifically for use with your Docking Station.
For more information or to order, please visit www.havis.com.
LPS-140
120W Power Supply
External in-vehicle power supply and cable for Getac K120
Tablet with cigarette lighter adaptor.
DS-DA-103
Stylus Holder
Secure a wide array of styluses to your Docking Station.
DS-DA-218
Desktop Stand for Tablet Docking Stations
Durable stand for mounting tablet Docking Stations for use in
the home or office.
DS-DA-102
USB Powered Keyboard Light
Soft red LED light illuminates the laptop keyboard for night
viewing.
LPS-211
Power Supply Mounting Bracket
Mount a power supply directly to your Docking Station with this
versatile bracket.
DS-DA-502
Replacement Keys
Set of two (2) replacement keys for DS-GTC-900 Series
Docking Stations.
