04/21 MODEL 1119HO/1119HO2 PAGE 1 OF 7
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0510001123 (2)
Model 1119HO/1119HO2
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential damages
claimed to arise under the contract of sale. The drinking fountain manufactured by
HAWS is warranted to function if installation and maintenance instructions provided
are adhered to. The units also must be used for the purpose for which they were
intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
CAUTION! Prior to making any electrical connections, verify with a voltmeter that power
from the service panel is off.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.

04/21 MODEL 1119HO/1119HO2 PAGE 2 OF 7
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 5/64“ hex key wrench, 9/16”, 1/2", 7/16” socket wrench or open-end
wrench.
LOCATION OF UNIT: The Model 1119HO/1119HO2 Drinking Fountain is a wheelchair
accessible drinking facility. The height dimensions shown, meet current ADA requirements.
When installing this unit, local, state or federal codes should be adhered to. If height other
than shown is required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet is 3/8” O.D. push-in type fitting. Waste outlet is female 1-
1/4” NPT.
ELECTRICAL CONNECTIONS: Drinking Fountain may be mounted on external wall of
building provided transformer shall be mounted inside the wall and protected from
water as shown on RKHO Series O&M details (page 8) per NEC/CEC and local code.
Sensor(s):
1119HO with 1RKHO.H: 100-277VAC x 9VDC, 50-60Hz, 5 Watts.
1119HO2 with 2RKHO.H: 100-277VAC x 9VDC, 50-60Hz, 5 Watts.
MAINTENANCE: Periodically clean out the supply line Y-strainer (and strainer located inside
push button valve on Model 1119HO). Refer to 5874 Series Valve Manual for more
information.
INSTALLATION PROCEDURE
GENERAL NOTES:
1. For all plastic push-in type fitting connections, only connect NSF-61 copper or
plastic tubing. Stainless steel or glass tubing is not recommended. The
following assembly instructions must be followed to ensure a watertight
connection:
a. Cut tubing square and clean.
b. Mark from end of tube the length of insertion (See table below).
c. Push tube into the fitting until it bottoms out.
d. To remove, depress collet and pull tubing out.
Tube Sizes
O.D.
Tolerance
Insertion Depth
3/8”
±.005”
3/4”
INSTALLATION PROCEDURE…
STEP 1: Thoroughly flush supply line to remove all foreign matter. Connect 1/2” IPS supply
screwdriver-stop (not supplied). Install supply 3/8” O.D. tubing (supplied), between
screwdriver-stop and supplied Y-strainer. (Cut tubing to proper length and follow
general notes for proper connection procedures for push-in type fittings). Connect
3/8”O.D. tube between supplied tee and fountains and solenoid valve outlet(s) (if not
already connected). See installation drawing at the end of this manual for supply
plumbing and wiring details.

04/21 MODEL 1119HO/1119HO2 PAGE 3 OF 7
STEP 2:Open screwdriver-stop wide open while checking for leaks at all connections. Also,
check waste for leaks.
STEP 3: Model 1119HO (only): 5874 Series Valve –Adjust bubbler stream height using a
small flat-head screwdriver inserted through a hole in the center of the push button
for increased flow turn clockwise and for decreased flow turn counterclockwise. If
flow problems arise, see troubleshooting guide for additional instructions to correct
problem. Bubbler stream may lower during short break-in period. Set initial stream
height a little high to minimize or eliminate the need for break-in period readjustment.
Model 1119HO/1119HO2: 5867 Valve Pressure Regulator –Adjust bubbler stream
height using the black pressure regulator mounted inside bracket that has HO sensor
unit, by loosening the locknut and rotating the knob clockwise to increase flow or
counterclockwise to reduce flow. Tighten the locknut and check flow height. Repeat
these steps until the bubbler flow height is correct.
STEP 4: 1RKHO.H & 2RKHO.H Transformer and Sensor Setup: Refer to the 1RKHO.H &
2RKHO.H manuals for instructions (supplied).
MAINTENANCE
STEP 1: Periodically clean out the supply line Y-strainer and the strainer located in the push
button valve body on Model 1119HO (Refer to 5874 Series Valve Manual for more
information).
5874 Series VALVE TROUBLESHOOTING (Model 1119HO Only)
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve (not
supplied) is in wide-open position.
b.
Verify minimum 30 psi flowing supply pressure.
c.
Clean strainer. See 5874 Series Valve Manual.
d.
Adjust valve to increase flow. Use front adjust
screw or see 5874 Series Valve Manual.
For more information about Haws products, see our website: www.hawsco.com
© 2021 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
FV
10/23/20
2
0510001123
1119HO/1119HO2
1:4
12
BJM 04/28/21
5605
FV
4 OF 7
PARTS BREAKDOWN
5684
2021
DP
8
5
10
9
(OPTIONAL)
2
A
5REF
34
1
STRAINER, WASTE ASSY1
BACK PANEL
2
BUBBLER HEAD ASSY, PCP
3
PUSH BUTTON ASSY
4
BUTTON, PUSH, FLANGED, PCP W/ VALVE
5
PLATE, BOTTOM6
8
9
5703M
PBA6
5874PBF
PBM1105
0004023580
6462
ITEM DESCRIPTION 1119HO
* DENOTES OPTIONAL PART.
VALVE REPAIR KIT VRK5874
TRAP 0005982900
10
*PLATE, MOUNTING 6700.4
PLATE, BOTTOM PBM1109
7
6
7
1
ROTATED 90° INTO VIEW
DETAIL A
REMOVE INSERT
WITH 5/16 HEX SOCKET
(NOT SUPPLIED)
3
NOTES:
1 5874PBF (ITEM 2) INCLUDES VRK5874 CARTRIDGE ASSEMBLY
(ITEM 3), PBA6 FLANGED PUSH BUTTON (ITEM 4) AND
SPANNER WRENCH (ITEM 15).
2 ITEMS 2, 3 AND 4 ARE ONLY USED ON MODEL 1119HO.
3 ENSURE TUBE IS DISCONNECTED FROM PUSH BUTTON VALVE
BODY PRIOR TO REMOVAL. APPLY ONE DROP OF LOCTITE
222MS TO NOZZLE THREADS PRIOR TO FASTENING BACK
ONTO BUBBLER HEAD. RE-ATTACH TUBE TO VALVE.
PARTS BREAKDOWN
11
SOLENOID
12
13 VRKH05
TRANSFORMER VRKH08
14 PRESSURE REGULATOR 5867
SENSOR VRKH06
11
14
12
13
11
15 1
15 SPANNER WRENCH 0006983506
1119HO SHOWN
1119HO2 ON SHEET 2
16 Y-STRAINER 6433
16
2
2
2
222

APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
FV
10/23/20
2
0510001123
1119HO/1119HO2
1:4
22
BJM 04/28/21
5605
FV
5 OF 7
PARTS BREAKDOWN
5684
2021
DP
5
9
A
1
PARTS BREAKDOWN
12
16
8
10
(OPTIONAL)
6
714 1119HO2 SHOWN
1119HO ON SHEET 1
13
11

813mm
32"
BACK PANEL
305mm
2-1/8"
54mm
413mm
16-1/4"
12"
305mm
12"
406mm
16"
27"
1029mm
40-1/2"
12.7mm457mm
311mm
12-1/4"
18" (BACK PANEL)
1/2"
6"
152mm
1-1/4" NPT
TRAP
(SUPPLIED)
WALL FACE
FLOOR LINE
(OPTIONAL)
MOUNTING PLATE
3/8" MOUNTING BOLTS
(NOT SUPPLIED)
9.5mm
MOUNTING
3-1/4"
83mm
TO FLOOR
27-7/16"
697mm
83mm
BACK VIEW
MOUNTING DETAIL
3-1/4" SLOTS
2-3/4"
SUPPLY
5-1/8"
130mm
70mm
WASTE
C
3/8"
Ø
33-1/16"
TO
FLOOR
840mm
WASTE
686mm
876mm
34-1/2"
(TO SPOUT
1. HOLD ROUGH-IN DIMENSIONS ± 1/4" (6.4mm).
2. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL
CODES SHOULD BE ADHERED TO. FOR INSTALLATION HEIGHTS
OTHER THAN SHOWN, DIMENSIONS MARKED (*) MUST BE
ADJUSTED ACCORDINGLY.
3 REFER TO 5874 SERIES/VRK5874 OPERATION AND MAINTENANCE
MANUAL FOR PUSH BUTTON AND VALVE INSTALLATION AND
MAINTENANCE INSTRUCTONS.
4 REFER TO 1RKHO OR 2RKHO SERIES OPERATION
INSTRUCTONS FOR TRANSFORMER AND SENSOR SETUP.
NOTES:
36-1/2"
927mm
35-3/8"
899mm
30-3/4"
781mm
29-5/8"
752mm
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
PAGE
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
FV
10/23/20
2
0510001123.D
1119HO/1119HO2
1:14
12
BJM 04/28/21
5605
FV
6 OF 7
INSTALLATION
5684
6 OF 7
2021
DP
OUTLET)
(TO SPOUT
OUTLET)
L
100-277VAC-9VDC
TRANSFORMER
AND DC CABLE
(SUPPLIED)
FROM DIRECT
CONTACT WITH WATER
MUST BE PROTECTED
LOCATE AND INSTALL
ELECTRICAL
9 VDC
TRANSFORMER
WITHIN WALL
SENSOR
EYE
WASTE
SUPPLY
WASTE
SUPPLY
4
SOLENOID
VALVE
4
4Ø3/8" SUPPLY TUBING IS
SUPPLIED. SCREWDRIVER
STOP (NOT SHOWN) IS
NOT SUPPLIED.
REGULATOR
3
MODEL 1119HO SHOWN
MODEL 1119HO2 ON SHEET 2
(ROUGH-IN DIMENSIONS APPLY TO BOTH MODELS)
Y-STRAINER
(SUPPLIED)
SOLENOID VALVE
TEE
(SUPPLIED)
(SUPPLIED)
SUPPLY LINE TO TEE
SENSOR
FROM SUPPLY
TO
BUBBLER
HEAD
-Vo
+Vo
AC(L)
AC(N)
BLACK WIRE
WHITE WIRE
TRANSFORMER
SENSOR WIRING / SUPPLY
PLUMBING SCHEMATIC
TO PUSH
BUTTON
FOUNTAIN
VALVE
SOLENOID
VALVE
Y-STRAINER
PRESSURE
REGULATOR

BACK PANEL
FLOOR LINE
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
PAGE
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
FV
10/23/20
2
0510001123.D
1119HO/1119HO2
1:14
22
BJM 04/28/21
5605
FV
7 OF 7
INSTALLATION
5684
7 OF 7
2021
DP
LOCATE AND INSTALL
ELECTRICAL
9 VDC
TRANSFORMER
WITHIN WALL
SENSOR
EYE
SOLENOID
VALVES
4
4
REGULATOR
MODEL 1119HO2 SHOWN
MODEL 1119HO ON SHEET 1
(SEE SHEET 1 FOR APPLICABLE ROUGH-IN DIMENSIONS)
POWER SPLITTER CABLE
SENSOR
Y-STRAINER
SOLENOID VALVE
PRESSURE REGULATOR
FROM SUPPLY
TO BUBBLER
HEAD
SENSOR WIRING / SUPPLY PLUMBING
SCHEMATIC
SENSOR
SOLENOID VALVE
PRESSURE REGULATOR
TO BUBBLER
HEAD
POWER SPLITTER
CABLE
-Vo
+Vo
AC(L)
AC(N) BLACK WIRE
WHITE WIRE
TRANSFORMER
100-277VAC-9VDC
TRANSFORMER
AND DC SPLITTER CABLE
(SUPPLIED)
FROM DIRECT
CONTACT WITH WATER
MUST BE PROTECTED
4
TO FLOOR
406mm
254mm
10"
305mm
12"
(OPTIONAL, HAWS 6700.4)
MOUNTING PLATE
406mm
914mm
36"
16" 16"
702mm
27-5/8"
203mm
8"
8"
203mm
C
L
SENSOR
EYE 4
