03/17 Model 3380/3380G Page 1 of 4
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
Model 3380/3380G
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
No. 2077367 (18)
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Compa
ny, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be lia
ble for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential
damages claimed to arise under the contract of sale. The dr
inking fountain
manufactured by HAWS is warranted to function if installation and maintenance
instructions provided are adhered to. The units also must be used for the purpose
for which they were intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/17 Model 3380/3380G Page 2 of 4
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12"
adjustable wrench, 10" pipe wrench, 5/64“ hex key wrench, 9/16”, 1/2", 7/16” socket
wrench or open end wrench.
LOCATION OF UNIT: The Model 3380/3380G Drinking Fountain is a wheelchair
accessible drinking water facility. The height dimensions shown, meet current ADA
requirements. When installing this unit, local, state or federal codes should be
adhered to. If height other than shown is required, then dimensions must be adjusted
accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6
ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet
filter is recommended.
PLUMBING CONNECTIONS: Inlet is 1/4" IPS male fitting. Waste outlet is 1-1/2”
O.D. tailpiece.
MAINTENANCE: Periodically clean the strainer. Refer to 5874 Series Valve Manual
for more information.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop
valve is in wide-open position.
b.
Verify minimum 30 psi flowing
supply pressure.
c.
Clean strainer. See 5874 Series
Valve Manual.
d.
Adjust valve to increase flow. Use
front adjust screw or see 5874
Series Valve Manual.
e.
Clean screens (inside nozzle body).
Unscrew nozzle insert and very
gently activate water supply to pop
out qty. 3 screens (be careful not to
lose screens). Remove any debris
clogging the screen openings and
place back into nozzle body.
Reassemble nozzle insert.
General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out to
ensure correct engagement with O-Ring.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1
2
STRAINER
3
4BUTTON, PUSH, RECESSED W/VALVE VALVE REPAIR KIT
PARTS BREAKDOWN
SCREWDRIVER STOP
5
STYLE B
(TUBING CONNECTS TO
INSERT ASSY)
FOUNTAIN COULD HAVE EITHER STYLE
STYLE A
(TUBING CONNECTS
TO ELBOW)
ROTATED 90° INTO VIEW
DETAIL A
5705 LAMIN
(OPTIONAL)
FOR REMOVAL
OF NOZZLE
WITH TUBE
(STYLE A OR STYLE B)
BUBBLER HEAD
VRK5874
5874PB
5705
0005624292
( NOT SUPPLIED)
1/2" NPT
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
D. OLLOM
11-25-95
18
0002077367
3380/3380G
.
1:8
11
FV 07/07/17
.
VWC
3 OF 4
PARTS BREAKDOWN
5189
2017
JP
3
4
5
NOTES:
1 5874PB (ITEM 3) INCLUDES VRK5874 CARTRIDGE ASSEMBLY
(ITEM 4) AND PBA7 RECESSED PUSH BUTTON (ITEM 5).
2 ENSURE TUBE IS DISCONNECTED FROM PUSH BUTTON
VALVE BODY PRIOR TO REMOVAL. APPLY ONE DROP OF
LOCTITE 222MS TO NOZZLE THREADS PRIOR TO FASTENING
BACK ONTO BUBBLER HEAD. RE-ATTACH TUBE TO VALVE.
1
1
1
DRIVER, NOZZLE .25 HEX 0002082253 6BUTTON, ASS'Y, PUSH, 5874 PBA7
2
1
6

(SUPPLIED)
TAILPIECE
1-1/2" O.D.
SLAB. (NOT SUPPLIED)
30" SQUARE CONCRETE
1/2-13UNC X 4" LONG CLEARANCE
RECESS
12"
305mm
12.7mm
1/2"
3.2mm
1/8"
5"
127mm
36"
914mm
27"
686mm
AND VALVE MAINTENANCE.
IN SUPPLY LINE FOR STRAINER
ALLOW 8" [203mm] OF SLACK
MIN.
152mm
6"
356m
14"
B.C.
9"
229mm
Ø1/2" IPS SUPPLY
1-1/2" O.D. WASTE
1-1/2"
38mm
76mm
3"
40-1/2"
1029mm
ACCESS.
SLACK FOR FRONT PLATE REMOVAL AND VALVE
TO BUBBLER DOES NOT KINK. ALLOW EXTRA
SURE SUPPLY LINE AND LINE FROM VALVE
DURING INSTALLATION OF THIS FOUNTAIN, MAKE
ATTENTION INSTALLER IMPORTANT READ THIS
SCREWDRIVER STOP
(NOT SUPPLIED) 1/2" IPS SUPPLY
(NOT SUPPLIED)
ANCHORS 4X (SUPPLIED).
(TO SPOUT OUTLET)
1 REFER TO 5874 SERIES OPERATION AND MAINTENANCE
MANUAL FOR PUSH BUTTON AND VALVE INSTALLATION/
MAINTENANCE INSTRUCTIONS.
NOTES:
1
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
C. HAYES
07/27/92
18
0002077367.D
3380/3380G
.
1:12
11
FV 07/07/17
.
VWC
4 OF 4
INSTALLATION
5189
2017
JP
