Haws 7611 Guide

05/19 Model 7611 Page 1 of 5
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0002080063 (11)
Model 7611
Eye/Face Wash
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing
to Haws within a reasonable period after receipt of the product. Where claims for defects
are made, the defective part or parts shall be delivered to the Company, prepaid, for
inspection. HAWS will not be liable for the cost of repairs, alterations or replacements, or
for any expense connected therewith made by the owner or his agents, except upon
written authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages
caused by defective materials or poor workmanship, except for replacements, as provided
above. Buyer agrees that Haws has made no other warranties either expressed or implied
in addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

05/19 Model 7611 Page 2 of 5
LOCATION OF UNIT: The Model 7611 Eye/Face Wash should be installed in close
proximity to potential accident areas. It should be clearly identified free from
obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1/2" IPS with 30-90 psi (2-6
ATM) flowing line pressure. Where sediment or mineral content is a problem, an inlet
filter is recommended.
PLUMBING CONNECTIONS: Inlet supply is 1/2" O.D. slip joint.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
No flow.
1.
Check the main shut-off valve.
2.
Insufficient water flow.
2.
a.
Verify minimum 30 psi flowing supply
line pressure.
b.
Probable clogging of flow control due
to inadequate line flushing. Unscrew
eye/face wash head and remove the
four screws to disassemble head.
Clean flow control and reassemble
head.
3.
Eye/face wash stream does not
meet desired eye level.
3.
a.
Possible blocked flow control, see
above solution.
b.
Possible non-leveled eye/face wash
assembly.
INSTALLATION INSTRUCTIONS
Refer to installation drawing to clarify installation procedure.
Note: Model 7611 Eye/Face Wash can be mounted on either right or left side of the
sink. For left hand use, reconfigure as shown on installation drawing.
STEP 1: Remove the 3" O.D. flange from valve body.
STEP 2: Remove the protective backing from rubber washer.
STEP 3: After making sure that bottom surface of the counter top or deck, around
the drilled hole is clean and free of grease, slide valve through drilled hole
from the bottom.
STEP 4: Place sign over valve.
STEP 5: Reinstall the 3" O.D. flange, ensure that the top surface of flange is flush
with valve. Wrench tighten locknut against base of counter or deck.
STEP 6: Install eye/face wash assembly to valve and after checking for proper
alignment, tighten the setscrew on the cap.
© 2019 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

PARTS BREAKDOWN
1E/F WASH AXION
2
3
4
VALVE ASSEMBLY
4
EYEWASH SIGN
5
SWING AWAY SIGN
5TEST TAG
REPAIR KIT
2
3
1
VRK7650
SP170
SP175
0005240025
-
0002953160
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
STH
10/21/96
11
0002080063
7611
1:1
11
IR 05/30/19
DP
3 of 5
PARTS BREAKDOWN
5400
2019
FV

OFF
6"(152mm) MIN.
CLEARANCE 3-1/4"
83mm
1-3/4"
45mm
10"
254mm
4-7/8"
124mm
1/2" O.D. SUPPLY
(BY OTHERS)
SUPPLY SHANK CAN BE
POSITIONED IN ONE OF FOUR DIRECTIONS 90°
APART BY LOOSENING
THE CAP SET SCREW
AND ROTATING VALVE
1-5/8"
41mm
MAX. DECK
THICKNESS
CLEARANCE RADIUS
SINK
(REFERENCE)
DRILL ONE Ø1-3/8" [35mm] HOLE WHERE UNIT IS TO BE INSTALLED.
FLANGE
SIGN
VALVE
CAP SET SCREW
LOCKNUT
RUBBER WASHER
D-NOTCH WASHER
INSTALL SO THAT EYEWASH HEAD IS OVER SINK WHEN ACTIVATED.
3. 2.
SET SCREW
LEFT HAND MOUNTING LOCATION RIGHT HAND
MOUNTING LOCATION
1. SPECIFIES EYEWASH NOZZLE HEIGHTS
THE ANSI Z358.1-2009 STANDARD
NOTES:
TO BE 83.8cm (33 IN.) TO 114.3cm (45 IN.) ABOVE THE FLOOR
4. ±1/2" [6.4mm].
THESE DIMENSIONS MAY VARY
MIN. CLEARANCE TO SINK EDGE
LEFT HAND APPLICATION
SIGN
Left Hand Right Hand
FLIP OVER
MOVE
SET SCREW
SUPPLY
SHANK
SPOOL FOR CAP
INDENTATION IN
SET SCREW
3-5/8"
92mm &
5"
127mm
MIN.CLEARANCE
RADIUSFOR
FACEWASHSTREAMS
AND15.2cm(6IN.)MINIMUMFROM
WALLORNEARESTOBSTRUCTION.
OPPOSITESIDE
SEALBASEWITH
SILICONECAULK
(BETWEENBOTTOMOF
SIGNANDCOUNTERTOP)
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
STH
10/96
11
0002080063.D
7611
8:1
12
IR 05/30/19
2065
DP
4 OF 5
INSTALLATION
5400
2019
FV
R
R

BE SURE SIGN IS ON PROPER SIDE
BE SURE TOP SURFACE OF FLANGE
BE SURE PROTECTIVE BACKING
D-NOTCH LOCKNUT
IS REMOVED FROM RUBBER WASHER
IS FLUSH WITH VALVE AS SHOWN
WASHER
SEAL BASE WITH
SILICONE CAULK
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
STH 10/96
11
0002080063.D
7611
1:1
22
IR 05/30/19
DP
5 of 5
INSTALLATION
5400
2019
FV
