Haws 3121FR Guide

03/20 Model 3121FR Page 1 of 4
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0002077064 (13)
Model 3121FR
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material
or poor workmanship for a period of one year from date of shipment. HAWS
liability under this warranty shall be discharged by furnishing without charge F.O.B.
HAWS Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential
damages claimed to arise under the contract of sale. The drinking fountain
manufactured by HAWS is warranted to function if installation and maintenance
instructions provided are adhered to. The units also must be used for the purpose
for which they were intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/20 Model 3121FR Page 2 of 4
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 5/64“ hex key wrench, 9/16”, 1/2", 7/16” socket wrench or open end
wrench.
LOCATION OF UNIT: When installing Model 3121FR Drinking Fountain, local, state or
federal codes should be adhered to. If height other than shown is required, then dimensions
must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS. Flowing pressure is 30-90
psi (2-6 ATM) for Model 3121FR. Where sediment or mineral content is a problem, an inlet
filter is recommended.
PLUMBING CONNECTIONS: Waste outlet is 1-1/4” IPS.
MAINTENANCE: Periodically clean the strainer. Refer to 6518FR Operation and
Maintenance Sheet for additional information.
TROUBLESHOOTING 3121FR
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve is
wide open. (Customer supplied). Turn
counterclockwise.
b.
Verify minimum 30psi flowing supply
pressure.
c.
Adjust valve to increase flow. See
6518FR Valve Manual.
General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out to
ensure correct engagement with O-Ring.
For more information about Haws products, see our website: www.hawsco.com
© 2020 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1VALVE, FREEZE RESISTANT
2
3STRAINER ASSY
4BUBBLER HEAD
PUSH BTN ASS'Y
PARTS BREAKDOWN
4
3
2
1
VALVE BOX
A
5881PBA
5703M
6466
6518FR
ENSURE TUBE IS DISCONNECTED FROM
"PUSH-IN" TYPE CONNECTOR ON PRESSURE
REGULATOR PRIOR TO REMOVAL. APPLY A DROP
OF LOCTITE 222MS ON NOZZLE THREADS PRIOR
TO REASSEMBLING BACK ONTO BUBBLER HEAD.
REATTACH TUBE TO "PUSH-IN" TYPE
CONNECTOR ENSURING IT IS FULLY BOTTOMED
OUT.
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
D. OLLOM
11/25/95
13
0002077064
3121FR
1:1
11
FV 04/02/20
DP
3 of 4
PARTS BREAKDOWN
5527
2020
FV
(NOT SUPPLIED)
REMOVE INSERT
WITH 5/16 HEX SOCKET
(NOT SUPPLIED)
DETAIL A
ROTATED 90° INTO VIEW
DETAIL OF ITEM 3
1
1
NOTE:
1
**
** REQUIRED - SOLD SEPARATELY

BURY DEPTHS OF 48"[1219mm] AND 72"
CONCRETE ANCHORS
FROST LINE (NOT SUPPLIED).
MAIN SEWER LINE LOCATED BELOW
MINIMUM TO A POROUS GRAVEL FILL OR
[1829mm]. WASTE TO BE 1-1/4" IPS
6"
152mm
1054mm
MOUNTING DETAIL
GROUND LEVEL
8"
203mm
41-1/2"
(SUPPLIED)
MOUNTING HOLES FOR
1/2" ANCHOR BOLTS
IN CONCRETE SLAB
8"
203mm
4X
1/2"-13 UNC
MTG BOLTS 4X
TEMPLATE
PEDESTAL
30" SQUARE
CONCRETE SLAB
(NOT SUPPLIED)
RECESSED
PLATE ACCESS
152mm
6"
14-1/4"
SQUARE
362mm
(TO SPOUT
OUTLET)
TO REPLACE BUBBLER HEAD
DISCONNECT COUPLING
SQ.
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CJL 9/29/92
13
0002077064.D
3121FR
1:1
12
FV 04/02/20
DP
4 OF 4
INSTALLATION
5527
2020
FV
6518FR VALVE ASSY
VALVE BOX
(NOT SUPPLIED)
REQUIRED - SOLD SEPARATELY
