Model 1920/1920HPS
Bottle Filler
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential damages
claimed to arise under the contract of sale. The drinking fountain manufactured by
HAWS is warranted to function if installation and maintenance instructions provided
are adhered to. The units also must be used for the purpose for which they were
intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

06/16 Model 1920/1920HPS Page 2 of 5
REQUIRED TOOLS: Tubing cutter, 3/32” and 5/32” hex key set, adjustable wrench or
socket.
LOCATION OF UNIT: The Model 1920/1920HPS bottle filler water dispenser that can be
installed in various applications. Possible installations include indoor over an existing drinking
fountain, outdoor over an existing fountain, or a standalone wall-mounted bottle filler. When
installing this unit, local, state or federal codes should be adhered to.
SUPPLY LINE: The minimum recommended line size is 3/8"O.D. copper or plastic tubing
with 30-90 psi (2-6 ATM) pressure. Where sediment or mineral content is a problem, an inlet
filter is recommended.
PLUMBING CONNECTIONS: Inlet is 3/8“O.D. push-in type fitting.
MAINTENANCE: Periodically clean the strainer. Refer to 5874HF Valve Manual for more
information.
INSTALLATION PROCEDURE
GENERAL NOTES:
1. For all plastic push-in type fitting connections, only connect NSF-61 copper or
plastic tubing. Stainless steel or glass tubing is not recommended. The
following assembly instructions must be followed to ensure a watertight
connection:
a. Cut tubing square and clean.
b. Mark from end of tube the length of insertion (See table below).
c. Push tube into the fitting until it bottoms out.
d. To remove, depress collet and pull tubing out.
Tube Sizes O.D.
Tolerance Insertion Depth
1/4” ±.005” 11/16”
3/8” ±.005” 3/4”
1/2” ±.005” 7/8”
CLEANING INSTRUCTIONS FOR HI-POLISHED STAINLESS PRODUCTS:
Haws’ recommended cleaning procedure for hi-polished stainless products is as follows:
Use a mild detergent or soap and water for removing stains and fingerprints or use a clean cloth
with window cleaner.
BOTTLER FILLER BRACKET:
If installing the bottler filler in new construction, use Model 6700 or 6700.4 Mounting Plate.
Follow the supplied installation instructions referencing the dimensions shown on Page 5.
If installing as a retrofit in old construction, it is recommended to use Model 6700 or 6700.4
Mounting Plate. If that is not possible, it is recommended to install wood stud cross braces
behind the wall and mount the 1920/1920HPS direction to the wood support. If that is not
possible, Model 6700R retrofit may be used. Follow the installation instructions supplied with the
6700R.
If installing as a standalone bottle filler, use the mounting hole location diagram on Page 5 and
thru bolt the 1920/1920HPS securely to the wall.

06/16 Model 1920/1920HPS Page 3 of 5
TROUBLESHOOTING
PROBLEM REPAIR CHECKLIST
1. Insufficient water flow. 1a. Check that any inlet screwdriver stop valve
(not supplied) is wide open. Turn
counterclockwise.
b. Verify minimum 30 psi flowing supply
pressure.
c. Clean strainer. See 5874HF Valve Manual.
d.
e.
Adjust valve to increase flow. Use front
adjust screw or see 5874HF Valve Manual.
Make sure nozzle is free of debris.
2. Excessive water flow. 2a. Adjust valve to decrease flow. Use front
adjust screw or see 5874HF Valve Manual.
3. Water flow is crooked or
splatters. 3a.
b.
c.
Make sure nozzle is free of debris.
Verify that bottle filler is installed level and
straight.
Adjust valve to decrease flow. Use front
adjust screw or see 5874HF Valve Manual.
For more information about Haws products, see our website: www.hawsco.com
© 2016 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1
2PUSH BUTTON ASSY
PARTS BREAKDOWN
PBA6
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
MJ
06/08/16
1
0510000490
1920/1920HPS
1:14
11
FV 06/22/16
5081
RVH
4 OF 5
PARTS BREAKDOWN
5081
2016
MJ
VALVE 5874HF
1
2

APPROVED:
DRAWN:
PARTNUMBER
SCALE:SHEETOF
REVISION
DRAWINGTYPE:SIZE:A
BY: ECNNO.
PAGE
DATE:
DATE:
ECN:
REVISEDPER
CHK'D.:
HawsCorporation-AllRightsReserved.HAWSandothertrademarksusedinthesematerialsaretheexclusivepropertyofHawsCorporation.
CR
MODEL(S)
1455KLEPPELANE
SPARKS,NEVADA89431
[phone]FAX[phone]
E-MAIL:[e-mail]
WEBSITE:WWW.HAWSCO.COM
THISDOCUMENTISTRUEANDCORRECTATTIMEOFPUBLICATION.CONTINUEDPRODUCTIMPROVEMENTS
MAKESPECIFICATIONSANDMEASUREMENTSSUBJECTTOCHANGEWITHOUTNOTICE.
DS 05/25/16
1
0510000490.D
MODEL1920/1920HPS
N/A
11
JL 06/22/16
5081
RVH
5of5
INSTALLATION
5081
2016
DS
253
8"[645mm]
171
8"[434mm]
1920
BP15
6700
INSTALLATIONABOVEASINGLEFOUNTAIN
1
2"[13mm]
11
8"[29mm]
BP32
1920
6700.4
INSTALLBRACKETON
FINISHWALLAFTER
LOWERBACKPANEL
INSTALLATION
(FASTENERSNOTSUPPLIED)
INSTALLATIONABOVEADOUBLEFOUNTAIN
6700.4MOUNTINGPLATE
(BEHINDFINISHWALL)
3/8"PUSHINTEE
(CONNECTTOFOUNTAINSUPPLY)
6700MOUNTINGPLATE
(BEHINDFINISHWALL)
17
8"[47mm]
3"[76mm]
5
8"[17mm]
11
8"[29mm]
1920MOUNTINGHOLELOCATIONS
ø7
16"[11mm]
NOTES:
HOLDROUGH-INDIMENSIONS±1/8" 1.
(3.2mm)
2.WHENINSTALLINGTHISUNIT,LOCAL,
STATEORFEDERALCODESSHOULD
BEADHEREDTOFORINSTALLATION
LOCATIONS,WASTE&SUPPLY
REQUIREMENTSOTHERTHANSHOWN.
71
4"[184mm]
55
8"[143mm]
3/8"PUSHINTEE
(CONNECTTOFOUNTAINSUPPLY)
251
2"[648mm]
181
8"[460mm]
