Heatlie Barbecues SNAPPY KING RB1000SS User manual

1of 11
27TH November 2014
60 Kinkaid Ave
North Plympton SA 5037
Phn: 08 8376 9330
Email: [email protected] Website: www.heatlie.com.au
SNAPPY KING –Model RB1000SS
General Installation and Operation Instructions
MODEL AND TYPE OF APPLIANCE
SNAPPY KING (RB1000SS) - Is a 1 rack roaster that can also be used as a barbecue when using the optional
Hotplate. Overall dimensions; 1100mm (W) x 1250mm (H) x 600mm (D)
TO BE USED WITH A 9KG GAS BOTTLE.
GENERAL
The appliance shall be installed in accordance with the manufacturer’s installation instructions, local gas fittings
regulations, municipal building codes, water supply regulations, electrical wiring regulations, the AS5601 Gas
Installation Code, and other relevant statutory regulations.
WARNING: This appliance is for outdoor use only.

2of 11
27TH November 2014
DATA PLATE
This data plate is located on the side of the gas controller cover, on the right hand side.
GAS TYPE –UNIVERSAL LPG
For 1 BURNER
For 2 BURNERS
Injector diam- mm
1.15mm
1.15mm
Nominal Gas consumption
15.8 MJ/h
31.6 MJ/h
Nominal Test Point Pressure
2.75kPa
Rear burner 2.75kPa
Front Burner 2.65kPa
INSTALLATION & ASSEMBLY
This appliance is suitable for use with ULPG only.
Remove all plastic protection from the stainless steel before use.
Contents of carton:
1 x Snappy King body
1 x Rack (for roasting)
1 x Stainless steel burner for RB1000SS
1 x Stainless steel fat collection container. (3Litre) drawer
1 x LK40SS leg kit.
Tools required
1 x Adjustable Spanner
WHEEL KIT ASSEMBLY
Remove contents of Leg Kit box.
To secure wheels on wheel leg kit:
Remove all washers and nut from the stub axle.
Pass axles through hole at the bottom of the wheel leg so that the axle thread is protruding from the
outer side of the leg.
Place the 1 x1/2”and the 3/8th washer on the axle.
Place the wheel on the axle.
Place the other 1/2” washer the axle.
Screw on the Nylock nut with the nylon on the external side.
Tighten nut to required tension using spanner.
Repeat process for other wheel.
SNAPPY KING ASSEMBLY
Place Snappy King body on the floor.
Lift the body at the gas control end and lower the Snappy King stub into the wheel legs.
Ensure that the arms of the gas bottle bracket are facing out.
Insert thumbscrews into the Snappy King stub leg and tighten.
Repeat procedure for left hand leg end.
Place the food racks inside the Snappy King, resting on the support ledges at the front and rear of unit.
Slide burner through the burner entry hole at the back on the right hand side of the unit. It is secured
on the left hand side with a barrel bolt.
 9 kg Gas Cylinder only: Hang gas cylinder on the brackets provided . The handle at the top of the
cylinder sits over the bent brackets .
 Regulator: Connect the regulator to the cylinder . Do not over-tighten . Tighten gas cylinder
connection with fingers (left hand external thread POL Type 21 CGA510 fitting) .
 Keep gas line away from potential hot surfaces .
 Note: This is a low pressure appliance and pressure regulator must be used .
 You cannot connect this LPG Roaster directly to a natural gas supply .
 Leak Test : With the gas line connected to the controller unit - turn gas on at cylinder and check for
leaks . Use soapy water - brush over joints on gas cylinder and connection at controller unit and
watch for bubbles .

3of 11
27TH November 2014
ASSEMBLY OF OPTIONAL EXTRAS
BBQ Plate
To use as a barbecue, remove the Roasting rack, and replace it with the full hotplate. Wash the
hotplate with warm soapy water before use to remove any metal dust and oil. Then oil the plate
ready for use. (This helps to prevent rust)
Burner positioning:- If you have the single burner option remove the burner from the back to the
forward burner opening securing it with the barrel bolt on the left hand side
If you have the two burner option insert the burner into the forward opening attaching the burner
hose with the quick connect coupling as shown below. Secure the end of the burner with the barrel
bolt on the left hand side.

4of 11
27TH November 2014
Vegetable Rack
The Double up vegie rack is used in conjunction with the Roasting rack to extend the
cooking space. Place this on top of the roasting rack and to the rear of the unit.
End Table
End tables can be placed on either side of the barbecue.
Secure end table by positioning the mounting support hook into the space provided above the legs.
Use the adjustable feet to alter to the desired level.

5of 11
27TH November 2014
LOCATION REQUIREMENTS
WARNING: This appliance shall not be used indoors .
 It must be located at least 600 mm away from any combustible surfaces and with an
overhead clearance of 1.5 metres .
 This appliance shall only be used in an above ground open-air situation with natural
ventilation, without stagnant areas, where gas leakage and products of combustion
are rapidly dispersed by wind and natural convection .
 Any enclosure in which the appliance is used shall comply with one of the following
(also see diagrams):
1. An enclosure with walls on all sides, but at least one permanent opening at ground level and no
overhead cover (Figure 1) .
2.
Within a partial enclosure that includes an overhead cover and no more than two walls (Figures 2
and 3) .
3. Within a partial enclosure that includes an overhead cover and more than two walls, the following
shall apply (Figures 4 and 5):
(i) At least 25% of the total wall area is completely open and unrestricted .
(ii) At least 30% of the remaining wall area is open and unrestricted .
4. In the case of balconies, at least 20% of the total of the side, back and front wall areas shall be
and remain open and unrestricted .

6of 11
27TH November 2014

7of 11
27TH November 2014
OPERATION
Before lighting
Be sure the Snappy King is at least 600mm away from any combustible surfaces.
Place the unit on a firm solid surface.
The Snappy King must be level - adjust using thumbscrews on legs to raise or lower each end.
Make sure fat container is in place.
Turn gas burner controls to the OFF position.
Check there are no leaks - see Leak Test
Lighting Instructions
1. Open lid before lighting.
2. Turn on gas at the 9kg gas cylinder.
3. You will hear a click, the burner is now alight.
4. If the burner does not light try again.
5. The flame will be on high so adjust the flame to required heat.
6. Close lid and enjoy your cooking!
7. After use - turn off at valve on gas cylinder.
Manual Lighting
1. Turn on gas at the 9 kg gas cylinder.
2. Place a lit match through the viewing aperture adjacent to burner, turn tap to high and
hold down for 5 seconds once lit.
3. Repeat steps 4 to 6 from previous Lighting Section above.
Maintenance
Empty fat collection container after use, and wash with hot soapy water.
Wash the hotplate before use with warm soapy water to remove any metal dust and oil. Then oil the
plate ready for use. (This helps to prevent rust)
After using the hotplate, don’t wash all the grease off as this exposes the steel to the elements and
can cause rust. Simply scrape the plate down and wipe over with a paper towel, leaving a film of
grease on the plate to protect it.
To clean the Roaster after use, first of all, remove the burner. Wash unit with warm soapy water, you
may need to scrub with a scourer, but try to avoid using steel wool, as particles from the steel wool
can become embedded in the stainless steel and cause what looks like tiny rust spots.
Regular cleaning (at least annually) will ensure your Roaster provides many years of reliable
operation.

8of 11
27TH November 2014
Troubleshooting
1. Burner will not light:
Check gas cylinder valve is on . Check there is plenty of gas in the cylinder . Check that spark
occurs at burner port hole, if not then check wiring connections not loose . Check that
thermocouple is within the flame when burner is alight .Check the gas control valve is working
correctly and is on High setting . Otherwise refer to service/repair section .
2. Burner lights but does not stay on:
Check that thermocouple at burner is still within a flame when burner is alight . Check
connection to gas valve is not loose . Any thermocouple replacement must be performed by
an authorised person, refer to service/repair section .
3. Flame is low, excessively yellow or depositing soot:
Check the gas cylinder is not nearly empty (i.e . low pressure) . Check that burner ports are not
blocked by removing the burner tube assembly and clean as necessary . Check that gas valve
is at correct setting . Check there is no blockage (e.g . spider webs) at the burner gas entry
mixing tube . To remove the burner simply undo the barrel bolt at the end of the roaster,
unscrew the regulator at the gas cylinder and slide the burner out through the hole .
4. Flame is not sharp and blue but is blurry and “soft” and giving off smelly combustion
products:
This indicates the burner flame is starving for air . Check all ventilation openings in the roaster
for blockage .
If any of the above conditions cannot be fixed or if the roaster does not
perform correctly, contact the place of purchase, they may be an authorised
service centre, or alternatively return the product to Heatlie for repair .
Heatlie Barbecues
60 Kinkaid Ave
North Plympton SA 5037
Phone: [phone] Fax: [phone]
Email: [email protected]

9of 11
27TH November 2014
COOKING INSTRUCTIONS
ROASTING
Always roast with the lid down.
Make sure the burner is in the rear position. (Do not use 2 burners for roasting.)
Use the Rack to roast, not the Hotplate.
Following lighting instructions, start on high for half an hour, then turn down to low (this seals
in the flavour).
1. If you have a Vegie rack (double up), remember it is hotter on the higher rack, so food will cook
quicker.
2. These may vary with weather conditions and are only a guide:-
Whole Snapper 8-9kg 1 to 1.5 hours
Whole turkeys 2 to 3 hours
Leg Lamb/Roast Beef 3 to 4 hours (depending on size)
Roast vegetables 1 hour approx.
Scones/cakes/puddings varies - much the same as an oven
Refer to our web site www.heatlie.com.au for more ideas and recipes.
You can actually cook anything in a Snappy King that you can cook in an oven or on a
barbecue, it is only limited by your imagination.

10 of 11
27TH November 2014
BARBECUING
Remove roasting rack, and replace with the hotplate.
Move the burner to the forward position, and secure the barrel bolt on the left hand side or
alternatively if you have the two burner option secure both barrel bolts and attach the hose
with the quick connect coupling as shown above.
Preheat the hotplate for a few minutes and then barbecue on high or low flame.
Leave the Snappy King lid in the open position to use as a barbecue.
The vegetable double rack can be used on the hotplate to hold your cooked food.

11 of 11
27TH November 2014
Warranty Policy
Heatlie Engineering warrants its products to be free of original manufacturing defects in material
and workmanship, for a period of ten years from the date of purchase of purchase for domestic use
and one year for commercial use. Any claim must be made within this time, dating from the date
of purchase.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
This warranty is subject to the following conditions:
1. The warranty applies to the original owner, so long as the original date of purchase can be
verified or Warranty Card has been completed and returned to Heatlie Engineering.
2. The owner has the responsibility of adequately packaging the product and transporting it
under insurance to place of purchase, Heatlie Authorised Service Centre, or to Heatlie
Engineering, at the owner’s cost.
3. Warranty service must be performed by a Heatlie Authorised Service Centre or by Heatlie
Engineering.
4. Installation must conform to the applicable Gas and Building standards laid down by the
country or state, and according to the Heatlie product instructions.
5. This warranty policy does not cover any problem associated with rust.
6. This warranty policy does not cover buckling or warping of the hotplate.
7. Lack of maintenance, abuse, misuse, neglect, accident or improper installation of the
appliance will not be covered.
8. Corrosion or damage caused by exposure to the elements, insects, weather or hail will not
be covered under this warranty.
NOTE: All barbecues must be covered by a weatherproof cover when not in use.
9. Any evidence that the product has been modified or serviced by an unauthorised person
will void the warranty.
10. Heatlie Authorised Service Centres or their representatives may provide on-site warranty
service. No other costs shall be covered by warranty other than the costs of parts and
labour.
In the event that warranty service is required, contact a Heatlie Authorised Service Centre or the
retailer from whom the product was purchased.
No other warranties, either expressed or implied, whether by distributor, retailer or employees of
Heatlie, will be recognized or honoured by Heatlie. This limited warranty sets forth the sole remedy
of the owner. The total liability of Heatlie Engineering is limited to the purchase of the product.
Heatlie are continually updating and improving their products. Therefore details and specifications are subject to
change.
