Fundamentals

Fundamentals | About this manual
4HEIDENHAIN | User’s manual for cycle programming | 10/2017
About this manual
Safety precautions
Comply with all safety precautions indicated in this document and
in your machine tool builder's documentation!
Precautionary statements warn of hazards in handling software
and devices and provide information on their prevention. They are
classified by hazard severity and divided into the following groups:
DANGER
Danger indicates hazards for persons. If you do not follow the
avoidance instructions, the hazard will result in death or severe
injury.
WARNING
Warning indicates hazards for persons. If you do not follow the
avoidance instructions, the hazard could result in death or
serious injury.
CAUTION
Caution indicates hazards for persons. If you do not follow the
avoidance instructions, the hazard could result in minor or
moderate injury.
NOTICE
Notice indicates danger to material or data. If you do not follow
the avoidance instructions, the hazard could result in things
other than personal injury, like property damage.
Sequence of information in precautionary statements
All precautionary statements comprise the following four sections:
Signal word indicating the hazard severity
Type and source of hazard
Consequences of ignoring the hazard, e.g.: "There is danger of
collision during subsequent machining operations"
Escape – Hazard prevention measures

Fundamentals | About this manual
HEIDENHAIN | User’s manual for cycle programming | 10/2017 5
Informational notes
Observe the informational notes provided in these instructions to
ensure reliable and efficient operation of the software.
In these instructions, you will find the following informational
notes:
The information symbol indicates a tip.
A tip provides important additional or supplementary
information.
This symbol prompts you to follow the safety
precautions of your machine tool builder. This symbol
also indicates machine-dependent functions. Possible
hazards for the operator and the machine are described
in the machine manual.
The book symbol represents a cross reference to
external documentation, e.g. the documentation of your
machine tool builder or other supplier.
Would you like any changes, or have you found any errors?
We are continuously striving to improve our documentation for you.
Please help us by sending your requests to the following e-mail
address:
[email protected]

Fundamentals | TNC model, software and features
6HEIDENHAIN | User’s manual for cycle programming | 10/2017
TNC model, software and features
This manual describes functions and features provided by TNCs as
of the following NC software numbers.
TNC model NC software number
TNC 640 340590-08
TNC 640 E 340591-08
TNC 640 Programming station 340595-08
The suffix E indicates the export version of the TNC. The export
version of the TNC has the following limitations:
Simultaneous linear movement in up to 4 axes
The machine tool builder adapts the usable features of the TNC to
his machine by setting machine parameters. Some of the functions
described in this manual may therefore not be among the features
provided by the TNC on your machine tool.
TNC functions that may not be available on your machine include:
Tool measurement with the TT
Please contact your machine tool builder to become familiar with
the features of your machine.
Many machine manufacturers, as well as HEIDENHAIN, offer
programming courses for the TNCs. We recommend these courses
as an effective way of improving your programming skill and
sharing information and ideas with other TNC users.
Operating instructions:
All TNC functions not connected to the cycles are
described in the TNC 640 User’s Manual. Please contact
HEIDENHAIN if you require a copy of this User's
Manual.
ID of User's Manual for conversational programming:
892903-xx.
ID of User’s Manual for DIN/ISO programming:
892909-xx.

Fundamentals | TNC model, software and features
HEIDENHAIN | User’s manual for cycle programming | 10/2017 7
Software options
The TNC 640 features various software options that can be enabled by your machine tool builder. Each option is to
be enabled separately and contains the following respective functions:
Additional Axis (options 0 to 7)
Additional axis Additional control loops 1 to 8
Advanced Function Set 1 (option 8)
Expanded functions Group 1 Machining with rotary tables
Cylindrical contours as if in two axes
Feed rate in distance per minute
Coordinate conversions:
Tilting the working plane
Advanced Function Set 2 (option 9)
Expanded functions Group 2
Export license required
3-D machining:
Motion control with minimum jerk
3-D tool compensation through surface-normal vectors
Using the electronic handwheel to change the angle of
the swivel head during program run without affecting the
position of the tool center point (tool tip or center of sphere)
(TCPM = Tool Center Point Management)
Keeping the tool normal to the contour
Tool radius compensation perpendicular to traversing direction and
tool direction
Interpolation:
Linear in 6 axes
HEIDENHAIN DNC (option 18)
Communication with external PC applications over COM component
Display Step (option 23)
Display step Input resolution:
Linear axes down to 0.01 µm
Rotary axes to 0.00001°
Dynamic Collision Monitoring – DCM (option 40)
Dynamic Collision Monitoring The machine manufacturer defines objects to be monitored
Warning in Manual operation
Collision monitoring in the Test Run mode
Program interrupt in Automatic operation
Includes monitoring of 5-axis movements

Fundamentals | TNC model, software and features
8HEIDENHAIN | User’s manual for cycle programming | 10/2017
CAD Import (option 42)
CAD import Support for DXF, STEP and IGES
Adoption of contours and point patterns
Simple and convenient specification of presets
Selecting graphical features of contour sections from conversational
programs
Adaptive Feed Control – AFC (option 45)
Adaptive Feed Control Milling:
Recording the actual spindle power by means of a teach-in cut
Defining the limits of automatic feed rate control
Fully automatic feed control during program run
Turning (option 50):
Cutting force monitoring during machining
KinematicsOpt (option 48)
Optimizing the machine kinematics Backup/restore active kinematics
Test active kinematics
Optimize active kinematics
Mill-Turning (option 50)
Milling and turning modes Functions:
Switching between Milling/Turning mode of operation
Constant surface speed
Tool-tip radius compensation
Turning cycles
Cycle 880: Gear hobbing (option 50 and option 131)
KinematicsComp (option 52)
Three-dimensional compensation
Export license required
Compensation of position and component errors
3D-ToolComp (option 92)
3-D tool radius compensation
depending on the tool’s contact
angle
Export license required
Compensate the deviation of the tool radius depending on the tool’s
contact angle
Compensation values in a separate compensation value table
Prerequisite: Working with surface normal vectors (LN blocks)
Extended Tool Management (option 93)
Extended tool management Python-based
Advanced Spindle Interpolation (option 96)
Interpolating spindle Interpolation turning:
Cycle 291: Interpolation turning, coupling
Cycle 292: Interpolation turning, contour finishing

Fundamentals | TNC model, software and features
HEIDENHAIN | User’s manual for cycle programming | 10/2017 9
Spindle Synchronism (option 131)
Spindle synchronization Synchronization of milling spindle and turning spindle
Cycle 880: Gear hobbing (option 50 and option 131)
Remote Desktop Manager (option 133)
Remote operation of external
computer units
Windows on a separate computer unit
Incorporated in the control's interface
Synchronizing Functions (option 135)
Synchronization functions Real Time Coupling – RTC:
Coupling of axes
Visual Setup Control – VSC (option 136)
Camera-based monitoring of the
setup situation
Record the setup situation with a HEIDENHAIN camera system
Visual comparison of planned and actual status in the workspace
Cross Talk Compensation – CTC (option 141)
Compensation of axis couplings Determination of dynamically caused position deviation through axis
acceleration
Compensation of the TCP (Tool Center Point)
Position Adaptive Control – PAC (option 142)
Adaptive position control Changing of the control parameters depending on the position of the
axes in the working space
Changing of the control parameters depending on the speed or
acceleration of an axis
Load Adaptive Control – LAC (option 143)
Adaptive load control Automatic determination of workpiece weight and frictional forces
Changing of control parameters depending on the actual mass of the
workpiece
Active Chatter Control – ACC (option 145)
Active chatter control Fully automatic function for chatter control during machining
Active Vibration Damping – AVD (option 46)
Active vibration damping Damping of machine oscillations to improve the workpiece surface
Batch Process Manager (option 154)
Batch process manager Planning of production orders

Fundamentals | TNC model, software and features
10 HEIDENHAIN | User’s manual for cycle programming | 10/2017
Feature Content Level (upgrade functions)
Along with software options, significant further improvements of
the TNC software are managed via the Feature Content Level (FCL)
upgrade functions. Functions subject to the FCL are not available
simply by updating the software on your TNC.
All upgrade functions are available to you without
surcharge when you receive a new machine.
Upgrade functions are identified in the manual with FCL n, where n
indicates the sequential number of the feature content level.
You can purchase a code number in order to permanently enable
the FCL functions. For more information, contact your machine tool
builder or HEIDENHAIN.
Intended place of operation
The TNC complies with the limits for a Class A device in
accordance with the specifications in EN 55022, and is intended for
use primarily in industrially-zoned areas.
Legal information
This product uses open source software. Further information is
available on the control under
Programming operating mode
MOD function
License Info softkey

Fundamentals | Optional parameters
HEIDENHAIN | User’s manual for cycle programming | 10/2017 11
Optional parameters
The comprehensive cycle package is continuously further
developed by HEIDENHAIN. Every new software version thus
may also introduce new Q parameters for cycles. These new Q
parameters are optional parameters, which were not all available
in some older software versions. Within a cycle, they are always
provided at the end of the cycle definition. The section "New and
changed cycle functions of software 34059x-08" gives you an
overview of the optional Q parameters that have been added in
this software version. You can decide for yourself whether you
would like to define optional Q parameters or delete them with
the NO ENT key. You can also adopt the default value. If you have
accidentally deleted an optional Q parameter or if you would like
to extend cycles in your existing programs after a software update,
you can include optional Q parameters in cycles when needed. The
following steps describe how this is done:
To insert optional Q parameters in existing programs:
Call the cycle definition
Press the right arrow key until the new Q parameters are
displayed
Apply the default value or enter a value
To transfer the new Q parameter, exit the menu by pressing
the right arrow key once again or by pressing END
If you do not wish to apply the new Q parameter, press the
NO ENT key
Compatibility
The majority of part programs created on older HEIDENHAIN
contouring controls (TNC 150 B and higher) can be executed with
this new software version of the TNC 640. Even if new, optional
parameters ("Optional parameters") have been added to existing
cycles, you can normally continue running your programs as usual.
This is achieved by using the stored default value. The other way
round, if a program created with a new software version is to be
run on an older control, you can delete the respective optional
Q parameters from the cycle definition with the NO ENT key.
In this way you can ensure that the program will be downward
compatible. If NC blocks contain invalid elements, the TNC will
mark them as ERROR blocks when the file is opened.

Fundamentals | New cycle functions of software 34059x-04
12 HEIDENHAIN | User’s manual for cycle programming | 10/2017
New cycle functions of software 34059x-04
The character set of the fixed cycle 225 Engraving was
expanded by more characters and the diameter sign See
"ENGRAVING (Cycle 225, DIN/ISO: G225)", page 340
New machining cycle 275 Trochoidal milling See "TROCHOIDAL
SLOT (Cycle 275, DIN/ISO: G275)", page 247
New machining cycle 233 Face milling See "FACE MILLING
(Cycle 233, DIN/ISO: G233)", page 194
In Cycle 205 Universal Pecking you can now use parameter
Q208 to define a feed rate for retraction See "Cycle parameters",
page 100
In the thread milling cycles 26x an approaching feed rate was
introduced See "Cycle parameters", page 138
The parameter Q305 NUMBER IN TABLE was added to Cycle
404 See "Cycle parameters", page 520
In the drilling cycles 200, 203 and 205 the parameter Q395
DEPTH REFERENCE was introduced in order to evaluate the T
ANGLE See "Cycle parameters", page 100
Cycle 241 SINGLE-LIP DEEP HOLE DRILLING was expanded
by several input parameters See "SINGLE-LIP DEEP-HOLE
DRILLING (Cycle 241, DIN/ISO: G241)", page 109
The probing cycle 4 MEASURING IN 3-D was introduced See
"MEASURING IN 3-D (Cycle 4)", page 633

Fundamentals | New and changed cycle functions of software 34059x-05
HEIDENHAIN | User’s manual for cycle programming | 10/2017 13
New and changed cycle functions of software
34059x-05
New Cycle 880 GEAR HOBBING (software option 50 and
software option 131), See "GEAR HOBBING (Cycle 880, DIN/
ISO: G880)", page 476
New Cycle 292 CONTOUR FINISHING TURNING
INTERPOLATION (software option 96), See "INTERPOLATION
TURNING, CONTOUR FINISHING (Cycle 292, DIN/ISO: G292,
software option 96)", page 323
New Cycle 291 COUPLING TURNING INTERPOLATION
(software option 96), See "COUPLING INTERPOLATION
TURNING (cycle 291, DIN/ISO: G291, software option 96)",
page 333
New Load Adaptive Control (LAC) cycle for the load-dependent
adaptation of control parameters (software option 143), See
"ASCERTAIN THE LOAD (Cycle 239, DIN/ISO: G239, software
option 143)", page 351
Cycle 270: CONTOUR TRAIN DATA was added to the cycle
package (software option 19), See "CONTOUR TRAIN DATA
(Cycle 270, DIN/ISO: G270)", page 246
Cycle 39 CYLINDER SURFACE (software option 1) Contour was
added to the cycle package, See "CYLINDER SURFACE (Cycle
39, DIN/ISO: G139, software option 1)", page 269
The character set of the fixed cycle 225 Engraving was
expanded by the CE, ß and @ characters and the system time,
See "ENGRAVING (Cycle 225, DIN/ISO: G225)", page 340
Cycles 252 to 254 were expanded by the optional parameter
Q439, See "Cycle parameters", page 168
Cycle 22 was expanded by the optional parameters Q401 and
Q404, See "ROUGHING (Cycle 22, DIN/ISO: G122)", page 228
Cycles 841, 842, 851 and 852 were expanded by the plunging
feed rate Q488, See "Cycle parameters", page 417
Cycle 484 was expanded by the optional parameter Q536, See
"Calibrating the wireless TT 449 (Cycle 484, DIN/ISO: G484)",
page 726
Eccentric turning with Cycle 800 is possible with option 50 and
option 135, See "ADAPT ROTARY COORDINATE SYSTEM (Cycle
800, DIN/ISO: G800)", page 366

Fundamentals | New and changed cycle functions of software 34059x-06
14 HEIDENHAIN | User’s manual for cycle programming | 10/2017
New and changed cycle functions of software
34059x-06
New Cycle 258 POLYGON STUD, See "POLYGON STUD (Cycle
258, DIN/ISO: G258)", page 189
New Cycles 600 and 601 for camera-based monitoring of the
setup situation (software option 136), See "Camera-based
monitoring of the setup situation VSC (option 136)", page 656
Cycle 291 INTERPOLATION TURNING, COUPLING (software
option 96) was expanded expanded to include parameter Q561,
See "COUPLING INTERPOLATION TURNING (cycle 291, DIN/
ISO: G291, software option 96)", page 333
Cycles 421, 422 and 427 have been expanded to include
parameters Q498 and Q531, See "MEASURE HOLE (Cycle 421,
DIN/ISO: G421)", page 595
Cycle 247 PRESETTING: The number of the preset can be
selected from the preset table, See "PRESETTING (Cycle 247,
DIN/ISO: G247)", page 297
Cycles 200 and 203: The behavior of the dwell time at top was
modified, See "UNIVERSAL DRILLING (Cycle 203, DIN/ISO:
G203)", page 88
Cycle 205 performs deburring on the coordinate surface,
See "UNIVERSAL PECKING (Cycle 205, DIN/ISO: G205)",
page 98
For SL cycles, M110 is now taken into account for arcs
compensated on the inside of the arc if M110 is active during
machining, See "SL Cycles", page 216

Fundamentals | New and changed cycle functions of software 34059x-07
HEIDENHAIN | User’s manual for cycle programming | 10/2017 15
New and changed cycle functions of software
34059x-07
New Cycle 444 for three-dimensional probing of any coordinate,
See "3D PROBING (Cycle 444)", page 635
Cycle 451 has been expanded by parameter Q406. This makes
it possible to use KinematicsComp (software option 52) to
compensate the measured angle position errors of the rotary
axes, See "MEASURE KINEMATICS (Cycle 451, DIN/ISO: G451,
option)", page 686
Cycle 460 has been expanded by parameter Q455. This makes
it possible to measure, store, and compensate the deviations
determined by KinematicsComp (software option 52), See
"CALIBRATE TS (Cycle 460, DIN/ISO: G460)", page 642
In the protocol of the KinematicsOpt cycles 451 and 452 the
position of the measured rotary axes can be output before
and after optimization. See "MEASURE KINEMATICS (Cycle
451, DIN/ISO: G451, option)", page 686, See "PRESET
COMPENSATION (Cycle 452, DIN/ISO: G452, option)",
page 700
Cycle 225 has been expanded by parameters Q516, Q367,
and Q574. This makes it possible to define a preset for the
respective text position, as well as to scale the text length
and character height. The pre-positioning for engraving on a
circular path has changed, See "ENGRAVING (Cycle 225, DIN/
ISO: G225)", page 340
Cycle 861 has been expanded by parameters Q510, Q511, and
Q462. This makes it possible to program an overlap, a feed
rate factor, and a selectable retraction behavior. See "RADIAL
RECESSING (Cycle 861, DIN/ISO: G861)", page 437
Cycle 862 has been expanded by parameters Q510, Q511,
and Q462. This makes it possible to program an overlap, a
feed rate factor, and a selectable retraction behavior, See
"RADIAL RECESSING EXTENDED (Cycle 862, DIN/ISO: G862)",
page 441
Cycle 871 has been expanded by parameters Q510, Q511, and
Q462. This makes it possible to program an overlap, a feed
rate factor, and a selectable retraction behavior, See "AXIAL
RECESSING (Cycle 871, DIN/ISO: G871)", page 450
Cycle 872 has been expanded by parameters Q510, Q511,
and Q462. This makes it possible to program an overlap, a
feed rate factor, and a selectable retraction behavior, See
"AXIAL RECESSING EXTENDED (Cycle 872, DIN/ISO: G872)",
page 454

Fundamentals | New and changed cycle functions of software 34059x-07
16 HEIDENHAIN | User’s manual for cycle programming | 10/2017
Cycle 860 has been expanded by parameters Q510, Q511, and
Q462. This makes it possible to program an overlap, a feed rate
factor, and a selectable retraction behavior, See "RECESSING
CONTOUR RADIAL (Cycle 860, DIN/ISO: G860)", page 445
Cycle 870 has been expanded by parameters Q510, Q511, and
Q462. This makes it possible to program an overlap, a feed
rate factor, and a selectable retraction behavior, See "AXIAL
RECESSING (Cycle 870, DIN/ISO: G870)", page 458
In Cycle 810, parameter Q499 was expanded with the input
option "2". This modifies the tool position if the contour is
machined in the direction opposite of the programmed direction,
See "TURN CONTOUR LONGITUDINAL (Cycle 810, DIN/ISO:
G810)", page 389
In Cycle 815, parameter Q499 was expanded with the input
option "2". This modifies the tool position if the contour is
machined in the direction opposite of the programmed direction,
See "TURN CONTOUR-PARALLEL (Cycle 815, DIN/ISO: G815)",
page 393
In Cycle 820, parameter Q499 was expanded with the input
option "2". This modifies the tool position if the contour is
machined in the direction opposite of the programmed direction,
See "TURN CONTOUR FACE (Cycle 820, DIN/ISO: G820)",
page 411
In Cycles 481 to 483, parameter Q340 was expanded with
the input option "2". This makes it possible to check the tool
without changing the tool table, See "Measuring tool length
(Cycle 31 or 481, DIN/ISO: G481)", page 728, See "Measuring
tool radius (Cycle 32 or 482, DIN/ISO: G482)", page 730,
See "Measuring tool length and radius (Cycle 33 or 483, DIN/
ISO: G483)", page 732
Cycle 251 has been expanded by parameter Q439. In addition,
the strategy for finishing was revised, See "RECTANGULAR
POCKET (Cycle 251, DIN/ISO: G251)", page 159
In Cycle 252, the strategy for finishing was revised, See
"CIRCULAR POCKET (Cycle 252, DIN/ISO: G252)", page 164
Cycle 275 has been expanded by parameters Q369 and
Q439, See "TROCHOIDAL SLOT (Cycle 275, DIN/ISO: G275)",
page 247

Fundamentals | New and changed cycle functions of software 34059x-08
HEIDENHAIN | User’s manual for cycle programming | 10/2017 17
New and changed cycle functions of software
34059x-08
New Cycle 453 KINEMATICS GRID. This cycle makes it possible
to probe a calibration sphere in tilting-axis positions predefined
by the machine tool builder. The measured deviations can be
compensated with the aid of compensation tables. Options
48 KinematicsOpt and 52 KinematicsComp are needed; the
machine tool builder must adapt the function to the specific
machine. See "KINEMATICS GRID (Cycle 453, DIN/ISO: G453,
option)", page 710
New Cycle 441 FAST PROBING. You can use this cycle to
globally specify various touch probe parameters (e.g. the
positioning feed rate) for all subsequently used touch probe
cycles. See "FAST PROBING (Cycle 441, DIN/ISO G441)",
page 652
New Cycle 276 3-D Contour Train See "THREE-D CONT. TRAIN
(Cycle 276, DIN/ISO: G276)", page 241
Enhancement of the contour train: Cycle 25 with machining of
residual material, the cycle was expanded with the following
parameters: Q18, Q446, Q447, Q448 See "CONTOUR TRAIN
(Cycle 25, DIN/ISO: G125)", page 237
Cycles 256 RECTANGULAR STUD and 257 CIRCULAR STUD
have been expanded to include parameters Q215, Q385, Q369
and Q386. See "RECTANGULAR STUD (Cycle 256, DIN/ISO:
G256)", page 180, See "CIRCULAR STUD (Cycle 257, DIN/ISO:
G257)", page 185
The recessing cycles 860 to 862 and 870 to 872 were expanded
by the input parameter Q211. In this parameter, a dwell time
can be specified in revolutions of the workpiece spindle, which
retards the retraction after the recessing on the floor. See
"RECESSING CONTOUR RADIAL (Cycle 860, DIN/ISO: G860)",
page 445, See "RADIAL RECESSING (Cycle 861, DIN/ISO:
G861)", page 437, See "RADIAL RECESSING EXTENDED
(Cycle 862, DIN/ISO: G862)", page 441, See "AXIAL
RECESSING (Cycle 870, DIN/ISO: G870)", page 458, See
"AXIAL RECESSING (Cycle 871, DIN/ISO: G871)", page 450,
See "AXIAL RECESSING EXTENDED (Cycle 872, DIN/ISO:
G872)", page 454
Cycle 239 can ascertain the current load of the machine
axes with the control function LAC. Cycle 239 can now also
modify the maximum axis acceleration. Cycle 239 supports
the determination of the load on synchronized axes. See
"ASCERTAIN THE LOAD (Cycle 239, DIN/ISO: G239, software
option 143)", page 351
Cycles 205 and 241: The feed rate behavior was modified.
See "SINGLE-LIP DEEP-HOLE DRILLING (Cycle 241, DIN/ISO:
G241)", page 109, See "UNIVERSAL PECKING (Cycle 205,
DIN/ISO: G205)", page 98
Detail changes with Cycle 233: Monitors length of the cutting
edge (LCUTS) with finishing operations, when roughing with
the milling strategy between 0 to 3, the surface in the milling
direction is increased by the value from Q357 (provided that no
limitation is set in this direction) See "FACE MILLING (Cycle 233,
DIN/ISO: G233)", page 194

Fundamentals | New and changed cycle functions of software 34059x-08
18 HEIDENHAIN | User’s manual for cycle programming | 10/2017
CONTOUR DEF can be programmed in DIN/ISO
The technically obsolete cycles 1, 2, 3, 4, 5, 17, 212, 213, 214,
215, 210, 211, 230, 231 subordinated in "old cycles" can no
longer be inserted via the editor. These cycles can however still
be modified and executed.
The tool touch probe cycles 449,480, 481, 482 can be hidden
See "Setting machine parameters", page 720
Cycle 225 Engraving can engrave the current counter reading
with a new syntax See "Engraving the counter reading",
page 345
New column SERIAL in the touch-probe table See "touch probe
data", page 499

Contents
HEIDENHAIN | User’s manual for cycle programming | 10/2017 19
Contents
1 Fundamentals / Overviews............................................................................................................53
2 Using Fixed Cycles......................................................................................................................... 57
3 Fixed Cycles: Drilling......................................................................................................................77
4 Fixed Cycles: Tapping / Thread Milling...................................................................................... 121
5 Fixed Cycles: Pocket Milling / Stud Milling / Slot Milling........................................................157
6 Fixed Cycles: Pattern Definitions................................................................................................ 205
7 Fixed Cycles: Contour Pocket......................................................................................................215
8 Fixed Cycles: Cylindrical Surface................................................................................................ 257
9 Fixed Cycles: Contour Pocket with Contour Formula...............................................................275
10 Cycles: Coordinate Transformations........................................................................................... 289
11 Cycles: Special Functions............................................................................................................ 315
12 Cycles: Turning..............................................................................................................................359
13 Using Touch Probe Cycles........................................................................................................... 491
14 Touch Probe Cycles: Automatic Measurement of Workpiece Misalignment.......................... 501
15 Touch Probe Cycles: Automatic Presetting................................................................................525
16 Touch Probe Cycles: Automatic Workpiece Inspection.............................................................583
17 Touch Probe Cycles: Special Functions......................................................................................629
18 Visual Setup Control VSC (Software Option 136).................................................................... 655
19 Touch Probe Cycles: Automatic Kinematics Measurement......................................................679
20 Touch Probe Cycles: Automatic Tool Measurement..................................................................717
21 Tables of Cycles............................................................................................................................ 735

Contents
20 HEIDENHAIN | User’s manual for cycle programming | 10/2017
