Heinner HPM-8012X User manual

PLANETARY MIXER
Model: HPM-8012X
www.heinner.ro
Planetary mixer
Planetary mixing
Power: 800W

www.heinner.com 800W, 50Hz, 220-240V
1
Thank you for purchasing this product!
I. INTRODUCTION
Before using the appliance, please read carefully this instruction manual and keep it for future
reference.
This instruction manual is designed to provide you with all required instructions related to the
installation, use and maintenance of the appliance.
In order to operate the unit correctly and safety, please read this instruction manual carefully before
installation and usage.
Planetary mixer
User manual
Warranty card
II. PACKAGE CONTENT

www.heinner.com 800W, 50Hz, 220-240V
2
Before using the appliance, you must always follow these basic precautions:
1. Read all instructions.
2Make sure that your outlet voltage corresponds to the stated on the rating label of
the mixer.
3. Do not operate mixer with a damaged cord or plug, after the appliance malfunction,
or if it is dropped or damaged in any manner. Return the appliance to the nearest
authorized Service Center for examination, repair or electrical or mechanical
adjustment.
4. Do not leave mixer unattended while it is operating.
5. Close supervision is necessary when any appliance is used by or near children.
6. Unplug from outlet while not in use, before putting on or taking off parts, and before
cleaning.
7. The use of attachments not recommended or sold by the manufacturer may cause
fire, electric shock or injury.
8. Remove beater/dough hook/whisk from mixer before washing.
9. Do not place on or near a hot gas or electric burner or in a heated oven.
10. Always check that the control is OFF before plugging cord into wall outlet. To
disconnect, turn the control to OFF, then remove plug from wall outlet.
11. Avoid contacting with moving parts.
12. Keep hands, clothing, as well as spatulas and other utensils away from beaters
during operation to reduce the risk of injury to persons, and/or damage to the mixer.
13. To protect against risk of electrical shock, do not put mixer in water or other liquid.
This may cause personal injury or damage to the product.
14. Do not use mixer for other than intended use.
15. This appliance is not intended for use by persons with reduced physical (including
children), sensory or mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
16. Keep the appliance and its cord out of reach of children less than 8 years.
17. Do not let cord hang over edge of table or counter or touch hot surfaces, including
the stove.
18. Do not use outdoors.
21. Save these instructions.
III. SAFETY INSTRUCTIONS

www.heinner.com 800W, 50Hz, 220-240V
3
IV. DESCRIPTION

www.heinner.com 800W, 50Hz, 220-240V
4
Before assembling the mixer, be sure the power cord is unplugged from the power
outlet and the speed selector is in the “Off” position.
1. Turning the tilt/release bar 90°clockwise, the head of mixer will automatically
release and lift it backwards with hand lightly to lock it into tile position.
2. Select the desired attachments, which are depending on the mixing task to be
performed: flat beater for normal to heavy mixtures, and dough hook for mixing
and kneading yeast dough, the whisk for mixture that need air incorporated.
3. Assemble the flat beater/ dough hook/whisk into the shaft under the head, align
the rectangle groove of flat beater/dough hook/whisk with the pin on the shaft to
insert (see fig.1), then push the flat beater/dough hook/whisk upwards as far as
possible and turn it in anti-clockwise synchronously, hooking beater/dough
hook/whisk over pin on shaft. When detaching, firstly push the beater/dough
hook/whisk upwards and turn it in clockwise synchronously, then pull out for
detaching.
Note: Ensure the flat beater/dough hook/ whisk is fully locked into the shaft,
otherwise it may drop out during operation.
4. Place bowl on position. First place the bowl on the base, then turn the bowl in
clockwise until it lock into position (see fig.2).
5. To lower the head, firstly press the tile/release button and place beater / dough
hook/whisk into the bowl by pressing down the head with hand directly. A click
sound will be heard when the head has reached the correct position.
6. And make sure the bowl cover in place (see fig.3).
V. BEFORE USING

www.heinner.com 800W, 50Hz, 220-240V
5
VI. USING INSTRUCTIONS
1. Ensure that the speed selector is at the “Off” position, then plug in the power
source.
2. Turn the speed selector to your desired setting. There are 12 setting.
Warning: Do not stick knife, metal spoons, fork and so on into bowl when operating.
3. The max operation time per time shall not exceed 7minutes and minimum 20
minutes rest time must be maintained between two consecutive cycles. When
kneading yeast dough, use low speed for slowing mixing, if using high speed, it may
damage the mixer.
Note: during kneading, some flour may be adhered on the inside of the bowl, you
shall stop the appliance and remove the bowl cover, scrape the flour on the inside
wall of bowl by spatula to obtain well kneading results.
4. During mixing, you can add ingredient according to your task from the opening of
bowl cover. When mixing is completed, turn the speed selector to “Off” position,
unplug the cord from power outlet.
5. Turning the tilt/release bar 90°clockwise, the head of the mixer will automatically
lift and lock into the tilt position.
6. If necessary you can scrape the excess food particles from the beater/dough hook
by plastic spatula.
7. Firstly push the beater/dough hook/whisk upwards and turn it in clockwise
synchronously, then pull out for detaching.
Caution: The speed selector must be at “Off” position and the power outlet must be
unplugged before pulling out the beater/dough hook/whisk.
VII. MAINTENANCE AND CLEANING
1. Before cleaning, unplug the appliance and wait for it to cool completely.
2. Wipe the outside of it with a damp cloth and then wipe with a soft dry cloth.
3. Wipe any excess food particles from the power cord.
4. Immerse the bowl, beater, spatula, dough hook and whisk in warm soapy water for
complete cleaning. Then rinse under running water and wipe dry. They also can be
placed in the dishwasher.
WARNING: Mixer can not be immersed in water or other liquid.
WARNING:Any intervention should be performed by an authorized service representative.

www.heinner.com 800W, 50Hz, 220-240V
6
Paste
(dough hook)
Ingredients
Procedure
1.1 lb sifted flour(500 gram)
1) Sift together into a big bowl, sifted flour, egg, white
sugar, baking powder and salt. Add shortening; pour in
the milk and butter
2) Knead 0.5min, on the lowest setting until blended
3) Then on the highest setting for 4.5 min.
0.35 lb milk(160 gram)
0.23 lb white sugar(106 gram)
2 eggs(108 gram)
0.38 lb butter(172 gram)
2-1/2teasp. Double-acting baking
powder(5 gram)
3/4 teaspoon. Salt(10 gram)
Cake
(Stirring paddle)
0.9 lb sifted flour(414 gram)
1) Sift together into a big bowl, sifted flour,white sugar,
baking powder and egg white. Add shortening; pour in
the milk and butter
2) Knead 0.5min, on the lowest setting until blended
3) Then on the highest setting for 4.5 min.
1 lb white sugar(472 gram)
4teasp. Double-acting baking
powder
0.68 lb milk(310 gram)
0.57 lb butter(260 gram)
0.13 lb egg white(60 gram)
1. Refrigerated ingredients, such as butter and eggs, then should be at room temperature
before mixing begins. Set these ingredients out ahead of time.
2. To eliminate the possibility of shells or deteriorated-off eggs in your recipe, break eggs into
separate container first, then adding to the mixture.
3. Do not over-beat. Be careful that you only mix/blend mixtures until recommended in your
recipe. Fold into dry ingredients only until just combined. Always use the low speed.
4. Climatic conditions. Seasonal temperature changes, temperature of ingredients and their
texture variation from area to area all play a part in the required mixing time and the results
achieved.
5. Always start mixing at lower speed. Gradually increase to the recommended speed as
stated in the recipe.
VIII. COOKING ADVICES
IX. RECIPE

www.heinner.com 800W, 50Hz, 220-240V
7
Make egg white
(whisk)
4 eggs
1) Put the egg white into a bowl
2) Whisk at the highest setting
Power
800W
Voltage
220-240V, 50Hz
Color
white
X. TECHNICAL DETAILS

www.heinner.com 800W, 50Hz, 220-240V
8
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipment’s to
an appropriate waste disposal center.
HEINNER is a registered trademark of Network One Distribution SRL. Other brands and
product names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from NETWORK
ONE DISTRIBUTION.
Copyright © 2013 Network One Distribution. All rights reserved.
www.heinner.com, http://www.nod.ro
This product is in conformity with norms and standards of European Community.
Importer: Network One Distribution
Marcel Iancu Street, 3-5, Bucharest, Romania
Tel: [phone], www.heinner.com , www.nod.ro

www.heinner.com 800W, 50Hz, 220-240V
9
