Helo Ring1118-600-0405 User manual

ELECTRIC SAUNA HEATER:
1118-600-0405
1118-900-0405
CONTROL PANELS:
1601-12 (RA 12 Digi II)
1601-13 (RA 13 Digi I)
1601-16 (RA 16 Easy)
1601-18 (RA 18 Midi)
314 SKLT A
Installation and User Manual Helo Ring

Contents
1. Quick instructions for use of the sauna heater 3
1.1. Check before taking a sauna bath 3
1.2. Operation of the sauna heater controls 3
2. Information for users 3
2.1. Sauna room 3
2.2. Recommended sauna room ventilation 4
2.3. Heating the sauna 4
2.4. Sauna heater stones 5
2.5. If the sauna heater will not heat up 5
3. Instructions for the installer 6
3.1. Preparing for sauna heater installation 6
3.2. Installation 6
3.3. Sauna heater safety clearances 7
3.4. Connection of the sauna heater to the mains 8
3.5. Electric heating toggle 8
3.6. Locating the connecting box for the connection cable in the sauna room 9
3.7. Principle image when Digi II is used as control panel 10
3.8. Wiring diagram 11
4. Helo Ring spare part list 12
5. ROHS 12
Images and tables
Image 1 Recommended sauna room ventilation 4
Image 2 Location for the connection box 9
Image 3 Principle image 10
Image 4 Wiring diagram for the sauna heater 11
Table 1 Safety clearances 7
Table 2 Connection cable and fuses 8
Installation and User Manual Helo Ring 2

1. Quick instructions for use of the sauna heater
1.1.Check before taking a sauna bath
1. The sauna room is suitable for taking a sauna bath.
2. The door and the window are closed.
3. The sauna heater is topped with stones that comply with the manufacturer's recommendations, the heating elements are
covered with stones, and the stones are piled sparsely.
NOTE! Ceramic rocks are not allowed.
A pleasant, smooth sauna bath temperature is about 70 °C degrees.
Rearrange the sauna stones at least once a year and replace any weathered stones. This enhances air circulation between the
stones, which extends the useful life of the heating elements.
If you encounter any problems, please contact the manufacturer's warranty service shop.
For additional information about enjoying a sauna bath, please visit our website at www.helo.fi
1.2.Operation of the sauna heater controls
The main switch is located on the side of the sign at the bottom of the sauna heater.
The sign shows the position of the switch. ( 0 I )
Refer to the specific control panel operating instructions.
2. Information for users
Persons with reduced physical and mental capacity, sensory handicap, or little experience and knowledge about how the device
is operated (e.g. children), should only operate the device while supervised or according to instructions given by the persons in
charge of their safety.
Make sure that children aren't playing with the sauna heater.
2.1.Sauna room
The walls and ceiling of a sauna room should be thermally well insulated. All surfaces that store heat, such as tiled and
plastered surfaces must be insulated. It is recommended to use wooden panel cladding inside the sauna room. If there are heat
storage elements in the sauna room, such as decorative stone, glass etc., note that these elements may extend the pre-heating
period even though the sauna room is otherwise well insulated (see page 6, section 3.1. Preparing for sauna heater installation).
Installation and User Manual Helo Ring 3

2.2.Recommended sauna room ventilation
55
4
4
2
1
1
1
A
7
A
min 500 mm
6
3
B
3
B
C
C
C
C A
1000 mm
Image 1 Recommended sauna room ventilation
1. Sauna room 3. Electric sauna heater 5. Exhaust flue or channel
2. Washroom 4. Exhaust valve 6. Door to the sauna room
7. A ventilation valve can be installed here to be kept closed while the sauna is heated and during bathing.
Inlet vent can be positioned in the A zone. Make sure the incoming fresh air will not interfere with (i.e. cool down) the sauna
heater's thermostat near the ceiling.
The B zone serves as the incoming air zone, if the sauna room isn't fitted with forced ventilation. In this case, the exhaust valve
is installed min 1m higher than the inlet valve.
DO NOT ISTALL INLET VALVE WITHIN ZONE C, IF THE SAUNA HEATER'S CONTROL THERMOSTAT IS LOCATED IN
THE SAME ZONE.
2.3.Heating the sauna
Before turning the sauna heater on, make sure the sauna room is suitable for taking a sauna bath. When heated for the first
time, the sauna heater may emit some odour. If you detect any odour while the sauna heater warms up, disconnect the sauna
heater briefly, and air the room. Then you can turn the sauna heater on again.
The sauna heater is turned on from the control panel that has controls for the heating temperature and
time.
The heating of a sauna should be started roughly an hour before you plan to take a sauna bath, so that the stones have time to
heat up properly and the air warms up evenly in the sauna room.
Do not put any objects on the sauna heater. Do not dry clothes on the sauna heater or anywhere in its vicinity.
Installation and User Manual Helo Ring 4

2.4.Sauna heater stones
Quality stones meet the following requirements:
1. Sauna stones should withstand heat and heat variation caused by vaporisation of the water thrown on the stones.
2. Stones should be rinsed before use in order to avoid odour and dust.
3. Sauna stones should have an uneven surface to supply a larger surface for the water to evaporate from.
4. Sauna stones should be large enough, measuring about 50–80 mm to allow good ventilation between the stones. This
extends the useful life of the heating elements.
5. Sauna stones should be piled sparsely in order to enhance ventilation between the stones. Do not bend the heating
elements together or against the frame.
Rearrange the stones regularly (at least once a year) and replace small and broken stones with new, larger stones.
Stones are piled so that they cover the heating elements. Do not, however, pile a large heap of stones on the heating elements.
For a sufficient amount of stones refer to Table 1 on page 7. Any small stones in the package of stones must not be piled on the
sauna heater.
The warranty does not cover defects resulting from poor ventilation caused by small and tightly packed stones.
Ceramic rocks are not allowed. They may cause damage to the sauna heater that will not be covered by the warranty.
2.5.If the sauna heater will not heat up
If the sauna heater will not heat up, please check that:
- the power is on;
- the main fuses of the sauna heater are intact;
- is there any error messages on the control panel. In case of an error message on the control panel, please refer to the control
panel instructions.
Installation and User Manual Helo Ring 5

3. Instructions for the installer
THE PERSON INSTALLING THE SAUNA HEATER SHOULD LEAVE THESE INSTRUCTIONS AT THE PREMISES FOR THE
FUTURE USER.
3.1.Preparing for sauna heater installation
Check the following before installing the sauna heater.
1. The ratio of the heater's input (kW) and the sauna room's volume (m3). Volume recommendations are presented in Table 1
on page 7. The minimum and maximum volumes must not be exceeded.
2. The sauna room height must be a min. of 1900 mm.
3. Uninsulated and masonry stone walls extend the preheating time. Each square metre of plastered ceiling or wall surface adds
1.5 – 2 m3to the sauna room's volume.
4. Check page 8 Table 2 for a suitable fuse size (A) and the correct diameter of the power supply cable (mm²) for the sauna
heater in question.
5. Conform to the specified safe clearance around the sauna heater. Please refer to Table 1 on page 7.
6. There should be enough room around the sauna heater for maintenance purposes. Also a doorway can be considered as a
maintenance area.
3.2.Installation
Follow the safety clearance specifications on page 7 when installing the sauna heater.
The sauna heater is a floor-standing model. The base must be solid, because the sauna heater weighs about 75 kg.
The sauna heater is levelled by the adjustable legs.
The sauna heater is fixed on the floor from its legs by the provided metal fasteners (2 pcs). This will keep the safety clearances
intact during use.
The minimum clearances specified on page 7 must be followed even if the sauna room wall materials are incombustible.
Walls or ceilings must not be clad with fibre-reinforced plaster board or other light-weight cladding, because they may cause a
fire hazard.
Install the sauna heater so that the sign and the warnings can be read even after the installation.
The control panels are installed outside the sauna room with the exception of the Midi controller which is installed on the wall
beside the sauna heater. Refer to more detailed installation instructions in the installation and operation guide of the control
panel.
Only a single sauna heater is allowed per sauna room
Installation and User Manual Helo Ring 6

3.3.Sauna heater safety clearances
Power
kW
Saunaroom Safety clearances min.
Adequate amount
of stones
n. kg
min.
max.
Height
min.
On the
sides
In front
To the ceiling
m3m
3
H A
mm
D
mm
F
mm
mm
6,0 5 9 1900 60 60 1100 60
8,0 8 13 1900 60 60 1100 60
Table 1 Safety clearances
Installation and User Manual Helo Ring 7
*) = Absolute measurement
1900
60
mm mm
60
770
60 *)
60
40 *)
OLET 19
425 mm
800
OLET 19
Heater’s
leg
Metal
fastener
Adjustable
leg
Floor
fastener
Corner and wall installation:
The sensor is placed on the
centreline of the heater 40 mm
from the ceiling
Mid-floor installation:
NOTE !
If the heater is placed more than
60 mm from the wall the
installation type is always a mid-
floor installation.
The sensor must be fitted to the
ceiling according to instructions.
1900
60
mm
60
770
OLET 19
OLET 19

3.4.Connection of the sauna heater to the mains
The sauna heater must be connected to the mains by a qualified electrician and in compliance with current regulations. The
sauna heater is connected with a semi-permanent connection. Use H07RN-F (60245 IEC 66) cables or a corresponding type.
Other output cables (signal lamp, electric heating toggle) must also adhere to these recommendations. Do not use PVC
insulated cable as a connection cable for the sauna heater.
A multipolar (e.g. 7-pole) cable is allowed, if the voltage is the same. In the absence of a separate control current fuse, the
diameter of all cables must be the same, i.e. in accordance with the front fuse.
The connecting box on the sauna wall should be located within the minimum safety clearance specified for the sauna heater.
The maximum height for the connection box is 500 mm from the floor. See page 9 Image 2 Location for the connection box
If the connection box is located at over 500mm distance from the heater, the maximum height is 1000mm from the floor.
Sauna heater insulation resistance:
The sauna heater heating elements may absorb moisture from air, e.g. during storage. This may cause leakage currents. The
moisture will be gone after a few heating sessions. Do not connect the heater power supply through a ground fault interrupter.
However, adhere to the effective electrical safety regulation when installing the sauna heater.
Power
kW
Sauna heater’s
connection cable
H07RN-F /
60245 IEC 66
mm2
400 – 415V 3N~
Fuse
A
Sauna heater’s
connection cable
H07RN-F /
60245 IEC 66
mm2
230V 3~
Fuse
A
Sauna heater’s
connection cable
H07RN-F /
60245 IEC 66
mm2
230-240V 1N~/2~
Fuse
A
6,0
8,0
5 x 1,5
5 x 2,5
3 x 10
3 x 16
4 x 2,5
4 x 6
3 x 16
3 x 25
3 x 6
3 x 6
35
35
Table 2 Connection cable and fuses
3.5.Electric heating toggle
The electric heating toggle applies to homes with an electric heating system.
Sauna heater has a connection (marked 55) for controlling the electric heating toggle. Connector 55 and the heating elements
are simultaneously live (230V).
Installation and User Manual Helo Ring 8

3.6.Locating the connecting box for the connection cable in the sauna room
200 mm
60 mm 60 mm
500 mm
3.
2.
500 mm
1
3.
2.
Image 2 Location for the connection box
60 mm = Specified minimum safety clearance
1. Recommended location for the connecting box
2. Silumin box recommended in this area.
3. This area should be avoided. Always use a silumin box.
In other areas, use a heat-resisting box (T 125 °C) and heat-resisting cables (T 170 °C). The connection box must be clear of
obstacles. When installing the connection box to zones 2 or 3, refer to the instructions and regulations of the local energy
supplier.
Installation and User Manual Helo Ring 9

3.7.Principle image when Digi II is used as control panel
Image 3 Principle image
Installation and User Manual Helo Ring 10
4
3
2
1
4
3
2
1
A 1 2 3 4 5 B1 2 3 4 5
A 1 2 3 4 5 B1 2 3 4 5
A1 Valk Vit White Weiss
A2 Ruskea Brun Brown Braun
A3 Vihreä Grön Green Grün
A4 Kelt Gul Yellow Gelb
A5 Harm Grå Grey Grau
B1 Rosa Ljusröd Pink Rose
B2 Sin Blå Blue Blau
B3 Pun Röd Red Rot
B4 Musta Svart Black Schwarz
B5 Violetti Violett Violet Violett
OLET 19
1 Blue
2 White
3 Red
4 Yellow
1 Blue
2 White
3 Red
4 Yellow
Limiter
Connector strip
HeaterHeaterHeater Sensor
Sensor cable
Heater Control panel
Sensor
OLET 19
Sensor
OLET 19
Sensor
OLET 19
Sauna
heater
Silicone 4 x 0,25
Control panel
1601 - 12
LiYY 10 x 0,25
230 - 240V 1N~/ 2~
Input 230V 3~
400 - 415V 3N~

3.8.Wiring diagram
kW
6,0
8,0
230 V
SEPC 202 SEPC 203
2000W 2670W
1,2,3
1A 1A
N
L
L L L
1 2 3
A 1 2 3 4 5 B 1 2 3 4 5 1 2 3 4
J10 J11 J12
Light Fan
Control
U V W
2
3
1
1 2 3 4
341 2
1.
5.
4.
N N N 55
3.
2.
1 2 3 4 5 6
6.
*)*)
*)
*)
123 6
45
230 V 3~
L1 L2 L3
N
123 6
45
230V - 240V 1N~ / 2~
N L2
123 6
45
400V - 415V 3N~
L1 L2 L3
K1
K2
T1 AH
F1
1,2,3
Teho, Effekt
Power, Leistung
Puissance, Vermogen
Potencia
Lämpövastukset, Värmeelement, Éléments chauffants
Heating elements, Heizeelement, Verwarmingselementen
Resistencias
1. Syöttö / Nätet / Stromnetz / Power input. / Puissance absorbée / Vermogensingang / Entrada de
alimentación
2. Saunavalo / Bastu belysning / Saunabeleuchtung / Sauna light / Éclairage du sauna /
Saunaverlichting / Luz de sauna
3. Tuuletin / Fläkt / Ventilator / Fan / Ventilation / Ventilator / Ventilación
4. Sähkölämmityksen vuorottelu / Alternering med elvärme / Signal kontakt / Signal contact / Contact
du signal / Signaalcontact / Contacto señal
5. Ohjauskeskus / Styrpanel / Steuergerät / Control panel. / Panneau de commande / Bedieningspaneel
Panel de control
6. Tuntoelin / Sensor / Fühler / Sensor / Capteur / Sensor
Katso ohjauskeskuksen käyttöohje
Se styrpanelens bruksanvisning
Sehe die Bedienungsanleitung des
Steuergerätes
See the control panel manual
Voir le manuel du panneau de commande
Zie handleiding bedieningspaneel
Consulte el manual del panel de control
*)
1
Sin.
Blå
Blau
Blue
Bleu
Blauw
Azul
2
Val.
Vit
WeiB
White
Blanc
Wit
Blanco
3
Pun.
Röd
Rot
Red
Rouge
Rood
Rojo
4
Kelt.
Gul
Gelb
Yellow
Jaune
Geel
Amarillo
max. 100W
354 SKLT 5 B
Image 4 Wiring diagram for the sauna heater
Installation and User Manual Helo Ring 11

4. Helo Ring spare part list
5. ROHS
Part Part number Part name Helo Ring 600 Helo Ring 900
1 5916229 Circuit board OLEA 57 1 1
2 6214032 Sensor OLET 19 1 1
3 7812550 Mains connector NLWD 1-1 1 1
4 5716203 Relay Finder 2 2
5 6119649 Rocker switch 1 1
6 7306611 Rubber cover for rocker switch 1 1
7 7801711 Fuse F1 T1 AH 1 1
8 4316221 Heating element SEPC 202 2000W / 230V 3 -
8 5207518 Heating element SEPC 203 2670W / 230V - 3
9 6216410 Circuit board OLEA 83 (Heater with Midi control panel) 1 1
Installation and User Manual Helo Ring 12
Ympäristön suo jeluun liittyvi ä ohjeit a
Tämän tuotteen käyttöiän päätyttyä sitä ei
saa hävittää normaalin talousjätteen
mukana, vaan se on toimitettava
sähkö- ja elektroniikkalaitteiden kierrätykseen
tarkoitettu un keräy spisteeseen.
Symboli tuotteessa,
käyttöohjeessa tai
pakkauksessa tarkoittaa sitä.
Valmistusaineet ovat kierrätettävissä merkintänsä
mukaan. Käytettyjen laitteiden
uudelleenkäytöllä, materiaalien hydöyntämisellä
tai muulla uudelleenkäytöllä teet arvokkaan teon
ympäri stöm me h yväk si.
Tuote palautetaan ilman kiuaskiviä ja verhouskiviä
kierrätyskeskukseen.
Tietoa kierrätyspaikoista saat
kuntasi palvelupisteestä.
A
n
v
isningar för miljöskydd
D
en na pr oduk t får i nte kastas m e
d
v
anliga hushållssopor när den
i
nte längre används. Istället ska den
l
evereras till en återvinningsplats
f
ör elektriska och elektroniska apparater.
S
ymb ol en på pr oduk te n,
h
andboken eller
f
örpackningen refererar till detta.
D
e olika materialen kan återvinnas enlig
t
m
ärknin gen på dem. Geno m att återanvända,
n
yttja materialen eller på annat sätt återanvända
u
tsliten utrustning, bidrar du till att skydda vår
m
iljö.
P
rodukten returneras till återvinningscentralen
u
tan bastusten och eventuell täljstensmantel.
V
änligen kontakta de kommunala myndigheterna
f
ör att ta reda på var du hittar närmaste
å
tervinningsplats.
Instructions for environmental protection
This product must not be disposed with
normal household waste at the end of
its life cycle. Instead, it should be
delivered to a collecting place for the recycling
of electrical and electronic devices.
The symbol on the product, the
instruction manual or the
package refers to this.
The materials can be recycled according to the
markings on them. By reusing, utilising the
materials or by otherwise reusing
old eq uipment, you make an im portant
contributio n for th e protectio n of our environment.
Please note that the product is returned to the
recycling centre without any sauna rocks and
soapstone cover.
Please contact the municipal administration
with enquiries concerning the recycling place.
H
inweise zum Umweltschutz
D
ieses Produkt darf am Ende seiner Lebens-
D
au er ni ch t üb er de n n or m al en Ha u sh alts a bf all
E
ntsorgt werden, sondern muss an einem
S
ammelpunkt für das Recycling von elektrischen
u
nd el ektr onischen Ger ät en abgeg eben werden.
D
as Symbol auf dem produk t, d er
G
eb rau chsan lei tung od er d er
V
erpack ung weis t darauf hin.
D
ie Werkstoffe sind gemäß ihrer Kennzeichnung
w
iederverwertbar, Mit der Wiederverwendung,
d
er stofflichen Verwertung oder anderen Formen
d
er Verwertung von Altgeräten leisten Sie einen
w
ichtigen Beitrag zum Schutze unserer Umwelt.
D
ieses Produkt soll ohne Steine und
S
peckstein
m
antel an dem Sammelpunkt für
R
ecycling zurückgebracht werden.
B
itte erfragen Sie bei der Gemeindeverwaltung
d
ie zuständige Entsorgungsstelle.
