Haws 1431 Guide

03/17 Model 1431 Page 1 of 6
No. 2076851(16)
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
Model 1431
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS
warrants that this specific product is guaranteed against defective material
or poor workmanship for a period of one year from date of shipment. HAWS
liability under this warranty shall be discharged by furnishing without charge F.O.B.
HAWS Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
clai
m is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential
damages claimed to arise under the contract of sale. The drinking fountain
manufactured by HAWS is warranted to function if installation and maintenance
instructions provided are adhered to. The units also must be used for the purpose
for which they were intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/17 Model 1431 Page 2 of 6
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12"
adjustable wrench, 10" pipe wrench, 5/64” hex key wrench, 9/16”, 1/2”, 7/16” socket
wrench or open end wrench.
LOCATION OF UNIT: The Model 1431 Drinking Fountain is a wheelchair accessible
drinking water facility. The height dimensions shown, meet current ADA requirements.
When installing this unit, local, state or federal codes should be adhered to. If height
other than shown is required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“ IPS with 30-90 psi (2-6
ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet filter
is recommended.
PLUMBING CONNECTIONS: Inlet is 3/8” O.D. tubing fitting. Waste trap outlet is 1-
1/2” IPS.
MAINTENANCE: Periodically clean the strainer. Refer to 5874 Series Valve Manual
for more information.
INSTALLATION PROCEDURE
GENERAL NOTES:
1. For all plastic push-in type fitting connections, only connect NSF-61 copper or
plastic tubing. Stainless steel or glass tubing is not recommended. The
following assembly instructions must be followed to ensure a watertight
connection:
a. Cut tubing square and clean.
b. Mark from end of tube the length of insertion (See table below).
c. Push tube into the fitting until it bottoms out.
d. To remove, depress collet and pull tubing out.
Tube Sizes
O.D.
Tolerance Insertion Depth
1/4”
±.005”
11/16”
3/8”
±.005”
3/4”
1/2”
±.005”
7/8”
Refer to Installation drawing for mounting height. For steps below, refer to exploded
view in Parts Breakdown drawing.
STEP 1:Remove nut and washers from bubbler heads, set aside. Install bubbler head
through receptor. Install respectively, rubber washer, fiber washer, then nut
onto bubbler shank. Securely tighten nut.
STEP 2:Remove push button assembly from 5874 Series valves with spanner wrench
provided. Be sure to also remove (chrome plated) ring nut and (chrome-
plated) washer from valves. At this point, carefully follow installation
instructions shown on 5874 Series Valve/Push Button Operation and
Maintenance Manual under heading: “INSTALLATION INSTRUCTIONS
FOR 5874PB”

03/17 Model 1431 Page 3 of 6
INSTALLATION PROCEDURE
STEP 3: Make tubing connections from bubbler to the outlet side of control valve.
(Refer to Installation drawing.) Follow instructions for tubing preparation and
insertion depths from Step 3.
STEP 4: Place strainer into receptor, using putty, secure in place using a fiber washer
and lock nut.
STEP 5: Mount fountain with appropriate hardware as shown on Installation Drawing.
STEP 6: Flush supply line to clear debris. Connect to a 1/2” NPT supply line and
tighten.
STEP 7: Make certain that fountain is level and well secured to wall. Connect waste
trap to a 1-1/2” waste pipe (to be supplied by customer).
STEP 8:Completely open the screwdriver stop (not supplied) and check for leaks.
STEP 9: Adjust valves for desired flow height. See 5874 Series Valve Manual
(supplied).
STEP 10: Attach bottom plate to fountain using #10-24 hardware provided.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1. Insufficient bubbler flow. 1a. Check that inlet screwdriver stop valve is
in wide-open position.
b. Verify minimum 30 PSI flowing supply
pressure.
c. Clean strainer. See 5874 Series Valve
Manual.
d. Adjust valve to increase flow. Use front
adjust screw or see 5874 Series Valve
Manual.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

2-3/4 x 2 x 1/16 FIBRE WASHER
1-1/2 PLAIN LOCK NUT
1-1/2 TRAP
PBA7 PUSH BUTTON
2X 1 1/4 X 1/2 X 1/8
RUBBER WASHER
2X 1 1/4 X 1 1/16 X 1/8
FIBRE WASHER
2X 3/8 HEX LOCK NUT
5703M BUBBLER
ASSEMBLY, 2 PLACES
6454 STRAINER ASSEMBLY
4X 10-24 SCREW
(NUTS & WASHERS INCLUDED)
5874PB VALVE,
2 PLACES
1-1/2 SLIP JOINT NUT
AND POLY WASHER
1.73 X 1 5/16 X 1/8 WASHER
1-1/2 SLIP JOINT NUT
TAILPIECE
1-1/2
PARTS BREAKDOWN
1
2
P/N 0005987000
WAVE WASHER
WASHER 1-3/4 X 1-1/4 X .05
POLISHED CHROME PLATED
3
2 PLACES
CLEAR POLY TUBING
(ASSEMBLED TO
BUBBLER HEAD)
A
4X 1 1/4 X 3/4 X 1/16 RECT WASHER
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
A. DAY
05/07/01
16
0002076851
1431
.
1:6
11
FV 07/06/17
.
VWC
4 OF 6
PARTS BREAKDOWN
5188
2017
JP
4X 5/16-18 HEX NUT
4X ANCHOR
(PART OF 10-24 HARDWARE)
LOCK NUT 1 REQ'D, 2 PLACES
2X 1 3/4 X 1 5/16 X 3/32
FIBRE WASHER
2X 1 13/16 X 1.73 X .12
NEOPRENE WASHER
1 REFER TO 5874 SERIES/VRK5874 OPERATION AND MAINTENANCE MANUAL
FOR INSTALLATION INSTRUCTIONS.
3 APPLY ONE DOT OF LOCTITE 222MS THREADLOCKER ON FEMALE THREADS
OF PUSH BUTTON. SEE 5874 SERIES OPERATION AND MAINTENANCE MANUAL
FOR PROPER APPLICATION PROCEDURE.
4. FOR TUBING ROUTING AND LENGTHS SEE SHEET 2
OF INSTALLATION DRAWING.
DETAIL OF 5703M
VIEW A
DRIVER,
NOZZLE
.25 HEX
PN 0002082253
(0PTIONAL)
FOR REMOVAL
OF NOZZLE
WITH TUBE
2 5874PB INCLUDES VRK5874 CARTRIDGE ASSEMBLY (NOT SHOWN) AND
PBA7 PUSHBUTTON.
NOTES:
2

FLOOR LINE
1-1/2" IPS
WALL FACE
TRAP (SUPPLIED)
(BY OTHERS)
457mm
18"
1-1/2" IPS WASTE
SUPPLY STOP AND
(BY OTHERS)
(BY OTHERS)
1/2" IPS SUPPLY
3/8" O.D. TUBING
40 3/16"
1021mm 381mm
15"
*25 7/8"
*30"
657mm
762mm
838mm
*33"
686mm
*27"
6"
3 3/4" 152mm 152mm
6"
95mm
2X
4"
6 1/4"
102mm
159mm
1/2-13 STAINLESS STEEL
MOUNTING HARDWARE
(BY OTHERS) 8X
WASTE
SUPPLY
3/4"
19mm
(TO SPOUT OUTLET)
NOTES:
1. HOLD ROUGH-IN DIMENSIONS ±1/4" (6.4mm).
2. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES
SHOULD BE ADHERED TO. FOR INSTALLATION HEIGHTS OTHER THAN
SHOWN, DIMENSIONS MARKED (*) MUST BE ADJUSTED ACCORDINGLY.
3 REFER TO 5874 SERIES OPERATION AND MAINTENANCE MANUAL FOR
PUSH BUTTON AND VALVE INSTALLATION/MAINTENANCE INSTRUCTONS.
(NOTES CONTINUED ON SHEET 2)
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
PM
09/20/00
16
0002076851.D
1431
1:10
12
FV 07/06/17
.
VWC
5 OF 6
INSTALLATION
5188
2017
JP
SEE SHEET 2 OF 2 FOR
TUBING ROUTING DETAIL

WHITE POLYPRO TUBING
13"
TEE FITTING WHITE POLYPRO TUBING
21"
CLEAR POLY TUBING
15" CLEAR POLY TUBING
15"
ELBOW FITTING
ELBOW FITTING
NOTES: (CONTINUED FROM SHEET 1)
4. CONNECT WHITE "POLYPROPYLENE" TUBING ON
PRESSURE SIDE (INLET) OF VALVE.
5. CONNECT CLEAR "POLYETHYLENE" TUBING ON
FREE FLOW SIDE (VALVE TO BUBBLER HEAD)
ONLY.
VALVE OUTLET
VALVE OUTLET
(3-1/2")
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
PM
09/20/00
16
0002076851.D
1431
1:10
22
FV 07/06/17
.
VWC
6 OF 6
INSTALLATION
5188
2017
JP
TUBING DETAIL
