2 700007063 C-Bow schwarz
1 700008016 C-Bow Halteadapter hinten
1 700008017 C-Bow Halteadapter vorne links
1 700008018 C-Bow Halteadapter vorne rechts
2 700007063 C-Bow black
1 700008016 C-Bow Halteadapter rear
1 700008017 C-Bow adapter front left
1 700008018 C-Bow adapter front right
190213/300916/290317/051218/140319
Kombinierbar mit Easy-/Alurack
Carrier can be combined with Easy-/Alurack
Width: 530 mm
Baubreite 530 mm
C-Bow Taschenhalter / Soft bag holder
4 Zylinderschraube mit Innensechskant M8 x 30mm
2 Zylinderschraube mit Innensechskant M6 x 35mm
8 Sechskantschraube M6 x 16mm
8 U-Scheibe Ø6,4
4 U-Scheibe Ø8,4
2 Karosseriescheiben Ø18xØ6,4x1,5mm
2 Aludistanzen Ø15xØ9x13mm
4 allen screw M8 x 30mm
2 allen screw M6 x 35mm
8 hexagon bolt M6 x 16mm
8 washer Ø6,4
4 washer Ø8,4
2 body washer Ø18xØ6,4x1,5mm
2 alu spacer Ø15xØ9x13mm
HONDA CB 500 X
Baujahr 2017-2018 / date of manufacture 2017-2018
Artikel Nr.: / Item-no.:
6309503 00 05 anthrazit/anthracite
HONDA CB 500 X
bis Baujahr 2016 / up to date of manufacture 2016
Artikel Nr.: / Item-no.:
630978 00 05 anthrazit/anthracite
HONDA CB 500 X
ab Baujahr 2019 / from date of manufacture 2019
Artikel Nr.: / Item-no.:
6309514 00 05 anthrazit/anthracite
1
INHALT
CONTENTS
4x
1
Fahrtrichtung
4x
driving direction
C-Bow Taschenhalter / Soft bag holder
HONDA CB 500 X
Baujahr 2017-2018 / date of manufacture 2017-2018
Artikel Nr.: / Item-no.:
6309503 00 05 anthrazit/anthracite
HONDA CB 500 X
bis Baujahr 2016 / up to date of manufacture 2016
Artikel Nr.: / Item-no.:
630978 00 05 anthrazit/anthracite
HONDA CB 500 X
ab Baujahr 2019 / from date of manufacture 2019
Artikel Nr.: / Item-no.:
6309514 00 05 anthrazit/anthracite
2
Befestigung Halteadapter vorne
links und rechts:
Die Adapter werden zwischen Rahmen
und Soziusrastenausleger mit den
Zylinderschrauben M8x30 sowie
U-Scheiben Ø8,4 montiert Die
Originalschrauben entfallen.
Teile noch nicht festziehen.
Fastening of the C-Bow adapters
front left+right:
The front adapter will be fixed between
the footrest bracket and the frame. Use
allen screws M8 x 30 with washers ø8,4.
Original screws are obsolete.
Do not tighten yet.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
Ratsche/Ratchet
Verlängerung/extension
Set
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
8x 8x
Montage der C-Bow links + rechts:
Dazu die Sechskantschrauben M6x16
und die U-Scheiben Ø6,4 verwenden.
Alle Teile korrekt ausrichten und die
Verschraubungen festziehen.
Fastening of the
C-Bow:
with hexagon bolts M6 x 16
and washers ø6,4.
After mounting all parts, the screws
should be tightened to the torque
specified.
Fahrtrichtung
2x
2
2x
2x
3
driving direction
C-Bow Taschenhalter / Soft bag holder
HONDA CB 500 X
Baujahr 2017-2018 / date of manufacture 2017-2018
Artikel Nr.: / Item-no.:
6309503 00 05 anthrazit/anthracite
HONDA CB 500 X
bis Baujahr 2016 / up to date of manufacture 2016
Artikel Nr.: / Item-no.:
630978 00 05 anthrazit/anthracite
HONDA CB 500 X
ab Baujahr 2019 / from date of manufacture 2019
Artikel Nr.: / Item-no.:
6309514 00 05 anthrazit/anthracite
3
Befestigung Halteadapter hinten:
Dieser verläuft quer in Fahrtrichtung
hinter dem Kotflügel.
Die beiden Originalschrauben der
Kunststoffabdeckung demontieren
(entfallen).
Zwischen Adapter und Verkleidung die
Aludistanzen Ø15xØ9x13mm fügen.
Die Verschraubung erfolgt mit den
Zylinderschrauben M6x35 sowie den
U-Scheiben Ø18 x Ø6,4 x1,5mm.
Schrauben noch nicht festziehen.
Fastening of the C-Bow adapters rear:
This is transverse to the direction of travel
behind the fender.
Dismantle original screws of the plastic
cover. Original screws are obsolete.
Sandwich alu spacer Ø15xØ9x13mm
between adapter and fender.
To fix, use allen screws M6x35 with
washers Ø18 x Ø6,4 x 1,5mm.
Do not tighten yet.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
Als weiteres Zubehör lieferbar:/ Also available:
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
C-Bow Taschenhalter / Soft bag holder
HONDA CB 500 X
Baujahr 2017-2018 / date of manufacture 2017-2018
Artikel Nr.: / Item-no.:
6309503 00 05 anthrazit/anthracite
HONDA CB 500 X
bis Baujahr 2016 / up to date of manufacture 2016
Artikel Nr.: / Item-no.:
630978 00 05 anthrazit/anthracite
HONDA CB 500 X
ab Baujahr 2019 / from date of manufacture 2019
Artikel Nr.: / Item-no.:
6309514 00 05 anthrazit/anthracite
4
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Kofferträger Lock it / Side carrier Lock it
Easyrack / Alurack
Motorschutzbügel / Engine guard
Tankschutzbügel / Tank guard
Frontschutzbügel / Front guard
Heckschutzbügel / Rear guard
Hauptständer / Center stand
Seitenständerplatte / Side stand enlargement
