1x 700007945 Kardanschutz
1 Schraubensatz 1x 700007945 Kardan protection
1x Screw Set
1x Senkschraube M6 x 14mm
1x Senkschraube M6 x 30mm
1x Linsenkopfschraube M6 x 10mm
2x Senkscheibe Ø6,4 x 18
1x Aludistanz Ø13 x Ø 7 x 16mm
1 Emblem H&B ø30mm
1x countersunk screw M6 x 14mm
1x countersunk screw M6 x 30mm
1x filister head screw M6 x 10mm
2x countersunk washer Ø6,4 x 18
1x alu spacer Ø13 x Ø 7 x 16mm
1 emblem H&B ø30mm
171212/290417
Kardanschutz / Kardan protection
HONDA Crosstourer
Artikel Nr.: / Item-no.:
420971 - 01 schwarz/black
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
INHALT
CONTENTS
2
Die Kunststoffabdeckung des Kardans demontieren. Dieser entfällt.
Dismantle the original plastic cover of the kardan. Cover is obsolete.
Montage Kardanschutz:
Die vordere Verschraubung erfolgt mit der Senkschraube M6 x 30 mm
und Senkscheibe Ø 6,4. Zwischen Kardan und Kardanschutz
muss die Aludistanz Ø13 x Ø7 x 16 zwischengefügt werden.
Front bolting with countersunk screw M6 x 30 mm and countersunk
washer Ø 6,4. Add alu spacer Ø13 x Ø7 x 16 between kardan
and kardan protection.
In das obere freie Gewinde die Linsenkopfschraube M6 x 10mm einschrauben.
Screw the filister head screw M6 x 10mm into the free thread.
Der Kardanschutz wird hinten am original Halter mit der
Senkschraube M6 x 14mm und Senkscheibe Ø 6,4 an montiert.
Rear bolting with countersunk screw M6 x 14mm
and countersunk washer Ø 6,4 at the original holder. 1x 1x
1x 1x
1x
1x
Kardanschutz / Kardan protection
HONDA Crosstourer
Artikel Nr.: / Item-no.:
420971 - 01 schwarz/black
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
