030716/310916
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Kombinierbar mit C-Bow Taschenhalter
combinable with C-Bow soft bag holder
1
WICHTIG
IMPORTANT
KTM 1290 Super Duke GT
ab Baujahr 2016 / from date of manufacture 2016
Easyrack
Artikel Nr.: / Item-no.:
661754101 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652754101 01 schwarz/black
Größe 30/40
2
INHALT
CONTENTS
Ratsche/Ratchet
Verlängerung
extension
Größe/Size 10 Größe/Size 4/5/6
1x 700009383 Rohradapter rechts - tube adapter right
1 700008650 Easyrack
1 700008647 Abdeckblende links
1 700008648 Abdeckblende rechts
Bei Bestellung eines Aluracks zusätzlich:
Bei Bestellung eines Easyracks zusätzlich:
1 799.901HB Alu-Rack
1 799.902HB TC-Bügel für Alu-Rack
1 799.903HB Abdeckplatte für Rack
1x 700009384 Schraubensatz/Screw kit:
1 700008650 Easyrack
1 700008647 plastic cover left
1 700008648 plastic cover right
When ordering a Alurack:
When ordering a Easyrack:
1 799.901HB alu-rack
1 799.902HB bow for Alu-rack
1 799.903HB plastic cover for rack
4x Inbusschraube M6x20
allen screw M6x20
4x U-Scheibe ø8,4
washer ø8,4
4x U-Scheibe ø6,4
washer ø6,4
2x Aludistanz Ø15xØ9x13mm
aluspacer Ø15xØ9x13mm
4x Viereck-Scheiben 20x20x6,4
special washer 20 x 20 x ø6,4
2x Inbusschraube M8x55
allen screw M8x55
4x Inbusschraube M6x12
allen screw M6x12
2x Inbusschraube M8x16
allen screw M8x16
1x 700009382 Rohradapter links - tube adapter left
2x Senkkopfschraube M6x50
countersunk screw M6x50
4x Selbstsichernde Mutter M6
self lock nut M6
KTM 1290 Super Duke GT
ab Baujahr 2016 / from date of manufacture 2016
Easyrack
Artikel Nr.: / Item-no.:
661754101 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652754101 01 schwarz/black
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
Die Beifahrersitzbank demontieren.
Den Haltebügel demontieren, dieser sowie
die Originalschrauben entfallen.
Die Originaldistanzen der hinteren Schraube
werden wieder verwendet.
Die beiden Originalschrauben hinten unter
dem Heck entfernen, diese entfallen.
Dismantle pillion seat.
Dismantle handle, Handle and original
screws are obsolete. Original spacer from
the rear bolting will be used again.
Dismantle the two original screws under the
rear fairing - screws are obsolete.
Preparing of the Alurack:
Fix the bow to the rack with allen screws M6 x 12.
NOTICE:
The bow is needed in use with a Hepco & Becker topcase only .
Vorbereitung des Aluracks:
Den beiliegenden TC-Bügel mit den Inbusschrauben M6 x 12
hinten unter dem Alu-Rack verschrauben.
HINWEIS:
Der TC-Bügel ist nur bei Anbringung eines Hepco & Becker Topcases
erforderlich.
Nur beim Alurack notwendig !
For Alurack mounting only !
3
VORBEREITUNG
PREPARING
4x
VORBEREITUNG
PREPARING
KTM 1290 Super Duke GT
ab Baujahr 2016 / from date of manufacture 2016
Easyrack
Artikel Nr.: / Item-no.:
661754101 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652754101 01 schwarz/black
Montage der Rohradapter oben rechts/ links:
In den nun freien Gewindebohrungen des
Haltegriffes.
VORNE:
mit den Inbusschrauben M8x16 sowie
U- Scheiben ø8,4.
Montage der Rohradapter rechts/ links:
hinten unten:
Mit den Senkkopfschrauben M6x50 in den
nun freien Gewindebohrungen unter dem
Heck.
Fastening of the tube adapters right/left:
In the now free threads of the handle.
FRONT:
with allen screws M8x16 and washers ø8,4.
REAR:
with allen screws M8x55 and washers ø8,4
and the original spacers. Add alu spacer
ø15xø9x13 between frame and original
spacer.
Fastening of the tube adapters
right/left rear bottom:
In the now free threads under the rear fairing
with countersunk screws M6x50.
HINTEN:
mit den Inbusschrauben M8x55 sowie
U- Scheiben ø8,4 und den Originaldistanzen.
Zwischen Originaldistanz und Rahmen die
Aludistanz ø15xø9x13 fügen.
Fahrtrichtung
driving direction
2x
2
2x
1
4
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2x 4x
2x
KTM 1290 Super Duke GT
ab Baujahr 2016 / from date of manufacture 2016
Easyrack
Artikel Nr.: / Item-no.:
661754101 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652754101 01 schwarz/black
Alurack:
Fastening of the Alurack:
On the tube adapters.
Use allen screws M6 x 20 and special
washer 20 x 20 x ø6,4. Secure with
washers ø6,4 and self-lock nuts M6.
Mount the plastic cover.
5
Montage des Aluracks:
Das Alurack wird mit den
Inbusschrauben M6x20,den Viereck-
Scheiben 20x20x6,4, den U-Scheiben
ø6,4 und den selbstsichernden Muttern
M6 auf den Rohradaptern verschraubt.
Anschließend die Kunststoffabdeckung
des Aluracks montieren.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
4x 4x 4x
4x
KTM 1290 Super Duke GT
ab Baujahr 2016 / from date of manufacture 2016
Easyrack
Artikel Nr.: / Item-no.:
661754101 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652754101 01 schwarz/black
Als weiteres Zubehör lieferbar:/ Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
Easyrack:
Fastening of the Easyrack:
On the tube adapters.
Use allen screws M6 x 20 and special
washer 20 x 20 x ø6,4. Secure with
washers ø6,4 and self-lock nuts M6.
Mount the plastic cover.
6
Montage des Easyracks:
Das Easyrack wird mit den
Inbusschrauben M6x20,den Viereck-
Scheiben 20x20x6,4, den U-Scheiben
ø6,4 und den selbstsichernden Muttern
M6 auf den Rohradaptern verschraubt.
Anschließend die Kunststoff-
abdeckungen montieren.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
4x 4x 4x
4x
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
KTM 1290 Super Duke GT
ab Baujahr 2016 / from date of manufacture 2016
Easyrack
Artikel Nr.: / Item-no.:
661754101 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652754101 01 schwarz/black
6307541 00 01 C-Bow Taschenhalter / C-Bow soft bag holder
6707541 00 01 Sportrack
5067541 00 09 Tankring
