230413/040618
1
Easyrack
Alurack
Bei Bestellung eines Aluracks zusätzlich:
1x 799.901HB Alu-Rack
1x 799.902HB TC-Bügel für Alu-Rack
1x 799.903HB Abdeckplatte für Rack
Bei Bestellung eines Easyracks zusätzlich:
1x 700008650 Easyrack
1x 700008647 Abdeckblende links
1x 700008648 Abdeckblende rechts
When ordering a Alurack:
1x 799.901HB alu-rack
1x 799.902HB bow for Alu-rack
1x 799.903HB plastic cover for rack
When ordering a Easyrack:
1x 700008650 Easyrack
1x 700008647 plastic cover left
1x 700008648 plastic cover right
1 700008029 Adapterlasche links
1 700008030 Adapterlasche rechts
1 700008046 Rohradapter links
1 700008047 Rohradapter rechts
4x Zylinderschraube M6x40
4x Zylinderschraube M6x30
4x Zylinderschraube M6 x12
2x Zylinderschraube M8x20
4x Zylinderschraube M6x20
2x U-Scheiben Ø8,4
4x Viereck-Scheiben 20 x 20 x ø6,4
4x selbstsichernde Muttern M6
12x U-Scheiben Ø6,4
4x Aludistanzen Ø10x Ø7 x 11mm
1 700008029 adapter left
1 700008030 adapter right
1 700008046 tube adapter left
1 700008047 tube adapter right
4x allen screw M6x40
4x allen screw M6x30
4x allen screw M6 x12
2x allen screw M8x20
4x allen screw M6x20
2x washer Ø8,4
4x special washer 20 x 20 x ø6,4
4x self-lock nut M6
12x washer Ø6,4
4x alu spacer Ø10x Ø7 x 11mm
MV AGUSTA Brutale 675/800
Baujahr 2012-2016 / date of manufacture 2012-2016
Easyrack
Artikel Nr.: / Item-no.:
6617522 01 01
Alurack
Artikel Nr.: / Item-no.:
6507522 01 01 schwarz/black
INHALT
CONTENTS
Preparing of the Alurack:
Fix the bow to the rack with allen screws M6 x 12.
NOTICE:
The bow is needed in use with a Hepco & Becker topcase only .
Vorbereitung des Aluracks:
Den beiliegenden TC-Bügel mit den Zylinderschrauben
M6 x 12 hinten unter dem Alurack verschrauben.
HINWEIS:
Der TC-Bügel ist nur bei Anbringung eines Hepco & Becker Topcases
erforderlich.
2
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
VORBEREITUNG
PREPARING
4x
Ratsche/Ratchet
Verlängerung/extension
Set
1
4x 4x
Dismantle seat and the complete blinker holder/fender. It is not
necessary to disconnect the cables. Original screws are obsolete.
Fastening of the adapter holders left+right:
between the frame and the blinker holder/fender with allen screws
M6 x 40mm and washers Ø6,4.
2
MV AGUSTA Brutale 675/800
Baujahr 2012-2016 / date of manufacture 2012-2016
Easyrack
Artikel Nr.: / Item-no.:
6617522 01 01
Alurack
Artikel Nr.: / Item-no.:
6507522 01 01 schwarz/black
Sitzbank abnehmen, kompletten Blinkerhalter lösen und an den
Kabeln hängen lassen. Die Original Schrauben entfallen.
Montage der Adapterlaschen links/ rechts:
Die Adapter werden zwischen Heckteil und Blinkerhalter montiert.
Hierzu die Zylinderschrauben M6x40 sowie U-Scheiben Ø6,4
verwenden.
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
Montage der Rohradapter hinten links und rechts:
An den zuvor montierten Adapterlaschen von unten mit der
Zylinderschrauben M8x20 sowie U-Scheiben Ø8,4.
3
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
4
3
2x 2x
4x 4x 4x
Fastening of the tube adapters to the adapter holder left+right:
with allen screws M8 x 20mm and washers Ø8,4.
Fastening of the tubeadapters front holder left+right:
Dismantle the footrest. Original screws are obsolete.
Mount the C-Bow adapters together with the footrest again
(from behind).Use allen screws M6 x 30mm with washers Ø6,4.
Dandwich alu spacers ø10xø7x11mm-
(if a C-Bow holder is also mounted, spacers are obsolete)
MV AGUSTA Brutale 675/800
Baujahr 2012-2016 / date of manufacture 2012-2016
Easyrack
Artikel Nr.: / Item-no.:
6617522 01 01
Alurack
Artikel Nr.: / Item-no.:
6507522 01 01 schwarz/black
Montage der Rohradapter vorne links/ rechts:
Die Soziusfußrasten demontieren. Die Original Schrauben entfallen.
Die Adapter von hinten zusammen mit den Soziusrasten montieren.
Hierzu die Zylinderschrauben M6x30 sowie U-Scheiben Ø6,4
verwenden.
Zwischen die Verschraubung die Distanzen ø10xø7x11mm fügen.
(Werden zusätzlich C-Bowhalter montiert entfallen die Distanzen.)
Schrauben noch nicht ganz festziehen.
4
Als weiteres Zubehör lieferbar:/ Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Alurack:
Easyrack:
5
Fastening of the Alurack/Easyracks:
On the tube adapters.
Use allen screws M6 x 20 and special washer
20x20xø6,4. Secure with washers ø6,4 and
self-lock nuts M6. Mount the plastic cover.
Montage des Aluracks/Easyracks:
Das Rack wird mit den Zylinderschrauben
M6x20,den Viereck-Scheiben 20x20xø6,4,
den U-Scheiben ø6,4 und den selbst-
sichernden Muttern M6 auf den Rohradaptern
verschraubt. Anschließend die Kunststoff-
abdeckungen montieren.
4x 4x
4x
4x
MV AGUSTA Brutale 675/800
Baujahr 2012-2016 / date of manufacture 2012-2016
Easyrack
Artikel Nr.: / Item-no.:
6617522 01 01
Alurack
Artikel Nr.: / Item-no.:
6507522 01 01 schwarz/black
6307522 00 01 C-Bow Halter / C-Bow holder
