1x Schraubensatz: 1x Screw kit:
1
2 filister head screw M8x60
2 filister head screw M6x80
2 filister head screw M8x25
4 allen screw M6x12
4 allen screw M6x20
4 body washer ø8,4x30x1,2
8 washer ø6,4
4 washer ø8,4
2 spacer Ø13xØ7x14mm
2 spacer Ø18xØ9x14mm
4 special washer 20 x 20 x ø6,4
6 self-lock nut M6
2 tensilock nut M8
2 Linsenkopfschrauben M8x60
2 Linsenkopfschrauben M6x80
2 Linsenkopfschrauben M8x25
4 Zylinderschrauben M6x12
4 Zylinderschrauben M6x20
4 Karosseriescheibe ø8,4x30x1,2
8 U-Scheibe ø6,4
4 U-Scheibe ø8,4
2 Aludistanzen Ø13xØ 7x14 mm
2 Aludistanzen Ø18xØ9x14 mm
4 Viereck-Scheiben 20 x 20 x ø6,4
6 Selbstsichernde Mutter M6
2 Tensilockmutter M8
080410/180416/030220
1 700007280 Adapter links
1 700007281 Adapter rechts
1 700003799 Verstärkungsbügel
1 700007280 Adapter left
1 700007281 Adapter right
1 700003799 bracing bow
Bei Bestellung eines Aluracks zusätzlich:
1x 799.901HB Alu-Rack
1x 799.902HB TC-Bügel für Alu-Rack
1x 799.903HB Abdeckplatte für Rack
Bei Bestellung eines Easyracks zusätzlich:
1x 700008650 Easyrack
1x 700008647 Abdeckblende links
1x 700008648 Abdeckblende rechts
When ordering a Alurack:
1x 799.901HB alu-rack
1x 799.902HB bow for Alu-rack
1x 799.903HB plastic cover for rack
When ordering a Easyrack:
1x 700008650 Easyrack
1x 700008647 plastic cover left
1x 700008648 plastic cover right
SUZUKI GSF 650 Bandit
Baujahr 2007-2008 / date of manufacture 2007-2008
SUZUKI GSX 650 F
Easyrack Alurack
SUZUKI GSF 1250 Bandit
6613513 01 01 schwarz/black 6503513 01 01 schwarz/black
6613512 01 01 schwarz/black 6503512 01 01 schwarz/black
6613517 01 01 schwarz/black 6503517 01 01 schwarz/black
INHALT
CONTENTS
Easyrack - Symbol
Alurack - Symbol
Unbedingt zuerst den Verstärkungsbügel montieren, um den Rahmen zu verstärken !
Folgende Teile demontieren:
Sitzbank
Dismantle first:
Seat bench
Preparing of the Alurack:
Fix the bow to the rack with allen screws M6 x 12.
NOTICE:
The bow is needed in use with a Hepco & Becker topcase only .
Vorbereitung des Aluracks:
Den beiliegenden TC-Bügel mit den Zylinderkopf-
schrauben M6 x 12 hinten unter dem Alurack
verschrauben.
HINWEIS:
Der TC-Bügel ist nur bei Anbringung eines Hepco & Becker
Topcases erforderlich.
2
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
VORBEREITUNG
PREPARING
4x
First mount the bracing bow. It´s essential to enforce the frame !
SUZUKI GSF 650 Bandit
Baujahr 2007-2008 / date of manufacture 2007-2008
SUZUKI GSX 650 F
Easyrack Alurack
SUZUKI GSF 1250 Bandit
6613513 01 01 schwarz/black 6503513 01 01 schwarz/black
6613512 01 01 schwarz/black 6503512 01 01 schwarz/black
6613517 01 01 schwarz/black 6503517 01 01 schwarz/black
Ratsche/Ratchet
Verlängerung/extension
Set
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
3
2x
4x
Montage der Adapter links und rechts:
In die nun freien Bohrungen vorne
die Aludistanzen Ø13xØ7x14mm
hinten die Aludistanzen Ø18xØ9x14
mm einstecken.
Die Befestigung der Halteadapter erfolgt
vorne mit der Linsenkopfschraube M
6x80,und U-Scheibe Ø6,4.
Innen mit einer weiteren U-Scheibe Ø6,4
und selbstsichernden Mutter M6
verschrauben.
Hinten mit der Linsenkopfschraube
M8x60, und U-Scheibe Ø8,4.
2x
2x
2x
2x
2x 4x
2x
2
1
Montage des Verstärkungsbügels:
Er wird auf der Quertraverse des Rahmens,
auf der auch das Sitzbankschloß verschraubt
ist, befestigt. Dazu Linsenkopfschrauben M8
x 25 und U-Scheiben ø8,4 verwenden, unter-
seitig die Karosseriescheibe ø8,4x30x1,2 und
Tensilockmutter M8.
Fastening of the bracing bow:
Fix it on the transverse joint of the frame
with filister head screw M8 x 25 and washer
ø8,4. At the bottom with body washer
ø8,4x30x1,2 and tensilock nut M8.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2x 2x
Fastening of the adapters left and right:
Put spacer Ø13xØ7x14mm in the free
front borings and spacer Ø18xØ9x14
mm in the rear borings.
For fixing, use filister head screw M 6x80
with washers Ø6,4 front inside a
washer ø6,4 with a self-lock nut M6.
Filister head screw M8x60 with washers
Ø8,4 at the rear side
SUZUKI GSF 650 Bandit
Baujahr 2007-2008 / date of manufacture 2007-2008
SUZUKI GSX 650 F
Easyrack Alurack
SUZUKI GSF 1250 Bandit
6613513 01 01 schwarz/black 6503513 01 01 schwarz/black
6613512 01 01 schwarz/black 6503512 01 01 schwarz/black
6613517 01 01 schwarz/black 6503517 01 01 schwarz/black
4
Als weiteres Zubehör lieferbar:/ Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Alurack:
Easyrack:
3
Fastening of the Alurack/Easyracks:
On the rack adapters.
Use allen screws M6 x 20 and special washer
20x20xø6,4. Secure with washers ø6,4 and
self-lock nuts M6. Mount the plastic cover.
Montage des Aluracks/Easyracks:
Das Rack wird mit den Zylinderschrauben
M6x20,den Viereck-Scheiben 20x20xø6,4,
den U-Scheiben ø6,4 und den selbst-
sichernden Muttern M6 an den Gepäck-
brückenhalter verschraubt. Anschließend
die Kunststoffabdeckung montieren.
4x 4x
4x
4x
SUZUKI GSF 650 Bandit
Baujahr 2007-2008 / date of manufacture 2007-2008
SUZUKI GSX 650 F
Easyrack Alurack
SUZUKI GSF 1250 Bandit
6613513 01 01 schwarz/black 6503513 01 01 schwarz/black
6613512 01 01 schwarz/black 6503512 01 01 schwarz/black
6613517 01 01 schwarz/black 6503517 01 01 schwarz/black
Kofferträger schwarz / Side carrier, black
Motorschutzbügel schwarz / Engine guard, black
