Herman Miller Canvas Channel Finished End Installation instructions

Parts Included
Tools Required
IMPORTANT: Save these instructions for layout changes.
HermanMiller
Canvas Channel Finished End
Installation and Disassembly for
Recycling Instructions
How to assemble your Finished End
Finished End
Finished End Top Cap Finished End Hook
Light Seal - Finished End
Safety Glass
Finished End
Step 
1.1 Install tiles on frames.
1.2 Top hook, bottom hook and light seal come assembled to
nished end.
1.3 Attach nished end assembly to frame by aligning hooks to slots
in frame. Align bottom hook rst, then top. Hold light seal against the
hooks so it is sandwiched between the frame and the nished end
hooks.
Top Hook Engagement
Location
1.4 Insert nished end top cap into upper top cap.
Upper Top Cap
Light Seal
aligned at Top
Assembly Instructions1HermanMiller 1BKTM6 rev A

Disassembly for Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling
codes. Use these codes to identify material type for recycling. Non
marked components should be treated as mixed plastic. Ferrous metals
can be identied using a small magnet for recycling. Non-ferrous metals
should be separated and recycled separately.
To disassemble product, reverse the above installation steps.
For more information about our products and services please visit us at
hermanmiller.com or call [phone].
©2017 Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. BKTM  A
1.5 Attach top cap assembly to frame.
Assembly Instructions2HermanMiller 1BKTM6 rev A
