HERO SPLENDOR+ User manual

No : IBED
Thank you for selecting a Hero MotoCorp SPLENDOR+. We wish you many miles of
continued riding pleasure in the years ahead.
We at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with all applicable environment legislation and strengthen the green
supply chain.
This booklet is your guide to the basic operation and maintenance of your new
Hero MotoCorp SPLENDOR+. Please take time to read it carefully. As with any fine
machine, proper care and maintenance are essential for trouble-free operation and optimum
performance.
Authorised Distributor or the authorised dealer(s) of the Distributor ("Dealer") will be glad to
provide further information or assistance and to handle your future service needs.
Let us make this world a safer, healthier and more environment friendly place.
PREFACE

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE
AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR
CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.
Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS
CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY
OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY
PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN
PERMISSION FROM Hero MotoCorp Ltd.
NOTE

Pg. No. Pg. No.
CONTENTS
VEHICLE IDENTIFICATION 1
VEHICLE VIEWS 2
VEHICLE SPECIFICATION 5
ACCESSORIES & MODIFICATIONS 7
ANTI-THEFT TIPS 7
VEHICLE SAFETY 8
ŸImportant safety information 8
ŸProtective apparel 9
SAFE RIDING TIPS 10
TIPS FOR HEALTHY ENVIRONMENT 11
PARTS FUNCTION 12
ŸIgnition switch 12
ŸInstruments & Indicators 13
FEATURES 14
ŸSteering lock 14
HANDLEBAR SWITCHES CONTROL 14
Ÿi3s (Idle stop start system) 15
ŸFuel tank 16
ŸFuel valve 17
PRE-RIDE INSPECTION 19
STARTING THE ENGINE 20
RIDING 21
BRAKING 21
PARKING 22
UTILITY BOX 22
TOOL KIT 22
CLEANING AND WASHING OF VEHICLE 23
MAINTENANCE 23
ŸImportance of maintenance 23
ŸMaintenance safety 24
ŸSafety precaution 24
ŸMaintenance schedule 25
ŸSpark plug inspection 28
ŸEngine oil 28
ŸEngine oil level inspection/Top up process 29
ŸEngine oil replacement/Oil circulation inspection 29
ŸOil filter screen & Centrifugal filter cleaning 30
ŸAir cleaner 31
ŸCarburetor (idle speed adjustment) 33
ŸThrottle controlled ignition system (TCIS) 33
ŸValve clearance adjustment 34
ŸClutch lever free play adjustment 35
ŸThrottle operation & free play adjustment 36
ŸDrive chain slackness adjustment 36
ŸDrive chain slider inspection 39
ŸBrakes 39
ŸSuspension 41
ŸWheel 42
ŸMain/Side stand lubrication 43
ŸTyre 44
ŸNuts, bolts & fastners 46
ŸBattery 46
ŸFuse replacement 49
ŸStop lamp switch 50
ŸHeadlamp focus adjustment 50
ŸCatalytic converter 51
ŸEvaporative emission control 51
POLISHING OF VEHICLE 51
BASIC TROUBLESHOOTING 52
DELIVERY CERTIFICATE
HERO GENUINE PARTS
JOBS APPLICABLE TO PERIODIC SERVICES
SERVICE RECORD SHEET
SERVICE ADVICE SHEET
OWNERSHIP RECORD & DATA

XXXXAGY
ZXYYYYY
VIN and Engine No. may be required:
1. During registration of the vehicle.
2. For dealing with legal & insurance departments.
VIN
Location : Stamped on the right side of the
steering head tube.
Engine No.
Location : Stamped on the lower side of the
left crankcase.
VEHICLE IDENTIFICATION
Engine No.: XXXXAGYZXYYYYY
Model: Splendor+
VIN
009
717
Engine
AF
AF
Kick start/Drum/Cast wheel
Kick start/Drum/Spoke wheel
Variants
XXXXAG Y Z X YYYYY
Engine
Description Year of
Manufacturing Assembly Plant Month of Manufacturing Serial Number
R08 AG
Electric start/Drum/Cast wheel
1
VIN: MBLXXR07XYZXYYYYY
MBL XXR07 Y Z X YYYYY
Manufacturer
code Vehicle
Description Model Year Plant
Code Month of
Manufacturing Production
Serial Number
X
Check
Digit
Electric start/Drum/Cast wheel/i3s AG
R07
MBLXXR07XYZXYYYYY

(1) Turn signal indicator
(2) Horn switch
(3) Turn signal switch
(4) Clutch lever
(5) Headlamp dimmer switch
(6) Speedometer
(7) Odometer
(8) i3s indicator (Optional)
(9) Fuel gauge
(10) High beam indicator
(11) Rear view mirror
(12) i3s switch (Optional)
(13) Front brake lever
(14) Throttle grip
(15) Electric starter switch (Optional)
(16) Neutral indicator
(17) Ignition switch with steering lock
(18) Leg guard
(19) Fuel tank lid
*Accessories and features shown may not be part of standard fitment.
TOP VIEW VEHICLE VIEWS
2
116
10
9
2
11
15
19
3
4
5
678
12
13
14
17
18

(1) Carburetor
(2) Gear shift pedal
(3) Rider foot rest
(4) Main stand
(5) Side stand
(6) Pillion foot rest
(7) Women pillion step
(8) Saree guard
(9) Reflex reflector
(10) Rear turn signal lamp
(11) Tail/Stop lamp
(12) Rear carrier
(13) Left side cover
(14) Fuel valve
(15) Front turn signal lamp
11
13
14
LEFT SIDE VIEW
2456
3
*Accessories and features shown may not be part of standard fitment.
12
8
9
10
15
3
7
VEHICLE VIEWS
1

(1) Pillion foot rest
(2) Kick start pedal
(3) Rider foot rest
(4) Oil level dipstick
(5) Rear brake pedal
(11) Battery compartment(inside)
(12) Seat
(13) Rear suspension
(14) Exhaust muffler
6
7
12 11
8
9
(6) Utility box
(7) Front suspension
(8) Headlamp
(9) Front cowl
(10) Starter motor (Optional)
RIGHT SIDE VIEW
14
13
*Accessories and features shown may not be part of standard fitment.
2345
1
4
10
VEHICLE VIEWS

VEHICLE SPECIFICATION SPECIFICATIONSITEM
Dimensions
Overall length
Overall width
Overall height
Wheelbase
Saddle height
Ground clearance
Engine oil
Fuel tank
Fuel reserve
Front fork oil
Maximum power
Maximum torque
Bore and stroke
Compression ratio
Displacement
Spark plug gap
Valve clearance
Idle speed
Front Suspension
Rear Suspension
Caster angle
2000 mm
720 mm
1040 mm
1230 mm
785 mm
159 mm
0.95 litre at disassembly and 0.75 litre at draining
11.0 litres (Minimum)
1.1litres (Usable reserve)
162-165 ml
6.15 kW (8.36 Ps) @ 8000 rpm
0.82 kgf-m (8.05 N-m) @ 5000 rpm
50.0x49.5 mm
9.9:1
97.2 cc
NGK-CR7HSA, BOSCH-UR4AC,
Federal Mogul-P-RZ9HC
0.6-0.7 mm
0.10 mm
0.10 mm
1400±100 rpm
Telescopic Hydraulic Shock Absorbers
Swingarm with 5 Step Adjustable Hydraulic
Shock Absorbers
26°
Weight
Capacities
Engine
Intake (cold)
Exhaust (cold)
Chassis and suspension
Spark plug
5
Kerb weight 109 kg (Kick Start)
112 kg (Electric Start)

SPECIFICATIONSITEM
Primary reduction
Final reduction
st
Gear ratio, 1
rd
3th
4
Alternator
Starting System
Headlamp (High/Low)
Tail/Stop lamp
Turn signal lamp
Meter Illumination/Fuel indicator lamp
Neutral indicator
Turn signal indicator
Position lamp
Hi Beam indicator
Fuse
3.722 (67/18)
3.143 (44/14)
3.182 (35/11)
1.706 (29/17)
1.238 (26/21)
0.958 (23/24)
115 W
Kick/Electric Start
12V-35/35W Halogen Bulb-**MFR
12V-5/10W MFR**
12V-10Wx4 **MFR
12V-1.7Wx2
12V-1.7W
12V-3Wx2
12V-3.4W
12V-1.7W
7A, 10A (Kick) 10A, 15 A (Electric Start)
Transmission
Tyre size 2.75 x 18-42P/4 PR
2.75 x 18-48P/6 PR
Front
Rear
Electricals
Spoke/Cast Wheel (Optional)
Spoke/Cast Wheel (Optional)
Front Wheel
Rear Wheel
nd
2
Brakes Dia. 130 mm
Dia. 110 mm
Front (Drum type)
Rear (Drum type)
6
Battery Conventional Battery, 12V-2.5 Ah (Kick Start),
*MF Battery,12V-3Ah ETZ 4 (Electric Start)
* MF stands for Maintenance Free
** MFR stands for Multi-Focal Reflector
i3s indicator 12V-1.7W
VEHICLE SPECIFICATION
