HERO SPLENDOR iSMART+ User manual

PREFACE
Thank you for selecting a . We wish you many Hero MotoCorp SPLENDOR iSMART+
miles of continued riding pleasure in the years ahead.
This booklet is your guide to the basic operation and maintenance of your new
. Please take time to read it carefully. As with any Hero MotoCorp SPLENDOR iSMART+
fine machine, proper care and maintenance are essential for trouble-free operation and
optimum performance.
This vehicle is fitted with a lighting feature known as “Automatic Headlamp ON”. The feature
is mandated for all 2 Wheelers by Ministry of Road Transport & Highways (Government of
India) vide notification GSR 188 (E) dated 22nd February 2016. This feature helps in
conspicuity for improving rider safety. The headlamp of this vehicle will always be lit ON when
the engine gets ON.
Let us make this world a safer, healthier and more environment friendly place.
We at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with and all applicable legislation including environment legislation
strengthen the green supply chain.
Your Authorised dealer will be glad to provide further information or Hero MotoCorp
assistance and is equipped to handle your future service needs.
Your vehicle is conforming to latest (Bharat stage- norms) regulation for emission, safety & IV
noise levels. We are also using non asbestos brake shoes/pads and engine gaskets which are
environment friendly in nature.

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE
AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR
CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.
Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS
CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY
OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY
PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN
PERMISSION FROM Hero MotoCorp Ltd.
NOTE
ACCESSORIES SHOWN MAY NOT BE THE PART OF STANDARD FITMENT. IT IS
OUR ENDEAVOUR TO CONSTANTLY IMPROVE OUR PRODUCTS. THIS COULD
LEAD TO CHANGE IN PRODUCT SPECIFICATIONS WITHOUT NOTICE. Hero
MotoCorp Ltd ‘SPLENDOR iSMART+’ COMPLIES WITH THE LATEST EMISSION
NORMS.

Pg. No.Pg. No.
CONTENTS
Pg. No.
VEHICLE SPECIFICATION 5
VEHICLE IDENTIFICATION 1
VEHICLE VIEWS 2
ACCESSORIES & MODIFICATIONS 7
ANTI-THEFT TIPS 7
VEHICLE SAFETY 8
ŸImportant safety information 8
SEAT LOCK/HELMET HANGER 19
HANDLEBAR SWITCHES CONTROL 14
FUEL TANK 18
ŸProtective apparel 9
PRE-RIDE INSPECTION 20
PARTS FUNCTION 12
i3s (IDLE STOP START SYSTEM) 16
STARTING THE ENGINE 21
RIDING 22
CLEANING AND WASHING OF VEHICLE 24
ŸIgnition switch 12
TIPS FOR HEALTHY ENVIRONMENT 11
TOOL KIT/FIRST AID KIT 23
SAFE RIDING TIPS 10
SIDE STAND INDICATOR/SWITCH 17
FEATURES 14
ŸInstruments and Indicators 13
BRAKING 22
PARKING 23
FUEL VALVE 19
MAINTENANCE 24
SAFETY PRECAUTION 25
SUSPENSION 44
SPARK PLUG INSPECTION 29
OIL FILTER SCREEN & CENTRIFUGAL FILTER 31
THROTTLE OPERATION 38
MAINTENANCE SCHEDULE 26
DRIVE CHAIN SLACKNESS 38
FUSE REPLACEMENT 52
AIR CLEANER 32
CARBURETOR 34
ENGINE OIL 29
VALVE CLEARANCE ADJUSTMENT 35
DRIVE CHAIN SLIDER INSPECTION 41
CLUTCH LEVER FREE PLAY 37
BRAKES 41
WHEEL 45
TUBELESS TYRES 47
BATTERY 50
MAIN/SIDE STAND LUBRICATION 46
AIR SUCTION VALVE (ASV) 54
EVAPORATIVE EMISSION CONTROL SYSTEM 55
BASIC TROUBLESHOOTING 56
ROAD SIGNS 58
WARRANTY
HERO GENUINE PARTS
STOP LAMP SWITCH 53
CATALYTIC CONVERTER 54
ZONAL/REGIONAL/AREA OFFICES
HEADLAMP FOCUS ADJUSTMENT 53
POLISHING OF VEHICLE 55

VEHICLE IDENTIFICATION
1
Model: Splendor iSmart+
VINVariants
Electric start/Drum/Cast wheel
Engine No.
Location: Stamped on the lower side of the
left crankcase.
EU
Engine
MBLJAW03#########
JA06EU#
#######
1. During registration of the vehicle.
VIN and Engine No. may be required:
2. For dealing with legal & insurance departments.
VIN: MBLJAW03#########
MBL JAW03 #
Manufacturer
code Vehicle
Description Model Year
#
Check
Digit
Engine No.: JA06EU########
XXXXEU # #
Engine
Description Year of
Manufacturing Assembly Plant
## #####
Plant
Code Month of
Manufacturing Production
Serial Number
# #####
Month of
Manufacturing Serial Number
W03
Vehicle Identification Number (VIN)
Location: Stamped on the right side of the
steering head tube.

2
(12) Side stand indicator
(1) Dimmer switch
(4) Clutch lever
(2) Horn switch
(5) Passing switch
(3) Turn signal switch
(6) Rear view mirror
(8) High beam indicator
(9) Turn signal indicator
(7) i3s indicator
(11) Speedometer
(10) Fuel gauge
(14) Tripmeter
(16) Reset button
(20) Throttle grip
(18) Front brake lever
(19) Neutral indicator
(15) Service reminder indicator
(24) Leg guard
(13) Odometer
(23) Fuel tank cap
(17) i3s switch
(21) Electric starter switch
(22) Ignition switch with steering lock
*Accessories and features shown may not be part of standard fitment.
21
22
23
24
715
14
910
2
6
3
5
TOP VIEW VEHICLE VIEWS
4
17
11
1
81213 16
18
20
19
